Master Airscrew MA.AV23032S4 Installation Manual

Install the marked propellers on the corresponding marked motors.
Note: The installation pattern is the opposite of the one used for AVATA 1
R
CW
N
CCW
INSTALLATION:
To remove the old propellers, use the hex key provided with your AVATA drone to loosen and remove the screws. Replace the
blades with ones that have the same rotation direction (refer to the schematics above). Install the new screws using fresh thread-
locker glue. Ensure that the screws are aligned vertically when tightening them. Tighten the screws fully without overtightening to
avoid damaging the motor threads.
IMPORTANT:
Follow Manufacturer Guidelines: Always adhere to the installation instructions provided by the drone manufacturer.
Verify Propeller Direction: Ensure that the propeller rotation direction is correct. Incorrect placement can cause the drone
to flip or fail to lift, leading to potential damage.
Use Undamaged Propellers: Always replace damaged propellers immediately and use new, undamaged replacements.
Replace Screws with Fresh Threadlocker Glue: Each time you change blades, replace the screws with new ones and use
fresh threadlocker glue to prevent loosening during operation.
Check Installation and Tightness: Ensure that the propellers and motors are securely installed before each flight. Check
screw tightness after every 30 hours of flight.
Handle with Care: Propeller blades are sharp. Replace one motor's blades at a time to avoid misplacement, and always
refer to the schematics above for guidance.
Propeller Installation Manual for AVATA 2
FRONT
Unmarked Propeller
Normal
N
CCW
Marked Propeller
R
Reverse
CW
- CCW -
Counter Clockwise Rotation
- CW -
Clockwise Rotation
