- Page 1 VOLTA 5078...
- Page 2 124 X 77 X 63 cm 3,5 KM/H In : 100-240 V 50/60 Hz 24 V 7 AH Out : 24 V - 01 -...
- Page 3 Read carefully and follow all directions WARNING BE CAREFUL Assembly / Use : The product requires an adult to assemble. Children can be injured by small parts Sharp edges and sharp parts on assembled vehicles Be careful when opening or assembling a vehicle, children should not handle parts or help assemble the vehicle Always handle protective materials and polybags properly before assembling.
- Page 4 Battery / Charger / Alkaline Batteries: Battery / charger / alkaline batteries are not toys. Do not recharge a. non-rechargeable battery. Do not mix old batteries and new batteries or batteries of the type di erent alkaline standard (carbon-zinc) or rechargeable batteries (nickel-cadmium). Remove the battery when not in use for a long period of time.
- Page 5 Part diagram - 04 -...
- Page 6 Vehicle body Wheel Seat Ring wheel Steering wheel Cutter pin Windshield frames Remote Rear view mirror Velg Gearbox Charger Wheel Extension - 04 - - 05 - - 05 -...
- Page 7 1. Wheel installation Insert the wheel and ring, locked it with the cutterpin, then install the wheel rim until it locked, do the same thing on each front and rear wheel as follows example image beside. 2. Wheel installation Install the gearbox on the axle then insert the wheel and ring, locked it with the cutterpin, then install the wheel rim until it locked, do the same thing on each front and rear wheel as follows example image above.
- Page 8 4. Installation of seats, windshield & mirrors Attach the seat to the car by securing it with screws, for the windshield frame Position it on the car then press until it locked 5. Battery installation Insert the red cable into the red + column, then leave the black cable in the black - column. (ignore this condition if the battery path is installed) - 04 - - 07 -...
- Page 9 High / Low Speed Music Forward Stop Lamp switch Backward Gas pedal on/o Power button, forward / reverse button, speed button high / low on the instrument platform. Power button: Turn right the power button to unlock and it will turn o it pressed again Manual switch: Forward 1.
- Page 10 - 04 - - 09 -...
- Page 11 When the vehicle is overloaded or used incorrectly. The fuse will protect and then reset manually the red button above. Button Reset fuse - 04 - - 10 -...
- Page 12 - 04 - - 11 -...
- Page 14 Lexus LX 600 and other associated mark emblems and designs are intellectual property of Toyota Motor Corporation and used with permission. If you have any question, please contact at L843485741@outlook.com directly.
