CQR ALTO Operating And Installation Instructions

c
onnection exAmpleS
s m
#1 = Continuous Sound +ve
ounDer oDe
#2 = Alternating Sound +ve
GND = Common -ve
Tamper x 2 = Lid and mounting surface tamper.
+ve
Not connected
-ve
[
Tamper
Continuous sound only
s m
peaker oDe
Audio In
Audio In
Extension speaker only
S
s t
ounDer echnical
Nominal Voltage:
Voltage range:
Sounder Type:
Sound output level :
Continuous Sound only current:
Alternating Sound only current:
Temperature Range:
Sound Duration:
s t
peaker echnical
Nominal Impedance:
Speaker Type:
*Sound output level :
Temperature Range:
Sound Duration:
*control panel dependant
t D
Lid and mounting surface removal
amper etection
Base Material:
h
Lid Material:
ousing
Dimension:
EN50131-1:2006 + A3:2020
s
tanDarDs
EN50131-4:2019
s p
afety recautions
Always observe local regulations when disposing of this unit.
Plastic bags can suffocate, always dispose of packaging carefully.
Environmental Advice.
This product is covered by current WEEE regulations. Please
consider the effect on the environment when disposing of it.
Do not put in a domestic waste bin. Only dispose of at an
appointed recycling centre.
Not connected
+ve
-ve
[
Tamper
Alternating sound only
Not connected
Not connected
Not connected
[
Tamper
Tamper only
pecificAtionS
13.6 volts DC
9-15 volts DC
Tone (Piezo)
110 dB (A) @ 1 metre
107mA @ 13.6 volts dc
90mA @ 13.6 volts dc
(110mA @15 volts dc/ 80mA @ 9 volts dc)
-15° C to +40° C
Determined by control panel
Better than 16ohms
Tone (Piezo)
>110 dB (A) @ 1 metre
-15° C to +40° C
Determined by control panel
ABS
ABS
115mm x 115mm x 32mm
Security Grade 3 Environmental Class II
Type: Internal - Remotely Powered
Page 4
Operating and Installation
Instructions
D
This remotely powered internal sounder can be installed in security systems
up to and including Grade 3 Environmental class II in accordance with
EN50131:2006 + A2:2020. It complies to EN50131-4:2019. The warning device
gives an audible signal of alarm activation. The sound output is selectable for
either alternating or continuous tone. Additionally it can be selected to be
used as an unpowered extension speaker.It is also protected against
tampering by means of lid removal and removal from the mounting surface.
CQR Security Ltd. 125, Pasture Road, Moreton, Merseyside. CH46 4TH, United Kingdom
Tel: +44 (0)151 606 1000 | Support: +44 (0)151 606 6311 | email: info@cqr.co.uk | Web http://www.cqr.co.uk
issue:3-200722
A
lto
Internal Warning Device/Extension Speaker
SOSP/ALTO/*/G
* Denotes Colour
escription
