Summary of Contents for Bauhn ATSPM-0525
- Page 1 15.6” Portable Touch Screen Monitor MODEL: ATSPM-0525 User Manual AFTER SALES SUPPORT tempo.org/support 1300 002 534 MODEL: ATSPM-0525 PRODUCT CODE: 719431 05/2025...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome Contents Product Overview Controls & Connections Operation 10 Point Multi-touch Using the Magnetic Protective Case and Stand Display Mode Settings Menu Settings Troubleshooting Specif ications Compliance and Responsible Disposal Warranty Information Repair and Refurbished Goods or Parts Notice... -
Page 4: Product Overview
Product Overview What's in the box Before setting up your new product, check you have everything: A. 15.6" Portable Touch Screen Monitor B. Foldable Case/Stand C. USB-A to USB-C Cable D. USB-C to USB-C Cable E. HDMI to Mini HDMI Cable F. -
Page 5: Controls & Connections
Controls and Connections Mini HDMI port USB-C Port: Signal Input and/or Power Input/Output USB-C Port: Power Input only Power button: Press and hold to turn the monitor on. Press and hold again to turn the monitor off. Press to exit menu/selection. Power Indicator: Light will be off when the monitor has disconnected from the power supply. -
Page 6: Operation
Operation Connect and power on Connect and power on the supplied USB cable to the USB-C port on the monitor and the other end to an external power supply (not supplied). • Press and hold the power button to turn the monitor on. •... -
Page 7: Point Multi-Touch
USB-C to USB-C • Please use external power Signal cable supply greater than 15W (not External Power included) . Supply USB-A to USB-C USB-C to USB-C (not included) • Connect the monitor to external power supply (not included) via supplied USB-A to USB-C cable •... -
Page 8: Using The Magnetic Protective Case And Stand
Using the magnetic protective case and stand Stand Mode - rear view Portable Mode - side view Stand Mode - side view • Folded back with stand kicked out. • Folded back • Folded back with stand kicked out. *Images are for reference only. 8 | OPERATION... -
Page 9: Display Mode Settings
Display Mode Settings • Once you have connected the monitor to your PC/laptop, select screen resolution/display settings on your PC/laptop. • Choose the desired display mode. • For Windows 10 computers, you can also press the keyboard +"P" button to quickly choose the display mode. •... -
Page 10: Menu Settings
Menu Settings • When the monitor is connected and powered on, press the control wheel to enter the menu settings. Roll the control wheel upwards/downwards to switch between the menu options. • Press the control wheel to enter the submenu, and press the button again to adjust the values. To exit the menu settings, press the power button. -
Page 11: Troubleshooting
Troubleshooting Problem Solution • Press the power button to ensure the monitor is turned on. Monitor screen is not showing • Ensure the power supply is connected to the monitor and power source properly. anything/black • If using a HDMI cable, ensure it is plugged into the port properly. •... -
Page 12: Specifications
Power Supply 5V 3A without protective case: 0.8kg Net Weight with protective case: 1.1kg Dimensions 357 x 224 x 11.7mm (W x H x D) Pixel defects Resolution 1920 x 1080 For Technical and Warranty Support For active matrix TFTs with a resolution of 1920 x 1080 Panel Type pixels, which are each made up of three sub-pixels (red, 1300 886 649... -
Page 13: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can National Television and Computer Recycling be a suffocation hazard for babies and young children, please ensure all packaging materials are out of Scheme reach and are safely disposed of. -
Page 14: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 15: Repair And Refurbished Goods Or Parts Notice
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. -
Page 16: Online Support
Online support Please read the manual Visit bauhn.com.au for the latest User Manual. Warranty returns tempo.org/support Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work?
