Summary of Contents for Dacs HEADLITE 4
- Page 2 The unit is compatible with -10dBV and +4dBu inputs (see Using the DACS HeadLite 4 - “2 & 5 Inputs”). The +Power module will also drive multiple headphones - we have used up to 6 pairs of 400 Ohm headphones and experienced no level drop or quality loss.
- Page 3 HeadLite 4 1 White 2 Input Select 3 Blue 4 Volume 5 Input 6 Power +Power Channel Standard Channel Level meters Output Output 7 IEC inlet 8 Voltage Selector 9 Input Sensitivity switches of INs AB and CD 10 Inputs A, B, C, D...
-
Page 4: Installation
Installation 6, 7, 8 Connecting the Power The unit will accept 240 VAC and 110/115 VAC mains supplies via the fused IEC connector. The voltage selector switch selects which voltage the unit expects. PLEASE ENSURE THE VOLTAGE SELECTOR SWITCH IS SET CORRECTLY BEFORE CONNECTING THE POWER. - Page 5 This switches the power on and off, with o indicating OFF and the vertical line indicating ON. The unit comes with a spare fuse in the fuse carrier (T1A). Clarity HEADLITE 4 is fitted with an ultra quiet regulated linear power supply.
-
Page 6: Specifications
Specifications Noise floor: <-90dBu (110dB below peak) Dynamic range: >114dB THD+N 20Hz to 22kHz, +10dBu into 150R: <.002% CMRR: >84dB 50Hz to 20kHz Slew rate: Greater than required for 40kHz Frequency response: 5Hz to 40kHz ± .5dB Max phase rotation (inter channel phase): 100Hz .01 deg, 1kHz .03 deg, 10kHz .36 deg, 20kHz .72 deg Crosstalk:...
