Power Pruner
Operator's Manual
MODEL:
Read rules for safe operation and instructions carefully. ECHO provides an Operator's
Manual and a Safety Manual. Both must be read and understood for proper and safe
operation.
X7502096000
TM
PPT-260
Serial Number 03001001 - 03999999
WARNING
P
P
OWER
O
'
PERATOR
S
DANGER
TM
RUNER
1
M
ANUAL
X750002130
08/00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPT-260 - 08-00 and is the answer not in the manual?

Questions and answers

Related Manuals for Echo PPT-260 - 08-00

Summary of Contents for Echo PPT-260 - 08-00

  • Page 1 MODEL: PPT-260 Serial Number 03001001 - 03999999 WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X750002130 X7502096000 08/00...

  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operating tips and SAFETY messages.

  • Page 3: Manual Safety Symbols And Important Information

    Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.

  • Page 4: International Symbols

    Read and comply with all safety instructions listed in this manual. • ECHO, INC. will not be responsible for the failure of cutting devices or accessories which have not been tested and approved by ECHO for use with this unit.

  • Page 5: Fuel

    • Check that the cutting attachment, guide bar and saw chain is firmly attached and in safe operating condition. • Only use ECHO approved guide bar and saw chain. • Only use one ECHO approved extension on the pruner. • Do not hit rocks, stones, tree stumps and other foreign objects with the saw chain.

  • Page 6: Personal Condition And Safety Equipment

    Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection -- ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing -- Wear snug fitting, durable protective clothing; chain saw safety pants or chaps are recommended.

  • Page 7: Safe Operation

    OWER RUNER PERATOR ANUAL SAFE OPERATION WARNING DANGER All over head electrical conductors and communications wires can have electricity flow with high voltages. Never touch wires directly or indirectly when pruning, otherwise serious injury or death may result. Determine Operation Area •...

  • Page 8: Kickback

    Keep A Firm Grip • Grip Power Pruner with both hands with thumbs and fingers encircling the handle, and lower shaft tube. Keep A Solid Stance • Maintain footing and balance at all times. Do not stand on slippery, uneven or unstable surfaces. Do not work in odd positions or on ladders.

  • Page 9: Extended Operation/Extreme Conditions

    OWER RUNER PERATOR ANUAL EXTENDED OPERATION EXTREME CONDITIONS Vibration and Cold It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sensations followed by loss of color and numbness in the fingers.

  • Page 10: Description

    Due to packaging restriction the ECHO product you have purchased requires some assembly. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.
  • Page 11 OWER RUNER PERATOR ANUAL...
  • Page 12 POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Starter. THROTTLE TRIGGER - Spring loaded to return to idle when released. During acceleration press trigger gradually for best operating technique. SHOULDER HARNESS - An adjustable strap that suspends the unit from the operator. CUTTING ATTACHMENT - Sealed, gear ratio is 1.5:1 reduction.

  • Page 13: Specifications

    OWER RUNER PERATOR ANUAL PECIFICATIONS i t i i t i . l f ) " i l i ) "...

  • Page 14: Assembly

    SSEMBLY SHAFT TUBE POWER HEAD Tools Required: 10x19mm (13/32x3/4in) T-wrench, 8x10 mm Wrench, 4 mm Hex Wrench Parts Required: Power Head, Shaft Tube Assembly; Cutting Attach- ment Loosen bolt (A). Match square socket in engine shaft with square power transmis- sion shaft (B) and slide together until engine rests against the machine surface of lower shaft tube housing coupler (C).

  • Page 15: Throttle Linkage Installation

    Check throttle for freedom of movement and that wide open throttle / low idle extremes are adjusted properly. If adjustment cannot be achieved with adjusting nuts, consult with your Echo Dealer for correct adjustment procedure. Connect ignition stop leads (C) and (D).

  • Page 16: Saw Chain Tension Adjustment

    50:1 oil meets these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD and J.A.S.O. FC certified oil, such as Echo Premium 50:1 Two-stroke Oil, will void the two-stroke engine warranty. (Emission related parts only are covered for two years, regardless of two-stroke oil used, per the statement listed in the EPA Phase II Emission Defect Warranty Explanation.)
  • Page 17 RUNER PERATOR ANUAL IMPORTANT Echo Premium 2-Stroke Oil may be mixed at 50:1 ratio for applica- tion in all Echo engines sold in the past regardless of ratio specified in those manuals. Mixing Instructions Fill an approved fuel container with half of the required amount of gasoline.

  • Page 18: Lubricating The Guide Bar And Saw Chain

    IMPORTANT S M T Stored fuel ages. Do not mix more fuel than you expect to use in thirty (30) days, ninety (90) days when a fuel stabilizer is added. 8 9 10 11 12 13 14 IMPORTANT 15 16 17 18 19 20 21 Stored two-stroke fuel may separate.

  • Page 19: Equipment Check

    OWER RUNER PERATOR ANUAL EQUIPMENT CHECK Before operation a complete check of the unit must be performed; • Check unit for loose/missing nuts, bolts and screws. Tighten and/or replace as needed. • Inspect fuel lines, tank and area around carburetor for fuel leaks. DO NOT operate unit if leaks are found.

  • Page 20: Operation

    DANGER The cutting attachment should not move at idle. If cutting attach- ment moves, readjust carburetor according to "Carburetor Adjust- ment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. Stop Switch - Start/Run.

  • Page 21: Starting Warm Engine

    The cutting attachment should not move at idle. If cutting attach- ment moves, readjust carburetor according to "Carburetor Adjust- ment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. Stop Switch - Start/Run. Move Stop Switch button (A) forward away from the STOP position.

  • Page 22: Pruning Technics

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed see your ECHO Dealer for repairs.

  • Page 23: Maintenance Intervals

    OWER RUNER PERATOR ANUAL MAINTENANCE INTERVALS n i l t I - t l i t l i n i l l f f l i o s t l t n i ®...

  • Page 24: Air Filter

    AIR FILTER Level 1. Tools required: 25 or 50 mm (1 or 2 in.) medium bristle paint brush Parts required: 90030 REPOWER FILTER KIT Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumu- lated dirt from the air cleaner area.

  • Page 25: Spark Plug

    OWER RUNER PERATOR ANUAL WARNING DANGER Do not perform maintenance on the muffler until engine and muffler are completely cool, otherwise serious personal injury may occur. SPARK PLUG Level 2. Tools required: 10x19mm (13/32x3/4in) T-wrench, Feeler gauge, (preferably a wire gauge), Soft metal brush Parts Required: 90065 REPOWER Remove spark plug and check for fouling, worn and rounded center electrode.

  • Page 26: Exhaust System

    Remove spark plug lead. Remove two (2) muffler cover screws and muffler cover (A). Remove screw and arm rest (B). Remove engine cover (C). IMPORTANT DO NOT use a metal scraper to remove dirt from the cylinder fins. Use brush to remove dirt from the cylinder fins. Remove grass and leaves from the grid between the recoil starter and fuel tank.

  • Page 27: Carburetor Adjustment

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. CARBURETOR ADJUSTMENT...

  • Page 28: Guide Bar And Saw Chain Replacement

    NOTE Every unit is run at the factory and the carburetor is set in compli- ance with EPA Emission Regulations. This carburetor does not have acceleration and high speed adjustment needles. Check idle speed and reset if necessary. If a tachometer is avail- able, idle speed screw (A) should be set to the specifications found on page 13 "Specifications"...

  • Page 29: Filing Saw Chain

    OWER RUNER PERATOR ANUAL FILING SAW CHAIN Level 3. Tools required: 4.5 mm round File P/N 89751001130; Flat File P/N 89751100230; Depth Gauge P/N 89751400232. IMPORTANT Dull or damaged cutters will result in poor cutting performance, increased vibration and premature saw chain failure. WARNING DANGER Always stop engine and disconnect spark plug wire before...

  • Page 30: Troubleshooting

    ROUBLESHOOTING l f f t l i f t n I t l i f t l i f WARNING DANGER Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark near an open spark plug opening, otherwise serious personal injury may result.

  • Page 31: Storage

    OWER RUNER PERATOR ANUAL TORAGE WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage maintenance which...

  • Page 32: Servicing Information

    • Sending a check or money order for $2.00 per Parts Catalog or $1.50 per Operator's Manual made payable to ECHO, INCORPORATED. State on a sheet of paper the model number and serial number of the ECHO unit you have, part number of the manual (if known), your name and address and mail to address above.
