This manual applies to:

Vehicle model

DFM6470M5D1

DFM6470M5D2

DFM6470M5F1HEV

In this manual, certain equipment or functions are marked with "*", which means that the equipment or function is only available on certain models, and

may not be available on the vehicle you purchase.

Be sure to read the entire manual (including the online version) carefully, especially the contents with "WARNING", "CAUTION" and "NOTE" marks.

WARNING" indicates that failure to follow the instruction will probably cause severe personal injury or even death.

CAUTION" indicates that dangerous or unsafe operations will cause personal injury or damage to the vehicle.

NOTE" indicates the information that must be observed in the use and maintenance of the vehicle.

When using and operating this vehicle, please strictly abide by local laws and regulations.

This User's Manual is an effective part of the vehicle. Please transfer this User's Manual with the vehicle when transferring the vehicle.

Do not modify the vehicle, which may affect vehicle safety, maneuverability, performance and service life, and may violate regulations. In addition,

damage or performance problems caused by modification, adjustment and disassembly will not be covered under our company's warranty.

Please make sure that the vehicle is regularly serviced and maintained in accordance with the "Quality assurance" section.

Dongfeng Motor Corporation Passenger Vehicle Company reserves the right to modify the vehicle model, equipment or features without prior notice.

Power type

Fuel vehicle

HEV (hybrid electric

vehicle)

Foreword

Engine model

Transmission model

DFMC15TP1

DFMC15TE1

Drive type

7DCT300

HD120

Emission

standard

China VIb

Need help?

Do you have a question about the Haoji and is the answer not in the manual?

Questions and answers

Summary of Contents for DongFeng Haoji

Page 1 Please make sure that the vehicle is regularly serviced and maintained in accordance with the “Quality assurance” section. Dongfeng Motor Corporation Passenger Vehicle Company reserves the right to modify the vehicle model, equipment or features without prior notice.
Page 2 Contents 1 Preparation before driving Adjustment before driving ......49 Instrument cluster 1* ......102 Inspection before driving ......6 Adjustment of steering wheel position ..49 Instrument cluster 2* ......108 Inspection before driving ......6 Interior rearview mirror ......49 Indicator lamps and warning lamps* ..
Page 3 Cruise control* .......... 145 Around view monitor system * ....193 Removing damaged wheel ..... 214 Cruise control * ........145 Full assisted parking aid (FAPA)* ..197 Installing spare wheel......215 Adaptive cruise control (ACC)* ..... 147 Anti-theft system * ........204 Storing damaged wheel and tools ..
Page 4 Other routine maintenance items ... 235 6. Technical parameters Exterior cleaning ........236 Vehicle identification ........ 278 VIN and manufacturer’s plate ....278 Interior cleaning ........238 Selecting sunshade film* ......240 Event data recorder (EDR) ....279 Vehicle corrosion protection ....240 DLC ............
Page 5 1. Preparation before driving Inspection before driving ......6 Walk away lock ........17 Interior rearview mirror ......49 Inspection before driving ......6 Storage / power supply ......18 Exterior rearview mirror ......50 Unlocking / locking ........6 Storage ...........
Page 6 Inspection before driving Unlocking / locking Inspection before driving Smart key* Functions of smart key* ● Check and that the turn signal lamps, brake lamps, reversing lamps, fog lamps, etc. work Composition of smart Key normal. ● Visually check the tires for damage or impurities and for proper tire pressure according routine...
Page 7 Unlocking / locking Passive keyless entry Keyless door locking CAUTION Keyless door unlocking ● Contact authorized dealer immediately if any of the keys is lost. ● Never leave the smart key inside the vehicle when getting off the vehicle. ● With electronic components, the smart key should be kept off water;...
Page 8 Unlocking / locking Keyless automatic window closing* Operating range of passive keyless entry NOTE feature Do not pull the door outside handle and touch the bulge on the door handle at the same time. Otherwise, the doors may not be locked.
Page 9 Unlocking / locking The smart key generates weak radio wave, Passive keyless entry failure CAUTION which may be influenced under the following The request switch fails to work under the ● When the smart key is within the conditions: following conditions: ●...
Page 10 Unlocking / locking Remote controller CAUTION CAUTION The remote controller is a sensitive control After remote door locking, be sure to pull the device. Do not fiddle with it lest the doors door outside handle to verify that the doors might be unlocked unexpectedly and the are locked securely.
Page 11 Unlocking / locking ● Or press and hold the trunk lid unlock button Remote engine start/shutdown* NOTE on the remote controller, so the trunk Press and hold the engine start/shutdown button During automatic window opening, releasing lid will automatically open for vehicles with on the key to start the engine remotely.
Page 12 Unlocking / locking Conditions where the remote controller fails Conditions where the doors can not be to work locked The operating distance of the remote controller Possible causes and Symptom depends on the vehicle surroundings, and the solutions remote controller cannot be used for locking or unlocking doors under the following conditions: Check if one smart key is left inside the vehicle.
Page 13 Unlocking / locking Mechanical key Replacing the key battery If the passive keyless entry and remote door Unlocking/locking doors The service life of the battery is about 2 years unlocking/locking features do not work, the doors mechanical key normally, depending on the operating frequency may be unlocked/locked by the mechanical key.
Page 14 Unlocking / locking Battery replacement steps Notice for environmental protection The battery contains pollutants. It is illegal to discard the battery with domestic garbage. Battery materials must be sorted out for collection and recycled in an environmentally friendly manner. Please discard the battery in an environmentally friendly manner.
Page 15 Unlocking / locking Unlocking/locking the door by the door locking button CAUTION Unlocking the door by driver’s door locking button ● When the vehicle is parked by the When the door is locked by the interior central roadside, after the vehicle comes to a locking system, pull the driver’s door locking stop, the driver should check from the button ②...
Page 16 Unlocking / locking Emergency door locking / unlocking Speed sensing door lock If the smart key battery has run out or the central Speed sensing door lock feature locking system is faulty, the door can be locked When the speed sensing door lock feature is by the door inside locking button.
Page 17 Unlocking / locking Child safety lock CAUTION CAUTION ● When there is a child passenger in the Even if the vehicle allows automatic door re- vehicle, the driver should activate the locking, do not play with the smart key after child safety lock and deactivate the the vehicle is locked, and keep the vehicle passenger’s window switches, so as to...
Page 18 Storage / power supply Storage Unlocking by the remote controller Opening by keyless entry ● Within the effective remote control range, Trunk storage press the unlock button on the remote controller to activate the trunk lid unlock The trunk lid can be opened in any of the request, and press the request switch in the following ways: middle of the lower edge of the trunk lid:...
Page 19 Storage / power supply Opening by in-car trunk lid switch* When the AR projection function is turned on WARNING (set in the MP5 system) and the vehicle power supply is in “OFF” position, carry the smart key, If the vehicle is driving with the trunk lid open, stand close to the trunk lid, and step on the be sure to observe the following precautions: projection, so the trunk lid will automatically...
Page 20 Storage / power supply Manually closing the trunk lid Automatically closing the trunk lid* Closing with remote controller Check the area where the trunk lid is closed for Check the area where the trunk lid is closed for Press and hold the trunk lid unlock button obstacles or other body parts.
Page 21 Storage / power supply Closing with trunk lid switch on instrument Closing with AR projection* Power trunk lid function setting* panel Setting of Lock at closing LG ● Enter “CarCenter” – “Body setting” – “DL and key” – “Lock at closing LG” on the MP5 display, and use the slider on the right side to turn on or off the Lock at closing LG.
Page 22 Storage / power supply Opening angle setting of power trunk lid Luggage storage precautions Trunk underfloor storage box (left and right sides) The trunk can be used to store objects in large sizes. Please follow the precautions below: ● The gravity of object should be close to the floor and rear seat back.
Page 23 Storage / power supply Storage box on door Central storage box on instrument panel Front cup holder and central armrest box The central storage box of the instrument panel The storage box located on each door interior can be used to store objects such as mobile trim panel can be used to store towels, papers, phone, ticket and coin.
Page 24 Storage / power supply Front cup holder Central armrest Console side storage boxes The cover of the central armrest box functions as The console side storage boxes are located on The front cup holder is located on the right side the central armrest.
Page 25 Storage / power supply Coat hook Storage bag on front seat back CAUTION Never hold heavy objects to avoid damaging the ticket holder. Glove box The coat hook is located next to the handle The storage bag on the front seat back can be above the rear door window, and can be used to used to store light and soft items, such as hook light coats and hats.
Page 26 Storage / power supply Rear cup holder* Power supply CAUTION Rear cup holder ● When the instrument cluster display shows Power outlet “Power system failure”, please go to the authorized dealer as soon as possible for inspection of the power system. ●...
Page 27 Storage / power supply USB interface and wireless charging* Wireless charging* Front electrical interface on roof* There is a USB interface at the front of the storage space under the console. These interfaces work only when the ENGINE START/STOP button is in “ACC” or “ON” position.
Page 28 Safe ride Driver’s seat The longitudinal adjustment travel of seat is WARNING about 240mm, with 200mm forward adjustment, and 40mm for backward adjustment. ● Never adjust the driver's seat when the vehicle is Electric adjustment* running! Otherwise, seat move WARNING The power seat is adjustable in six directions unexpectedly and the driver may be unable to control the vehicle or be distracted in this case,...
Page 29 Safe ride Driver's seat headrest Removing headrest Appropriate height of seat headrest Pull the headrest up to the limit, and press down the headrest locking button to pull out the headrest. Installing headrest Align the support rod with the hole on the seat back, press the headrest locking button and press the headrest down to the desired position, and then check whether the headrest is locked...
Page 30 Safe ride Driver’s seat ventilation function* Reclining forward: pull up the handle and tilt the seat back forward; Manual adjustment* Reclining backward: pull up the handle and tilt the seat back backward. Leg support* Switch the ENGINE START/STOP button to “ON”...
Page 31 Safe ride Rear seat Seat back reclining The angle of rear seat backs can be adjusted as follows: 1. Pull up the upper locking handle on the outer Rear seat center armrest* side of the seat back to the limit position (as arrowed in the figure) and release it until the corresponding seat back is completely unlocked.
Page 32 Safe ride Folding rear seats Folding steps for rear seats The rear seats can be folded by the split 1. Move the front seat forward to the limit; 4. Move the seat belt aside, tilt the rear seat proportion of 6:4, and the rear seats can be back forward until it is tilted to the lowest 2.
Page 33 Safe ride Seat belts Front seat belts The front seat belts are emergency locking seat belts with load limiter and, for some models, pre- Fastening seat belts CAUTION tensioner function. driver's seat belt reminder is provided. Some models may also be ●...
Page 34 Safe ride Adjusting seat belt Unfastening seat belt Rear seat belts The rear seats are equipped with 3 three-point seat belts. For some models, the left and right seat belts of the rear seats are designed with pre-tightener and load limiter*. Wearing rear left and right seat belts The length of seat belt can be adjusted by To unfasten the seat belt, press the red button...
Page 35 Safe ride Wearing rear middle seat belt CAUTION If the seat belt latch plate is buckled into the buckle of other seats, the seating position will deviate too far from the seat belt buckle. In the event of a collision accident, the seat belt may move up to the abdomen of the occupant and exert force on the abdomen instead of the hip bone, causing a serious injury thereafter.
Page 36 Safe ride Children’s safety Recommendations for pregnant women and special occupants Children are not allowed to ride the vehicle Elder children without the attendance of an adult. Please select Pregnant women an appropriate child restraint system according to the body size of the child. WARNING ●...
Page 37 Safe ride ● Never allow more than one passenger to Disabled persons WARNING share a seat belt, as one seat belt is Disabled persons are required to fasten the seat ● intended for use by one passenger only. All passengers in the vehicle are required belts when riding.
Page 38 Safe ride Inspecting seat belt reliability WARNING The seat belt retractor will lock the seat belt Use neutral soap or solution suitable for cleaning ● Pretensioner seat belt cannot be reused when: interior trims and carpets to clean the seat belt after activation, and it must be replaced webbing, and after cleaning, dry it naturally.
Page 39 Safe ride Supplemental restraint system Introduction supplemental restraint Frontal airbag Side curtain airbag system Driver's frontal airbag is located in the middle of The side curtain airbags are located at the side steering wheel, and the passenger’s frontal This section contains important information members on both sides of the roof.
Page 40 Safe ride ● Precautions supplemental restraint In frontal collisions, rear-end collisions, CAUTION system rollovers or minor side collisions, the side ● Move driver’s seat front airbag and side curtain airbag will Recommendations effective passenger’s seat backward as far as generally not inflate. Therefore, always airbags But for driver’s seat, the seating...
Page 41 Safe ride Precautions for SRS The protection effect of supplemental restraint WARNING WARNING system (SRS) for short person is lower than normal case. Always fasten the seat belt ● ● Do not place any object between the When the airbag deploys, a big BOMB properly, and always keep a certain distance sound and smoke will be produced.
Page 42 Safe ride ● ● Prevent the children stretching their Collision monitoring area If the driver is too close to the steering wheel, the frontal airbag may fail to play heads, hands, feet or faces to the front for protection, but may even cause fatal passenger's frontal airbag.
Page 43 Safe ride Conditions for airbag to deploy Conditions in which airbag may not deploy Conditions for airbag to deploy include: The frontal airbag, side airbag* and side curtain airbag* may not deploy in the following cases: ● Power supply is normal. If the power supply ①...
Page 44 Safe ride SRS fault indication Maintenance and scrapping of airbags The SRS fault indicator lamp is indicated as SRS components are installed in different WARNING locations of the vehicle, and any operation to the on the instrument cluster. It is used to SRS or removal/installation of SRS components ●...
Page 45 Safe ride Child safety seat Child safety seat anchorage This vehicle is equipped with 2 sets of suitable WARNING ISOFIX child safety seat anchorages, each of which consists of 1 upper anchor support ① ● This vehicle only supports the installation and 2 lower anchor supports ②.
Page 46 Safe ride Child safety seat warning label Applicability of different seating positions for child restraint systems Seating position (or other location) Weight group Front Left/right rear seat Rear center seat passenger’s seat Group 0: < 10kg Group 0+: <13kg Group I: 9-18 kg Group II: 15-25 kg Group III: 22-36 kg Note: The meanings of uppercase letters in the table are as follows:...
Page 47 Safe ride Information on applicability of ISOFIX child safety seat for different ISOFIX positions Seating position (or other location) Front passenger’s Weight group Size class Anchorage Left/right rear Rear center seat Others seat seat ISO/L1 Carry cot ISO/L2 Group 0: < 10kg ISO/R1 ISO/R1 Group 0+: <13kg...
Page 48 Safe ride Precautions for use of child restraint system It is required to use an appropriate child restraint After the child restraint system is installed, check WARNING system for babies during driving, otherwise, if it is well fixed before use. For this purpose, serious or fatal injuries may be caused.
Page 49 Adjustment before driving Adjustment of steering wheel position Anti-dazzling function WARNING When driving at night, if the reflection of the Do not adjust the steering wheel position rearview mirror causes the driver to dazzle, during driving, or serious traffic accident may please pull the adjusting lever backward as occur.
Page 50 Adjustment before driving Recommended angles of exterior rearview Exterior rearview mirror 2. Operate the adjusting knob forward or mirror backward to adjust the exterior rearview mirror The exterior rearview mirrors have functions of vertically, and leftward or rightward to adjust the electric adjustment, electric heating*, and electric exterior rearview mirror horizontally;...
Page 51 Adjustment before driving Manual folding of exterior rearview mirrors* Electrical folding exterior rearview Unfolding mirrors* When the adjusting knob is turned out of the position, the exterior rearview mirrors will be unfolded automatically. This operation will be ineffective if the exterior rearview mirrors are already unfolded.
Page 52 Adjustment before driving Electric heating function of exterior rearview Sun visor CAUTION mirrors* Blocking front sunlight If you need to turn the sun visor to the side while driving, please observe the distance to the front and rear vehicles and slow down or stop the vehicle before any operation.
Page 53 Adjustment before driving Power window Power window master switch ● Automatic mode (express-up & down*): The 4 doors of this vehicle are all equipped with Press or pull the switches ① ~④ to the limit power windows that allow express-up & down* and anti-pinch function*.
Page 54 Adjustment before driving Passenger’s window regulator switch Automatic UP/DOWN* Window power delay* After the vehicle power is switched off, Within 30 s after the ENGINE START/STOP button is switched from “ON” position to “OFF” convenient automatic lifting/lowering of windows can be realized by the smart key and the request position, the windows can be lifted or lowered by switch.
Page 55 Adjustment before driving Panoramic sunroof* Sunroof sunshade Opening sunroof sunshade Level 2 CAUTION Toggle the switch backward to the 1st position, ● Before closing the sunroof, check that no and then release the switch, so the sunroof Level 1 occupant is close to the sunroof, so as to sunshade slides to the fully open state.
Page 56 Adjustment before driving When the Close blind @ LK is turned on, if the Sliding opening of sunroof WARNING vehicle is locked, the sunshade will automatically If the sunroof glass is closed and the sunshade ● Do not close the sunshade when driving close.
Page 57 Adjustment before driving Automatic closing* Initialization of Panorama Sunroof System CAUTION When the ENGINE START/STOP button is In case the sunroof does not work normally due The sunroof rails and grooves may be turned off for 6 hours and the vehicle power to battery cable disconnected or faults detected, supply is in the “OFF”...
Page 58 Adjustment before driving ① Fan speed control/A/C Off knob HVAC (automatic A/C)* Button control of control panel ② Automatic mode (AUTO) button ③ Air outlet mode button ④ “A/C” button ⑤ Recirculation/fresh air mode button ⑥ Front windshield defogger button ⑦...
Page 59 Adjustment before driving ① Automatic mode (AUTO) button Control by MP5 system ② “A/C” button ③ AC MAX button ④ A/C On/Off button ⑤ Recirculation/fresh air mode button ⑥ Front windshield fastest defogger mode ⑦ Rear windshield defroster button ⑧ Temperature up button ⑨...
Page 60 Adjustment before driving Recommendations for A/C For better use of the A/C, please use the operation methods recommended in the table below in a reasonable manner. Recirculation/fresh Purpose Airflow distribution Temperature control Air volume control Remarks switch air mode Adjust temperature, observe the temperature value on Press the fan speed up button...
Page 61 Adjustment before driving A/C sensor Manual mode Temperature control When the A/C is in the AUTO mode, press the Turn the temperature control knob on the control recirculation/fresh air mode button, air outlet panel clockwise or touch the temperature up button on the MP5 display to increase the mode button,...
Page 62 Adjustment before driving Air volume control Switching fresh air/ recirculation mode Front windshield defogger When the A/C is off, if you press the air volume When the ENGINE START/STOP button is in Press the recirculation button on the the “ON” position, the front windshield defogger down button or the air volume up control panel, after which the indicator lamp on...
Page 63 Adjustment before driving After cleaning the front windshield, please press Anti-hot air function CAUTION When the engine is started, the outside button to activate the automatic mode. For a continuous use of the defogger, be temperature is higher than 28° C and the inside When the front windshield defogger button sure to start the engine for fear that the temperature is higher than 30°...
Page 64 Adjustment before driving Cooling One-touch Max A/C The A/C works only when the engine is running. CAUTION Press the Max A/C button , then the button indicator lamp will light up, the A/C will activate 1. Press the button, and check that the the maximum A/C function, and be adjusted ●...
Page 65 Adjustment before driving Max A/C function Heating A/C refrigerant When the A/C is on, turn the temperature control The environmental impact of refrigerant added to 1. Press the button, and check that the the A/C system has been considered thoroughly. knob until appears on the A/C display.
Page 66 Adjustment before driving HVAC (electric A/C)* ① Fan speed control button Button control of control panel ② Air outlet mode button ③ A/C OFF button ④ “A/C” button ⑤ Recirculation/fresh air mode button ⑥ Front windshield defogger button ⑦ Rear windshield defroster button ⑧...
Page 67 Adjustment before driving A/C control by MP5 system * ① “A/C” button ②Maximum cooling button ③ A/C On/Off button ④ Recirculation/fresh air button ⑤ Front windshield fastest defogger mode ⑥ Rear windshield defroster button ⑦ Temperature up button ⑧ Temperature down button ⑨...
Page 68 Adjustment before driving Recommendations for A/C For better use of the A/C, please use the operation methods recommended in the table below in a reasonable manner. Recirculation/fresh Purpose Airflow distribution Temperature control Air volume control Remarks switch air mode When the compressor is working, it consumes part First recirculation Adjust the A/C temperature...
Page 69 Adjustment before driving Adjustment of A/C system Temperature control Switching fresh air/ recirculation mode Manual mode Slide the temperature control button on the Press the recirculation mode button control panel upward or touch the temperature Manually adjust the air outlet mode, air volume, the control panel, so the indicator lamp above up button on the MP5 display to increase the temperature, recirculation/fresh air, front/rear...
Page 70 Adjustment before driving Switching air outlet modes Front windshield defogger Rear windshield/exterior rearview mirror defogger* When the A/C is turned on, click the mode When the ENGINE START/STOP button is in the “ON” position, the front windshield defogger button on the MP5 display to select the air outlet When the ENGINE START/STOP button is in the “ON”...
Page 71 Adjustment before driving Cooling One-touch Max A/C The A/C works only when the engine is running. CAUTION Press the Max A/C button , then the button indicator lamp will light up, the A/C will activate 1. Press the button, and check that the the maximum A/C function, and be adjusted ●...
Page 72 Adjustment before driving Heating A/C refrigerant Air filter The environmental impact of refrigerant added to The air filter equipped on the A/C system is used 1. Press the button, and check that the the A/C system has been considered thoroughly. to remove the dirt, pollen, dust and others.
Page 73 Adjustment before driving Center air outlet Front side air outlet Rear center air outlet* Turn the control knob ① (up/down, left/right) to Turn the control knob ① (up/down, left/right) to Turn the control knob ① (up/down, left/right) to adjust the direction of airflow at air outlet so as to adjust the direction of airflow at air outlet so as to adjust the direction of airflow at air outlet so as to guide air to the required position.
Page 74 Adjustment before driving Lighting Lamp position (front) ① Low beam ② Daytime running lamp/position lamp ③ Front roof lamp ④ Rearview mirror side turn signal lamp ⑤ Low/high beam ⑥ Turn signal lamp - 74 -...
Page 75 Adjustment before driving Lamp position (rear) ① Position lamp ② Turn signal lamp ③ Turn signal lamp* ④ High-mounted stop lamp ⑤ Position lamp ⑥ Reversing lamp ⑦ Rear fog lamp ⑧ License plate lamp ⑨ Position lamp ⑩ Brake lamp ⑪...
Page 76 Adjustment before driving Lighting function Lighting combination switch Main lighting functions CAUTION In case of lighting, the Road Traffic Safety Law should be observed. Since a lot of heat produced when the headlamp is on should dissipate through the The head and tail lamps of the vehicle are used air vent on the headlamp, the headlamp is to guarantee good field of view for the driver, not fully sealed.
Page 77 Adjustment before driving Lighting control Automatic headlamp ON* Low/high beam ON Turn the lighting control knob, so that the mark Turn the lighting control knob, so that the mark on the lighting control knob is aligned with is aligned with the position, and the position, and the automatic headlamp low beam ON indicator lamp...
Page 78 Adjustment before driving Intelligent high beam control (IHBC)* The IHBC automatically switches between high Turning on IHBC Factors affecting IHBC beams and low beams according to the driving Turn-on method of IHBC: turn on the IHBC Due to unavoidable environmental factors and environment, so as to avoid the driver from switch in “CarCenter”...
Page 79 Adjustment before driving Turn signal lamp Lane change function of turn signal lamp* CAUTION Turn the lighting combination switch upward to When lane change is required, pull the lighting Turning on the high beam under good lighting the bottom parallel to the steering wheel plane, combination switch lever gently.
Page 80 Adjustment before driving Fog lamp Fog lamp OFF Example of headlamp levelling When the rear fog lamps are on, push the fog Position of Number of levelling Load in trunk occupants lamp control knob to . The rear fog lamps knob will be turned off.
Page 81 Adjustment before driving Follow-me-home function Lighting power delay function Vanity mirror lamp* The Follow-me-home function can be realized by When the ENGINE START/STOP button is in “ON” position and the low beam, high beam, rear the following operations: fog lamp are on, set the ENGINE START/STOP 1.
Page 82 Adjustment before driving Front dome lamp Rear dome lamp Daytime running lamp When the ENGINE START/STOP button is in “ON” position, the engine will run and the daytime running lamps will come on. This increases the driving safety and also highlights the fashion style.
Page 83 Adjustment before driving Windshield wiper & washer Windshield wiper & washer combination switch The windshield wiper and washer can operate When the combination switch is in the position, only when the ENGINE START/STOP button is the windshield wiper and washer will not operate. in “ON”...
Page 84 Adjustment before driving Rear windshield wiper Front wiper automatic wiping function * CAUTION Select the operating mode of the rear windshield When the ENGINE START/STOP button is in the “ON” position and the wiper switch is in the wiper by rotating the knob ②. ●...
Page 85 Adjustment before driving WARNING When the ambient temperature is below 0℃, if the washer fluid is sprayed on the windshield, the washer fluid may freeze on the windshield, resulting in blurred vision and affecting driving safety; if it is necessary to clean the windshield, please do it at a low speed or at a stop.
Page 87 2. Safe driving Notice about driving ........88 Electronic brake force distribution (EBD) 138 Emergency lane keeping (ELK)*..... 168 Keep the vehicle in normal conditions ..88 Brake assist (BA) ........138 Triggered lane change (TLC)* ....171 Maintain the correct riding posture ... 88 Brake override system (BOS) ....
Page 88 Notice about driving This section mainly introduces important 3. Adjust the headrest to make its middle part Correct riding posture of rear passengers information, operating essentials, flush with the middle part of the driver's ears and For safe riding, rear passengers should observe recommendations and safety precautions for the back of the driver's head as close to the the following:...
Page 89 Notice about driving Safe riding of pets Precautions for driving ● Avoid If there are pets in the vehicle, please pay sudden acceleration sudden CAUTION attention to the following: braking. ● Avoid sharp turns. 1. During driving, do not play with pets. ●...
Page 90 Notice about driving Common sense and skills of driving Efficient use of the vehicle 7. Avoid unnecessary parking and braking, and WARNING keep driving at a stable speed. Observing traffic 1. Perform maintenance on the vehicle in time to lights during driving can minimize stops. Or, try keep the vehicle in good operating conditions.
Page 91 Notice about driving Three-way catalytic converter Exhaust (carbon monoxide) Driving in the rain The three-way catalytic converter is an emission Do not run the engine for a long time in a closed When it rains, as the visibility decreases, control device exhaust system.
Page 92 Notice about driving Wading Driving skills in winter Driving through tunnels If it is required to wade through a waterlogged 1. When the winter comes, please go to an Human eyes need a period of time to adapt road section, please pay attention to the authorized dealer for winter protection and when the ambient light suddenly darkens or following:...
Page 93 Notice about driving Braking skills ● Precautions for braking ● Braking during downhill driving ● Braking on roads with road salt After braking, move the foot from the brake During downhill driving, do not depress the brake During driving on roads with road salt, a salt pedal.
Page 94 Notice about driving Running-in Precautions for running-in Engine running-in Running-in of tires and brake pads In order to prolong the service life of the vehicle, Once engine run-in according Drive at a moderate speed in the first 500km for a new vehicle should be run-in at the initial stage specifications, its service life can be prolonged the running-in of new tires.
Page 95 Notice about driving Driving in severe cold weather Driving in hot weather severe cold weather, addition In hot weather, due to high ambient temperature, CAUTION requirements for driving in winter, pay attention accidents are easily caused by dangerous to the following: conditions such as engine overheating and tire Do not operate the hood locking handle when burst.
Page 96 Notice about driving Safe parking Parking method Parking on a downhill road with curb Parking on an uphill road with curb The vehicle should be parked in a safe and flat area. A correct parking method ensures that the vehicle is secured to prevent accidental vehicle sliding: 1.
Page 97 Notice about driving Parking on a ramp without curb Precautions for parking WARNING ● park near flammable explosive materials to avoid fire. ● During parking, be sure to apply the parking brake and check that the EPB indicator lamp on the instrument cluster comes on.
Page 98 Cab overview - 98 -...
Page 99 Cab overview ① Steering wheel ⑪ A/C control panel ⑫ Driving mode knob ② Cruise control button and mute button ⑬ Driver’s power window regulator switch, passenger’s window locking ③ MP5 system/instrument cluster control button switch ④Lighting combination switch ⑭ Exterior rearview mirror adjuster ⑤Wiper and washer combination switch ⑮...
Page 100 Steering wheel control Horn switch Instrument cluster/MP5 system control MP5 system/call control buttons button Press the upper part of the round switch ⑤ to increase the volume; Press the lower part of the round switch ⑤ to reduce the volume. When playing media music such as USB music, Bluetooth music, press the left side of round switch ⑤...
Page 101 Steering wheel control Custom function buttons Cruise control buttons Through “CarCenter” – “Body settings” – “Convenient” – “Steering wheel * button settings” in MP5, you can set custom button functions, including LKA*, IHBC*, AVM* and parking SayHi. After the setting is completed, press the button ④...
Page 102 Instrument cluster Instrument cluster 1* (for fuel vehicle with full Driving mode display LCD instrument panel) A driving mode indicator lamp is displayed in the area○ , and the driving mode can be switched by operating the driving mode knob on the console. Normal mode ON indicator lamp* The vehicle is running in normal mode with the normal mode ON indicator lamp...
Page 103 Instrument cluster Tachometer If the temperature reaches the red zone and the Fuel gauge high engine coolant temperature warning lamp comes on, it indicates that the coolant temperature is too high. In that case, let the engine idle for several minutes, and then shut down the engine and stop the vehicle.
Page 104 Instrument cluster Driving information display Gear position information and total mileage CAUTION When refueling, ensure that the vehicle is on a flat road and the filling volume is more than 8L; otherwise the fuel gauge cannot detect the change in fuel level. Instrument cluster operation button The vehicle information will be automatically ①...
Page 105 Instrument cluster Vehicle speed display Trip A/B Tire information (DDS) ① Average fuel consumption (L/100km): the Current vehicle speed (km/h). Tire pressure status is displayed for four wheels. When one or more of the four wheels have low volume of fuel consumed per 100km in trip A/B. Driving range, instant fuel consumption tire pressure, the corresponding wheels on the ②...
Page 106 Instrument cluster Remaining distance to the next service Multimedia information Vehicle status information display Display USB music, Bluetooth music, online The maintenance information includes The instrument cluster display shows vehicle status information with text, such as: “Low fuel music, online radio, radio and other multimedia remaining distance to the next service.
Page 107 Instrument cluster Driving assistance information Door ajar reminder Brightness adjustment The backlight brightness of the instrument cluster defaults to the brightness set the last time the ENGINE START/STOP button was set to “OFF” position. The backlight brightness of the instrument cluster can be adjusted through MP5 system - System settings - Display - Display brightness.
Page 108 Instrument cluster Instrument cluster 2* (for HEV with full LCD instrument panel) Driving mode display A driving mode indicator lamp is displayed in the area○ , and the driving mode can be switched by operating the driving mode knob on the console. Normal mode ON indicator lamp* The vehicle is running in normal mode with the normal mode ON indicator lamp...
Page 109 Instrument cluster Speedometer NOTE CAUTION When the vehicle is idling in place for a long Please keep an eye on the battery SOC and time, there may be a difference between the fuel gauge at all times, and make sure that fuel gauge and the actual fuel level.
Page 110 Instrument cluster Instrument cluster operation button Driving information display Vehicle speed display Gear position information and total mileage Current vehicle speed (km/h). page scrolling button ① Press ① Gear position information: current gears: “P”, Driving range, instant fuel consumption switching between different driving information, “R”, “N”...
Page 111 Instrument cluster Trip A/B Tire information (DDS) Remaining distance to the next service ① Average fuel consumption (L/100km): the The maintenance information includes Tire pressure status is displayed for four wheels. remaining distance to the next service. volume of fuel consumed per 100km in trip A/B. When one or more of the four wheels have low tire pressure, the corresponding wheels on the Default maintenance mileage intervals are set as...
Page 112 Instrument cluster Multimedia information Vehicle status information display Bluetooth phone information Display USB music, Bluetooth music, online The instrument cluster display shows vehicle Display Bluetooth phone information, including status information with text, such as: “Low fuel music, online radio, radio and other multimedia Bluetooth connection status, all calls, dialed calls level.
Page 113 Instrument cluster Door ajar reminder Brightness adjustment The backlight brightness of the instrument cluster defaults to the brightness set the last time the ENGINE START/STOP button was set to “OFF” position. The backlight brightness of the instrument cluster can be adjusted through System settings - Display - Instrument brightness in MP5 system.
Page 114 Instrument cluster Indicator lamps and warning lamps* Engine system MIL Left turn signal indicator lamp ABS fault warning lamp EPB fault warning lamp* Right turn signal indicator lamp Brake system warning lamp Tire pressure warning lamp Rear fog lamp ON indicator lamp Charging fault warning lamp* ESC fault warning lamp Position lamp ON indicator lamp...
Page 115 Instrument cluster Inspection of instrument cluster If the ABS is abnormal, the anti-locking function ICA ON indicator lamp* of brake system will be inoperative. However, Top up the fuel tank, close all doors, apply the common braking functions will remain normal IHBC ON indicator lamp* parking brake, fasten the seat belt, and set the (see page for details).
Page 116 Instrument cluster If the brake system warning lamp comes on Traction battery fault warning lamp* Charging fault warning lamp* when the vehicle is traveling, stop the vehicle When the traction battery is faulty, this lamp will For fuel vehicle: rapidly and safely as early as possible. Shut come on.
Page 117 Instrument cluster Motor fault warning lamp* EPS fault warning lamp Oil pressure warning lamp When the motor is faulty, this lamp will come on. When the ENGINE START/STOP button is set When the ENGINE START/STOP button is in to “ON” position, the EPS (electric power “ON”...
Page 118 Instrument cluster High engine coolant temperature SRS fault warning lamp Seat belt warning lamp warning lamp When the ENGINE START/STOP button is in When the ENGINE START/STOP button is in “ON” position, the SRS will perform a self-test, “ON” position, the seat belt warning lamp will When the ENGINE START/STOP button is in “ON”...
Page 119 Instrument cluster EPB fault warning lamp* Engine system MIL ESC fault warning lamp With the ignition switch in the “ON” position, if When the ENGINE START/STOP button is set When the ENGINE START/STOP button is in to “ON” position, the EPB fault warning lamp will “ON”...
Page 120 “ESA ACC fault warning lamp*(red) engine is restarted, contact the authorized dealer fault”. At this time, contact Dongfeng Franchise This lamp will come on when the ACC is faulty. for inspection as soon as possible. (See page Store for inspection as soon as possible.
Page 121 Instrument cluster Performance limited indicator lamp* Automatic wiper ON indicator lamp* Right turn signal indicator lamp With the ENGINE START/STOP button in the When the automatic wiper function is turned on, When the steering combination switch is moved “ON” position, if this lamp comes on briefly and this indicator will come on.
Page 122 Instrument cluster AUTO HOLD status indicator lamp* ICA indicator lamp* ACC READY indicator lamp*(gray) This lamp will come on when the AUTO HOLD is When the ICA is in different working modes, the This lamp will come on when the ACC is ready. enabled.
Page 123 “JA fault”. At this time, contact the On - only FCTA is turned on, without fault; ALC ON indicator lamp* Dongfeng Franchise Store for inspection. On - any of LCW, RCTA and DOW is When the ALC is in different working modes, the...
Page 124 Instrument cluster Reminder buzzer and text* Lighting ON reminder buzzer Driver's seat belt reminder buzzer EPB fault reminder buzzer The driver's seat belt reminder buzzer will be When the EPB switch is released with the When the headlamp switch is in activated when the vehicle speed is no less than service brake pedal not depressed, the buzzer 10km/h.
Page 125 Instrument cluster Front passenger's seat belt reminder* Power supply system fault reminder* BPM reminder* If the vehicle speed is not less than 10km/h and When the 12V power supply system fails, the When the vehicle is under the following instrument cluster display will show “Power the front passenger's seat belt is not fastened, conditions, the instrument cluster will display the instrument cluster display will show “Front...
Page 126 Starting, gear shifting Pedal Area Checking brake pedal WARNING ● If the service brake pedal cannot return to its normal position, contact an authorized dealer for overhaul. ● It is strictly prohibited to wear high-heeled shoes and slippers during driving, as heels of high-heeled shoes may prevent the brake pedal from moving to the end, and slippers may cause slippage when...
Page 127 Starting, gear shifting Vehicle engine start and shutdown Power mode switching Engine start With the brake pedal not depressed, every press on the ENGINE START/STOP button can make Starting switch the power supply state of the system change. The power mode switches between “OFF”→ “ACC”→...
Page 128 Starting, gear shifting Engine start in emergency mode Emergency start of engine WARNING When the engine is accidentally shut down and ● the power mode is “ON”: Once the engine is started, immediately release ENGINE START/STOP ● Set the shift lever to “N”, depress the brake button.
Page 129 Starting, gear shifting Gearshift control* CAUTION The vehicle is equipped with an electronic shift ● After the engine is shut down, the cooling lever. After the driver fastens the seat belt and fan may still run for a while. closes the driver's door, the following gearshift control can be performed: Emergency shutdown of engine If the vehicle fails and the engine cannot be shut...
Page 130 Starting, gear shifting When the vehicle power is ON and the engine Automatic P gear engagement upon sliding: Gear description* is not started, only the P and N gears can be ● When the vehicle power is ON, the gear is in “P”...
Page 131 Starting, gear shifting “D” (drive gear): Engagement of reverse gear WARNING The shift lever is set in this position when the 1. Stop the vehicle completely; Always apply the parking brake while the vehicle is moving forward, and the transmission 2.
Page 132 Starting, gear shifting Driving mode Drive mode MEM function setting ECO mode The Drive mode MEM function can be turned on or off through “CarCenter” – “Convenient” - It is applicable to ECO driving. “Drive mode MEM” in MP5 display. When the Rotate the driving mode knob to enter the ECO function is set ON, the system will memorize the mode.
Page 133 Brake and brake assist Factors affecting the braking effect CAUTION 1. Wear 3. Mountain environment ● During normal driving, do not rest your The wear of the brake pads depends to a large Due to high mountains and long slopes in a foot on the brake pedal habitually, or the extent on the conditions of use and the driving mountain environment, the brake is applied...
Page 134 Brake and brake assist 5. Icy or snowy weather Brake overheating Brake system fault warning lamp Due to the low friction coefficient of icy or snowy Do not place a foot on the brake pedal when If the brake system fault warning lamp road, the braking distance will be greatly braking is not required.
Page 135 Brake and brake assist When the ENGINE START/STOP button is set Electric park brake (EPB) CAUTION to “ON” position or the engine is running, depress the brake pedal, move the shift lever out ● When EPB is applied or released, it is of “R”...
Page 136 Brake and brake assist Dynamic emergency brake AUTO HOLD WARNING If the vehicle service brake system has any fault ● To prevent the vehicle from moving or in the abnormal or emergency situation, pull accidentally, apply the parking brake after up and hold the switch to apply the parking parking, and set the shift lever to “P”.
Page 137 Brake and brake assist AUTO HOLD on Deactivation of AUTO HOLD Anti-lock braking system (ABS) When the engine is running, the left front door is If you unfasten the seat belt, open the front left The ABS prevents the wheels from being locked closed, and the driver’s seat belt is fastened, if door or restart the engine, the AUTO HOLD will during braking, helps the driver to better control...
Page 138 Brake and brake assist Electronic brake force distribution (EBD) Brake override system (BOS) CAUTION The EBD automatically adjusts the distribution The BOS is used to first guarantee the braking ● The functions of ABS have certain ratio of braking force for front and rear axles to effect of the vehicle.
Page 139 Brake and brake assist Electronic stability control (ESC)* NOTE The ESC (including EBD, ABS, TCS, AYC, HBA, ESC activation ESC cannot be turned off when the vehicle HHC, ARP,HDC, assisted braking, and DDS) This system will be automatically activated each speed is above 60km/h.
Page 140 Brake and brake assist Hydraulic brake assist (HBA)* Hill hold control (HHC)* CAUTION This system can assist the driver in emergency The HHC increases the convenience of parking ● The HHC will keep the vehicle still on the braking. It determines whether it is necessary to and starting on a slope.
Page 141 Brake and brake assist Hill descent control (HDC)* Active rollover protection (ARP)* This function can limit the vehicle speed during The active rollover protection (ARP) is an active CAUTION going downhill within the low speed range, so safety protection, which reduces the risk of that the vehicle speed does not exceed the potential rollover when a vehicle steers quickly ●...
Page 142 Electric power steering system Electric power steering system WARNING If the EPS fault warning lamp stays on The electric power steering system (EPS) is when the engine is running, it indicates that the designed to provide steering assist under ● EPS functions abnormally.
Page 143 Dual-mode drive and energy regeneration* Dual-mode drive system working mode Energy regeneration HEV models are equipped with dual-mode drive HEV driving system, which can realize three drive modes: EV When the battery power is low, the vehicle will driving, HEV driving, and engine driving. During run in HEV mode, mainly driven by the motor, the driving process of the vehicle, the vehicle and the engine will assist in generating...
Page 144 Acoustic vehicle alerting system (AVAS)* HEV models are equipped with the AVAS. When Function activation the vehicle is running at a low speed, the AVAS CAUTION installed at the front of the vehicle will issue the warning sound to alert surrounding pedestrians ●...
Page 145 Cruise control* Cruise control * The cruise control is a system that controls the WARNING accelerator pedal by using an electronic program to keep the vehicle running at a constant speed ● During driving on congested roads, in automatically. When the cruise control function is windy areas, on winding or steep roads, activated during long-distance driving on an or on slippery roads such as rainy, snowy...
Page 146 Cruise control* Increasing cruising speed Pausing cruise control NOTE Reset to a higher speed by using one of the In the cruise control status, use one of the During downhill driving, the cruise control following methods: following methods to pause the cruise control, cannot keep the vehicle at a constant speed, after which the cruise control is paused and a Depress the accelerator pedal.
Page 147 Cruise control* ● The ACC system is suitable for driving on Adaptive cruise control* The cruising speed of the ego vehicle and the headway to the lead vehicle may be set through expressways and good roads, but not on Adaptive Cruise Control (ACC) is based on the cruise control button on the steering wheel.
Page 148 Cruise control* ACC activation conditions CAUTION WARNING ● The engine is started. ● ● When following a vehicle ahead to a stop, In some complex traffic scenes that ● EPB is released; in rare cases the system will not cannot be handled, the function may be ●...
Page 149 Cruise control* Use of function When the ACC function is turned on and there is Setting headway Press the right part of round switch ③ to adjust a fault, the ACC indicator lamp (red) vehicle speed to keep an appropriate distance the instrument cluster display, accompanied by the message “ACC fault”.
Page 150 Cruise control* Increasing vehicle speed Pausing ACC Deactivating ACC If the ACC is already activated, reset to a higher When the ACC is activated, if the brake pedal is With the ACC active or suspended, press the depressed lightly or the button ② is pressed, speed using one of the following methods: button①...
Page 151 Cruise control* In addition to the above, when using the ACC system, drivers should be alert and ready to take over the vehicle and turn off the ACC system if necessary under the following conditions: ● The ego vehicle approaches the lead vehicle too quickly or the lead vehicle brakes suddenly, so that the ACC system cannot apply sufficient braking force.
Page 152 Driver assistance * AEB* When there is a risk of collision, the FCW function will work to warn the driver of the CAUTION danger of collision ahead through warning texts, graphics and alarm buzzer, requiring the driver ● The AEB system cannot replace the to take timely braking or other measures to driver’s driving and observation.
Page 153 Driver assistance * Autonomous emergency braking (AEB) AEB function settings ● The FCW and AEB functions can be set If the system detects that the vehicle is still at CAUTION “CarCenter” – “Driving risk of collision when the driver applies off/on through assistance”...
Page 154 Driver assistance * ● The camera performance will be affected AEB system fault CAUTION degraded when lighting When the vehicle is running normally, if the AEB conditions around the vehicle are poor The AEB system will not work in the following (insufficient or too strong light).
Page 155 Driver assistance * LKA* Lane departure warning (LDW)* The LKA system includes lane departure Function description CAUTION warning (LDW) and lane keeping assist (LKA). ● If the LDW function is set on through MP5, The system uses a camera located on the upper ●...
Page 156 ● The vehicle is driving on a straight or slightly of time after the engine is restarted, contact please make sure that there is no dirt, ice, snow Dongfeng Franchise Stores for inspection as curved road; or other obstructions on the top surface of the soon as possible.
Page 157 Driver assistance * Lane keeping assist (LKA)* NOTE NOTE Function description In case of lane change with the turn signal When the LKA function is enabled, both the When the camera located on the upper edge of lamp not turned on, the LKA function may be LDW and LKA functions are turned on.
Page 158 ● When the system can detect the lane of time after the engine is restarted, contact markings on both sides, the vehicle is driving Dongfeng Franchise Stores for inspection as at the boundary of the lane markings, there is soon as possible.
Page 159 Driver assistance * ● Glare due to direct sunlight, oncoming traffic, ● TSR* Recognizable signs reflected light from road water-logging, etc.; ● Recognizable signs include Construction ● Sudden changes in outdoor brightness, such Ahead, Cross Road, Slippery Road, Falling as when entering/exiting tunnels; Rocks, Crosswind, Danger,...
Page 160 Driver assistance * ● Sudden changes in outdoor brightness, such Intelligent speed limit information (ISLI)* Function setting as when entering/exiting tunnels; The function can be turned on/off through ● Headlamp not turned on at night or when the “CarCenter” – “Driving assistance” – “TSR” – “ISA”...
Page 161 Driver assistance * When the speed limit reminder by the camera is Intelligent speed limit control (ISLC)* being given, if the vehicle changes lanes or the The ISLC function uses the camera at the upper Function setting camera recognizes the Speed Limit Cancellation edge of the front windshield and the navigation The function can be turned on/off through sign, the ISLI function will terminate the speed...
Page 162 Driver assistance * Speed limit reminder Cruise control Intelligent cruise assist (ICA)* The ISLI function can recognize speed limit The ISLC obtains speed limit information through The ICA is an advanced driver assistance signs and give speed limit reminders in the camera and navigation system.
Page 163 Driver assistance * ● Target selection may be delayed or ● The ICA system only reacts to moving WARNING disturbed when the vehicle is entering and vehicles same direction exiting curves. The ICA system may not stationary vehicles ahead, and does not ●...
Page 164 Driver assistance * Activation conditions of ICA ICA hands-off alarm and reminder Function on or off ● The engine is started. ● EPB is released; ● The shift lever is in D position; ● The vehicle does not slide backwards; ●...
Page 165 Driver assistance * If a factor that causes the function degradation of Function failure Factors causing function degradation ICA occurs, the ICA will perform the function When the ICA function is activated and ICA fails, Due to inevitable environmental factors and degradation, and on the instrument cluster vehicle status, the ICA may be degraded and the ICA fault indicator lamp (red)
Page 166 Driver assistance * Setting headway Pausing the ICA system ICA limitations Press the right part of round switch ③ to adjust When the ICA function is activated, depress the The radar and camera sensors of ICA have a brake pedal lightly or press the button ② to limited detection range.
Page 167 Driver assistance * In addition to the above, when using the ICA 2. A lead vehicle with little overlap with the ego 4. A vehicle that is turning and a lead vehicle system, drivers should be alert and ready to take vehicle may be outside of the system's detection that is stopped.
Page 168 Driver assistance * Emergency Lane Keeping (ELK) * CAUTION ● The vehicle is shifted into a forward gear; The ELK can detect lane markings, curbs and ● Always hold the steering wheel with both oncoming vehicles and rear overtaking vehicles ●...
Page 169 Driver assistance * Function status description When the ELK is enabled through MP5 and the When the activation conditions are met and the related system has no fault, the ELK status ELK function is activated, the lane markings on the activated side will change from green to blue, indicator lamp (green) comes on.
Page 170 Driver assistance * Function failure Factors of function limitations ● Marks or objects similar to lane markings on When the vehicle is driving normally, if the ELK The ELK may be affected or inoperative under the following conditions: roads; fault warning lamp (red) on the instrument ●...
Page 171 Driver assistance * Triggered Lane Change (TLC) * For TLC, the multi-lane triggered lane change CAUTION CAUTION function is added on the basis of ICA. When the turn signal lamp is turned on at a vehicle speed ● ● The TLC can assist the driver, aiming at When the vehicle is changing to the target higher than 60km/h, the vehicle will automatically improving the comfort and safety of...
Page 172 Driver assistance * Use of function Function status description CAUTION The TLC can be enabled and used by the If TLC is selected through MP5 and ICA is ● Dirty or covered sensors may restrict the following operations: activated, when the system has no fault and the detection.
Page 173 Driver assistance * Function failure Factors of function limitations Auto Lane Change (ALC) * When the vehicle is running normally, if the TLC Even if the TLC function is activated and For ALC, the function of automatically judging working, the system may be affected or whether lane changes are allowed in the left lane fault warning lamp (red) on the instrument...
Page 174 Driver assistance * Function activation conditions CAUTION CAUTION The ALC can be used only when the following ● Dirty or covered sensors may restrict the ● The vehicle will judge the quality of lane conditions are met: detection. Do not cover the detection area markings, including lane markings on the ●...
Page 175 Driver assistance * Use of function Function status description Function failure The ALC can be enabled and used by the If ALC is selected through MP5 and ICA is When the vehicle is running normally, if the ALC following operations: activated, when the system has no fault and the fault warning lamp (red) on the instrument...
Page 176 Driver assistance * Factors of function limitations Junction Assist (JA) * Enabling/disabling JA Even if the ALC function is activated and The JA monitors the driving environment in front Each time the ENGINE START/STOP button is set to “ON” position, the JA will remember the working, the system may be affected or of the vehicle in real time, and requests the inoperative under the following conditions:...
Page 177 Driver assistance * ● The vehicle speed is within the specified Use and state description of function Factors of function limitations range (5~30km/h for the ego vehicle, and When the ENGINE START/STOP button is set Even if the JA function is activated and working, 0~55km/h for oncoming vehicles);...
Page 178 Driver assistance * ● The camera performance will be affected and Emergency Steering Assist (ESA) * The ESA is an auxiliary function, and the vehicle degraded when the lighting conditions around is controlled by the driver during its activation the vehicle are poor (insufficient or too strong and control.
Page 179 Driver assistance * Function activation conditions CAUTION CAUTION The ESA can be used only when the following ● The driver should not completely rely on ● Even if there is a risk of collision ahead conditions are met: ESA, intentionally test and other activation conditions of the ESA ●...
Page 180 Driver assistance * Function failure Front crossing traffic alert (FCTA)* Function activation conditions When ESA is faulty, the ESA fault warning lamp The FCTA is used to monitor other front side The FCTA can be used only when the following road targets laterally approaching in real time conditions are met: will come on, and the instrument cluster will...
Page 181 Driver assistance * Function limitations LCW* CAUTION The FCTA function may be affected and have LCW cannot monitor the following types of false/neglected alarms under the following vehicles or objects: conditions: ● ● The front bumper is slightly covered with mud Scooters, bicycles, pedestrians, etc.
Page 182 Driver assistance * Function activation conditions CAUTION When the LCW function is triggered, the ● In strong sunlight, it may be difficult to see indicator lamp on the exterior rearview mirror on the indicator lamp on the exterior rearview the corresponding side lights up. mirror.
Page 183 Driver assistance * Function deactivation cases Function limitations During driving along the road boundary (such as metal guardrail, fence, isolation strip and grass), the system may have false/neglected alarms. Function failure If one or more of the millimeter wave radar sensors located inside the rear bumper work abnormally, the LCW function will fail and not work normally.
Page 184 Driver assistance * Rear crossing traffic alert (RCTA)* Function limitations Function limitations The RCTA is used for reminders with flashing The RCTA does not always achieve the best The system may not work properly if any of the indicator lamp on the exterior rearview mirror on effects for all parking spaces.
Page 185 Driver assistance * ● The target (vehicle, pedestrian, etc.) is Function failure stationary. When the RCTA function fails (for example, CAUTION ● Harsh environments such as rain and snow. faulty rear corner radar sensor), the BSD ● Sharp bends, slopes, excessively wide or indicator lamp (orange) goes on or the The DOW is only a driver assistance system,...
Page 186 Driver assistance * Deflation detection system (DDS) Initializing DDS When one or more of the four wheels have low For any operation that affects the tire pressure tire pressure, the corresponding wheel on the change, the tire pressure should be initialized via instrument cluster will flash in yellow signal, and the MP5.
Page 187 Driver assistance * Driver monitoring system* Face recognition When the vehicle power supply is switched to CAUTION ACC, after the system is started (about 7s), if the driver faces the camera for 2s, the instrument Wearing glasses may affect the fatigue “Face recognition cluster will...
Page 188 Driver assistance * Occupant Monitoring System (OMS)* Monitoring functions CAUTION Rear seat belt reminder Different children have unbalanced When the vehicle is running at a speed higher development. When a child is tall, MP5 may than 10km/h, if the system detects that the rear not issue a voice reminder.
Page 189 Driver assistance * Passenger calling monitoring Gesture recognition area: CAUTION During driving, if the system detects that the Please perform gesture operations in the ● Different people have different stature. No front passenger or rear passenger is making a specified area. Gestures beyond this area may call, MP5 will give a text pop-up window of “The reminder will be given if adults or taller not be identified.
Page 190 Parking assist There are two levels of alarm frequencies for the WARNING CAUTION side parking radar: ● If the driver does not notice conditions behind the Under no circumstances can the parking Distance to Sounding mode of Color of auxiliary vehicle before or during reversing, it may cause assist replace...
Page 191 Parking assist Cases where the parking radar cannot work Obstacles that may not be detected by the properly radar The parking radar may not work properly in the The radar may not detect obstacles below: following cases: 1. The sensor is frozen or damp (the sensor can work normally after...
Page 192 Parking assist Reverse camera * When the shift lever is moved to the “R” position, Cases where the camera cannot work Function description of auxiliary line the LCD touch screen will automatically display properly the image behind the vehicle. 1. The vehicle is running in a stormy or foggy This system can help the driver observe the day;...
Page 193 Parking assist Operation instructions of reverse camera Around view monitor (AVM)* CAUTION When being activated, the reverse camera This system can provide a 540° panoramic ● The width between two reversing auxiliary system is required to be initialized for some time, image that assists the driver in viewing the lines is larger than the actual vehicle during which the image shown on the display...
Page 194 Parking assist Panoramic camera Enabling/disabling AVM When the panoramic image is displayed through the “R” position and the left/right turn Arrangement of panoramic cameras signal lamp switch, if the vehicle speed is The body is provided with a wide-angle camera higher than 30m/h, the AVM will be disabled respectively in the front, rear, left and right for automatically and the MP5 image will be...
Page 195 Parking assist Switching 2D image Switching 2D/3D image Switching images When the vehicle passes through narrow roadways, narrow river embankments, etc., if “Forward touch narrow space"/"Backward narrow space” icon on the AVM interface, the images near front/rear wheels can be viewed. AVM settings When the AVM is displaying images, perform the When the AVM is displaying images, if you touch...
Page 196 Parking assist Parking assist lines In the panoramic image+2D image mode, when CAUTION the steering wheel is turned, the dynamic auxiliary lines (as shown in the panoramic Due to the blind spot in the field of view of the image+rear view above) will occur indicating the camera, the images near the front/rear general track of vehicle movement, and vary with bumper or near the four corners of the...
Page 197 Parking assist Fusion Automatic Parking Assist (FAPA)* WARNING Press the FAPA button in the shortcut menu bar on the touch screen of the MP5 ● The FAPA may not detect some special FAPA system to activate the FAPA, and perform obstacles, so the driver should confirm whether automatic parking according to the graphic and parking is suitable and safe.
Page 198 Parking assist Enabling conditions of FAPA Park-in operation ● The engine is started; 1. Start the engine, set the shift lever to “D” 3. Touch the parking space icon on the touch screen to select the required parking space; ● The ultrasonic sensor is free of fault; position, and press the FAPA button 4.
Page 199 Parking assist Prompt displayed on the touch screen of the Park-out operation CAUTION MP5 system: 1. Start the engine, and press the FAPA button system cannot accurately identify in the shortcut menu bar on the touch parking spaces in the following cases: screen of the MP5 system to activate the FAPA;...
Page 200 Parking assist ● If there is enough space in front of the CAUTION vehicle, the touch screen of the MP5 system will show “There is enough space in front. ● areas involving Bluetooth signal Please park out manually. FAPA is interference, the remote parking function deactivated”: may be abnormal or fail.
Page 201 Parking assist Remote park-in via key Parking cannot be resumed under the following 4. Press and hold the remote parking button 1. Start the engine, set the shift lever to “D” conditions: on the key until the hazard warning lamp ●...
Page 202 Parking assist 8. In the remote parking mode, the remote 5. In the remote parking mode, the remote Parking will be suspended under the following parking function can be deactivated by pressing parking function can be deactivated by pressing conditions: ●...
Page 203 Parking assist Parking cannot be resumed under the following FAPA fault reminder CAUTION conditions: ● ● The associated system is faulty; The system may be disturbed by weather such as rain, snow, hail, etc. Especially ● The gradient exceeds the specified limit; during driving on wet roads, the ultrasonic ●...
Page 204 Anti-theft system General description Body anti-theft function The IMMO system will not allow the engine to Function activation start when unregistered keys are used. If the end of the interior central locking system However, the engine may also fail to start with a switch is pressed and held for more than registered key when:...
Page 205 Refueling Refueling Opening/closing fuel filler cap Precautions for self-service refueling 1. The fuel tank might be under a certain internal CAUTION pressure. Therefore, turn the fuel filler cap counterclockwise for a short period for bleeding ● Stop the vehicle with the left side close to until the “hissing”...
Page 207 3. Emergencies Hazard warning lamp and reflective vest . 208 Operations ..........212 Inspecting and replacing fuse ....221 Hazard warning lamp ......208 Wheel replacement* ......... 213 Bulb replacement ........222 Reflective vest ........208 Precautions for replacing damaged wheel213 Jump starting ..........
Page 208 Hazard warning lamp and reflective vest Hazard warning lamp The hazard warning lamp should be turned on in Reflective vest the following conditions: 1. The vehicle breaks down due to any technical problem; 2. The vehicle is at the tail end of a traffic jam; 3.
Page 209 Warning triangle Using warning triangle Storage location of warning triangle Unfolding warning triangle: Distance from warning triangle to vehicle The warning triangle is stored on the trunk floor Ordinary 1. Unfold the four supports at the bottom; Expressway highway or under the trunk carpet. 2.
Page 210 Driver’s tools and spare wheel Driver’s tool* Driver's tools (conventional fuel-powered Spare wheel vehicles)* Storage location driver's tools (conventional fuel-powered vehicles)* The driver's tools are stored under the trunk floor, and are visible when the trunk floor is lifted. Driver's tools (HEVs)* Storage location of driver's tools (HEVs)* The spare wheel is stored in the storage area under the trunk floor.
Page 211 Emergency tire repair* Precautions Preparations If puncture is found, please read the following safety instructions safe correct Preparing to stop Tool preparation emergency tire repair. If you find that a tire is pinned or punctured by Wear gloves and take appropriate protecting foreign objects and the diameter of the puncture measures before operation to prevent injury.
Page 212 Emergency tire repair* Operations 3. After the tire sealer is added, close the red 1. Shake the tire sealer well before use, and 2. Align the connecting valve of the tire repair valve counterclockwise, screw remove the red valve safety cap on the top of the tool with the tire valve and tighten it, turn the red connecting valve, and remove the tire repair tool.
Page 213 Replacing damaged wheel* Precautions for replacing damaged wheel Preparations In case of burst, pierced, bulged or leaky tire, ● Place the jack on a solid and flat ground, please read the following safety instructions for and never place any pad above or below Preparing to stop safe and proper wheel replacement.
Page 214 Replacing damaged wheel* Stabilizing vehicle on a flat road Removing damaged wheel Before replacing a tire on a flat road, use chocks 3. Rotate the jack screw to hold down the body or other suitable blocks, rocks, etc. in front of jacking point via the jack head slot, without and behind the wheel diagonal with the jacking the vehicle up;...
Page 215 Replacing damaged wheel* Installing spare wheel CAUTION WARNING ● When the vehicle is in motion, the heat from the brake system makes the wheel ● It is forbidden to use the spare wheel that bolts go hot, so be careful to avoid has been damaged or worn to the wear scalding while removing the wheel bolts.
Page 216 Replacing damaged wheel* 4. Tighten the wheel fixing bolts clockwise with CAUTION the wheel removal & refitting wrench without using any other tool such as a hammer or a ● Do not forget to take back the warning socket, and make sure the wrench is fully seated triangle after replacement of wheel.
Page 217 Replacing fuse Capacity Fuse function Type Engine compartment fuse box* Fuse instructions (for HEVs) Left front door window MINI Capacity Fuse function Type regulator Engine compartment fuse box (for HEVs) Left front low beam MINI Four-way adjustable MINI front passenger’s power Right front low beam MINI seat...
Page 218 Replacing fuse Reserved Engine compartment fuse (for Fuse instructions (for conventional fuel- Wiper main relay power MINI conventional fuel-powered vehicles) powered vehicles) supply Capacity Fuse function Type TCU cooling relay power MINI supply Reserved TCU power supply MINI Reserved A/C control panel power MINI IGN2 feedback input MINI...
Page 219 Replacing fuse Reserved Left rear door window Body fuse box MINI regulator power supply High beam relay power MINI supply Right rear door window MINI regulator power supply Starter relay coil power supply, compressor relay Left low beam MINI coil power supply, MINI...
Page 220 Replacing fuse MINI Terminal block fuse MINI Body fuse instructions Gateway power electric running MINI MINI Capacity Fuse function Type supply board T-Box, IVI, 12V power outlet ACC Anti-pinch module, left MINI MINI power supply power supply front door regulator MINI switch BCM,...
Page 221 Replacing fuse switch LED+, Inspecting and replacing fuse electronic shifter MINI If an electrical consumer in the vehicle stops power supply working, first check whether it is caused by a Door lock power supply MINI damaged fuse. It is possible to find out which Rearview mirror heater MINI fuse or fuses control the electrical consumer...
Page 222 Replacing bulb Replacing bulb Specifications for bulb Light Turn signal lamps, brake lamps and headlamps Name and model of lamp Qty. Power Bulb type color are important to driving safety. Check whether the lamps are in good condition every time Low beam: One on each 20.5W+8.5W...
Page 223 Jump starting Description of jump starting Avoiding accumulation of static electricity Description positive negative terminals on the battery If the engine cannot start due to over-discharge Highly flammable gas mixture is generated of the battery, it can be started by connecting the during charging the battery or jump starting, thus battery to that of another vehicle via the jumper make sure that neither you nor the battery...
Page 224 Jump starting Steps of jump starting Jump starting operation (Conventional vehicle) 5. Set the ENGINE START/STOP button to OFF position; 6. Open the engine hood, and remove the positive battery terminal trim cover; 7. Connect the red positive jumper cable by connecting positive terminal...
Page 225 Jump starting Jump starting operation (HEV): 6. Open the engine hood and remove the fuse box cover; 7. Connect the red positive jumper cable by connecting positive terminal inoperative battery to that of the other battery (① → ②). Connect it carefully so as to avoid short circuit;...
Page 226 Jump starting CAUTION ● In case of reversed polarity of positive ● When removing the jumper cable, turn on ● Be sure to connect the positive terminals and negative battery terminals during the blower or the rear windshield heater of (+) of the two batteries.
Page 227 Towing Precautions WARNING When the vehicle needs towing, always observe ● If the faulty vehicle cannot supply voltage, the local regulations. Improper towing method the brake lamp, turn signal lamp and will damage the vehicle. To ensure proper other lamps of the vehicle will not work. towing and to protect the vehicle against Never tow the vehicle in this case;...
Page 228 Towing Illustration of towing vehicle in wrong way Towing eye position Front towing eye of vehicle Alternatively, it is possible to fix both front wheels to the rescue vehicle and lay both rear WARNING wheels on the ground for towing. The following points should apply while towing the vehicle in Never tow the vehicle with the front wheels the above way:...
Page 229 Towing Towing trapped vehicle The towing eye should be used when a tire of the vehicle is trapped in sandy, snowy or muddy road and the vehicle cannot run out of the road. ● Only the towing eye in the vehicle can be used.
Page 231 4. Maintenance Maintenance instructions ......232 Exterior cleaning ........236 Scheduled maintenance ......260 Routine maintenance ........ 233 Interior cleaning ........238 Introduction to scheduled maintenance .. 260 Instruction for routine maintenance ..233 Selecting sunshade film* ....... 240 First maintenance scheduled maintenance item table ......
Page 232 Instructions for maintenance As the distance driven increases, the parts of the CAUTION CAUTION vehicle will gradually wear out and the technical condition will deteriorate. It is required to perform ● Please perform scheduled maintenance ● Never allow any spark or flame to be maintenance to the vehicle when it is in service to your vehicle according to the List of close to any part of fuel system and the...
Page 233 Routine maintenance Instruction for routine maintenance Precautions for routine maintenance Exterior routine maintenance items Routine maintenance, including the items that The driver should take care and follow safety Every day before normal driving, it is required to have to be checked every day before normal practices while performing routine maintenance carry out routine maintenance according to the driving, is imperative for the continuous normal...
Page 234 Routine maintenance Lamps A/C air inlet Interior routine maintenance items Clean the front and rear headlamps regularly. Regularly remove leaves, petals, pollens and Brake pedal Check that the brake lamps, turn signal lamps, other debris from the vent trim panel. Remove Check whether the brake pedal works normally, headlamps and other lighting equipment function snow from the vent trim panel in time, especially...
Page 235 Routine maintenance Warning lamp, indicator and buzzer Other routine maintenance items Ensure that all warning lamps, indicators and Engine oil Windshield wiper buzzers can work normally. See “Inspecting and changing engine oil” in this See “Cleaning wiper blade” and “Replacing Windshield defogger chapter for details about inspecting engine oil.
Page 236 Routine maintenance Exterior cleaning ● Waxing When to wash the vehicle CAUTION Please clean the vehicle to protect the body Frequent waxing can protect the paintwork, and ● The seams, doors, windows and engine paint in the following cases: keep the vehicle nice. hood, etc.
Page 237 Routine maintenance ● Washing exterior of window ● Washing chrome-plated parts CAUTION While removing dirt from the windshield with the Regularly wash the chrome-plated parts with Operate as follows in order to avoid staining windshield washer, spray windshield washer non-abrasive chrome polishing agent to keep and fading the rims: fluid onto the glass surface and then wipe the them bright.
Page 238 Routine maintenance While washing the vehicle using an automatic Interior cleaning WARNING vehicle washer, make sure the vehicle meets the Remove dust and dirt from the vehicle interior following conditions: Do not use fuel, turpentine, engine oil, nail (such as interior trims, plastic components and ●...
Page 239 Routine maintenance Wiping interior of windows Leather seat cover CAUTION When wiping the interior of windows, please do Leather seat cover has high quality, and can ● Without any recommendation of the not use the tools with blade or chlorinated keep good performance if being maintained manufacturer, never...
Page 240 Routine maintenance Selecting sunshade film* Vehicle corrosion protection Frequently wash and wax the vehicle to keep it CAUTION clean. The anti-freezing agent and snow-melting agent sprayed on roads are corrosive, hence the Don't pay too much attention to sun underbody should be rinsed immediately after protection, heat insulation and privacy.
Page 241 Routine maintenance Engine hood Unlocking the engine hood Locking the engine hood 1. Check that there is no foreign matter in the engine compartment; 2. Hold the engine hood stably and push it upward slightly with one hand. Then detach the stay bar from the support hole with the other hand and clamp it into the mounting point;...
Page 242 Routine maintenance Operation instructions routine maintenance Engine compartment layout (Conventional vehicle) ① Windshield washer fluid reservoir filler cap ② Engine coolant reservoir filler cap ③ Engine oil filler cap ④ Engine oil dipstick ⑤ Brake fluid reservoir filler cap ⑥ Engine compartment fuse box ⑦...
Page 243 Routine maintenance Engine compartment layout (HEV) ① Windshield washer fluid reservoir filler cap ② Engine coolant reservoir filler cap ③ Engine oil filler cap ④ Engine oil dipstick ⑤ Brake fluid reservoir filler cap ⑥ Engine compartment fuse box ⑦Coolant reservoir filler cap of hybrid system ⑧...
Page 244 Routine maintenance ● Do not unlock the engine hood while Safety instructions for operation in engine Inspecting and adding engine coolant compartment driving; an unlocked engine hood may The coolant can play the role of corrosion, open while the vehicle is in motion, Operating to the engine or in the engine cavitation, leakage, radiator boil, scaling and obscuring the driver's view and causing a...
Page 245 Routine maintenance Inspect the coolant level. If it is found that a Changing engine coolant Recommended SAE viscosity for engine oil small amount of coolant is consumed, open the The engine coolant shall be changed regularly coolant reservoir filler cap ①, and add coolant to according to the provisions of the “First the level near the MAX scale.
Page 246 Routine maintenance Adding engine oil WARNING 1. Park the vehicle on the flat and solid ground; Engine oil is a highly flammable substance. 2. Open the engine hood. Be careful when adding the oil. Do not spill oil 3. Place a rag around the filler to prevent oil from on the engine parts or exhaust system dripping onto the engine;...
Page 247 Routine maintenance Inspecting and adding brake fluid NOTE CAUTION Brake fluid is used to transfer pressure in the ● The color of the new engine oil will ● After the engine oil pressure warning hydraulic brake system. change very quickly after the engine is lamp comes on, continuous driving will If the brake pedal travel is unexpectedly long or running for a period of time.
Page 248 Routine maintenance Inspecting brake fluid level Adding brake fluid Changing brake fluid If the brake fluid level is below MIN, the brake To ensure proper operation of the brake system, fluid must be added in time. change the brake fluid regularly according to the “First maintenance and scheduled maintenance WARNING item table”...
Page 249 Routine maintenance Inspecting battery Battery operation warning symbols and Inspecting battery WARNING description 1. Inspect if the battery is well fixed; ● Never allow sparky substances, flame or 2. Inspect if the positive and negative cable Open fires, sparks, glare spark to be close to the battery.
Page 250 Routine maintenance Charging battery Protection in winter Replacing battery If the vehicle is out of service for a long time, or As the starting power provided by the battery at Be sure to read and follow the safety warning is frequently started, or is often driven for a short low temperatures is lower than that at normal instructions for battery operation before starting distance in a cold environment, the battery may...
Page 251 Routine maintenance Adding windshield washer fluid CAUTION ● The battery shall be replaced with one of CAUTION the same manufacturer and model at the ● In winter, to avoid freeze, select some authorized dealer. ● Only replace with the battery of the same antifreeze windshield washer fluid.
Page 252 Routine maintenance Cleaning wiper blade Replacing wiper blade Any contamination of either the windshield or the The wiper blade must be inspected regularly and CAUTION wiper blade will reduce the wiping effect of the the damaged wiper blade replaced in time, wiper.
Page 253 Routine maintenance Vertical folding method of front windshield Replacement method of front windshield wiper arm wiper blade In the event of replacement of the wiper blade, cold weather, etc., it is necessary to vertically Drawn fold the front wiper arm by doing the following: 1.
Page 254 Routine maintenance Replacement method of rear windshield wiper blade 4. Replace with a new wiper blade; 6. Rotate the wiper blade clockwise so that 1. Lift the wiper arm away from the windshield. bosses ○ Place a thick towel at the lower part of the wiper on both ends are refitted into the 5.
Page 255 Routine maintenance Visual inspection of wheels and tires Four tires shall be inspected before driving, and Regularly inspect the tread depth and tread Inspect if all wheels are equipped with valve the tread and sidewall shall be inspected condition along the entire tire width. A low tread caps and inspect the valve for dirt and air leaks.
Page 256 Routine maintenance Inspecting tire pressure Tire information label General description Proper tire pressure can extend the service life of the tire while improving the driving comfort, fuel economy and operating stability of the vehicle. A low tire pressure will aggravate the tire wear, greatly affect the operating stability and fuel economy of the vehicle, and increase the risk of tire failure.
Page 257 Routine maintenance Inspecting wheel dynamic balance WARNING The dynamic unbalance of vehicle will cause that If the tire pressure is obviously insufficient, the wheels sway, the tires are worn improperly, and the vehicle continues to run at a high and the driving stability is affected. Therefore, speed, the tire will continue to be deformed, you should inspect the wheel balance regularly which will easily lead to overheating of the...
Page 258 Routine maintenance Replacing tires Winter tire WARNING Replace with a new tire if any of the followings It is recommended to use winter tires of the ● Do not use old tires of unknown origin as occurs: same size as the original tires, and all four they have no visible damage, but they wheels must be replaced.
Page 259 Do not install tire chains that are not approved puncture is not common in normal driving and severely scratched, replace it. If the tire leaks by Dongfeng Passenger Vehicle Company. even rarer if the tires are properly maintained. due to rim damage, the rim shall also be...
Page 260 Introduction to scheduled maintenance In order to keep the vehicle in good condition and prolong its service life, Dongfeng Motor Corporation will provide a free maintenance (pay for the oil, oil filter material and corresponding man-hours in the free maintenance) during the vehicle warranty period.
Page 261 Scheduled maintenance First Maintenance items Maintenance category Scheduled maintenance maintenance Mileage (×1,000km) 12.5 27.5 42.5 57.5 72.5 87.5 Every 7,500km or 6 months (whichever comes first) Operating time (months) Tension and condition of accessory drive belt ★ Brake fluid (level, leakage) Power steering function and condition of pipeline joints Windshield washer fluid, and working condition of washer pump and wipers...
Page 262 Scheduled maintenance First Maintenance items Maintenance category Scheduled maintenance maintenance Mileage (×1,000km) 12.5 27.5 42.5 57.5 72.5 87.5 Every 7,500km or 6 months (whichever comes first) Operating time (months) Front and rear brakes and related components (tightening, wear, aging or oil leakage) Vacuum air intake pipe, brake pipe (connection, wear, fixing, leakage, aging) Exhaust system line...
Page 263 Long-term operation in areas where the temperature is often above 30° C or often below -15° C, and in dusty areas. ● Please use genuine engine coolant of Dongfeng Motor Corporation to avoid internal corrosion of engine cooling system due to use of improper engine coolant.
Page 264 Recycling & environmental protection Plastics and rubber Scrapped or damaged parts Discarded traction battery Plastics and rubber parts are marked in Scrapped or damaged parts cannot be discarded When the traction battery needs to be repaired accordance with the current regulations. casually.
Page 265 5. MP5 system* Precautions ..........266 CarCenter ..........269 Safety precautions ......... 266 Bluetooth phone ........273 Problems that may be encountered ..267 Video ............ 274 MP5 system ..........268 Image ........... 274 Turning on/off system ......268 System settings ........275 A/C/seat control* ........
Page 266 Precautions ● Charging mobile phones via USB interface is ● For complex road conditions, use the system Safety precautions not recommended for the system, otherwise as appropriate so as not to affect its ● Read this manual and the related materials the following problems may occur: performance.
Page 267 Problems that may be encountered If you doubt some functions of MP5 system fail, please read carefully the instructions in the chapter about MP5 and navigation of this manual, and do inspection against the table below before repair, which contributes to troubleshooting. Symptom Possible causes and solutions Remove the host from the instrument panel, and check the fuses and connectors of the host...
Page 268 A/V system Activating or deactivating system A/C/seat control* Top status bar Click the “ ” icon in the bottom menu bar to Generally, a row of icons are displayed at the top open the A/C/seat control interface: right screen, showing status information of other function icons.
Page 269 A/V system ⑨ Temperature down button Music CarCenter Click the “Music” icon in all menus or bottom ⑩ Front windshield defogger/air outlet mode Click the “ ” icon in the bottom menu bar to menu bar to open the multimedia-local music open the CarCenter interface: ⑪...
Page 270 A/V system Body setting Window and roof setting In the body setting interface, you can set the “DL and key”, “Window and roof”, “Wiper and mirror”, “Interior “Exterior lighting”, lighting” “Convenient”. DL and key setting ● In the CarCenter interface, you can view and set the body setting, driving assistance, ●...
Page 271 A/V system Interior lighting setting Exterior lighting setting Convenient setting I● In the body setting - interior lighting interface, click the slider on the right side of “Interior mood lamp” and “Dome lamp automatic lighting” enable disable corresponding function. When the mood lamp function is set ON, the brightness and color of the mood lamp can be adjusted.
Page 272 A/V system Driving assistance* setting Driving fun* setting Vehicle condition viewing In the driving assistance interface, you can set The intelligent driving fun function can be the driving assistance functions such as “LKA”, enabled or disabled in the driving fun interface. “FWA”, “Rear side warning assist”...
Page 273 A/V system Bluetooth phone Dialpad Click the “ ” icon in the bottom menu bar or the “Call” icon in the App menu bar to open the ● In the main interface of Bluetooth call, click Before use a Bluetooth phone, please ensure that the Bluetooth function of the system and call interface.
Page 274 A/V system Video Picture ● Drag the progress bar left and right or slide Before playing video, please make sure the USB Before playing picture, please make sure the device is correctly connected. the screen left and right to control the video USB device is correctly connected.
Page 275 A/V system System settings Bluetooth connection settings Network settings Touch the “System settings” entry in the shortcut After entering the system settings interface, After entering the system settings interface, menu interface or the “System settings” icon in touch “Bluetooth” to enter the Bluetooth function touch “Network”...
Page 276 A/V system Display settings Sound settings System function viewing and setting After entering the system settings interface, After accessing the system settings interface, After entering the system settings interface, touch “Display” to enter the display function click “Sound” to access the sound settings Touch “System”...
Page 277 6. Technical parameters Vehicle identification ........ 278 Traction battery serial number* ....282 VIN and manufacturer’s plate....278 Safety warning label ......282 Event data recorder (EDR) ....279 Main parameters of vehicle ...... 284 DLC ............281 Technical parameters of vehicle .... 284 Microwave window ........
Page 278 Vehicle identification VIN and manufacturer’s plate The VIN is the vehicle's unique identification number, which is pasted or marked in the front and rear of the vehicle as shown in the left figure (only the VIN on the vehicle): ● The VIN ○ is located at the top left of the instrument panel and is visible through the front windshield.
Page 279 EDR. ● Model of EDR data reading equipment: Dongfeng X431-PR04 diagnostic scan tool. ● Availability of data reading of event data recorder (EDR): the EDR data extraction tool is provided by the suppliers specified by the competent department, and can be purchased from franchise stores or suppliers.
Page 280 Vehicle identification It refers to the RPM of the engine main crankshaft (not recorded for battery electric vehicles and plug-in Revolutions per minute (RPM) hybrid electric vehicles). The number of power cycles from the first use of the ECU that records the EDR data to the ECU that Power-on cycle during event records the EDR data when the event occurs.
Page 281 The unique engine serial number is engraved on diagnostic scan tool as follows: connect the the cylinder block of each engine. DLC, turn on the diagnostic scan tool, first click the Dongfeng diagnostic software to select the corresponding model, and then enter the EMS/BCM, etc.
Page 282 Vehicle identification Motor serial number * Traction battery serial number Safety warning sign Coolant sign Each motor has a unique serial number engraved on the housing. The coolant label is pasted on the upper side of the coolant reservoir. The traction battery serial number is pasted on the upper surface of the traction battery, which can be seen only after the traction battery cover is removed.
Page 283 Vehicle identification Oil and refrigerant sign Fan safety warning sign High-voltage component warning label Warning labels are pasted on high-voltage components such as MCU and traction battery. WARNING The engine oil and A/C refrigerant sign is pasted The fan safety warning sign is pasted on the on the right of the inside front edge of engine right side of fan upper guard plate.
Page 284 Main parameters of vehicle Technical parameters of vehicle Model series Haoji Vehicle model DFM6470M5D1 DFM6470M5D2 DFM6470M5F1HEV Curb weight (kg) 1608 1608 1697 Max. allowable gross weight (kg) 2009 2009 2093 Front axle load under curb weight (kg) Rear axle load under curb weight (kg) Front axle load at full load (kg) 1067 1067...
Page 285 Main parameters of vehicle Model series Haoji Vehicle model DFM6470M5D1 DFM6470M5D2 DFM6470M5F1HEV Permanent magnet synchronous Type of motor motor Rated working voltage (V) Rated power (kW) Peak power (kW) Drive motor 12500 (under load); 14000 Speed range (rpm) (under no load) Rated speed (rpm) 3600 Rated torque (N·...
Page 286 Main parameters of vehicle Model series Haoji Requirements for wheel dynamic balance Vehicle model DFM6470M5D1 DFM6470M5D2 DFM6470M5F1HEV Aluminum Wheel type Steel wheel Front overhang (mm) wheel Rear overhang (mm) Wheel Inner rim ≤ 15g imbalance Minimum ground clearance (mm) Outer rim ≤ 25g (Main tire) (full load) Approach angle/departure angle...
Page 287 Overall dimensions Dimensions: mm NOTE: ● Exterior rearview mirrors and antennas are not included in the overall dimensions of the vehicle. - 287 -...
Page 288 Specifications and capacity of main fluids The fluids capacities given in the table below are approximate values and may be a little different in actual use. See chapter “Inspection and Maintenance” for filling amount of various fluids. Capacity Fluid Type Grade DFM6470M5D1 DFM6470M5D2...
Page 289 Specifications and capacity of main fluids Recommenced fuel type Recommended engine oil type A/C system refrigerant Refrigerant of R134a is applied to the A/C system of this vehicle. Other refrigerants, if applied, may result in the replacement of whole A/C system. It is prohibited to drain the refrigerant of R134a used for this vehicle directly to the air, even though it has no damage to the ozone layer.

DongFeng Haoji Manual

Quick Links

Need help?

Questions and answers

Related Manuals for DongFeng Haoji

Summary of Contents for DongFeng Haoji
