- Page 1 Espace Eiffel - Lot D6 19-21, Avenue Gustave Eiffel 28630 Gellainville - FRANCE +33 2 37 33 37 10 contact@vartools.com PR-88100 ELECTRIC REPAIR STAND SINGLE CLAMP ELECTRIC REPAIR STAND DOUBLE CLAMP PR-88200 PR-88100 PR-88200 MADE IN FRANCE...
-
Page 2: Table Of Contents
SUMMARY Abstract Introduction I. GENERAL INFORMATION 1. Identification 2. Foreword II. PRESENTATION 1. Technical specifications 2. Repair Stand description III. INSTALLATION 1. Work environment 2. Handling operation 3. Assembly 4. Power Supply 5. Single to double repair stand transformation IV. OPERATING PROCEDURE 1. -
Page 3: Abstract
The user should read this manual carefully before use. Introduction Now you are an owner of the new generation VAR electric repair stand. You can work faster, safier and with more efficiency and ergonomy than you need on all types of bikes. -
Page 4: General Information
- Risks of destruction of the equipment or other property of the user. - Obstruction of efficient work by the equipment or operator. VAR company shall not be held responsible in case of incidents or accidents attributable or resulting from the use of the equipment under the following conditions: - Disabling safety devices. - Page 5 The safety devices must be regularly checked for their effectiveness to preserve the operator and the machine from any accidents. It is strictly prohibited to dismantle the safety guards. VAR company shall not be held responsible in case of non-compliance with instructions.
-
Page 6: Presentation
230V~ 50Hz +/- 10% Noise (average / maximum) < 50 dB / < 70 dB Torsion-resistant steel plate to be removed for conversion of a single PR-88100 stand to a double PR-88200 stand Manufactured from folded steel sheet Epoxy paint... -
Page 7: Repair Stand Description
They are intended for businesses with a high demand for assembly and repair of various types of bikes. - The PR-88100 single stand can be converted into a double stand PR-88200 using the secondary column PR-88150. - Page 8 Column frame Mechanically welded structure ensuring the guidance of the clamping arm Guided by a pad on a sheet metal profile Single base plate supporting a single column or two columns PR-72000 clamp attachment system with interior sensor obstacle detection safety. Clamp rotation tightening allowing bike orientation for the desired operations.
-
Page 9: Installation
III. INSTALLATION 1. Work environment Our electric repair stands are not intended to be used in environments with explosion or chemical hazards. The area where the electric repair stand is installed must be equipped with an electrical power source. The ambient temperature must be between +5°C and +40°C. The machine’s support surface must be flat, stable, and free from vibrations. -
Page 10: Assembly
3. Assembly The assembly must be carried out by working people with appropriate qualifications. During lifting operations, no person should be close to the load. Respect the recommended work area and safety distances to install the machine. During assembly operations, the wearing of gloves and safety shoes is mandatory. -
Page 11: Power Supply
4. Power Supply Make sure that the power supply is disconnected and cannot be accidentally restored. Ensure compatibility of the electrical network with the voltage supply of the electric repair stand. Ensure compliance of the electrical installation and protections. It is IMPERATIVE to use an electrical socket with a 30 mA differential or equivalent for the connection of the electric repair stand. -
Page 12: Single To Double Repair Stand Transformation
5. Single to double repair stand transformation This operation is only necessary in case of delivery of the secondary column PR-88150 separately from the main column, when converting a single-column repair stand PR-88100 to a double-column repair stand PR-88200. The pairing operation requires a 4 mm hex key, an 8 mm hex key, and a 7 mm open-end wrench (or a 6 mm hex socket). -
Page 13: Operating Procedure
IV. OPERATING PROCEDURE 1. Commissioning THE COMMISSIONING OF AN ELECTRIC REPAIR STAND MAY REQUIRE TWO OPERATORS. - Remove the protective packaging from the repair stand. - Remove the four holding screws of the repair stand from its transportation pallet. - Lower the repair stand from its transportation pallet and place it in its intended location. - Using the necessary tools, anchor the repair stand to the ground. -
Page 14: Operation
2. Operation The electric repair stand’s up and down system is controlled by the remote control located on the right side of each column. The up button allows you to go up to the high position of the column. The down button allows you to go down to the low position of the column. If an obstacle is detected under the load or the load touches the ground, then the system will stop descending. -
Page 15: Fault Managment
V. FAULT MANAGMENT 1. Defaut list ISSUE POSSIBLE CAUSE Descent blockage Slider safety crushing sensor not Check that the clamping engaged arm is in its lowest possible position. Positioning of the slider Using too heavy load Depending on the load being lifted, the slider may have a more or less significant inclination, but the system... -
Page 16: Maintenance
Lubrication of the column at every 6 months the carriage guide if visually necessary. The use of lubricants or penetrating oil such as ‘WD40’ is strictly prohibited. The use of lithium grease VAR NL-76500 is perfectly suitable. 2. Preventive maintenance MAINTENANCE FREQUENCY CHAPTER... -
Page 17: Stainless Steel Guides Lubrication
3. Stainless steel guides lubrication Cut off the column power With a 4 mm hex wrench, With a 4 mm hex wrench, supply and wait 15 minutes. remove the lower fastening remove the upper fastening screws from the lateral screw from the lateral casing. casing. -
Page 18: Safety Devices Operation Check
4. Safety devices operation check The safety devices operation check has to be performed every six month and recorded in the maintenance log. 3 sensors (per column) ensure the safe operation of your electric repair stand : - Highest position limit sensor. - Lowest position limit sensor. -
Page 19: Maintenance Log
5. Maintenance log DATE COLUMN NR MAINTENANCE PERFORMED OPERATION SIGNATURE MADE IN FRANCE... -
Page 20: Components
6. Components Professional lifting clamp PR-72000 : Reinforced fiberglass nylon handle for VAR professional clamp PR-89944 : Spring and steel parts for the professional clamp, PR-88105 MADE IN FRANCE... -
Page 21: Accessories
7. Accessories Tool tray for electric repair stand PR-88301 : Computer holder for electric repair stand PR-88311 : MADE IN FRANCE... -
Page 22: Declaration Of Conformity
VII. DECLARATION OF CONFORMITY We, VAR TOOLS, declare under our responsibility that the following machines, references and designations: - PR-88100, Single Electric Repair Stand - PR-88200, Double Electric Repair Stand - PR-88150, Single Conversion Column Comply with the essential requirements of the following CE and NF directives :...
