Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's Date Code in the back of
the manual (or month and year of purchase if product has no number). Keep this manual and the receipt in
a safe and dry place for future reference.
UNIVERSAL
TOOL STAND
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-800-444-3353 as soon as possible.
©
Copyright
2025 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: https://www.harborfreight.com
Email our technical support at: productsupport@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
25d
ITEM 69805
Advertisement
Table of Contents
Related Manuals for Central Machinery 69805
Summary of Contents for Central Machinery 69805
- Page 1 Write the product’s Date Code in the back of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. ITEM 69805 UNIVERSAL TOOL STAND Visit our website at: https://www.harborfreight.com...
-
Page 2: Important Safety Information
15. Maintain product labels and Follow tool instructions for nameplates. These carry mounting and operation. important safety information. If unreadable or missing, contact Harbor Freight Tools for a replacement. Page 2 For technical questions, please call 1-800-444-3353. Item 69805... -
Page 3: Specifications
Maximum Weight Capacity 500 Lb. Height Adjustment 3" Increments (26 – 29 – 32 inches) Mounting Holes 8 Holes @ 0.270" Diameter Leg Anchor Holes 4 Holes @ 0.270" Diameter Item 69805 For technical questions, please call 1-800-444-3353. Page 3... - Page 4 Extension attach the remaining Bottom Long Foot and Leg. Attach Spring Washers Brace to the two remaining Legs. (9), and Nuts (8) to the Carriage Bolts and finger tighten loosely. Page 4 For technical questions, please call 1-800-444-3353. Item 69805...
- Page 5 Bottom Short Brace to the remaining two Legs. Figure 4 12. Repeat Steps #10 and #11 above to attach the remaining Top Long Brace to the two remaining Legs. Item 69805 For technical questions, please call 1-800-444-3353. Page 5...
- Page 6 12-17/32" ( 318 mm ) Figure 5 20-7/8" ( 530.23 mm ) 15. Repeat Steps #13 and #14 above Figure 6 to attach the remaining Top Short Brace to the remaining two Legs. Page 6 For technical questions, please call 1-800-444-3353. Item 69805...
-
Page 7: Maintenance And Servicing
• loose hardware • misalignment or binding of parts • loose or improper mounting of a tool • cracked or broken parts • any other condition that may affect its safe operation. Item 69805 For technical questions, please call 1-800-444-3353. Page 7... - Page 8 Note: If product has no Date Code, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Specify UPC 193175569592 when ordering parts. Page 8 For technical questions, please call 1-800-444-3353. Item 69805...
- Page 9 AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Item 69805 For technical questions, please call 1-800-444-3353. Page 9...
-
Page 10: Parts List
Top Short Brace 18.11" (460 m m) Leg 25.07" (637mm) Bottom Short Brace 21.73" (552 m m) Extension Foot 10.35" (263 m m) Carriage Bolt M6 Nut M6 Spring Washer Ø6 Page 10 For technical questions, please call 1-800-444-3353. Item 69805... -
Page 11: Assembly Diagram
Assembly Diagram Item 69805 For technical questions, please call 1-800-444-3353. Page 11... - Page 12 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
