Norwood NOR-TSU3012BK-SO Assembly Instructions

A B
1PC 1PC
C D
1PC 1PC
E
1PC
NOR-TSU3012BK-SO
NOR-TSU3012WH-SO
NOR-TSU3012NB-SO
ASSEMBLY NOTES:
During assembly, hand tighten screws only. When all screws are in place,
you may then tighten all screws completely.
CAUTION:1.Do not use this chair as a step ladder.
2.Check for loose screws and tighten them anytime.
1
remove the cap
C
D
3
E
The screw E need to be
backed out .
2014.02.05 B
2
A
4
B
E
The tablet needs to be at 45
degree angle so that the screw
will turn into the opening.
