LG CM6520-AP Service Manual

LG CM6520-AP Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LG Electronics Online
Factory
Factory
Factory
Model
Suffix
Model
CM6520-
ECHZ
DUSALLK ENAI
AP
Buyer Name Buyer Code Buyer Name Buyer Code Buyer Name Buyer Code
Buyer
LGEUS
US000001
EFFECTIVE
2013-06-18
DATE
Subject
Volume encoder changed
No.
Loc No.
Part No
1
VR3V02
6110E00019E
2
VR3V02
EBF61474401
3
VR3V02
Reason Of Change
Volume Encoder changed for sensitivity improvement.
- Location : VR3V02
- Before Changed : 6110E00019E or EBF61474401
- After Changed : EBF61915401
4M_C20130450.pdf
** FILE THIS SERVICE BULLETIN WITH YOUR SERVICE MANUAL
Parts
Original
A
New
Original
B
New
Original
C
New
Original
D
New
file:///C:/Users/BiteMe/Downloads/Documents/LG%20Electronics%20Online.htm
SERVICE BULLETIN
Sales
Sales
Sales
Subsidiary
Model
Suffix
CM6520 DUSALLK CM6520
LGEAI
US000002
EFFECTIVE FROM(SERIAL NO.)
Before Change
DESC./SPEC.
Switch,Encoder /
EVEKD2F3024M ENCODER 5VDC 0.01A
VERTICAL 50GF.CM 24 D-TYPE 12mM Y
N - Panasonic Corporation.
Switch,Encoder /
EC12H-109 ENCODER 5VDC 0.01A
VERTICAL 50GF.CM . D-TYPE 12mM Y
N - YUQIU MACHINERY & ELECTRONIC
EBF61915401
/
NOTE(**) : INTERCHANGEABILITY CODE
Set
Early
Original or new parts may be used in early or late production sets.
Use original parts until exhausted, then stock new parts.
Late
Early
Original parts may be used in early production sets only.
New parts may be used in early or late production sets.
Use original parts where possible, then stock new parts.
Late
New parts only may be used in early or late production sets.
Early
Stock new parts.
Late
Original parts only may be used in early production sets.
Early
New parts may be used in late production sets only.
Stock original and new parts.
Late
No.
Date
Customer
Factory
Factory
Factory
Model
Model
Suffix
After Change
Part No
DESC./SPEC.
/
/
Switch,Encoder /
EC12H-109A ENCODER 5VDC 1MA
VERTICAL 400GF.CM . D-TYPE 30mM Y
N - DONGGUAN YUQIU ELECTRONIC
CO.,LTD
1. To improve performance
2. To improve productivity
3. To improve reliability
4. Change of material or dimension
5. Addition
6. Deletion
7. Correction
CHIEF ENGINEER ,
Factory.
Page 1 of 1
:
4M/C20130450
: 2013-06-19
Sales
Sales
Sales
Customer
Subsidiary
Model
Suffix
Model
~304xxxxx
Note
K-Code
Remark
C
6
C
6
C
5
KEY-WORD CODE
10/15/2014
