PCB Piezotronics IMI SENSORS UHT-12 YEX600B14 Installation And Operating Manual

High temperature, charge mode accelerometer kit containing a side exit accelerometer with shear sensing crystal, 10 ft integral hard-line cable, and integral charge amplifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model YEX600B14
UHT-12™, high temperature, charge mode accelerometer kit containing a side exit
accelerometer with shear sensing crystal, 10 ft integral hard-line cable, and integral charge
amplifier
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 800-959-4464
24-hour SensorLine: 716-684-0001
Fax: 716-684-3823
E-mail: imi@pcb.com
Web: www.imi-sensors.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMI SENSORS UHT-12 YEX600B14 and is the answer not in the manual?

Questions and answers

Related Manuals for PCB Piezotronics IMI SENSORS UHT-12 YEX600B14

Summary of Contents for PCB Piezotronics IMI SENSORS UHT-12 YEX600B14

  • Page 1 10 ft integral hard-line cable, and integral charge amplifier Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 800-959-4464 24-hour SensorLine: 716-684-0001 Fax: 716-684-3823 E-mail: imi@pcb.com...
  • Page 2  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 6 Piezoelectric ICP® Accelerometers Operating Guide Operating Guide with Enclosed Warranty Information 3424 Walden Avenue, Depew, New York 14043-2495 Phone (716) 684-0003 Fax (716) 684-3823 Toll Free Line 1-800-959-4IMI MANUAL NUMBER: 18405 MANUAL REVISION: A ECN NUMBER: 49766...
  • Page 7 General OPERATING GUIDE for use with PIEZOELECTRIC ICP® ACCELEROMETERS SPECIFICATION SHEET, INSTALLATION DRAWING AND CALIBRATION INFORMATION ENCLOSED IMI ASSUMES NO RESPONSIBILITY FOR DAMAGE CAUSED TO THIS PRODUCT AS A RESULT OF PROCEDURES THAT ARE INCONSISTENT WITH THIS OPERATING GUIDE 1.0 INTRODUCTION Congratulations on the purchase of a quality ICP®...

  • Page 8: Optional Features

    The environment of the application is a critical input voltage. Also, the diode can be changed to supply consideration during program implementation. The higher currents for driving long cable lengths. Constant sensor chosen must be capable of surviving the wide current diodes, as shown in Figure 3, should be used in range of conditions to which it is subjected;...

  • Page 9: Standard Stud Mount

    MS – Mine Safety Approved Sensors 4.1 STANDARD STUD MOUNT TO – Temperature Output Sensor This mounting technique requires smooth, flat contact surfaces for proper operation and is Note: Not all sensors are available with the optional recommended permanent and/or secure prefixes.

  • Page 10: Adhesive Mount

    semi-permanent mounting, substitute epoxy or another METHOD 2 – Direct Adhesive Mount type of adhesive. For restrictions of space or for convenience, most sensors STEP 3: Hand-tighten the sensor/mounting stud to the (with the exception of integral stud models) can be machine, then secure the sensor with a torque wrench to adhesive-mounted directly to the machine surface.
  • Page 11 ICP® accelerometers are internally amplified, two-wire accelerometers. Connections to the sensor require two leads: one for the power and signal, and the other for the common and signal return. Often, coaxial cables are used since only two conductors are needed. Coaxial cables are less expensive.
  • Page 12 �� (Equation 1) exceed its maximum temperature specification. For this 10 9 max= 2������ reason, do not supply excessive current over short cable runs [ �� �� −1 ] or when testing at elevated temperatures. Where, f = maximum frequency (hertz) 5.1 CABLE CONNECTOR PROCEDURE C = cable capacitance (picofarads) Care and attention to installation is essential, as the...

  • Page 13: Accelerometer Calibration

    6.0 POWERING the system still does not operate properly, consult All ICP® sensors require constant current excitation an IMI Application Engineer. for proper operation. For this reason only use approved constant-current sources. A typical system Note: Always operate the accelerometer within the schematic is shown in Figure 11.

  • Page 14: Sensor Calibration

    Periodic recalibration may be required by plants with piezoelectric accelerometers. This method relies on strict certification and traceability requirements. It is a simple comparison to a previously calibrated always recommended that the user has the sensor accelerometer, typically referred to as a reference recalibrated periodically, particularly if the sensor standard, as shown in Figure 12.

  • Page 15: Troubleshooting

    ICP® sensors are two-wire sensors. They are powered with a constant current DC source. The power supply is typically 18 to 30 volts DC current limited via a constant current between 2 and 20 mA. Typical battery operated supplies offer 2mA of constant current to extend battery life while Figure 14.

  • Page 16: Customer Service/Warranty

    11.0 CUSTOMER SERVICE/WARRANTY IMI, a division of PCB Piezotronics, guarantees Total Customer Satisfaction. If, at any time, for any Figure 18. DC Bias Voltage Measurement reason, you are not completely satisfied with any IMI product, IMI will repair, replace or exchange it at no charge.
  • Page 18 Model Number Revision: B VERY HIGH TEMPERATURE INDUSTRIAL ICP® ACCELEROMETER ECN #: 46623 EX600B14 Performance ENGLISH OPTIONAL VERSIONS Sensitivity(± 5 %) 10 mV/g 1.02 mV/(m/s²) Optional versions have identical specifications and accessories as listed for the standard model except where noted below. More than one option may be used. Measurement Range(Peak) ±...
  • Page 19 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. ADDED CABLE LENGTH & TOLERANCE TABLE 49810 RELATED DRAWING NO MODIFICATIONS PERMITTED WITHOUT THE APPROVAL OF ...
  • Page 25 6< 1/66 Project: Date Issued: Issued to: Industrial Monitoring Instr. (IMI) A Div. of PCB Piezotronics, Inc. 3425 Walden Ave Depew, NY 14043 Attention: Nick Fulciniti The products listed below are eligible to bear the CSA Mark shown with adjacent indicators 'C' and 'US' for Canada and US or with adjacent indicator 'US' for US only or without either indicator for Canada only.

  • Page 26: Applicable Requirements

    1?<;>1/ B 6/?6.:C 62:<26 Certificate: Master Contract: 1?<;>1/ 6< 1/66 Project: Date Issued: CLASS 11>2 2?          !"    " @"  ") # $ %       9   4949 Ex nA IIC / AEx nA IIC: Class I, Zone 2: Class I, Div.
  • Page 27 1?<;>1/ B 6/?6.:C 62:<26 Certificate: Master Contract: 1?<;>1/ 6< 1/66 Project: Date Issued: 4A .//;< 66F >(  1//< 3* @" 4) *(" "   66F E%*)"  "  ,    !" GH 4A .//;< 6>F ?  1//< "   4** % ! 3* @"...
  • Page 28 Supplement to Certificate of Compliance 78 7 Certificate: Master Contract: The products listed, including the latest revision described below, are eligible to be marked in accordance with the referenced Certificate. Product Certification History Project Date Description         !"#  $%   &' ()* )++   '  , -.  &...
  • Page 29 EU Declaration of Conformity PS116 In Accordance with ISO/IEC 17050 Manufacturer: PCB Piezotronics, Inc. Authorized PCB Piezotronics Europe GmbH European Porschestrasse 20-30 3425 Walden Avenue Representative: 41836 Hückelhoven,Germany Depew, New York 14043 USA Certifies that type of equipment: ICP® Vibration Sensor(s)
  • Page 30 Notified Body Name Laboratoire Central des Industries Electriques (0081) Notified Body’s FONTENAY-AUX-ROSES (Head Office Address 33, avenue du Général Leclerc FR- 92260 Fontenay-aux-Roses Tel. : + 33 1 40 95 60 60 Fax : + 33 1 40 95 86 56 I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) Standard(s) Place: Depew, NY Date: 04/04/2022 Signature:...
