- Page 1 Non-Contact Thermometer Instruction Manual Fever Signal Normal Mild High CLINICALLY PROVEN ACCURACY...
-
Page 2: Table Of Contents
Catalogue Foreword Notice Safety Information 1- Overview 2- Operation 3-Troubleshooting 4-Replacing the Battery 5-Cleaning, Care and Storage 6-Disposal 7-Warranty 8-Calibration 9-EMC Declaration... -
Page 3: Foreword
General knowledge of Non Contact Infrared Thermometer and an understanding of the features and functions of the H8831US Thermometer model are prerequisites for proper use. The Non Contact Infrared Body Thermometer is a medical device, and can be used repeatedly, which using life is 5 years. - Page 4 Warning Warnings are identified by the WARNING symbol shown above. The Non Contact Infrared Body Thermometer is to be operated by consumers in the home setting and primary care setting as screening tool. This manual, accessories, direction for Use, all precautionary information, and specifications should be read before use.
- Page 5 This product must be operated in a stable environment, if the ambient environment was mutations, please should be note whether there is fog on the sensor, if any,before using accordance with the "Care and Storage" section to removing the fog. Do not near strong electrostatic field or strong magnetic fields,thus avoiding the impact on the accuracy of the measurement data.
-
Page 6: 1-Overview
ACCOMPANYING DOCUMENTS. 1-OVERVIEW Indication for Use The Infrared Body Thermometer, Model: H8831US, is an electronic clinical thermometer using an infrared sensor to detect body temperature from the forehead in people of all ages for home setting use. - Page 7 Infrared body thermometer Figure 1: H8831US 1. Surface Mode 1. LCD Display 2. Body Mode 2. Battery Cover 3. Digital Display 3. ON /Scan Button 4. Smile or Cry Indicator 4. Set Button 5. Battery Indicator 5. MEMO Button 6. Buzzer on/ off Indicator 6.
-
Page 8: Equipment Symbols
Thermometer Applications Adult Pediatric Thermometer Thermometer Style Model Number Ear Forehead Ear Forehead Non Contact Infrared Body H8831US Thermometers Equipment Symbols Compliance withe Warning WEEE Standard DO NOT THROW AWAY Non sterile Packaging Intended for multiple use Refer to operating instructions Operating atmospheric pressure 40℃... -
Page 9: Technical Specifications
Technical Specifications Measurement Unit ˚F/˚C Adjusted mode(Body mode) Operating Mode Direct mode(surface mode) Measuring Site Forehead Reference Body Site Oral Body mode: 93.2˚F -109.4˚F/34.0˚C~43.0˚C Rated Output Range Surface mode: 32˚F~212˚F/0˚C~100˚C Body mode: 93.2°F -109.4°F/34.0˚C~43.0˚C Output Range Surface mode: 32°F -212°F/0˚C~100.0˚C Body mode: 93.2°F -94.8°F:±0.5°F/34.0˚C~34.9˚C: ±0.3˚C;... - Page 10 Dimension and Weighting Weight (without batteries) Size 136.5mm x 88mm x 40mm (LxWxH) Compliance Item Compliant with Equipment classification Safety Standards: IEC 60601-1:2005+AMD1:2012+AMD2:2020, IEC 60601-1-2:2014+AMD1:2020 Type of protection Internally powered equipment (on battery power) Front panel and case labeling ISO 15223-1:2021 Temperature ASTM E1965-98 (2016) Home healthcare environment...
-
Page 11: 2-Operation
2-Operation 2.1 Battery installation Caution: The Non Contact Infrared Body Thermometer does not operate with dead batteries and does not input outer power. Install new batteries. 1. Press the "PUSH" button lightly to eject the battery compartment. 2. Pull down the battery compartment. 3. - Page 12 Forehead scan mode: press On/Scan button to open the device, the thermometer is aligned with the forehead to measure body temperature and keep the vertical distance, midway between the eyebrow and the hairline, press and hold the On/Scan button. Lightly slide the thermometer across the forehead keeping the sensor flat with the skin until reaching the right hairline, release the On/Scan button and remove the thermometer from the forehead, then the temperature will display on the screen, the whole process takes about 4 seconds, see figure 3.
-
Page 13: General Setup And Use
General Setup and Use Start measuring 1. Turn on the thermometer by pressing the On/Scan button. The thermometer will perform self-test with all segments displayed for 2 seconds. See figure 5. 2. Align staff forehead to keep the distance, the position lamp (blue aperture) indicates the measuring site, and then press (and hold) the On/Scan button to start the measurement, read the data. - Page 14 H8831US below step: 1)In the boot or shutdown state, short press the MEMO button to view the history of measured values. See figure 6. 2)An empty memory cell shows “---˚C” or “---°F”. See figure 7. 3)Temperature readings can be stored in memory. Up to 50 temperature readings can be stored into the memory cells and automatically overwrite historical data.
-
Page 15: 3-Troubleshooting
3)Prompt sound settings-F3 Under F2 state , short press SET button to enter F3, press MODE button or MEMO button to set voice switch, and press the SET button to confirm the settings. (The factory default is the voice Prompt to open). 4) Exit setting mode In the F3 mode, press the SET button will automatically turn off the screen, exit setting. -
Page 16: 4-Replacing The Battery
4-Replacing the Battery Open and release battery cover following indicator on the surface of battery cover. Before changing the battery be sure the system is already power off. Remove the battery and replace with 2 new one, type AAA, Make sure align properly as indicated inside the battery cover. -
Page 17: 5-Cleaning, Care And Storage
5-Cleaning, Care and Storage 1). Cleaning: Purpose: This thermometer is for single patient reuse to measure body temperature, you may clean the surface of thermometer since which can be contaminated during use with organic soil and microorganisms carried by human hands immediately after each use. -
Page 18: 6-Disposal
2). Care The lens is very delicate. It is very important to protect the lens from dirt and damage. The Infrared probe is very delicate. Do not touch or use tools press it. Must be carefully protected otherwise it will affect the accuracy of the measure. 3). -
Page 19: 7-Warranty
7- Warranty Our company warrants Non Contact Infrared Body Thermometer at the time of its original purchase and for the subsequence time period of one year. The warranty does not cover the followings: The device series number label is torn off or cannot be recognized. Damage to the device resulting from misconnection with other devices. -
Page 20: 8-Calibration
8- Calibration The thermometer is initially calibrated at the time of manufacture. If this thermometer is used according to the use instructions,periodic re-adjustment is not required. If at any time you question the accuracy of temperature measurements,please contact us timely. 9- EMC Declaration This equipment needs to be installed and put into service in accordance with the information provided in the ACCOMPANYING DOCUMENTS;... - Page 21 Guidance and manufacture’s declaration – electromagnetic immunity The Non Contact Infrared Body Thermometer is intended for use in the electromagnetic environment specified below. The customer or the user of Non Contact Infrared Body Thermometer should assure that it is used in such an environment. IEC 60601-1 test level Compliance level Anti-interference detection...
- Page 22 Guidance and manufacture’s declaration – electromagnetic immunity The Non Contact Infrared Body Thermometer is intended for use in the electromagnetic environment specified below. The customer or the user of Non Contact Infrared Body Thermometer should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level...
- Page 23 Guidance and manufacturer's declaration - RF wireless communication equipment immunity Test de Maximum Distance IMMUNITY Band Serviciu Modulation frequency power TEST LEVEL MHz) (MHz) (V/m) Pulse 380- TETRA 400 modulation 18Hz 430- GMRS 460, ± 5 kHz deviation FRS 460 1 kHz sine 704- LTE Band 13,...
- Page 24 HETAIDA TECHNOLOGY GO.,LTD. Add: Room 801, 802, 803, 804, 901, 2# Building Scientific Research Center, Songhu Intelligent Valley, No.6 Minfu Road, Liaobu Town, Dongguan City, Guangdong Province, P.R.China Made in China...
