Komatsu PC78US-8 Brochure

LIFTING CAPACITY
A
A: Reach from swing center
B: Bucket hook height
C: Lifting capacity
Cf: Rating over front
Cs: Rating over side
B
: Rating at maximum reach
C
PC78US-8 Arm : 1650mm 5'5" Bucket : 0.28 m 3 0.37 yd 3 SAE heaped Shoe width : 450mm 17.7" triple grouser
Maximum 4.5m 14'
A
B Cf Cs Cf
5.0m *1780 1430
16' *3920 3150
3.0m 1160 860 1500
9' 2550 1910 3320
0.0m 1050 760 1370
0' 2310 1690 3020
-2.0m 1440 1050 1360
-6' 3170 2330 3010
PC78US-8 Arm : 2250mm 7'5" Bucket : 0.20 m 3 0.26 yd 3 SAE heaped Shoe width : 450mm 17.7" triple grouser
Maximum 4.5m 14'
A
B Cf Cs Cf
5.0m *1420 1090 *1490
16' *3140 2420 *3290
3.0m 980 720 1540
9' 2160 1600 3400
0.0m 880 640 1370
0' 1950 1410 3020
-2.0m 1120 820 1330
-6' 2490 1810 2930
Load is limited by hydraulic capacity rather than tipping. Ratings are based on SAE Standard No. J1097. Rated loads do not exceed 87% of hydraulic lift capacity
or 75% of tipping load.
PC78US-8 Arm : 1650mm 5'5" Bucket : 0.28 m 3 0.37 yd 3 SAE heaped Shoe width : 450mm 17.7" triple grouser
A Maximum 4.5m 14'
B Cf Cs Cf
5.0m *1780 1500
16' *3920 3310
3.0m *1670 910 *1780
9' *3680 2020 *3930
0.0m *1710 810 *2120
0' *3770 1800 *4680
-2.0m *1650 1120 *1510
-6' *3650 2460 *3330
PC78US-8 Arm : 2250mm 7'5" Bucket : 0.20 m 3 0.26 yd 3 SAE heaped Shoe width : 450mm 17.7" triple grouser
A Maximum 4.5m 14'
Cf
B Cf Cs
*1490
5.0m *1420 1150
*3290
16' *3140 2540
*1570
3.0m *1350 770
*3470
9' *2990 1700
0.0m *1520 680 *2090
0' *3360 1510 *4600
-2.0m *1540 870 *1880
-6' *3400 1920 *4140
Load is limited by hydraulic capacity rather than tipping. Ratings are based on SAE Standard No. J1097. Rated loads do not exceed 87% of hydraulic lift capacity
or 75% of tipping load.
www.Komatsu.com
CEN00339-00
Without blade
3.0m 9' 1.5m 4'
Cs Cf Cs Cf
*1790 *1790
*3960 *3960
1130 *2300 2280
2500 *5070 5030
1000 2650 1900
2220 5850 4200
1000 *2630 1890 *4060
2210 *5810 4180 *8960
Without blade
3.0m 9' 1.5m 4'
Cs Cf Cs Cf
1200
2650
1170 *1870 *1870
2580 *4130 *4130
1000 2660 1920
2220 5880 4230
960 2590 1850 *4230
2130 5710 4070 *9330
Blade on ground
3.0m 9' 1.5m 4'
Cs Cf Cs Cf
*1790 *1790
*3960 *3960
1190 *2300 *2300
2640 *5070 *5070
1060 *3360 2010
2350 *7410 4430
1060 *2710 2000 *4060
2340 *5980 4410 *8960
Blade on ground
3.0m 9' 1.5m 4'
Cs
Cf Cs Cf
1260
2780
1230
*1870 *1870
2710
*4130 *4130
1060 *3320 2020
2350 *7330 4460
1020 *3010 1950 *4230
2260 *6640 4300 *9330
Printed in Japan 200810 IP.As(10)
Materials and specifications are subject to change without notice.
is a trademark of Komatsu Ltd. Japan.
PC78US
Unit : kg lb
Cs
*4060
*8960
Unit : kg lb
Cs
*4230
*9330
Unit : kg lb
Cs
*4060
*8960
Unit : kg lb
Cs
*4230
*9330
-8
Photo may include optional equipment.
HORSEPOWER
Gross: 42.8 kW 57 HP @ 1950 rpm
Net: 41 kW 55 HP @ 1950 rpm
OPERATING WEIGHT
6945– 7535 kg 15,315– 16,615 lb
BUCKET CAPACITY
0.09– 0.34 m 3 0.12– 0.45 yd 3
PC
78
US
