Summary of Contents for KOFIRE UG-05
- Page 1 UG-05 USER MANUAL 深圳市品存数码科技有限公司...
-
Page 2: Pairing Status
LED Indicator Light Description Pairing Status Blue and green LED twinkle alternately Blue LED stays on indefinitely, blue LED Power On flashes slowly when music playing Standby Mode Blue LED stays on indefinitely Low Battery Blue LED flashes 3 times per second Status * Vibration switch is on: white LED stays on indefinitely Vibration Switch... -
Page 3: Volume Adjustment
The headphone will enter pairing mode. Turn on the Wireless in your cell phone and search for "UG-05", click to connect. The blue LED will stay on indefinitely after connected successfully, and the blue LED will flash slowly when music playing. -
Page 4: Boom Microphone
Vibration Function Switch In the power-on status, flip the vibration switch down, the vibration function will be turned on (the white LED stays on indefinitely), and the headphone will vibrate with the bass. The stronger the bass, the stronger the vibration. Flip the vibration switch upward to turn off... - Page 5 Headset And Wireless Transmitter Overview Indicator On/Off Answer/Hang Up Play/Pause Vol +/ Next Track Vol -/ Previous Track Vibration Switch Micro USB Charging port 3.5MM Built-in Audio Port Decoration Microphone LED Light LED Indicator Microphone Multifuction Mute Button Button Long Boom Microphone...
-
Page 6: Charging Mode
Charging Mode When in a low battery, please charge it for around 3 hours with USB charging cable The headphones will be turned off automatically while charging. Red LED stays on indefinitely while in charging, and red LED goes out while fully charged. Power Status When the headphone is connected to the IOS device, the current power status of the headphone will be showed on the upper right corner of the device screen. -
Page 7: Power On/Power Off
① Insert the Wireless transmitter into the USB port of the device, the device will automatically install the driver, the name displayed on the device is: UG-05, and the default is device audio transmission, the transmitter enters the standby state with the red LED lighting on indefinitely. - Page 8 Wireless Disconnection/Clear Connection Short press the Wireless transmitter button, and the red LED will stay on indefinitely./In any state, long press the transmitter button for 8 seconds, the green and red light will stay on indefinitely. Headphone Parameters Information Profiles Supported A2DP/AVRCP/SMP/HFP Receiving distance 8-10M...
-
Page 9: Packing List
Wireless Transmitter Parameters Information Input USB2.0 Signal-to-Noise Ratio >90dB Frequency Range 20HZ---20KHZ Transmission Range Operating Voltage Operating Current 14mA---27mA Packing List 4. Audio Cable 1. Wireless Headphone 2. Boom Microphone 5. User Manual 3. Micro USB charging cable 6. Wireless Transmitter 7. - Page 10 3. When the headphone has not been used for a long time, we suggest you charge every 3 months to provide good protection for the battery. 4. We suggest you fully charge the headphone for the first time use. Attentions 1.
