- Page 1 WIRELESS INTERCOM SYSTEMS Owner’s Manual For Wireless Intercom WHI-2C WHI-3C WHI-4C...
- Page 2 EXPLANATION OF GRAPHIC WARNING SYMBOLS This symbol is intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. This symbol is intended to alert the user to the presence of important operating and maintenance ( S e r v i c i n g ) i n s t r u c t i o n s i n t h e l i t erature accompanying the device.
- Page 3 POWER CORD PROTECTION Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance. READ INSTRUCTIONS All the safety and operating instructions should be read before the product is operated.
- Page 4 IMPORTANT SERVICE NOTES DAMAGE REQUIRING SERVICE Unplug the unit from the wall outlet and refer servicing to qualified service personnel under the following conditions. ¥ If liquid has been spilled into the unit. ¥ If the unit has been exposed to water. ¥...
-
Page 5: Table Of Contents
Ë For continuous communication or monitoring, press the LOCK button. Ë For larger homes or offices additional units may be added. Ë Compatible with all Westinghouse Wireless Intercoms. Ë Up to 1500 foot range. Ë Full one year limited warranty. -
Page 6: Wireless Intercom Features
WIRELESS INTERCOM FEATURES 2-CHANNEL MIDDLE 3-CHANNEL ™ POWER IN USE By Linear LOCK CALL TALK 4-CHANNEL... -
Page 7: Operating Instructions
CHANNEL SELECTOR Allows you to select between channels. IN USE & POWER INDICATORS Lights when intercom is activated, lights when AC power is LOCK BUTTON Press down for continuous monitoring. CALL BUTTON Pages other units on the same channel. TALK BUTTON Press to talk. -
Page 8: Specifications
SPECIFICATIONS DESCRIPTION SPECIFICATION POWER SOURCE 110V-120V AC CARRIER FREQUENCY Channel A 230 KHz Channel B 260 KHz Channel C 290 KHz Channel D 200 KHz RF OUTPUT POWER 100 mW AUDIO OUTPUT POWER 500 mW MODULATION METHOD Frequency Modulation (FM) TRANSMISSION AND RECEPTION Phase Locked Loop (P.L.L.) DIMENSIONS...
