- Page 1 Model: 53982, 53044...
- Page 2 INTRODUCTION Product information The UPS series includes an online uninterruptible sine wave power system with bypass function, which can provide reliable and high-quality AC power for precision equipment. It can be used in a wide range of applications, from computer equipment, communication systems to industrial automatic control equipment.
- Page 3 3. There is a risk of electric shock and a short circuit in the battery. To avoid injury from electric shock, observe the following warnings when replacing the battery: a. Do not wear watches, rings or similar metal objects. b. Use insulated tools. c.
-
Page 4: Specification
If there is any damage or missing parts, please do not use the product but notify the carrier and your dealer immediately. Please retain the original packaging materials for future use . SPECIFICATION Model 53982 53044 Capacity 6KVA/4800W 10KVA/8000W Input Low power At 50% load: 110VAC ±... - Page 5 Phase Single-phase earthing Power factor With full load ≥ 0.99 Output Output voltage 208 / 220 / 230 / 240 VAC AC voltage regulation ± 1 % 40Hz - 54Hz @ 50Hz system; 56Hz - 64Hz @ 60Hz Frequency range system Frequency range (battery 50 Hz ±...
-
Page 6: Installation And Configuration
Keep the original packaging in a safe place for future use. Rear panel Diagrams of the rear panel of each model are shown in the appendix in Figure 1 (53982 and 53044 respectively). A description of the individual panel components follows. 1. RS-232 communication port 5. - Page 7 Note 2: The colour of the wires must comply with the local electrical code. Remove the terminal cover on the rear panel of the UPS. Then connect the earth wire according to the diagram below: (When wiring, please connect the earth wire first; please leave the earth wire to the end when disconnecting the wires).
- Page 8 phase neutral wires correctly connected, interchanged or connected in a short circuit. Software installation: To fully protect your computer, install UPS monitoring software. Press-key Buttons Function On/Enter START: Press the button for more than 1 second to start the UPS. CONFIRM: Press to confirm in the settings menu.
- Page 9 Holding time Display icon - figure 6 Remaining holding time displayed as pie chart Display icon - figure 7 Remaining holding time digitally displayed H: Hours, M: Minutes, S: Seconds Information on errors Display icon - figure 8 Occurrence of an error or alarm Display icon - figure 9 Warning and fault codes, a detailed list of codes can be found in the fault code table...
- Page 10 Audible alarm Indication Alarm UPS status Bypass mode Calls every 2 minutes Battery mode Calls every 4 seconds Fault Continuous ringing Warning Overload It rings every 2 seconds Low battery charge Battery not connected Battery overloaded EPO Start It rings every second Fan failure / overheating Charger fault Input fuse interruption...
-
Page 11: Output Voltage
illustration 29 Conversion device illustration 30 illustration 31 Deduct illustration 32 illustration 33 illustration 34 Not allowed illustration 35 Permitted illustration 36 Reserve LCD display settings This UPS system allows the setting of the three parameters indicated in Figure 37: Parameter 1: This is the programme option code. -
Page 12: Output Frequency
illustration Parameter 3: Output voltage setting 200VAC indicates that the output voltage is 200VAC. 208VAC indicates that the output voltage is 208VAC. 220VAC indicates that the output voltage is 220VAC. 230VAC indicates that the output voltage is 230VAC. 240VAC indicates that the output voltage is 240VAC. 02: Output frequency Display Settings... - Page 13 set. The setting range is 110 to 209V, the default value is 110V. Parameter 3: Bypass mode allows the maximum voltage value to be set. The setting range is 231 to 276V, the default value is 264V. 04: Bypass frequency range Display Settings image...
- Page 14 value is 990 minutes. DIS: Disable the battery discharge protection function, the back- up time depends on the battery capacity. 13: Battery voltage calibration Display Settings image illustration Parameter 2: Select <ADD> or <SUB> to adjust the battery voltage. Parameter 3: The voltage adjustment range is 0V to 5.7V, the default value is 0V.
- Page 15 100Ah. The default value is 9Ah. Parameter 3: Set the battery group value from 1 to 6. The default value is 1; this parameter is used to calculate the battery discharge time. 20: Calibration of discharge time Display image Settings illustration 49 Parameter 3: This setting calibrates the discharge time displayed on the screen, by adjusting the multiplication...
- Page 16 Display illustration 53 image Self- Descriptio When the UPS is in AC mode or CVCF mode, press the "TEST" inspection button for more than 1 second and the UPS will switch to of batteries battery self-inspection mode. The buzzer will sound once and the connection cable will start flashing between the I/P icon and the inverter to signal the user.
-
Page 17: Problem Solving
Battery overcharged illustration Beep every second Battery voltage too low illustration Beep every second Reloading illustration Beep every second EPO start illustration Beep every second Fan failure / overheating illustration Beep every second Charger error illustration Beep every second Overload occurs 3 times in 30 illustration Beep every second minutes... -
Page 18: Storage And Handling
code symbol due to an overload at the UPS from the UPS output and figure 13 is on, and at the output. restart it. same time the alarm sounds continuously. The LCD panel displays error shut down Please check if there is a code symbol automatically due to a short... - Page 19 ATTACHMENT...
