Galaxy A12 Repair Training
SM-A125U
2
Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM-A125U and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung SM-A125U

Summary of Contents for Samsung SM-A125U

  • Page 1 Galaxy A12 Repair Training SM-A125U Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 2: What's In This Guide

    This guide will cover: • Parts of the Device • Disassembly • Assembly So how does this help me? This guide will help you perform quality repairs on Galaxy A12. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 3: Removable Parts

    Galaxy A12 Parts: Removable Parts Galaxy A12 Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 4 The parts include: 6.7” 6.9” • Display Assembly • Main Printed Board Assembly (PBA) Sub PBA • • Components Rear Case • • Battery • Battery Cover Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 5 The Display Panel Battery Sensor  The Front Glass and Laminate • Fingerprint Sensor • Vibrator Motor • Battery • Power and Volume Keys • Speaker • Receiver Speaker Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 6 The Main PBA is the main board of the device. It contains the most essential components of the device such as: Mobile Chipset • • Main Camera Built-in Storage • • Sub Microphone (Mic) • Front Rear Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 7 FPCB stands for Flexible Printed Circuit Board; the printed circuit board built into the cable is the reason why it is so Fun Fact: important to be careful when connecting, disconnecting, or otherwise handling the ribbon part of an FPCB. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 8: Additional Components

    Parts Additional Components Galaxy A12 Galaxy A12 There are a few smaller components on the Galaxy A12 that can be removed. These are: Vibrator Motor Front Facing Cam The Vibrator Motor • • The Front Facing Camera (FFC) Main (Rear) Cameras •...
  • Page 9 Parts BT/WIFI ANT GPS ANT SUB ANT Main ANT The Rear Case NFC ANT Galaxy A12 has a Rear Case that contains the following: • BT/Wi-Fi Antenna Sub Antenna • • NFC Antenna Main Antenna • • Main Antenna L/MB •...
  • Page 10 Do not hold the Battery by its flex connector, as this can accidentally short the leads. NOTE: When handling the Battery, be careful not to puncture or damage it. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 11 Camera Window Parts The Battery Cover Fingerprint Galaxy A12 has a Battery Cover that is clipped to the Sensor Display Assembly. The Battery Cover contains the Fingerprint Sensor, which is connected to the Main PBA by its flex connector. The Camera Window that covers the Cameras is one piece, and can be replaced as a single unit using double-sided tape.
  • Page 12 Galaxy A12 Disassembly: Taking It All Apart Galaxy A12 Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 13 Disassembly of Galaxy A12 Taking the device apart In this section we will review the disassembly of Galaxy A12 This guide will cover: • The tools and equipment needed • The steps of disassembly So how does this help me? With this knowledge you will be able to completely disassemble the Galaxy A12.

  • Page 14: Tools And Equipment

    To ensure proper disassembly without damage to the device, use the proper tools and equipment: Tweezers Disassembly Stick Ceramic Scissors ESD Tweezers Isopropyl Alcohol Screwdriver ESD Wrist Strap Grounded Mat Anti-static Gloves Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 15 • Main PBA • Parts on the Main PBA •  Main Camera Sub PBA • Parts on the Bracket •  Vibrator Motor Battery • Display Assembly • Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 16: Electrostatic Discharge Precautions

    This includes: Wearing an ESD Strap which has passed all required tests • Wearing Anti-static Gloves • Working over a Grounded Mat • ESD Wrist Strap Grounded Mat Anti-static Gloves Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 17 Battery to ignite and cause injury In the event of a swollen Battery, use 99% Isopropyl Alcohol applied with a swab to carefully separate and remove the Back Cover. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 18 The SIM Tray is located at the top right side of the device, and can be removed with a SIM Eject Tool. SD Card – Galaxy A12: Up to 1 TB supported • Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 19 Starting from the right side, insert the Disassembly Stick and run it all the way around the edges to disconnect the Back Cover. Do not remove the Back Cover yet. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 20 Flip the Back Cover to the left, like a book, and use the Disassembly Stick to disconnect and remove the Fingerprint Sensor from the Main PBA. Set the Back Cover to the side. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 21 Disassembly Remove the Rear Case Screws Tool Required: Torque Screwdriver Galaxy A12 has a total of 13 screws. All screws must be removed and discarded. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 22 Remove the Rear Case Tool Required: Plastic Tweezers Using the Plastic Tweezers, enter the disassembly points from the right side to remove the Top and Bottom parts of the Rear Case. Bottom Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 23: Disconnect The Battery

    Disconnect the Battery Always disconnect the Battery whenever working on anything which is voltage sensitive. Tool Required: Disassembly Stick Using the Disassembly Stick, disconnect the Battery from the Main PBA. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 24 Remove and place Front Facing Camera with the lens facing up to the side to prevent lens damage. Upon disconnecting the connectors, remove and discard one (1) Main PBA screw. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 25 Disassembly Remove the Main PBA Tool Required: Disassembly Stick Remove the Main PBA by lifting the board from the top right side. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 26 Disconnect two (2) Cameras from the front of the Main PBA. Disconnect two (2) Cameras from the rear of the Main PBA. Set the cameras to the side with the lenses facing up to prevent lens damage. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 27 Disassembly Disconnect the Sub PBA Tool Required: Disassembly Stick Disconnect the flex connector and one (1) Coax connector from the Sub PBA. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 28 Disassembly Remove the Sub PBA Tool Required: Disassembly Stick Use the Disassembly Stick to remove the Sub PBA. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 29 Disassembly Remove the Vibrator Motor Tool Required: Plastic Tipped Tweezers Carefully insert the tip of the Tweezers underneath the Vibrator Motor to remove it. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 30 To remove the Battery, apply some Alcohol to the Swab and apply the Alcohol around the edges of the Battery. Allow between 30-60 seconds for the Alcohol to dissolve the adhesive holding the Battery to the Display Assembly. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 31 Tools Required: Battery Absorber With the adhesive now loose, adhere the Battery Absorber to the center of the Battery, and pull the Battery up and off of the Display Assembly. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 32 Disassembly Remove the Battery Tools Required: Ceramic Scissors Using the Ceramic Scissors, cut the lead from the Battery and return it to Samsung per U-Class procedure. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 33: Keep In Mind

    Disassembly of Galaxy A12 The device has now been disassembled We have covered the disassembly process of the Galaxy A12. At this point, all removable components have been removed. Keep in mind: In a repair scenario, only remove as much as required for the repair •...
  • Page 34 Galaxy A12 Assembly: Putting It Back Together Galaxy A12 Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 35 Assembly of Galaxy A12 Putting it all back together In this section we will go over the assembly of the Galaxy A12. This guide will cover: • The tools and equipment needed • The steps of disassembly So how does this help me? With this knowledge you will be able to completely assemble the Galaxy A12.

  • Page 36: Tools And Equipment

    Tools and Equipment To ensure proper assembly without damage to the device, use the proper tools and equipment: Disassembly Stick Screwdriver Tweezers ESD Wrist Strap Grounded Mat Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 37 Tools and Equipment To ensure proper assembly without damage to the device, use the proper tools and equipment: New Screws Battery Press Pads Press Jig Service PC Calibration Chart Camera Holder Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 38 Parts on the Bracket • ‣ Vibrator Motor Parts on the Main PBA • ‣ Main Camera Main PBA • Sub PBA • Rear Case • Back Cover • Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 39: Torque Wrench

    Pressing Time: 5 sec • Insert the device in the Press Jig and spin the Torque Wheel until it torques. Wait five (5) seconds before GH81-14467A unspinning and removing the device Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 40 Vibrator Motor, the Motor MUST be replaced. If the adhesive of the Vibrator Motor is worn out, attach new tape to the Vibrator Motor before installation. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 41 Insert the Sub PBA back onto the Display Assembly and make sure that it fits snugly. Connect the Flex connector to the Sub PBA • Connect the Coax cable to the Sub PBA • Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 42 Align the Rear Cameras with the Main PBA and connect two (2) flex cables to the back of the Main PBA and two (2) to the front of the Main PBA. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 43 Insert the Main PBA into the Display Assembly and ensure it lays flush. Once the Main PBA is installed, insert one (1) new screw to secure the Main PBA in place. Torque Specifications Torque Force: 1.3 kgf·㎠±0.07 Screwdriver Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 44 With the Main PBA secured, connect the following the Main PBA: One (1) Coax cable • Display Flex connector • Front Facing Camera • Lastly, connect the Battery flex connector to the Main PBA. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 45 Assembly Install the Rear Case Attach the Top of the Rear Case by snapping it in place along all of the edges. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 46 Attach the Bottom of the Rear Case by snapping it in place along all of the edges. If the sponge tape on the bottom piece has any damage, the tape needs to be replaced. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 47 Assembly Insert New Screws Tool Required: Screwdriver Insert thirteen (13) new screws to secure the Rear Case pieces in place. Torque Specifications Torque Force: 1.3 kgf·㎠±0.07 Screwdriver Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 48 Assembly Connect the Fingerprint Sensor Carefully connect the Fingerprint Sensor flex connector from the Back Cover to the Main PBA. Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 49 There should be no gaps or overlaps between the • Display Assembly and Back Cover The Back Cover will make a clicking sound as it snaps • into place at each connection point Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 50: Quality Control

    Galaxy A12 Quality Control: OQC and Calibrations Galaxy A12 Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 51 Launch Galaxy Diagnostics and perform Outgoing Quality Control to ensure that all components are connected and functioning properly. Calibrations: Galaxy A12 requires the following calibration: • Multi Camera Calibration Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
  • Page 52 Updated with the most recent firmware build • State of charge at 100% • • Wiped clean using microfiber cloth to remove any fingerprints or debris Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.

  • Page 53: Additional Support

    Additional Support Contacting FSS Submit a ticket using Zendesk or speak directly with a FSS agent and get support from an expert. 877-760-0257 Confidential Property of Samsung Electronics America, Inc. For Internal Use Only.
