Summary of Contents for OHLPRO CD-W11C
- Page 1 √ ROHS Shenzhen Hengyehui Technology Co., Ltd. USER MANUAL Wireless Car Charger Strong Fits Compatible Magnetic Force AII Phones with MagSafe...
-
Page 2: Table Of Contents
Contents Specifications Overview Installation Instructions Using Steps Attentions Customer Service... -
Page 3: Specifications
Temperature 32℉-104℉ Input Voltage 5V/9V/12V Input Current 2A-2.1A Output Power 5W/7.5W/10W/15W The parameters above are derived from the laboratory of OHLPRO.The actual parameters may differ from product to product or other factors. All images shown here are for reference only. -
Page 4: Overview
Overview Standard Wireless Charging Panel Magnetic Ring ( Single-use not reusable) Charging Cable (1M) Instructions Match-up Card... - Page 5 Optional A - CD Slot Mount Locking Handle 16mm Ball Joint B - 3M Adhesive Base 16mm Ball Joint Support Arm Bendable Part 3M Adhesive Sticker...
- Page 6 Rotating the Locking Handle can adjust the tightness inside the CD slot. � �...
-
Page 7: Installation Instructions
Installation Instructions Use with A - CD Slot Mount 1.Assemble as shown. 2.Push the ball joint firmly into the groove on the back of the CD slot mount then tighten the fixed nut. - Page 8 3. Insert the holder into the car's CD slot and turn the Locking Handle clockwise to lock the holder in the slot. 4. Stick the magnetic ring on the back of your phone and start using...
- Page 9 Suitability of CD Slot Mount Mount only supports CD slot, not car air vents, dashboards, windshields, curved CD slots, etc. √ √ √ Note: When installing the CD slot mount, please pay attention to the force of adjusting the knob to avoid damaging the car's CD slot.
- Page 10 Use with B - 3M Adhesive Base 1.Push the ball joint firmly into the groove on the back of the car mount then tighten the fixed nut. 2.Use a wet wipe to clean the area where the car mount needs to be attached, wait for it to dry.
- Page 11 3. Remove the protection paper of 3M adhesive from the base of the mount. 4. Attach and press firmly the base on the cleaning area.Please let it stand for 1 day to achieve maximum adhesion. Adjust the angle of the car mount to fit your sight. one day...
-
Page 12: Using Steps
Using Steps The magnetic car phone charger mount shall be used in the following 3 usage conditions, Please choose the corresponding usage according to the model of your mobile phone. iPhone 16/15/14/13/12 iPhone16 iPhone14 iPhone13 iPhone15 series mobile phone ： Direct magnetic attraction is OK ... - Page 13 Other situations ( iPhone 16/15/14/13/12 series with non-original non-magnetic case, or non-iPhone 16/15/14/13/12 bare machines/ phone with a mobile phone case ):It shall be used by matching up with metal rings. Other Situations iPhone12 iPhone13 Non-original Non-magnetic iPhone14 Case iPhone15 iPhone16 Other Situations...
- Page 14 Assembling the Metal Ring Take out the pairing card and Use a cleaning wipe to clean the fix it on the edge of the phone back of the phone( or phone case ) /back of the phone where the metal ring needs to be posted.
-
Page 15: Attentions
Attentions 1 . When using this product, please use an adapter with an out- put of 12V or compatible with QC 3.0 PD 2.0 quick charging function. Without this parameter car adapter can not guarantee the normal fast charging of cell phones. 2 . - Page 16 7 . To better protect your phone, it is recommended that you paste the metal ring on the back of the phone case. 8 . Please do not disassemble. 9 . Please install the car mount in a suitable place before starting the journey, do not operate and adjust the car mount while driving.
-
Page 17: Customer Service
Customer Service 24-months limited warranty Lifetime technical support support@ohlpro.com service@ohlpro.com office@ohlpro.com @OHLPRO https://ohlpro.com If you have any questions or concerns about our products, please feel free to contact us. We'd be more than happy to help and answer you. Thank... - Page 18 Visit Our Store for More Products! **Just scan & discover!** Shenzhen Hengyehui Technology Co., Ltd. Address: Xinmu Community, Pinghu Street, Longgang District, Shenzhen, No. 1 Building, Building 1,Area A, Zhanmiling Industrial Zone Business cooperation: support@ohlpro.com Website: https://ohlpro.com Shenzhen Hengyehui Technology Co., Ltd. All Rights Reserved.
