CARVIN SX50 Operating Manual

CARVIN ENGINEERING DATA
SX200
SX100
SX SERIES Classic Tube Emulation, awesome digital effects, famous X4 knobs,
rich black vinyl covering and the real brass red jewel light continue to make the
AMERICAN MADE SX Series one of the hottest amps on the market today!
EMULATION OR MODELING? Unlike other "modeling" amps, the SX
doesn't just copy the sounds of other amplifiers – it actually emulates 12AX7 tube
circuitry. The SX waveforms successfully "model" real tube waveforms that
breathe and express warmth from mild soft-clip to a full power soaked sustain.
Pro players and industry gurus have stated that the SX Tube Emulator actually
sounds better than many tube amps!
TWO CHANNELS – Clean and Distortion. Each channel has its own inde-
pendent volume control for setting up matching levels quick and easy. The SX200
adds true "DUAL CHANNEL A & B" capabilities allowing both channels to be played
at the same time with different instruments.

ACTIVE TONE CONTROLS

controls on both channels. The SX200 goes even further by adding a PRESENCE
control to each channel for more high-end.
24-BIT EFFECTS Once you have that perfect tone, you can add in just the
right amount of lush REVERBS, rich CHORUSES, thick textured FLANGING and
pristine ECHOES with fully adjustable parameters for damping, decay, depth,
speed, time and regeneration–up to 256 24-Bit DSP EFFECTS. The SX200 adds a
second digital processor dedicated to creating a lush, concert-hall reverb at the
push of a button.
SX MODELS The 50 watt SX50 with one heavy-duty 12" GT12 speaker is per-
fect for practice, small gigs or even large venues if you mic it. The SX100 and
SX200 feature a full 100 watts RMS – plenty for any situation. All models feature
the heavy-duty 100w GT12 speaker that provides awesome guitar reproduction –
from clean to blues to scream'n metal. The SX200 features two 12" speakers for
a bigger sound.
For your records, you may wish to record the following information.
Serial No._____________________ Invoice Date_______________
76-10205 11/01
SX50
All models feature BASS, MID and TREBLE
SX50, SX100 & SX200 GUITAR AMPS
WITH CLASSIC TUBE EMULATION & DSP
Rear Panel CONNECTIONS All back panels feature a LINE OUT
for recording or running a slave amp, HEADPHONE jack, EXTENSION
SPEAKER jack and a FOOT SWITCH jack for the optional FS22 (for remote-
ly changing channels and turning on/off the effects). The extra dedicated
reverb on the SX200 is controlled by a front panel switch. The SX200 also
adds SEND/RETURN jacks for your own external effects.

RUGGED CONSTRUCTION

ensure consistent, reliable performance and are nearly impervious to
bumps and vibrations. Strong, lightweight plywood cabinet (not particle
board), aluminum chassis, steel grill and corners deliver one of the light-
est, yet most rugged amps available.
RECEIVING INSPECTION—read before getting started
INSPECT YOUR AMP FOR ANY DAMAGE which may have occurred during ship-
ping. If any damage is found, please notify the shipping company and CARVIN
immediately.
SAVE THE CARTON & ALL PACKING MATERIALS. In the event you have to re-ship
your unit, always use the original carton and packing material. This will provide the
best possible protection during shipment. CARVIN and the shipping company are not
liable for any damage caused by improper packing.
SAVE YOUR INVOICE. It will be required for warranty service if needed in the
future.
SHIPMENT SHORTAGE. If you find items missing, they may have been shipped
separately. Please allow several days for the rest of your order to arrive before
inquiring.
RECORD THE SERIAL NUMBER on the enclosed warranty card or below on this
manual for your records. Keep your portion of the card and return the portion
with your name and comments to us.

SX SERIES SPECS:

Speakers:
RMS Power:
Output Impedance: 4-16 ohms
Power Amp:
Input Impedance:
Channels:
Tone Controls:
Drive Channel
Clean Channel
Ch 1 Sensitivity:
Ch 2 Sensitivity:
Line Out:
Power:
Fuse:
Cabinet Size:
Cabinet:
Net Weight:
Warranty:
Options:
c
OPERATING MANUAL
SMT surface mount electronics
SX50, SX100, SX200: GT12 12" 100w 8Ω speaker
SX50: 50 watts @ 8Ω SX100, SX200: 100 watts @ 8Ω
THD: Less than 1%
100k ohms
2—switching
BASS: 100Hz
MID: 700Hz
TREBLE: 8k Hz
PRESENCE: 12k Hz (SX200 only)
BASS: 80Hz
MID: 600Hz
TREBLE: 9k Hz
PRESENCE: 12k Hz (SX200 only)
1mV for clipping
75mV for full output
1.5 VAC @ full power
90-250VAC, 50-60Hz, 125VA
5A 250V internal
SX50/SX100: 19.5W x 10.25D x 17.5"H
SX200: 26W x 10.25D x 17.5"H
7-ply poplar wood
SX50/SX100: 30 lbs, SX200: 44 lbs
One Year
FS22 footswitch,
CV211 cover SX100 & SX50
CV3212 cover SX200
VE212 two 12" 200w 4Ω extension cabinet
12340 World Trade Drive, San Diego, CA 92128
(619) 487-1600 (800) 854-2235
www.carvin.com
