Chapter 7. Firewalls
CIPE connection requests from the outside can be accepted with the following command (replacing x
with your device number):
iptables -A INPUT -p udp -i cipcbx -j ACCEPT
iptables -A OUTPUT -p udp -o cipcbx -j ACCEPT
Since CIPE uses its own virtual device which transmits datagram (UDP) packets, the rule allows the
interface for incoming connections, instead of source or destination ports (though they can be
cipcb
used in place of device options). For information about using CIPE, refer to Chapter 6 Virtual Private
Networks.
There are other services for which you may need to define rules. Refer to the Red Hat Enterprise
Linux Reference Guide for comprehensive information on IPTables and its various options.
These rules allow access to regular and secure services on the firewall; however, they do not allow
nodes behind the firewall access to these services. To allow LAN access to these services, you can use
NAT with IPTables filtering rules.
7.4.

and NAT Rules

FORWARD

Most organizations are allotted a limited number of publicly routable IP addresses from their ISP. Due
to this limited allowance, administrators must find creative ways to share access to Internet services
without giving scarce IP addresses to every node on the LAN. Using private IP address is the common
way to allow all nodes on a LAN to properly access network services internally and externally. Edge
routers (such as firewalls) can receive incoming transmissions from the Internet and route the packets
to the intended LAN node; at the same time, firewall/gateways can also route outgoing requests from
a LAN node to the remote Internet service. This forwarding of network traffic can become dangerous
at times, especially with the availability of modern cracking tools that can spoof internal IP addresses
and make the remote attacker's machine act as a node on your LAN. To prevent this,
provides routing and forwarding policies that can be implemented to prevent aberrant usage of network
resources.
The policy allows an administrator to control where packets can be routed within a LAN.
FORWARD
For example, to allow forwarding for the entire LAN (assuming the firewall/gateway has an internal
IP address on eth1), the following rules can be set:
iptables -A FORWARD -i eth1 -j ACCEPT
iptables -A FORWARD -o eth1 -j ACCEPT
Note
By default, the IPv4 policy in Red Hat Enterprise Linux kernels disables support for IP forwarding,
which prevents boxes running Red Hat Enterprise Linux from functioning as dedicated edge routers.
To enable IP forwarding, run the following command:
sysctl -w net.ipv4.ip_forward=1
If this command is run via shell prompt, then the setting is not remembered after a reboot. You can
permanently set forwarding by editing the
replacing with
0 1
net.ipv4.ip_forward = 0
Execute the following command to enable the change to the
sysctl -p /etc/sysctl.conf
:
file. Find and edit the following line,
/etc/sysctl.conf
sysctl.conf
iptables
file:
69
