- Page 1 NETWORK VIDEO ENCODER Quick Guide SPE-101...
-
Page 2: What's Included
WHAT’S INCLUDED Please check if your network video encoder and accessories are all included in the product package. Appearance Item Name Appearance Item Name Instruction book, Network Video Encoder Installation CD Quick Guide (Optional) / Tapping screw Warranty card (Optional) (M3 X L12) Small machine screw Bracket... -
Page 3: Front Side
AT A GLANCE Front Side Item Description Video Input Port BNC port for video input. RS-422 TX Data line TX+, TX– This is not available in RS-485 mode. RS-422/485 port D+, D– RS-422 RX Data line or RS-485 Data line Reset Button Hold it down for 5 seconds to return all your settings to the factory default. -
Page 4: Rear Side
Rear Side LINK DC 12V NETWORK / PoE SPE-101 Video Encoder Item Description Power Port Used to connect the specified power source. Network Port Used to connect a PoE or Ethernet cable. 4_ English... -
Page 5: Connecting With Other Device
CONNECTING WITH OTHER DEVICE Connecting the camera Connect the [VIDEO IN] port of the network video encoder to the video output port of the camera. RS-422/485 Camera VIDEO IN Camera RESET Using the bracket or holder Align the product with the bracket holes. Insert and tighten the provided small machine screw (M2.6 X L6) to fix the product with the bracket. -
Page 6: Ethernet Connection
Connecting to the RS-422/485 device Connect the external device to the [D+, D-] ports. You can connect and control PTZ camera that supports RS-422/485 communication. Port Description Port Description RS-422 TX Data line RS-422 RX Data line or RS-485 Data line ... -
Page 7: Manual Network Setup
Be careful not to reverse the polarity when you connect the power cable. You can also use a router featuring PoE (Power over Ethernet) to supply power to the device. If PoE and DC 12V are both applied, this device will get supplied with power from PoE. ... - Page 8 In the <Address> pane, provide the necessary information. In the <Port> pane, provide necessary information. HTTP Port : Used to access the network device using the Internet browser, defaulted to 80. VNP Port : Used to control the video signal trans- fer, defaulted to 4520.
-
Page 9: Using The Live Screen
USING THE LIVE SCREEN Item Description Monitoring Move to the monitoring screen. Setup Move to the Setup screen. Displays the Live video on the screen. Viewer Screen You can use the mouse wheel to activate the digital zooming in Viewer screen. English _9... - Page 10 Item Description You can select a profile type in < Video profile > under the < Video > setup menu. Profile type When the Web Viewer is connected, the profile information currently using is displayed. Screen Optimization The video size of the camera will switch to as big as the Web browser. Regardless of the resolution setup configured in the camera, it sets the resolution to 640x480.
- Page 11 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin’s devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive. Correct Disposal of This Product (Waste Electrical &...
- Page 12 Head Offi ce 86 Cheonggyecheon-ro Jung-gu Seoul 04541 Korea Tel +82.2.729.5277, 5254 Fax +82.2.729.5489 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom Tel +44.1932.57.8100 Fax +44.1932.57.8101...
