Eagle Lights TC01 Installation Instructions

Eagle Lights Passing Lamp
Control Harness for 1990 - 2013
Street Glide, Electra Glide and
Trike Models Installation
Instructions
Installation Warning
If you feel uncomfortable installing this product, we recommend having a professional complete the installation. Eagle Lights LLC is
not liable for any damage to the product or vehicle due to an improper installation. If you have questions about the installation,
please feel free to call us at 1-800-921-3162 or email us at Support@EagleLights.com.
Installation:
Below are steps for a typical installation on most models. Steps may be different depending on the model. Please ensure you have
read through the instructions and understand them clearly before attempting the installation.
● T
o prevent possible electrical shock, disconnect the negative battery terminal before
installing this product. Park the bike on a level surface.
1. Remove the main fuse or disconnect the negative battery terminal.
2. Following the OEM service guide, remove the outer fairing. Remove the bolts for the windscreen and the
four bolts for the outer fairing. Disconnect the headlight and set the fairing to the side.
3. Find the main harness and disconnect the harness from itself.
4. Connect the TP01 in between the main harness plugs.
5. Reconnect the headlight and reinstall the main fuse / negative battery terminal.
6. Test the passing light functions.
7. Reinstall the outer fairing and windscreen.
