Icon Electronics D3-TTCT1 Operating Instructions And Guarantee

Description:
This device incorporates a digital temperature controller and a 24 hour timer with two "on" times and two "off" times. The two
functions operate independently and control separate relays.
The temperature controller interfaces directly with Type J,K,R,S,N,T & E thermocouples and offers adjustable hysteresis, offset,
maximum and minimum set point limits. The relay may be configured for heating or cooling applications. In case of a power failure
the clock's time is saved to non volatile memory. When the power is re-applied, the clock continues from where it left off. The
menu can be reduced and the parameters locked with an access code to protect programmed values. (see menu configuration).
Operation:
Heating mode:
Temperature must rise to set point value before relay de-energizes, then it must drop by the hysteresis amount before being re-
energized.
Cooling mode:
Temperature must drop to set point value before relay de-energizes, then it must rise by the hysteresis amount before being re-
energized.
The timer relay is energised whenever the clock's time falls between "ON 1" time and "OFF 1" time, or "ON 2" time and "OFF 2"
time.
Adjustable parameters:
· Pre-set temperature "°C" (default value: 25.0)
When the probe temperature reaches this value, the relay is de-energised.
· Time Adjustment "CLOCK" (default value: 00:00)
Use this setting to adjust the time of day. (24hr format)
· First ON time "On 1" (default value: 00:00)
Adjust when the timer relay must energise. The relay will remain energised until the clock's time has reached the value
programmed into the "OF 1" setting.
· First OFF time "OF 1" (default value: 00:00)
Adjust when the timer relay must de-energise.
D3
53mm
DIN rail mount
TEMPERATURE CONTROLLER
Type J,K,R,S,N,T & E THERMOCOUPLES
Operating instructions and Guarantee Certificate
www.iconelectronics.co.za
P44
48mmx48mm
panel mount
with 24h TIMER
D3-TTCT1
P44-TTCT1
P49-TTCT1
P49
48mmx96mm
panel mount
