Summary of Contents for Avantree WSHT-5049
- Page 1 Avantree® Q5049 User Manual 4 HEADPHONES Bedienungsanleitung 1 TRANSMITTER Mode d’emploi Manuale di Istruzioni WIRELESS AUDIO SYSTEM Manual de Usuario Model No.: WSHT-5049 Please visit www.avantree.com/product-support/q5049 for detailed step-by-step setup guide...
-
Page 2: Box Contents
Box Contents Ⓐ Ⓑ Ⓒ Wireless Transmitter X 1 Power Cable Optical Audio for Transmitter X 1 Cable X 1 Ⓓ Ⓔ Ⓕ AUX 3.5mm Audio Cable AUX 3.5mm Female Wireless Headphones X 4 to RCA Male Adapter X 1 for Transmitter X 1 Ⓖ... -
Page 3: Product Overview
Product Overview Antenna Power Switch Display Screen Volume Level Switch Pair Button OPT / AUX Switch Volume Control Bypass/ Input Speaker From TV OPTICAL OPTICAL DC IN USB Port Bypass Output Transmitter Input... - Page 4 Slide the power switch to ON / OFF Power on / o Press and hold for 3s until “Status” indicator starts Pairing mode ashing WHITE rapidly Toggle the volume switch to change between “default Vol + mode” / “Vol+” (loud mode) / “Vol++” (extra loud Volume mode adjust Default Vol ++...
- Page 5 Power on / o Slide the power switch to ON / OFF PAIR OFF PAIR OFF From Power ON status, slide the power switch to PAIR Pairing mode and hold for 3s until the LED ashes BLUE quickly PAIR OFF Volume up / down Press once...
- Page 6 PAIR OFF 2. Turn on the headphone – Slide the power switch to “ON” 3. Wait for a few seconds until they automatically reconnect. Once connected the headphones LED will show solid BLUE Note: The four headphones and the transmitter of Q5049 are factory pre-paired.
- Page 7 If your TV has Optical Out> 1. Please use the Optical cable Ⓒ to connect the transmitter and TV. Ensure the “OPT” LED on transmitter is lit. If not, please press once. 2. Go to your TV's SOUND settings, make sure that the AUDIO OUTPUT has been set to "External Speaker"...
-
Page 8: Charging Headphones
To “Bypass” the Q5049 If you want to use your sound system for TV watching, you can connect your sound system to the "Bypass / Speaker" port of the Q5049 transmitter. TV/Audio Source Sound System Bypass/ Input Speaker From TV ANTENNA/ CABLE IN RGB IN... - Page 9 Dispose of the packaging and this product in accordance with the latest provisions. Z-PKQG-HT5049-T-V0...
