- Page 1 CD Stereo System Operating Instructions The illustrations show SC-AK500. SC-AK500 Model No. SC-AK490 SC-AK300 SC-AK200 www.DataSheet4U.com Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference. RQT6085-4P...
-
Page 2: Table Of Contents
To order accessories contact 1-800-332-5368 TO PREVENT ELECTRIC SHOCK MATCH WIDE or web site (http://www.panasonic.com). BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. AC power supply cord ......1 pc. - Page 3 THE FOLLOWING APPLIES ONLY IN THE U.S.A.: Recording operations CAUTION: Before recording (Deck 2 only) ......21 This equipment has been tested and found to comply with Recording from compact discs ......22 the limits for a Class B digital device, pursuant to Part 15 of Tape-to-tape recording ..........
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the safety precautions listed below. Keep these operating instructions handy for future reference. 4. Outdoor antenna grounding—If you connect an outdoor an- Safety tenna, ground the antenna system to protect against voltage surges and built-up static charges. -
Page 5: Listening Caution
About the remote control Listening caution Battery installation SC-AK500 SC-AK490 SC-AK200 SC-AK300 Selecting fine audio equipment such as the unit you’ve just pur- chased is only the start of your musical enjoyment. Now it’s time to R6/LR6, AA, UM-3 R6, AA, UM-3 consider how you can maximize the fun and excitement your equip- ment offers. -
Page 6: Connections
Connections Basic connections (for supplied accessories) • Plug the AC power supply cord into a household AC outlet only after all other connections have been made. • To prepare the antenna wires and speaker cords, twist the vinyl cover tip and pull off. Connect the FM indoor antenna. -
Page 7: Optional Antenna Connections
Connections FM outdoor antenna (not included) Optional antenna connections You may need an outdoor antenna if you use this system in a mountainous region or inside a reinforced concrete building, etc. 75 Ω coaxial cable (not included) FM outdoor antenna Disconnect the FM indoor antenna if an FM outdoor antenna is in- stalled. -
Page 8: Front Panel Controls
Front panel controls Main unit Name Ref. page 1 AC supply indicator (AC IN) This indicator lights when the unit is connected to the AC power supply. 2 Standby/on switch (f/I, POWER) Press to switch the unit from on to standby mode or vice versa. In standby mode, the unit is still consuming a small amount of power. - Page 9 Front panel controls Remote control Buttons such as 2 function in exactly the same way as the buttons SLEEP SLEEP CL CLOCK PLAY AUTO OFF TO OFF TIMER TIMER on the main unit. Name Ref. page DISC DISC 2 Standby/on button (f) ..........11 ;...
-
Page 10: Turning The Demo Function Off
Turning the demo function off If the clock has not been set, a demonstration of the display is shown when the unit is switched to standby mode. This function is set to on at the time of purchase. During standby mode Press and hold [L/–DEMO] until “NO DEMO”... -
Page 11: Auto-Off Function
Auto-off function Remote control only When CD or tape is selected as the source SLEEP To save power, the unit turns off if it is left unused for ten minutes. –AUTO OFF Note This function does not work if the source is tuner or AUX. Press and hold [–AUTO OFF]. -
Page 12: Listening To Radio Broadcasts
Listening to radio broadcasts Press [TUNER/BAND] to select band. The unit comes on automatically. Every time you press the button: FM ↔ AM Press [PLAY MODE] on the remote control to select “MANUAL”. Every time you press the button: MANUAL ↔ PRESET. Press [g/REW/4] or [3/FF/f] to select the frequency of the required station. -
Page 13: Presetting Radio Broadcasts
Presetting radio broadcasts Remote control only There are two methods of presetting stations. Automatic presetting : All the stations the tuner can receive are preset. Manual presetting : You can select the stations to preset and the order they are preset in. Up to 15 stations each can be set in the FM and AM bands. -
Page 14: About Compact Discs
About compact discs With this system, you can only play compact discs having this mark. However, do not use irregular shaped CDs. CDs of the sort can damage the unit. XXXX XXXX XXXXX XXXX XX XXXX XXXX XXXXX XXXX XXXX XXXXX XXXX XXXX Handling precautions •... -
Page 15: Listening To Compact Discs
Listening to compact discs Playing MP3 (SC-AK500 and SC-AK490 only) This unit can play MP3 files compressed using MPEG 1 audio layer 3. How discs with MP3 differ to CDs When making MP3 files to play on this unit This unit can access up to 999 tracks, 255 albums and 20 sessions. Disc format L Starting play from a selected track Conform to ISO9660. - Page 16 Listening to compact discs This unit can play CD-DA (digital audio) format audio CD-R and CD-RW that have been finalized (a process that enables CD-R/ CD-RW players to play audio CD-R and CD-RW) upon completion of recording. It may not be able to play some CD-R or CD-RW due to the condition of the recording.
-
Page 17: Program Play
Listening to compact discs Program play Remote control only You can program up to 24 tracks.by remote control only Press [CD :/ J] and then [L]. Press [PROGRAM]. 1 • 7 Press [DISC]. (within 10 seconds or so) Press [1] – [5] to select the disc you want. Press the numeric button to select the desired track. -
Page 18: To Listen To Specific Cds And Tracks (Cd Play Mode Function)
Listening to compact discs To listen to specific CDs and tracks (CD Play Mode function) Remote control only This function makes it easier for you to select specific CDs and tracks from those loaded in the player. There are 5 disc/track selection modes. 1 •... -
Page 19: Direct Access Play
Listening to compact discs Direct access play Remote control only Press [DISC]. (within 10 seconds or so) Press [1] – [5] to select the disc you want. Press the numeric button to select the desired track number. The CD will be played from the selected track to the last track of the disc. -
Page 20: Listening To Tapes
Listening to tapes You can use either deck 1 or deck 2 for tape playback. Use normal position tapes. High position and metal position tapes can be played, but the unit will not be able to do full justice to the characteristics of these tapes. DECK 1/2 Press [TAPE :]. -
Page 21: Before Recording (Deck 2 Only)
Before recording (Deck 2 only) Types of tapes which can be recorded correctly To protect tapes against further recording Use normal position tapes. High position and metal position tapes can be used, but this unit will not be able to record or erase them correctly. Side A Erasure prevention The illustration shows how to remove the tabs to prevent recording. -
Page 22: Recording From Compact Discs
Recording from compact discs You can use 1-DISC/ALL-DISC/1-SONG mode (z page 18) to make recordings. Preparation: • Do the preparatory steps (z page 21). • Insert the disc(s) you want to record (z page 16). 1-DISC/ALL-DISC recording Do steps 1 to 4 on page 18. Ensure CD is stopped. -
Page 23: Recording From Radio Broadcasts
Recording from radio broadcasts Preparation: Do the preparatory steps (z page 21). Tune to the required station. (z page 12 or 13). Press [a REC] to start recording. To stop recording Press [L/–DEMO]. To record from a specific point on a tape Before recording, advance the tape to the point from where you want to start recording. -
Page 24: Using The Built-In Sound Quality Settings
Using the built-in sound quality settings Press [PRESET EQ] to select the sound quality. Every time you press the button: HEAVY SOFT CLEAR VOCAL EQ-OFF HEAVY : Select this when playing rock or other kinds of music that PRESET EQ sounds better with an added punch. -
Page 25: Using The Timer
Using the timer Using the play/record timer Remote control only The timer has two functions. It can be set to on at a certain time to 1 • 2 • 3 wake you up, or it can be set to record the radio or from the aux source. - Page 26 Using the timer Using the play/record timer Remote control only PLAY/REC To change the timer Press [rPLAY/REC] to select the desired timer. CLOCK/TIMER Every time the button is pressed the setting changes as follows. PLAY (OFF) To check settings While the unit is on and the “rPLAY” (or “rREC”) indicator is on, press [CLOCK/TIMER] so “rPLAY”...
-
Page 27: Using The Sleep Timer
Using the timer Using the sleep timer Remote control only This timer turns your system OFF at the set time (Max. 2 hours, set at 30-minute intervals). It lets you fall asleep listening to music. SLEEP – AUTO OFF Preparation Switch on the power. -
Page 28: Troubleshooting Guide
Before requesting service, make the below checks. If you are in doubt about some of the check points, or if the remedies indicated in the chart do not solve the problem: In the U.S.A., contact the Panasonic Customer Call Center at 1-800-211-7262, or e-mail consumerproducts@panasonic.com, or web site (http://www.panasonic.com). -
Page 29: Servicenter List (Only For U.s.a.)
Servicenter List (ONLY FOR U.S.A.) www.DataSheet4U.com RQT6085... -
Page 30: Warranty (Only For U.s.a.)
Servicenter. Carry-in or mail-in service in Puerto Rico can be obtained during the war- vary from state to state. ranty period by calling the Panasonic Sales Company telephone number listed in the Servicenter Directory. If a problem with this product develops during or after the warranty period, you may contact your dealer or Servicenter. -
Page 31: Specifications
Specifications AMPLIFIER SECTION FM TUNER SECTION SPEAKER SECTION SB-AK300 SC-AK500 SB-AK300 Power output Frequency range Type 3 way speaker system 10% Total harmonic distortion 87.9 – 107.9 MHz (200 kHz steps) Speaker(s) 60 Hz–3 kHz, both channels driven 87.5 – 108.0 MHz (100 kHz steps) Woofer 12 cm (4 ˝) cone type... -
Page 32: Maintenance
Product information For product information or assistance with product operation: In the U.S.A., contact the Panasonic Customer Call Center at 1-800-211-7262, or e-mail consumerproducts@panasonic.com, or web site (http://www.panasonic.com). In Canada, contact Panasonic Canada Inc. Customer Care Centre at 905-624-5505, web site (www.panasonic.ca), or an authorized...
