Summary of Contents for Aardwolf FB2-3580
- Page 1 OWNERʼS MANUAL AARDWOLF FORKLIFT BOOM FB2-3580 CREATED BY AARDWOLF INDUSTRIES Published on: info@aardwolf.com.au Contact us: April 2025 Marketing Department www.aardwolf.com.au...
- Page 2 INDEX Page OVERVIEW Introduction Technical data SAFETY INSTRUCTIONS General guidelines Warnings USER INSTRUCTIONS MAINTENANCE WARRANTY Aardwolf Forklift Boom - FB2-3580 - Manual...
- Page 3 OWNERʼS MANUAL Dear Customer, Thank you for choosing the Aardwolf Forklift Boom FB2-3580. Please read the manual carefully before use and keep it readily accessible beside the Forklift Boom at all times. If you have any questions, require spare parts, or need to report any...
- Page 4 OVERVIEW INTRODUCTION The Aardwolf Forklift Boom FB2-3580 is a robust telescoping attachment designed for forklift trucks ranging from 2 to 5 tonnes. Constructed from high-grade Australian rectangular tube steel (AS1163-450 LO), the boom extends in five increments to suit various lifting applications.
-
Page 5: Technical Data
TECHNICAL DATA DIMENSIONS 1175 mm (3000 kgs) 2107 mm (1500 kgs) 2598 mm (1200 kgs) 3089 mm (900 kgs) 3580 mm (700 kgs) 1200 mm FORK POCKET 165 mm 1200 mm 82 mm Aardwolf Forklift Boom - FB2-3580 - Manual... - Page 6 Extended: 700 kgs Extended: 1543 lbs Net weight 136 kgs 300 lbs Gross weight 146 kgs 322 lbs 88 5/8" x 24 3/4" Packaging dimensions 2250 x 630 x 550 mm x 21 5/8" Aardwolf Forklift Boom - FB2-3580 - Manual...
- Page 7 Adjusting Bar Cotter Pin Plain Washer M20 Bolt M16x30 Socket Head Cap Screw M20x50 Plain Washer M16 Pop Rivet Flange Label Slide Bar Locking Pin_1 Swivel Hook 3.0T (SH30T) Chain Ø6x300 mm Locking Pin_2 Aardwolf Forklift Boom - FB2-3580 - Manual...
-
Page 8: Safety Instructions
Bypass or remove safety features, including the built-in extension stop. Attempt to modify the boom without written manufacturer approval. Lift or move loads that are not properly secured to the hook or lifting device. Aardwolf Forklift Boom - FB2-3580 - Manual... - Page 9 ▪ Attach the lifting device to the hook. ▪ Secure the load, raise it slowly, and tilt the mast back slightly. ▪ If unstable, lower the load and adjust the boom or load position. Attach the lifting device Aardwolf Forklift Boom - FB2-3580 - Manual...
-
Page 10: Maintenance
Wipe down regularly and keep dry to prevent corrosion. Lubrication Lightly oil moving parts and sliding surfaces as needed. Storage Store retracted in a clean, dry place. Use anti-rust spray for long-term storage. Replacement Replace worn/damaged parts with genuine components. Aardwolf Forklift Boom - FB2-3580 - Manual... -
Page 11: Warranty Information
Any damages or losses must be officially reported to Aardwolf Industries within eight days of purchase. WARRANTY INFORMATION WARRANTY INFORMATION The product comes with a 12-month warranty from the date of purchase, following Aardwolf Industries warranty policy. WARRANTY EXCLUSIONS WARRANTY EXCLUSIONS The warranty coverage does not apply if: The product is mishandled, misused, or not operated according to its intended purpose. - Page 12 OWNERʼS MANUAL WE PROVIDE Simple, Reliable, Cost Saving And Awesome Ideas For Your Business FIND THE NEAREST AARDWOLF SERVICE CENTER AUSTRALIA INDIA Harmara Road, Industrial Area, Madanganj, Kishangarh, 1/5 Stanton Road, Seven Hills NSW 2147 District- Ajmer, Rajasthan India 305801...
