Komatsu D85EX_15R - D85PX-15R Dimensions

STANDARD EQUIPMENT
● Alternator 50 ampere/24V ● Hydraulic track adjusters
● Back up alarm ● Hydrostatic steering system (HSS)
● Batteries 140 Ah/2 x 12V ● Lighting system (including two front
● Decelerator pedal
and rear lights)
● Dry-type air cleaner with dust evacuator ● Muffler with rain cap
● Palm lever steering control
and dust indicator
● Electric priming pump ● Perforated side covers
● Engine hood ● Radiator reserve tank
● Final drive case wear guard ● Rear cover
● Front pull hook ● Segmented sprockets
● Hinged front mask, perforated
● Hydraulic drive radiator cooling fan
ROPS canopy (without cab):*
Weight. . . . . . . . . . . . . . . . . . 437 kg 970 lb
Roof dimensions
Length . . . . . . . . . . . . . . . 1368 mm 4'6"
Width . . . . . . . . . . . . . . . . 1850 mm 6'1"
Height from
compartment floor . . . . . . 1768 mm 5'10"
*Meets ISO 3471 and SAE J/ISO 3471 ROPS
standards, as well as ISO 3449 FOPS standard.
OPTIONAL EQUIPMENT
● Air conditioner ● Panel cover
● Alternator 75 ampere/24 V ● Seat belt
● AM-FM radio with cassette ● Shoes:
● Batteries 200 Ah/2 x 12V
610 mm 24" Single grouser shoe (EX)
● Fire extinguisher
660 mm 26" Single grouser shoes (EX)
● First-aid kit
910 mm 36" Swamp shoes (PX)
● Heater and defroster ● Starting motor 11 kW/24V
● Light for ripper point ● Sun visor
● Lunch box ● Suspension seat, turn, fabric material
● Mirror, rearview ● Thermos
ROPS for cab:* Steel cab:*
Weight. . . . . . . . . . . . . . . . . . 371 kg 820 lb Weight. . . . . . . . . . . . . . . . . . 410 kg 910 lb
Roof dimensions Dimensions:
Length . . . . . . . . . . . . . . . . 650 mm 2'2" Length . . . . . . . . . . . . . . . 1758 mm 5'9"
Width . . . . . . . . . . . . . . . 1774 mm 5'10" Width . . . . . . . . . . . . . . . . 1323 mm 4'4"
Height from Height from compartment
compartment floor . . . . . . . 1754 mm 5'9" floor to ceiling . . . . . . . . . . 1592 mm 5'3"
*Meets ISO 3449 FOPS standard.
*Meets ISO 3471 and SAE J/ISO 3471 ROPS
standards.
www.Komatsu.com
Materials and specifications are subject to change without notice.
CEN00192-00
● Shoes:
560 mm 22" single-grouser (EX)
910mm 36" single-grouser (PX)
● Starting motor 7.5 kW/24 V
● Suspension seat and reclining
● TORQFLOW transmission
● Track frames
● Track roller guards, full length (EX),
center and end section (PX)
● Warning horn
● Water separator
● Tool kit
● Vandalism protection kit
Multi-shank ripper (EX):
Hydraulically controlled parallelogram ripper
with three shanks.
Weight (including hydraulic
control unit) . . . . . . . . . 2500 kg 5,520 lb
Beam length . . . . . . . . . . . . . 2246 mm 7'4"
Maximum lift above ground . . 564 mm 1'10"
Maximum digging depth . . . . . 653 mm 2'2"
Printed in Japan 200706 IP.AD (10)
is a trademark of Komatsu Ltd. Japan.
D85EX
-15R
D85PX
-15R
C
RAWLER
HORSEPOWER
Gross: 199 kW 266 HP @ 1900 rpm
Net: 197 kW 264 HP @ 1900 rpm
OPERATING WEIGHT
D85EX-15R: 28000 kg 61,730 lb
D85PX-15R: 27550 kg 60,740 lb
Photo may include optional equipment.
D
OZER
