AEG L6FBG48SC User Manual

AEG L6FBG48SC User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
L6FBG48SC
USER
MANUAL
EN
User Manual
Washing Machine

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L6FBG48SC and is the answer not in the manual?

Questions and answers

Related Manuals for AEG L6FBG48SC

Summary of Contents for AEG L6FBG48SC

  • Page 1 L6FBG48SC User Manual Washing Machine USER MANUAL...

  • Page 2: Table Of Contents

    16. ACCESSORIES......................33 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    If a tumble dryer is stacked on the top of the washing • machine, make sure to use the correct stacking kit approved by AEG (see more details in chapter "Accessories - Stacking kit"). 2. SAFETY INSTRUCTIONS 2.1 Installation •...

  • Page 5: Electrical Connection

    ENGLISH 2.2 Electrical connection • This appliance is for household use only. • The appliance must be earthed. • Follow the safety instructions on the • Always use a correctly installed detergent packaging. shockproof socket. • Do not put flammable products or •...
  • Page 6 3.1 Unpacking WARNING! Remove all the packaging and the transit bolts before installing the appliance. WARNING! Use the gloves. 1. Use a cutter to cut through external 5. Carefully put down the appliance film. with the rear side on it.

  • Page 7: Positioning And Levelling

    ENGLISH We recommend that you 9. Remove the power supply cable and keep the packaging and the the drain hose from the hose holders. transit bolts for any movement of the appliance. It is possible to see 3.2 Positioning and levelling water flowing from the drain hose.

  • Page 8: The Inlet Hose

    A correct adjustment of the appliance level prevents the vibration, noise and the movement of the appliance when in operation. CAUTION! Make sure that there are no leaks from the couplings. Do not use an extension hose if the inlet hose is too 3.3 The inlet hose...
  • Page 9 ENGLISH 4. If the end of the drain hose looks like this (see the picture), you can push it directly into the stand pipe. 2. On the edge of a sink - Fasten the guide to the water tap or to the wall. Make sure that the plastic guide cannot move when the appliance drains.

  • Page 10: Product Description

    4. PRODUCT DESCRIPTION 4.1 Appliance overview 11 12 Worktop Drain hose Detergent dispenser Inlet hose connection Control panel Mains cable Door handle Transit bolts Rating plate Hose support Drain pump filter Feet for levelling the appliance...

  • Page 11: Control Panel

    ENGLISH 5. CONTROL PANEL 5.1 Control panel description Bavlna 11 10 Programme dial • Skvrny option • Předpírka option Display Odložený start touch button touch button Jemné+ touch button Úspora času touch button Odstřeďování Máchání reduction touch button touch button Teplota •...

  • Page 12: Knob And Buttons

    Maximum load indicator. The indicator flashes during the laundry load estimation. Door locked indicator. Delay start indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( ). • Warning code ( Washing phase indicator.
  • Page 13 ENGLISH 6.2 Introduction The appliance empties the water out The options/functions are automatically after 18 not selectable with all hours approximately. washing programmes. Check • Activate the Extra Silent option. the compatibility between The intermediate and the final options/functions and spinning phases are suppressed and washing programmes in the the programme ends with water in the...

  • Page 14: Odložený Start

    6.8 Úspora času containing sand, dust , mud and other solid particles. With this option you can decrease the The options can increase the programme duration. programme duration. • If your laundry is normally or lightly soiled, it may be advisable to shorten 6.6 Máchání...

  • Page 15: Programmes

    ENGLISH 7. PROGRAMMES 7.1 Programme Chart Washing programmes Programme Programme description Washing programmes White cotton and coloured cotton. Normal soil and light soil. Standard programmes for the Energy Label consumption Bavlna values. According to regulation 1061/2010, the programme Bavlna at 60 °C and the programme Bavlna at 40 °C with the option are respectively the «Standard 60°C cotton pro- gramme»...
  • Page 16 Programme Programme description Do not use fabric softener and make sure that Outdoor there is no softener residue in the detergent dispenser. Synthetic sport items. This programme is designed to gently wash modern outdoor sporting garments and is also suitable for sporting clothes such as gym, cycling or jogging and simi- lar.
  • Page 17 ENGLISH Programme Default tempera- Maximum spin speed Maximum load ture Spin speed range Temperature range 40 °C 1200 rpm 3 kg 40 °C - Cold 1200 rpm - 400 rpm Jemné 40 °C 1200 rpm 1,5 kg 40 °C - Cold 1200 rpm - 400 rpm Vlna/Hedvábí...

  • Page 18: Woolmark Apparel Care - Blue

    ■ ■ ■ ■ ■ ■ ■ Skvrny ■ ■ ■ ■ ■ Předpírka ■ ■ ■ ■ ■ ■ Extra máchání ■ ■ ■ ■ ■ ■ ■ ■ ■ Pouze máchání ■ ■ ■ ■ ■ ■...

  • Page 19: Settings

    ENGLISH 8. SETTINGS 8.1 Child Lock To deactivate/activate the acoustic signals, touch the Skvrny/Předpírka and With this option you can prevent children the Odložený start buttons from playing with the control panel. simultaneously for about 6 seconds. • To activate/deactivate this option, If you deactivate the touch the Odstřeďování...

  • Page 20: Filling The Detergent And Additives

    4. Close the door firmly. Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level ( ). This quantity will however guarantee the best washing results.

  • Page 21: Setting A Programme

    ENGLISH 4. To use liquid detergent, turn the flap The indicator of the Start/Pauza button down. flashes. The display shows the maximum declared load for the programme, the default temperature, the maximum spin speed, the washing phase indicators (when available) and an indicative programme duration.

  • Page 22: Programme Phase Indicators

    Changing the delay start after 10.9 Programme phase the countdown has started indicators To change the delay start: When the programme starts the indicator of the running phase flashes and the 1. Touch the Start/Pauza button to other phase indicators are steady on.

  • Page 23: Stand-By Option

    ENGLISH 10.12 Opening the door 10.14 Draining water out after end of cycle If the temperature and level of the water in the drum are If you have chosen a programme or an too high and/or the drum option that does not empty out the still rotates you cannot open water of the last rinse, the programme is the door.

  • Page 24: Hints And Tips

    Press the On/Off button to activate If you set a programme or an the appliance again. option that ends with water The display shows the end of the last in the drum, the Stand-by set programme. function doesn't deactivate...

  • Page 25: Care And Cleaning

    ENGLISH • Always start a washing programme additive for water softening. In areas with the maximum load of laundry where the water hardness is soft it is not allowed. necessary to use him. • If you pre-treat the stains, you can use To find out the water hardness in your a stain remover when you set a area, contact your local water authority.

  • Page 26: Cleaning The Detergent Dispenser

    For a complete cleaning: 1. Clean the drum with special products for stainless steel. Always follow the instructions that you find on the packaging of the product. 2. Run a short cotton programme at high temperature or use if is available programme Čištění...
  • Page 27 ENGLISH Clean the drain pump if: • The appliance does not drain the water. • The drum does not turn. • The appliance makes an unusual noise because of the blockage of the drain pump. • The display shows the alarm code WARNING! •...

  • Page 28: Cleaning The Inlet Hose And The Valve Filter

    12.8 Cleaning the inlet hose and the valve filter It is recommended to clean both the filters of the inlet hose and valve occasionally to remove any deposit, collected over the time: 1. Remove the inlet hose from the tap and clean the filter.

  • Page 29: Emergency Drain

    ENGLISH values around 0° C or drop below, remove the remaining water from the inlet hose and the drain pump. 1. Disconnect the mains plug from the mains socket. 2. Close the water tap. 3. Put the two ends of the inlet hose in a container and let the water flow out of the hose.

  • Page 30: Possible Failures

    • - The anti-flood device is on. WARNING! Disconnect the appliance and close Deactivate the appliance the water tap. Contact the Authorised before carrying out any Service Centre. check. 13.2 Possible failures Problem Possible solution • Make sure that the mains plug is connected to the mains socket.
  • Page 31 ENGLISH Problem Possible solution • Make sure that the couplings of the water hoses are tight and there is not water leakages. There is water on the • Make sure that the water inlet hose and the drain hose have floor.

  • Page 32: Consumption Values

    14. CONSUMPTION VALUES The data in this table are approximate. Different variables can affect the data: the quantity and type of laundry, the water and ambient tempera- ture. During the washing programme, the Prosense technology can vary the wash duration and the consumption values. For more details see 'The Prosense load detection' paragraph in 'Daily Use' chapter.

  • Page 33: Accessories

    The tumble dryer can be stacked on the top of the washing machine only by using the correct stacking kit manufactured and approved by AEG. Verify the compatible stacking kit by checking the depth of your appliances.

  • Page 34: Environmental Concerns

    Read carefully the instructions supplied WARNING! with the appliance and with the Do not put the tumble dryer accessory. under the washing machine. 17. ENVIRONMENTAL CONCERNS marked with the symbol with the Recycle the materials with the symbol household waste. Return the product to...
  • Page 35 ENGLISH...
  • Page 36 www.aeg.com/shop...
