Summary of Contents for Sweetcrispy ZBJ-X10D
- Page 1 Ice Maker Instruction Manual ZBJ-X10D HJ-Customer-Service@outlook.com (909)637-7665 | (909)637-7593 9:00AM--17:00PM...
-
Page 2: Table Of Contents
KIND REMINDER • Thank you for choosing our ice maker. • Please make sure your items have arrived in good condition and confirmation of goods receipt. • If you have any questions or problems, please feel free to contact us for assistance. •... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION To reduce the risk of injury or property damage, please follow these safety precautions. WARNING • Voltage power from outlet must match specifications on appliance nameplate. • This appliance must be grounded. • Using an extension cord may cause overheating and in crease the risk of fire. If an extension cord MUST be used: 1) Only use an extension cord with grounding plug. - Page 4 • The unit must be placed and set up according to installation instructions before use. The unit is for indoor house hold use only. • Do not store or use flammable vapors or liquids near the unit. • Do not immerse any part of the unit in water. •...
-
Page 5: Product Introduction
PRODUCT INTRODUCTION 1. Large Viewing Window 6. Filter 2. Ice Shovel 7. Maximum Water Fill Line 3. Air Exhaust Fan 8. Drain Plug 4. Control Panel 9. Ice Basket 5. Ice Full Sensor 10. Ice Scoop... -
Page 6: Control Panel Introduction
CONTROL PANEL INTRODUCTION POWER ADD WATER ICE FULL ON/OFF SELEC CLEAN SMALL CLEAN LARGR Key (with Functio indicator) Confirms large ice mode or small ice mode. SELEC Short press the ON/OFF/CLEAN button to turn the ice maker on Short press the ON/OFF/CLEAN button to turn ON/OFF the ice maker o . -
Page 7: Using Your Ice Maker
USING YOUR ICE MAKER BEFORE FIRST USE Missing parts? Stand upright for 24hrs. Check for accessories. Contact us. 24hrs Customer Service Clean the ice maker thoroughly Discard first 4 cycles of ice. before first use. Note: If not used in a long period, discard first 4 cycles of ice. - Page 8 HOW TO USE YOUR ICE MAKER Open cover and Pour water, do not exceed Press the ON/OFF remove basket. the “MAX” water mark. button. Press SELECT button to choose Wait for 6min-8min. ice cube size. LARGE 6min-8min Depending on room SMALL temp and ice size.
-
Page 9: Cleaning And Maintenance
CLEANING AND MAINTENANCE To keep your ice tasting fresh and the unit looking great, we recommend cleaning the unit once per week. SELF-CLEANING (15-MIN PROCESS) 1. Remove the basket and add water. 2. Hold for 5 sec to start self-cleaning. In Standby Mode 3. - Page 10 MANUAL CLEANING Turn o the unit and disconnect from power outlet before cleaning. 1. Remove the basket. 2. Clean using a soft cloth with warm water and vinegar. Clean the water filter,ice shovel and the evaporator to avoid dirt buildup. Evaporator Filter 3.
-
Page 11: Product Specifications
PRODUCT SPECIFICATIONS Model ZBJ-X10D Voltage/Frequenc 110-120V/60Hz ≤ 160 Working Power Electric Current Water Reservoir 0.26 gal (1L) Ice Basket Capacity 1.1 lbs (0.5kg) Ice-Making Rate 26 lbs per Day Ice Shape Bullet Ice Size Small or Large Material ABS, PP Net Weight 15.4 lbs (7kg) -
Page 12: Troubleshooting
TROUBLESHOOTING Problem Possible Causes Solution Leave a 6-inch clearance Poor heat dissipation. on all sides of the ice maker for ventilation. The water temperature Fill with water temperature between 46°F and 77°F. is too high. Poor ice shape or quality. Use the ice maker in The ambient room temperatures between... - Page 13 Problem Possible Causes Solution Ice is blocking the Empty the ice basket. infrared sensor. “ICE FULL“ 1. Wipe the infrared sensors clean. indicator Infrared sensors do not light is on. 2. Contact customer service work. if the infrared sensors still don’t work. Stop making ice.
-
Page 14: Warranty Information
Problem Possible Causes Solution Stop making ice, refill water, press ON/OFF Low water level or not enough water. button, then restart and try again. “ADD Water screen blocked at Start the self-cleaning WATER” the bottom of the water function. indicator reservoir. -
Page 15: Safety Tips And Warnings
SAFETY TIPS AND WARNINGS Do not plug and unplug the machine with wet hands. Do not attempt to repair or replace any part of the ice machine unless under manufacturer’s guide, otherwise inspections should be performed under the direction of a technician. Use the machine in a well-ventilated area with a temperature between 50°F and 100°F. - Page 16 At least 6 inches space is left around the ice machine to ensure free circulation of the cooling air. Do not use mechanical equipment or other means to accelerate the defrosting process except the method recommended by the manufacturer. Do not damage the ice machine refrigeration tube. Except for the type recommended by the manufacturer, the appliance shall not be used in the ice storage room of the appliance.
- Page 17 Technical Support (909)637-7665 | (909)637-7593 HJ-Customer-Service@outlook.com Thank you for choosing this product. We strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us.
