Orca Blinky Pro Instruction Manual

B P1001
Instruction Manual
Thank you for choosing ORCA Products. Welcome to the power and convenience
of Brushless RC. By purchasing the BP1001 Competition Brushless Electronic
Pro Blinky Speed Control ("ESC") you have chosen one of the most advanced
speed controls in RC Racing. The BP1001 allows customization for multiple
programmable parameters and the only one ORCA speedo can used the buttonin
esc without program card to programmale the esc. (If using the ESC's Program
Card which can be purchased separately).
Please read this manual thoroughly to familiarize yourself with the installation,
setup and operation. By operating this product, you accept the ORCA Warranty
Specification
*** 32 bit processor
*** Continuous current
System:
Forward/Brake/Reverse:
Dimensions:
Weight:
Voltage Input:
Peak Current:
Continuous current :
Motor Limit:
Motor Type:
B.E.C.:
Multi Protection System:
Install ation & Connectors
Lipo bat tery
Receiver
* Install/Solder the relevant battery connector (Battery Specific) to the battery wires.
Red to +ve and Black to -ve. (
your ESC and void the warranty.
* Connect supplied BEC wire(150mm) to 3pin port match the (- + s) between the
receiver connector and ESC.
* Connect the 3 motor wires to the motor; you can either solder the wires directly to the
motor or use your favorite connectors. Match the label of the ESC Output (A, B, C) to
the Tablabels on the motor when soldering. Avoid soldering each joint for longer than
5 seconds. Prior to operation make sure you have not created a short by either
creating a wire bridge or solder bridge on the solder tabs on the motor. (
Improper wiring may damage the ESC and void the warranty.)
Version 1.4
8.4V
CH4
CH3
CH2
Ch1
Bec cable
(BEC cable)
OFF ON
Power Switch
WARNING! Reversing the battery polarity will destroy
)
*** Low resistance FET
*** Auto Fan control
Brushless
Yes (Factory preset at Forward/Brake)
30.45(L) x30.35(W) x
20.80g
(excluding wires)
6V-11V
380A
100A
Over 10.5Turns
Sensored 540 sized brushless motors
4A_6V
Yes
Capacitor
-Bl ack
+Red
A
+
B
-
C
B P1001
+
SET
+
Red
10.35(H)
mm
+
+Red
-Bl ack
A
B
C
A B C
Sensor cable
WARNING!
