- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. ASKO D3350SS Owner's Manual Shop genuine replacement parts for ASKO D3350SS Find Your ASKO Dishwasher Parts - Select From 210 Models -------- Manual continues below --------...
- Page 2 Use & Care Guide Dishwasher ASKO D3350...
- Page 3 And this is what we try to give you. When you buy an ASKO product, we want you to feel assured that the inside is as good as the outside and that the ethics and morals on which we built this machine are just as high as the quality and performance you get from it.
- Page 4 Contents Press start Page Changing options Contents Do you want to load more dishes? If the machine is switched off with Before doing your first wash the main switch Read through the directions for use After dishwashing Take care with certain materials Check the door Eco-dishwashing Check the water hardness level...
- Page 5 Settings 24-26 (freestanding dishwasher) Reprogramming B. Adjusting machines with three Child-safe button lock or four feet Super rinse C. Adjusting machines with adjustable foot Setting water hardness Adjusting plinth Fault indications (Only with kick-plate as accessory) Troubleshooting 28-30 The dishes are not clean Screw the dishwasher into place Stains or a film on the china The china has a whitish-blue sticky film...
- Page 6 Before doing your first wash Read through the directions for use Check the water hardness level Read the directions of use before starting to Phone your local Water Board to check the use your machine, especially the Safety, water hardness in your area. This is important Child Safety and Basic Course sections.
- Page 7 Safety General: Cleaning • Read and keep the directions for use! Only use a slightly damp cloth for cleaning • Installation of water, drainage and elec- around the edge of the door. Do not use a tricity must be carried out by a qualified spray bottle! Water can penetrate into the professional.
- Page 8 Child safety! Child-safe button lock Closed To prevent children starting the machine, you can activate a button lock. Open Proceed as follows: 1. Switch off the dishwasher at the main switch. 2. Hold in the High temperature and Extra dry buttons, and at the same time switch on the main switch.
- Page 9 Parts of the dishwasher* 1. Knife basket 2. Upper basket 3. Lamp 4. Spray arms 5. Lower basket 6. Cutlery basket 7. Rinse Aid Filling 8. Dishwasher detergent compartment 9. Main switch 10. Program panel 11. Filter 12. Type plate * Details may differ depending on model and market! Technical information...
- Page 10 Baskets* 1. Wine glass shelf Upper basket 2. Cup rack 3. Folding plate stand 4. Cutlery basket with folding door and handle *Details may differ depending on the model and market! Lower basket Cutlery basket Knife basket...
- Page 11 Control panel P R O G P R O G S T A R T S T A R T S T A R T S T O P S T O P S T O P START START 1. Program selector 9.
- Page 12 Basic Course Below are step by step instructions to help you The cutlery basket has a folding flap in the achieve the best possible dishwashing results. middle for small items or narrow shafts, such as electric whisks. Load the baskets correctly! Place long cutlery and carving knives in the Your dishwasher has a Super Clean- special knife basket (if available) or in the...
- Page 13 Fragile dishes can be washed using the Delicate wash Only use dishwasher detergent program. See also the chapter on Fragile Detergent for washing by hand cannot be dishes. used as the build-up of foam impedes the machine’s performance. Quick wash Select Quick Wash if the dishes are very Press the Power main switch lightly soiled.
- Page 14 Options Select options hours until the start appears in the display To select an option, press one of the option window. buttons. • The thirteenth time you press the button, the option cuts out, the clock symbol goes Upper basket/ Lower basket/ out and the display window reverts to show- Both ing the expected program time.
- Page 15 After dishwashing Press start Once the machine has finished, it is only The dishwasher will now start. It manages drawing standing current. Should you wish the entire wash automatically. Close the to disconnect the current completely, just door properly, or the machine will not start. switch off at the main switch.
- Page 16 Eco-dishwashing Choose environmentally-friendly Only wash with a full load Waiting to run the wash until the machine is dishwasher detergent full saves energy. Read environmental declarations on the package! Wash at a lower temperature If the load is only lightly soiled, you can Connect to cold water supply lower the temperature: in Delicate Wash to If the machine is connected to the cold...
- Page 17 Fragile dishes A number of household goods are not suit- Wood able for machine washing. There can be Wooden articles should only be machine many reasons for this. Certain materials washed if they are labelled as dishwasher cannot withstand intense heat, others can proof.
- Page 18 Standard program Consumption Time Option Program procedure Energy kWh Min. (appr.) Water Program Main Final Cold Warm Cold Warm Pre- Temp. Drying wash Rinses rinse water water Litres water water wash °C °C (20°C) (60°C) (20°C) (60°C) Pots & pans High Long Heavy wash...
- Page 19 This page is empty for printing reasons...
- Page 20 Display When you have selected a program, the display shows the length of time the pro- The remaining time display can be slightly gram took the last time it was used. When misleading during the first run of each pro- you have started the machine, the display gram, as the machine is estimating the time.
- Page 21 Cleaning Cleaning The dishwasher’s inner container is made of stainless steel and is kept clean through normal use. However, if you have calciferous (hard) water, lime deposits can form in the dishwasher. In this case, run a normal wash program with two tablespoons of citric acid in Coarse the dishwasher detergent compartment.
- Page 22 If you still cannot start the machine and a humming noise can be heard, then the overfilling protection has been activated. • Shutoff the water • Remove the plug from the wall socket • Call Service CAUTION! Do not forget to replace the pump plug. Spray arms The holes and bearings can occasionally become clogged.
- Page 23 Rinse aid Pour in rinse aid Rinse aid, helps quicker the drying process. When the rinse aid runs out, the rinse aid symbol lights up on the panel.* Certain When the rinse aid has run out, the rinse machines do not have this function. There is aid symbol on the panel lights up.* a refill indicator in the middle of the dispenser (see picture).
- Page 24 Salt (applies to dishwashers with water softeners) Pour in salt Before using a dishwasher with a water softening filter, you must fill the salt com- partment with salt. Use coarse salt or spe- cial salt for dishwashers. Cover for the salt compartment It is best to fill with salt when you are about to do a wash, as the dishwasher needs to be rinsed out immediately after filling.
- Page 25 Settings Reprogramming Some of the machine’s functions can be reprogramd. You get into the machine’s change program using the machine’s ordinary buttons as per the instructions below. The selection will be retained until the next time you reset this function. Even if the machine is turned off at the main switch or loses power for any other reason, all selections registered before the interruption of power will be retained.
- Page 26 Super rinse Super rinse means that two extra rinses will be addes at the end of the main dish. Cannot be used in the Quick wash and Rinse & Hold programs. Switch off the dishwasher with the main switch. Hold in the Express button while pressing the main switch. The Express button and Start will flash.
- Page 27 Setting water hardness If you have a dishwasher with a water softener, you may need to change the setting, de- pending on the hardness level of the water. Phone your local Water Board to check the water hardness in your area. The dishwasher is set for low water hardness on delivery. Switch off the dishwasher at the main switch.
- Page 28 Fault indications Display Type of fault Action Too much water in the machine Phone service Fault with water inlet Check that the tap is open Valve leakage Shut off the tap and phone for service Blocked outflow See ‘Possible causes’ in chapter Troubleshooting Clogged filter Clean the filters, see chapter...
- Page 29 Troubleshooting Problems Action Possible causes • The spray arms are not • Lift off the arms and clean. The dishes are not clean. rotating. • Old dishwasher detergent. • Avoid large packs. NB! Detergent is a perishable. • Incorrect dosage of •...
- Page 30 Possible causes Problems Action • Too high dosage of rinse • Reduce dosage. See the The china has a whitish- chapter on rinse aid. If the aid. blue sticky film. water is very soft, you could try diluting the rinse aid (1 part rinse aid, 1 part water).
- Page 31 Action Problems Possible causes • Disconnect the drain hose Water remains in the • Obstruction in the drain machine. hose. where it is connected to the sink’s water trap. Check that no debris has become stuck. Is the cone-shaped part of the pipe cut so that the diameter is at least 16 mm? •...
- Page 32 Performance information Test dosage Heavy wash/Normal wash Main wash 25 gram Standard detergent. Rinse aid dosage 3. Energy labelling Australia: AS/NZS 2007 Dishwasher program: Normal wash, 45°C normal dry Program time: 100 minutes. Connection: Cold water Test method noise measurement: IEC-704-3 Example of dishwasher loading AS/NZS 2007.1:2003...
- Page 33 Installation Suggestions for positioning the Built-in installation dishwasher The dishwasher can be built in, fully free- standing or semi-freestanding. CAUTION! 820-870 Connection to electricity, water and drain- 820- age must be carried out by a suitably quali- 100- fied person. A.
- Page 34 Connection to water CAUTION! There must be a shut-off tap on the water The lead must be disconnected or the socket supply pipe. The shut-off tap should be voltage-free while the work is carried out! positioned above the work surface or at the front of the sink unit.
- Page 35 Positioning the machine 5. Check that the height of the machine A. Adjusting machines with 6 feet corresponds to the height from the floor to the (freestanding dishwasher) underside of the work surface. Tighten the 1. Adjust the height of the dishwasher with locking nuts (locking nut) on the rear feet.
- Page 36 Not all models To prevent kinks, pull the drain hose and the Fitting fixed kick-plate connecting pipe. Adjusting the plinth (Only with kick-plate as accessory) The dishwasher has two kick-plates (some models). The taller one should be used if the machine is to be 850 - 870 mm high and the plinth depth can be varied between 45 - 105 mm.
- Page 37 Setting water hardness If you have a dishwasher with a water softener, you may need to change the setting, de- pending on the hardness level of the water. Phone your local Water Board to check the water hardness in your area. The dishwasher is set for low water hardness on delivery. Switch off the dishwasher at the main switch.
- Page 38 Service & guarantee Service Guarantee Before calling for service, check to see For guarantee details, see the guarantee whether the faults are due to something that card. you can put rectify. See Trouble shooting pages 28-30.
- Page 39 Own comments...
- Page 40 Search words Advice! 7, 14 Plastic 5, 7, 16, 34 After dishwashing 14 Plinth 34 Pots & pans 7, 10, 12, 13, 24 Child safe 3, 5, 7, 24 Child safety lock 7 Quick wash 10, 12, 13 Citric acid 20, 22 Cleaning 6, 20, 21, 29 Connection 8, 17, 30, 31, 32 Recycling 6...
- Page 41 Quick Guide 1. Loading baskets Remove large food particles and debris. There is no need to rinse thanks to the Super ™ Cleaning System 2. Dispensing dishwasher detergent The detergent compartment has a small compartment for pre-wash and one for main wash.
