CARVIN TRX210N Datasheet

Features
♦ Powerful and Compact Trapezoid design
♦ Use Vertical or Horizontal flying
♦ Passive full range or Bi-amp crossover
♦ Heavy-Duty Neodymium 10-inch Woofer 2.5-inch VC
♦ Titanium 1-inch exit, 1.75-inch VC, HF driver
♦ Black DuraTex™ weather resistant finish
Application
The TRx210N is a Mid/High range sound reinforcement top
cabinet. The 10-inch woofers provide plenty of Mid low-end to
handle all frequencies down to the subs. Couple the TRx210N
with a TRx118N, for an extended low-end front of house system.
Effective for both permanent and portable applications, it comes
with handles, rubber footpads, and a 1-3/8-inch pole mount cup.
Applications include:
♦ Club system
♦ House of Worship
♦ Band PA
Description
The TRx210N is a trapezoidal, 2-way multi
purpose Main enclosure. The trapezoidal de-
sign and 60x40 HF horn allows multiple cabi-
nets to work together. The high power, light-
weight Neodymium dual 10-inch woofers fea-
tures a 2.5-inch voice coils with a low heat
high peak power capacity design that provides
all the punch and definition necessary. The
slim vertical design makes the TRx210N an
ideal horizonally mounted main for low ceiling
installs. The system provides 12 fly points for
overhead suspension. The enclosure is con-
structed of CNC machined 13-Ply Premium
Russian Baltic Birch with heavy gauge steel
powder coated front grills. The crossover in-
cludes 4 pin NL4 Speakon connectors
mounted on FR4 double sided circuit boards
for solid construction and durability. Carvin's
exclusive Speaker Guard™ HF Driver protec-
tion uses a self resetting relay circuit to dim
the HF driver 10 dB protecting the voice coil
from excessive power. The benefits are the
driver is not turned off losing all the high fre-
quencies, the circuit resets as soon as the
high frequency content is back to normal lev-
els.
12340 WORLD TRADE DRIVE SAN DIEGO, CA USA 92128
TRx210N
Recommended Amplifier Power: 800 – 1600w
Nominal Impedance full range:
Dual 10-inch 2-Way Main
Specifications TRx210N
System Type:
Frequency Response:
Coverage Pattern:
Crossover:
Crossover Frequency:
Power:
Full Range
Sensitivity (1w @ 1m):
Maximum SPL:
LF Driver:
HF Driver:
Bi-amp LF:
Bi-amp HF:
Enclosure:
Suspension/Mounting:
Finish:
Transport:
Grill:
Backing
Connectors:
Dimensions (H x W x D):
Net Wt:
Rigging Accessories:
CARVIN.COM (USA)
Dual 10-inch 2-Way, sealed
60 Hz – 20 kHz (-10DB)
90 Hz – 16 kHz (-3 dB)
60H x 40V
2-Way with Speaker Guard™ HF
protection
2.5 k Hz
Continuous / Program / Peak
600w /1200w /2400w
97dB
124dB Cont/ 130dB Peak
2x 10-inch Neodymium 2.6-inch VC
1-inch exit Neodymium 1.75-inch VC
4 ohms
4 ohms 600w /1200w /2400w
8 ohms 60w /120w /240w
13-Ply Premium Russian Baltic Birch
1-3/8-inch pole mount cup
12 captive 3/8in –16 nut fly points
Black DuraTex™
2 Recessed Handles
Black powder coated steel
Acoustically Transparent Foam
Two NL-4 Neutrik Speakon's
31-3/8 in x 13 in x 13-3/4 in
797 mm x 330 mm x 350 mm
43 lb (20 kg)
TCSHK10 3/8-16 Eyebolt
TCSHK15 3/8-16 Quicklink™
