  • Page 1 POWER ATTACHMENTS COLD PLANER CP16A CP18A CP24A CP30A CP36A...
  • Page 2 TO THE DEALER: Assembly and proper installation of this product is the responsibility of the WainRoy dealer. Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists in the Operator’s Manual are completed before releasing equipment to the owner. The dealer must complete the online Product Registration form at the WainRoy Dealer Website which certifies that all Dealer Check List items have been completed.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........2 SPECIFICATIONS .

  • Page 4: Introduction

    SPECIFICATIONS CP16ATD CP18ATD CP20ATD CP24ATD CP30ATD CP36ATD Planing Width 16" 18" 20" 24" 30" 36" Planing Depth 0 - 6" 0 - 6" 0 - 6" 0 - 6" 0 - 6" 0 - 6" Hyd Horsepower 30 - 60 hp 30 - 60 hp 30 - 60 hp 30 - 60 hp...

  • Page 5: Safety Rules

    ◼ Make sure that all operating and service person- equipment for eyes, hair, hands, hearing, and head; nel know that if hydraulic fluid penetrates skin, it and respirator or filter mask where appropriate. Safety 5 Alitec CP (Rev.11/24/2023)
  • Page 6 ◼ Keep bystanders away from equipment. stop engine, remove key, and remove seat belt. ◼ Never direct discharge toward people, animals, ◼ NEVER GO UNDERNEATH EQUIPMENT. Never or property. place any part of the body underneath equipment 6 Safety Alitec CP (Rev.11/24/2023)
  • Page 7 ◼ Be sure attachment properly secured, adjusted, and in good operating condition. Coupler lockpins must be fully extended and properly engaged into attachment retaining slots. ◼ ❖ Safety 7 Alitec CP (Rev.11/24/2023)

  • Page 8: Safety And Instructional Decals

    SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Replace Immediately If Damaged! D0193 WARNING WainRoy Equipment Company ROTATING CUTTER Oregon, Illinois, U.S.A. Keep clear during operation. See Operator's Manual for maintenance precautions. D0193 D0195 DO209 WARNING FLYING OBJECT HAZARD Keep clear during operation.
  • Page 9 SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Replace Immediately If Damaged! 54519 WARNING FALLING OFF CAN RESULT IN BEING RUN OVER. ■ Skid steer must have ROPS and seat belt/operator restraint. Keep seat belt/operator restraint securely fastened. ■...

  • Page 10: Operation 11

    In addition, each individual working with the equip- Although the Alitec Attachment is supplied fully assem- ment should be familiar with the safety precau- bled, some simple checks should be performed before tions.
  • Page 11 As noted in the Alitec literature, the attachment requires a minimum hydraulic supply of 25 gallons per minute The drum rotation will stall when the load on the planer (90 liters per minute) at 2000psi.

  • Page 12: Maintenance

    Inspect machine and replace worn or damaged ing applications. For replacement of multi-purpose parts. picks always specify Alitec B1050S picks from your ● Replace any safety decals that are missing or not local dealer. If the planer is to be used specifically for readable.
  • Page 13 ● Inspect machine and replace worn or damaged ● Remove the remainder using a low-pressure water parts. spray. ● Sand down scratches and the edges of areas of 1. Be careful when spraying near scratched or torn missing paint and coat with WainRoy spray paint of safety decals or near edges of decals as water matching color (purchase from your WainRoy spray can peel decal off surface.

  • Page 14: Service

    SERVICE WARNING WARNING ■ ■ BEFORE SERVICING THIS UNIT, THE MANDA- Use extreme caution during this operation to TORY SAFETY SHUTDOWN PROCEDURE MUST prevent planetary from tipping and falling. BE COMPLETED. SEE "SAFETY" SECTION. DRUM REMOVAL PLANETARY REMOVAL 1. With the attachment resting on a hard, flat surface, 1.
  • Page 15 FULL WIDTH SIDESHIFT FRAME Motor Removal 1. Remove and cap the motor hoses (1) shown in Figure 1. Figure 3 3. Slide shaft towards the motor side of the attach frame until the bearing side coupler clears the bearing. 4. Remove two 1/2" bolts (2). Figure 1 2.
  • Page 16 3. Place the nut flange in a vice and use a pipe wrench to remove the nut from the flange. Figure 5 3. Slide couplers off the acme screw. Figure 6 4. Manually turn the acme screw to back it out of the bearing side of the sideshift frame.

  • Page 17: Dealer Check Lists

    DEALER CHECK LISTS PRE-DELIVERY CHECK LIST DELIVERY CHECK LIST (Dealer’s Responsibility) (Dealer’s Responsibility) Show customer how to make adjustments. Inspect the equipment thoroughly prior to delivery to ensure it is set up properly before delivering it to the Point out the safety decals. Explain their meaning customer.

  • Page 18: Trouble-Shooting

    TROUBLESHOOTING CHART PROBLEM POSSIBLE CAUSE SOLUTION Planer loses power Relief setting in auxiliary system Remove/clean, or replace sole- lower than standard 2400 psi noid cartridge or replace O-rings. Check reliefs in the following Loader circuit pump or auxiliary sequence- loader valve, standard auxiliary valve.
  • Page 19 PARTS INDEX Cold Planer for Single Circuit Valve "A" Series Skid Steer CPA SINGLE CIRCUIT PLANER ................20 CPA SINGLE CIRCUIT PLANER PARTS LIST ............21 SINGLE CIRCUIT HYDRAULIC VALVE ..............22 SINGLE CIRCUIT HYDRAULIC VALVE PARTS LIST ..........23 FULL WIDTH SIDESHIFT ..................
  • Page 20 CPA SINGLE CIRCUIT PLANER 20 Parts M-CPSS AS/C (Rev. 11/24/2023)
  • Page 21 H1398 Hose #4 x 22.5" 6SLF 90 x 6SLF 100709 Pin weld 1 x 8.31 SR 7.8 P0276 Drum weld, CP16A 50 holders H1229 Hose #4 x 27" 6FLF 90 x 6FLF R1 P0277 Drum weld, CP18A 56 holders H1601 Hose #4 x 28"...
  • Page 22 SINGLE CIRCUIT VALVE Effective with Serial Number CP24ATDS/C 39023301202 22 Parts M-CPSS AS/C (Rev. 11/24/2023)
  • Page 23 SINGLE CIRCUIT VALVE PARTS LIST PART DESCRIPTION PART DESCRIPTION HC412 otor, aton 35 ° itting, #8 OM X 6FLM 45 F1123 HC321 otor, undstrand ° F1306 itting, #12 OM X 12 FLM 45 only) (CP16-30ATD) 101053 ylinder, epth F1006 itting #12 OM X 12FLM ST ylinder, ideshif C2201...
  • Page 24 FULL WIDTH SIDESHIFT 5, 17 Detail B Scale 0.250 See Detail A 18, 5, 1 2, 5 5, 17 7, 8 3, 5 19, 7 Detail A See Detail B Scale 0.250 PART DESCRIPTION PART DESCRIPTION Bolt, 3/8 " NC x 1 GR5 ZP 106425 Screw, Bolt, 3/8...

  • Page 25: Electrical Schematic

    ELECTRICAL SCHEMATIC Parts 25 M-CPSS AS/C (Rev. 11/24/2023)
  • Page 26 FITTING TORQUE CHART Always tighten fittings to these values unless a different torque value is listed for a specific service procedure. Make sure fastener threads are clean and threads are engaged properly. All torque values are adopted from SAE J514 and SAE J1453. SAE (JIC) O-Ring Style 37°...

  • Page 27: Bolt Torque Chart

    BOLT TORQUE CHART Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware: SAE for SAE hardware and Metric for metric hardware. Make sure fastener threads are clean and you start thread engagement properly.

  • Page 28: Bolt Size Chart

    BOLT SIZE CHART NOTE: Chart shows bolt thread sizes and corresponding head (wrench) sizes for standard SAE and metric bolts. SAE Bolt Thread Sizes 5/16 Metric Bolt Thread Sizes 10MM 12MM 14MM 16MM 18MM ABBREVIATIONS AG ..............Agriculture MPa ............Mega Pascal ASABE .....
