Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury
and/or property damage.
These instructions apply to installation of leakage
rated smoke dampers supplied with factory installed
damper actuators. Specific requirements in these
instructions are mandatory. These instructions meet the
requirements of UL 555S and UL classification R13317.
Receiving and Handling
Upon receiving dampers, check for both obvious
and hidden damage. If damage is found, record all
necessary information on the bill of lading and file
a claim with the final carrier. Check to be sure that
all parts of the shipment, including accessories, are
accounted for.
Dampers must be kept dry and clean. Indoor storage
and protection from dirt, dust and the weather is
highly recommended. Do not store at temperatures in
excess of 100°F (38°C).
Safety Warning
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury
or death. Read the installation, operating, and
maintenance instructions thoroughly before installing
or servicing this equipment.
SMD, SMDR, SESMD, and SSSSMD Series
Table of Contents
General Information . . . . . . . . . . . . . . . . . . 2
Electrical Guidelines . . . . . . . . . . . . . . . . . . 2
Pre-Installation Guidelines . . . . . . . . . . . . . . . 2
Smoke Damper Requirements . . . . . . . . . . . . . 2
Maximum Assembly Tables . . . . . . . . . . . . . . 3
Location of Damper in Ductwork . . . . . . . . . . . 4
Attaching Damper to the Duct . . . . . . . . . . . . . 4
Sealing After Installing . . . . . . . . . . . . . . . . . 4
Fan Isolation Application. . . . . . . . . . . . . . . . 5
Damper Maintenance . . . . . . . . . . . . . . . . . 6
Damper Troubleshooting . . . . . . . . . . . . . . . . 6
Document 461338
Smoke Dampers
Smoke Dampers
1
Advertisement
Related Manuals for Greenheck SMD Series
Summary of Contents for Greenheck SMD Series
-
Page 1: Table Of Contents
Document 461338 Smoke Dampers SMD, SMDR, SESMD, and SSSSMD Series ® Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/or property damage. -
Page 2: General Information
Verify power before wiring actuator. establish air pressure differentials and thereby prevent Greenheck is not responsible for any damage to, or the spread of smoke. failure of the unit caused by incorrect field wiring. To avoid causing death or serious bodily harm to building occupants, follow all instructions carefully. -
Page 3: Installing Multiple Section Damper Assemblies
Installing Multiple Section Damper Assemblies A damper assembly is not restricted to a maximum number of sections, but must not exceed the section sizes and assembly sizes shown in the Maximum Assembly Table. Some multiple section high damper assemblies require additional structural support between the damper frames. The following multiple section high damper assemblies require the use of either a support mullion between the damper frames as shown in Figure 1 or individual sleeves around each row of dampers as shown in Figure 2: •... -
Page 4: Location Of Damper In Ductwork
Location of Damper in Ductwork Place the damper assembly in its proper position relative to the barrier as shown (in Figure 3). The plane of the closed damper blades must be within 24 in. (610 mm) of the rated smoke barrier and before any duct inlets or outlets. -
Page 5: Actuator And Open/Close Indicator Connections
Actuator and Open/Close Indicator Connections Actuator Connections Electrical and/or pneumatic connections to damper actuators should be made in accordance with wiring and piping diagrams developed in compliance with applicable codes, ordinances and regulations (see Electrical Guidelines). A penetration through the damper sleeve may be necessary to accommodate the required wiring and/or pneumatic tubing. -
Page 6: Damper Maintenance
Damper Maintenance Dampers do not typically require maintenance as long as they are kept dry and clean. If cleaning is necessary, use mild detergents or solvents. If lubrication is desired for components such as axle bearings, jackshaft bearings and jamb seals, do not use oil-based lubricants or any other lubricants that attract contaminants such as dust. Dampers and their actuator(s) must be maintained, cycled, and tested a minimum in accordance with: •... - Page 7 Notes Smoke Dampers...
-
Page 8: Our Commitment
As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Product warranties can be found online at Greenheck.com, either on the specific product page or in the literature section of the website at Greenheck.com/Resources/Library/Literature.
