Sony LBT-ZX9 Service Manual

SERVICE MANUAL
Ver. 1.0 2007.01
• LBT-ZX9 is composed of following models.
As service manuals are issued for each component model, please refer to them.
COMPONENT MODEL NAME
COMPACT DISC DECK RECEIVER
FRONT SPEAKER
SURROUND SPEAKER
SPECIFICATIONS
General
Power requirements 120 V, 60 Hz
Power consumption 330 watts
Dimensions (w/h/d) (Main Unit)
Approx. 362 × 437 × 465 mm
Mass (Main Unit) Approx. 19.0 kg
Supplied accessories AM loop antenna (1)
FM lead antenna (1)
Remote Commander (1)
Batteries (2)
Speaker cords:
–grey (10m) (2)
–white (3m) (2)
Speaker pads (16)
Design and specif ications ar e subject to c hang e without
notice .
Sony Corporation
9-887-525-01
Home Audio Division
2007A04-1
Published b y Sony Techno Create Corporation
© 2007.01
LBT-ZX9
HCD-ZX9
SS-ZX9
SS-ZX9
ACCESSORIES
Part No.
1-478-518-21 COMMANDER, STANDARD (RM-SC3)
1-501-374-12 ANTENNA, LOOP (AM)
1-793-184-23 CONNECTOR (F TYPE ADAPTOR) (FM)
1-829-213-11 CORD (WITH CONNECTOR) (10m)
1-829-213-41 CORD (WITH CONNECTOR) (3m)
2-694-377-21 MANUAL, INSTRUCTION (ENGLISH)
2-694-377-31 MANUAL, INSTRUCTION (SPANISH)
4-210-254-02 CUSHION (FOOT) (for SS-ZX9)
COMPACT HI-FI STEREO SYSTEM
LBT-ZX9
Description
(including BATTERY COVER)
US Model
Remark
