- Page 1 UNIVERSAL SOUND PROCESSOR PROCESSEUR AUDIO UNIVERSEL DEQ-S1000A Instruction Manual Mode d’emploi 5707000012571V-A...
- Page 2 English Before You Start Thank you for purchasing this PIONEER product To ensure proper use, please read through this guide before using this product. It is especially important that you read and observe WARNINGS and CAUTIONS in this guide. Please keep the guide in a safe and accessible place for future reference.
- Page 3 For countries outside the European Union: If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal. CAUTION • This product is evaluated in moderate and tropical climate condition under the Audio, video and similar electronic apparatus - Safety requirements, IEC 60065.
- Page 4 • Check the connections of the power supply and speakers if this unit fuse blows. Determine and resolve the cause, then replace the fuse with and identical equivalent. • Always install this unit on a flat surface. Do not install this unit on a surface that is not flat or on a surface with a protrusion.
- Page 5 This unit This unit provides a variety of sound effects by intuitive operation using a smartphone. FUSE 10A Power cord input Parking brake cord input Subwoofer output Rear output/Middle range output Front output/High range output RCA input Remote control sensor input USB port Reset button Power indicator...
- Page 6 Preparing the remote control Remove the insulation sheet before use. How to replace the battery Insert the battery with the plus (+) and minus (–) poles orientated properly. WARNING • Do not ingest the battery, Chemical Burn Hazard. (The remote control supplied with) This product contains a coin/button cell battery.
- Page 7 Name of each remote control button VOLUME – VOLUME + MUTE SRC (source) Left Press to select the previous track / song. Right Press to select the next track / song. PLAY/PAUSE Press and hold to change the connection mode (for iPhone® / AOA connection of smartphone (Android)).
- Page 8 Connection of power cord and speaker Cut the attached power cord and then connect it to the vehicle. The wiring harness kit (sold separately) is also available to connect the cord. Refer to: • Connections when using the speaker input wire •...
- Page 9 Black (ground) To vehicle (metal) body Left Right Front speaker (STD) or high range speaker (NW) Rear speaker (STD) or middle range speaker (NW) White White/black Gray Gray/black Green Green/black Violet Violet/black...
- Page 10 For countries outside the European Union: If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal. Connections when using the speaker input CAUTION • This product is evaluated in moderate and tropical climate condition under the wire Audio, video and similar electronic apparatus - Safety requirements, IEC 60065.
- Page 11 Connections when using the RCA input jack Connect the car stereo RCA output jack and the RCA input jack of this unit. Slide the INPUT select switch to the RCA position. To RCA input RCA cable (sold separately) To RCA output Car stereo / navigation system Note •...
- Page 12 Connections when using the amplifier (sold separately) System remote control Connect to Blue/white cable. Power amp (sold separately) Connect with RCA cable (sold separately) To front output (STD) or high range output (NW) Front speaker (STD) / High range speaker (NW) To rear output (STD) or middle range output (NW) Rear speaker (STD) / Middle range speaker (NW) To subwoofer output (STD) or low range output (NW)
- Page 13 Parking brake cable connections Connect to the parking brake switch using the parking brake cord. To parking brake cord input Parking brake cord Used to detect the ON/OFF status of the parking brake. This lead must be connected to the power supply side of the parking brake switch. Power supply side Parking brake switch Ground side...
- Page 14 Installation This unit Important • Check all connections and systems before final installation. • Do not use unauthorized parts as this may cause malfunctions. • Consult your dealer if installation requires drilling of holes or other modifications to the vehicle. •...
- Page 15 Remote control sensor 1. Connect the remote control sensor to the remote control sensor input . Place the light receiving part of the remote control sensor in a place that can receive the remote control signal. Wire the cable so that it does not interfere with driving. Remote control sensor...
- Page 16 To use this unit, download Sound Tune to the iPhone or smartphone (Android). Slide the INPUT select switch to the SP position. Enter the search term "Pioneer Sound Tune" in the search window or search from the following QR code.
- Page 17 How to Use This Unit Depending on the connection method of the iPhone / smartphone (Android), this unit can be used as follows. When using this unit alone (When not connecting an iPhone or smartphone (Android)) The unit outputs the sound source of the car stereo / navigation system. Only the volume adjustment and mute functions can be operated with the supplied remote control.
- Page 18 Mix mode The unit mixes and outputs the sound of the iPhone / smartphone (Android) and the sound of the car stereo / navigation system. Use this mode when you want to use the voice guidance of the car stereo / navigation system while listening to the source of the iPhone / smartphone (Android).
- Page 19 Connecting the Smartphone to This Unit For iPhone users USB port USB cable (for Type-A) Lightning® – USB cable (genuine product or sold separately) iPhone For smartphone (Android) users (AOA connection) USB port USB cable (for Type-A) USB - micro USB cable (sold separately) Smartphone (Android)
- Page 20 For smartphone (Android) users (OTG connection) USB port USB cable (for Type-A) USB A-A cable (sold separately) USB OTG cable (sold separately) Smartphone (Android) Note Smartphone (Android) cannot be charged using the OTG connection.
- Page 21 About USB devices • For details on handling the iPhone / smartphone (Android), please read each manual. • Please understand that we do not assume responsibility for compensation even if data, etc. are lost at the time of use in combination with this unit. •...
- Page 22 Using Sound Tune − Time Alignment When connecting an iPhone or smartphone (Android) to this unit, a message − Network Filter is displayed on the iPhone or smartphone (Android). Sound Tune starts when − Speaker Level startup is allowed. • Fader / Balance •...
- Page 23 About the protection function This product has a protection function. When this product detects something abnormal, the following functions will operate to protect the product and speaker output. • The power indicator will turn Red, blink Red, and then the product will power off in the situations outlined below.
- Page 24 Specifications GENERAL POWER SOURCE 14.4V DC (10.8-15.1V allowable) GROUNDING SYSTEM Negative type MAX. CURRENT CONSUMPTION 9.2A DIMENSIONS 170(W) x 40(H) x 95(D)<mm> FUSE WEIGHT 0.59kg AUDIO MAX POWER 50W x 4 50Wx2ch/4Ω + 70Wx1ch/2Ω (for SUB-WOOFER) CONTINUOUS POWER 22W x 4 (50Hz to 15kHz, 5%THD, 4Ω...
- Page 25 Connecting the Smartphone to This Unit SPEAKER SETTING <STANDARD MODE> FRONT/REAR (HPF) For iPhone users FREQUENCY 50Hz, 63Hz, 80Hz, 100Hz, 125Hz, 160Hz, 200Hz SLOPE 0dB(Pass), -6dB/oct, -12dB/oct, -18dB/oct, -24dB/oct SUB WOOFER (LPF) FREQUENCY 50Hz, 63Hz, 80Hz, 100Hz, 125Hz, 160Hz, 200Hz SLOPE 0dB(Pass), -6dB/oct, -12dB/oct, -18dB/oct, -24dB/oct GAIN...
- Page 26 Trademarks iPhone, and Lightning are trademarks of Apple Inc., registered in the U.S. and other countries. Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge, and has been certified by the developer to meet Apple performance standards.
