Summary of Contents for Kokido Xtrojet 420
-
Page 2: Safety Warnings & Instructions
SAFETY WARNINGS & INSTRUCTIONS Information contained in this Instruction Manual will help you operate the item safely, protect yourself and others from hazards, and prevent damage to the device and other property. SAVE THESE INSTRUCTIONS WARNING! - This is not a TOY. Children should be kept out of reach from this robot and its accessories. - Page 3 - DO NOT handle the robot, external adaptor, and charging connector while it is charging with wet limbs and without shoes. - Ensure that children do not attempt to access the robot while it is operating. - It is not advisable to enter the pool when the robot is working to avoid damage to the robot.
- Page 4 · The transformer ( or external adaptor ) is to be located outside zone 1. · Keep the external adaptor and charging connector out of reach of children. · Never use the external adaptor and charging connector if any damage is detected.
-
Page 5: Getting Started
HOW THE ROBOT WORKS The robot has a water-propelling nozzles at the top of the robot. Water is first sucked in through the suction mouth at the bottom of the robot, which then goes through the filter and is dis- charged via the propelling nozzle. - Page 6 2. Align and insert the charging connector to the charging port. WARNING! Ensure both the charging connector and charging port are clean and dry before charging them. TIP: Use a cotton bud to dry the charging port and pads. Click 3.
-
Page 7: Set-Up Before Use
Set-Up Before Use Adjustment of Trajectory Locking Pin The trajectory of the robot is dependent on the position of the pin that fixes the axle to a certain angle. Recommended settings: NOTE: Wheel axle should be positioned above the locking pin. Pin location Pool size For pools where the shortest... -
Page 8: Operation
OPERATION WARNING! • Make sure the robot is off. • Make sure filter cover is in place. • Ensure the charging connector is detached before deploying the robot in the pool. 1. Bring the robot to the side of your pool. Slide the power switch to “ON” and all indicator lights will illuminate in blue. Immerse entire robot into water and all indicator lights will change to be green. - Page 9 3. Slide the power switch OFF. Rinse the robot with fresh water after every use. DO NOT use any detergent. 4. Dry the charging port and pads thoroughly ( TIPS: Use cotton bud to dry them ) NOTE: To ensure the most efficient cleaning, when your pool is quite dirty, it is recommended to empty the debris compart- ment after the first 30min of operation, or whenever the robot’s movement has slowed down noticeably.
- Page 10 EMPTYING THE DEBRIS COMPARTMENT WARNING! Using the robot without its filter cover in place will VOID your warranty. In order to maximize the cleaning efficiency, clean the debris compartment and the filter cover before and after each use. CAUTION! Before cleaning the debris compartment, make sure the robot is OFF. 1.
- Page 11 4. Align the top cover to the base as shown. Note: There is only one direction in alignment. 5. Press on all side clips until they are secured to the base. A“click” sound will confirm the top cover is secured to the base. TIPS: Before redeploying the robot to the pool, ensure the top cover is secured to the base.
-
Page 12: Battery Disposal
CAUTION! · Excessive heat can damage the battery and reduce the lifespan of your robot as a result. · Consult Kokido Support regarding battery replacement if the following happens: - Battery does not charge fully. - Battery operation time is noticeably reduced. Observe and record the run times of the first few operations (on a full charge). - Page 13 How to remove the battery pack for battery disposal ( To be done by authorized technician) Recommended tools (not included): Screwdriver. 1) Follow section “EMPTYING THE DEBRIS COMPARTMENT” to release the top cover. Pry open the screw covers and then unfasten the screws to release the frame.
-
Page 14: Troubleshooting
Battery is running out Charge the robot again. Power off the robot and inspect the hole under the cover to see if the impeller is jammed by large debris. If necessary, contact Kokido Support for further instructions. Impeller is jammed... - Page 15 Remove clogged objects from the suction mouth. or does not move Power off the robot and inspect the hole under the cover to see if the impeller at all is jammed by large debris. If necessary, contact Kokido Support for further Impeller is jammed instructions. WARNING! Make sure the robot is off before the unit is serviced.
