- Page 1 User’s Manual – A S Tool trolley 4 drawers red REBO Tool trolley 4 drawers red AR-HE-WW41R Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Safety Instructions
User’s Manual – A S Tool trolley 4 drawers red REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. -
Page 3: Technical Specifications
Have maintenance, adjustment and repair work carried out exclusively by a specialist or a specialist workshop. Technical Specifications Model AR-HE-WW41R Dimension without wheels 24.41 x 13 x 25.79 in (620 x 330 x 660 mm) Dimension with wheels 24.41 x 13 x 29.92 in (620 x 330 x 760 mm) 4x drawers 19.69 x 12.01 x 2.56 in (500 x 305 x 65 mm) -
Page 4: Items Supplied
User’s Manual – A S Tool trolley 4 drawers red REBO Layout and Use Layout 1. Tool trolley 2. Wheels 3. Handle 4. Locking switch Items supplied • Open the packaging and take out the equipment with care. • Remove the packaging material and any packaging and/or transportation braces (if available). - Page 5 User’s Manual – A S Tool trolley 4 drawers red REBO Assembly...
-
Page 6: Fitting The Handle
User’s Manual – A S Tool trolley 4 drawers red REBO • Important! To avoid malfunctions, please note that all the drawers must be COMPLETELY closed before you pull one out! Fitting the handle • Fit the handle (3) with the screws (a) as shown in Fig. 2. Fitting the wheels •... - Page 7 User’s Manual – A S Tool trolley 4 drawers red REBO Loosen the transport lock...
- Page 8 User’s Manual – A S Tool trolley 4 drawers red REBO...
-
Page 9: Cleaning And Maintenance
User’s Manual – A S Tool trolley 4 drawers red REBO Cleaning and Maintenance • Clean the tool trolley with a slightly damp cloth and if necessary a small amount of conventional paint cleaner. To avoid damaging the surfaces do not use solvents or other aggressive or scouring cleaning products. - Page 10 Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
