How to set up the Wemo WiFi Smart Dimmer
Watch the installation video
Compatible bulb types(https://www.belkin.com/us/support-article?articleNum=208552)
How to tell which version of Wemo Dimmer you have
Physical installation (Wemo Dimmer F7C059 and WSD060)
Finishing the setup in the Wemo app
Wemo Dimmer F7C059 (first generation)
Wemo Dimmer WSD060 (second generation)
Adjusting your brightness level
What does the power light color tell me?(https://www.belkin.com/us/support-article?articleNum=317059)
The Wemo® WiFi Smart Dimmer, F7C059 and WSD060 make it easy for you to control your dimmable
lighting anywhere you are and anytime you want.
If you are NOT familiar with electrical work, or feel uncomfortable about it, contact a professional electrician.
Watch the installation video
This video shows the installation of a Wemo Wi-Fi Smart Dimmer.
https://www.belkin.com/us/support-article?articleNum=211577#install
Belkin Official Support - How to set up the Wemo WiFi Smart Dimmer
1/34

Advertisement

loading
Need help?

Need help?

Do you have a question about the WeMo WDS060 and is the answer not in the manual?

Questions and answers

Summary of Contents for Belkin WeMo WDS060

  • Page 1 9/7/22, 10:19 AM Belkin Official Support - How to set up the Wemo WiFi Smart Dimmer  How to set up the Wemo WiFi Smart Dimmer Watch the installation video Compatible bulb types(https://www.belkin.com/us/support-article?articleNum=208552) How to tell which version of Wemo Dimmer you have...
