RTL8851B User's Manual
RTL8851B
11ax RTL8851BE one antenna Combo module
User's Manual
Preliminary Version
2022/12/20
Realtek Semiconductor Corp.
No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan
Tel.: +886-3-578-0211. Fax: +886-3-577-6047
www.realtek.com
Advertisement
Related Manuals for Realtek RTL8851B
Summary of Contents for Realtek RTL8851B
- Page 1 RTL8851B User’s Manual RTL8851B 11ax RTL8851BE one antenna Combo module User’s Manual Preliminary Version 2022/12/20 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com...
- Page 2 RTL8851B User’s Manual ONTENT TEMPERATURE ..........................3 WARNING ............................3 Federal Communication Commission Interference Statement ...... 3 ......................13 NDUSTRY ANADA TATEMENT NCC 警語 ....................13...
- Page 3 RTL8851B User’s Manual Temperature Warning Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 RTL8851B User’s Manual FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device and its antenna(s) must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures.
- Page 5 RTL8851B User’s Manual application or new certification This module is intended for OEM integrators only. Per FCC KDB 996369 D03 OEM Manual v01 guidance, the following conditions must be strictly followed when using this certified module: KDB 996369 D03 OEM Manual v01 rule sections: 2.2 List of applicable FCC rules...
- Page 6 RTL8851B User’s Manual 2.8 Label and compliance information The final end product must be labeled in a visible area with the following: “Contains FCC ID: TX2-RTL8851B ”. The grantee's FCC ID can be used only when all FCC compliance requirements are met.
- Page 7 RTL8851B User’s Manual Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module.
- Page 8 RTL8851B User’s Manual utilisé à plus de 20 cm entre le radiateur et votre corps. Radiation Exposure Statement: The product comply with the Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual.
-
Page 9: Important Note
RTL8851B User’s Manual autre type d'antenne est utilisé, il est requis pour une réévaluation distincte via une demande de changement permissif de classe II ou une nouvelle certification Opération portée sur le corps Cet appareil a été testé pour des opérations typiques portées sur le corps. Pour se conformer aux exigences d'exposition RF, une distance de séparation minimale de 5... -
Page 10: Note Importante
être installée et utilisée à plus de 20 cm entre l’antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 6317A-RTL8851B ". Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end... - Page 11 RTL8851B User’s Manual Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme indiqué dans ce manuel. Caution : (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;...
- Page 12 Le présent émetteur radio [IC: 6317A-RTL8851B] a été approuvé par Innovation, Sciences et Développement économique Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal.
- Page 13 RTL8851B User’s Manual 本器材限使用下列天線 Installing the Wireless NGFF module Hardware Installing PCIe NGFF2230 module to PCIe NGFF2230 connector and connect two external Wi-Fi antennas on I-PEX connectors.
- Page 14 RTL8851B User’s Manual Un-installing the Wireless NGFF module Hardware Remove 2 external Wi-Fi Antennas from the Wireless PCIe NGFF2230 module board and remove the Wireless PCIe NGFF2230 module board from PCIe NGFF2230 connector port...
- Page 15 RTL8851B User’s Manual Installing the WLAN & Bluetooth USB NGFF module Software Before you proceed with the installation, please notice following descriptions. Note1: The following installation was operated under Windows 7. Note2: If you have installed the WLAN driver & utility before, please uninstall the old version first.
- Page 16 RTL8851B User’s Manual C. Click “Next” button. D. Select “Complete” and click “Next” button.
- Page 17 RTL8851B User’s Manual E. Click “Install” button.
- Page 18 RTL8851B User’s Manual F. Click “Finish” button. G. Please click “下一步”to continue.
- Page 19 RTL8851B User’s Manual H. Please click “下一步”to continue. I. Please click “安装”to start installation.
- Page 20 RTL8851B User’s Manual J. Please click “完成”to finish the installation.
- Page 21 Un-installing the Wireless NGFF module Software A. Uninstall the RTL8852BE WLAN Driver from “Start”→ “Control Panel”→ “Programs” Please select items as below and click “Uninstall” to remove RTL8852BE WLAN, BT driver and MP UI.
