Summary of Contents for Porsche Cayman 2009

  • Page 1 ® Service Information 2009 Technik Introduction All Boxster Cayman Models...
  • Page 2 Important Notice: Some of the contents of this AfterSales Training brochure was originally written by Porsche AG for its rest-of- world English speaking market. The electronic text and graphic files were then imported by Porsche Cars N.A, Inc. and edited for content.
  • Page 3 Since its North American launch in 1997, “Boxster” has quickly become synony- mous with the ultimate in roadster feeling. Together with the Cayman launched in 2006, it is successfully continuing the Porsche tradition of roadsters and coupés that started over 50 years ago with the legendary 356 and 550 Spyder models.
  • Page 4 You can also learn all the details about the completely new Porsche Doppelkupplung (PDK) with 7 gears, redesigned Porsche Communication Management (PCM) and air-conditioned seats, which are now also available to offer superior driving comfort for the Boxster S and Cayman S.

  • Page 5: Table Of Contents

    High-pressure fuel system Ignition system Air routing on intake side Exhaust system, emission control 2.9-liter engine with MPI DME control unit ME 7.8.2 Intake system Fuel injectors EV14 Exhaust system 3 Porsche Doppelkupplung PDK) General information Transmission data Transmission Transmission oils...
  • Page 6 Boxster Boxster S Cayman Cayman S 3 Porsche Doppelkupplung PDK) Cont’d) Transmission concept Transmission Operation 3-spoke sports steering wheel for PDK Gearshift strategy Special functions Basic transmission Synchronization Final drive with differential Shifting Parking lock Power flow Double clutch Hydraulic control...
  • Page 7 Electrics and electronics Bi-Xenon, headlight Speed and swivel angle Tail lights Instruments, instrument cluster Shift indicator Audio and communication, CDR-30 Porsche Communication Management Touchscreen and operating logic Operating principles of PCM Audio Navigation module Electronic logbook Telephone module Mobile phone preparation...

  • Page 9: Engine

    Boxster 1 Engine Boxster S Cayman Cayman S General information All new Boxster and Cayman models, as with the new 911, use a completely new generation of engines with significantly higher performance figures. The displacement Engine of the completely new flat engine has been increased from 2.7 liters to 2.9 liters to achieve an increase in power output of 10 bhp to 225 bhp (188 kW) for the Boxster and 20 bhp to 265 bhp (195 kW) for the Cayman.

  • Page 10: Technical Data

    Boxster Boxster S Cayman Cayman S Engine 01_30_09 Technical data Boxster Boxster S Cayman Cayman S Engine type MA120 MA121 MA120C MA121C No. of cylinder Valves/cylinder 4 Displacement 2893 cc 3436 cc 2893 cc 3436 cc Bore 89 mm 97 mm 89 mm 97 mm Stroke...
  • Page 11 Boxster Boxster S Cayman Cayman S Boxster power/torque diagram Engine Engine type MA120 Displacement 2,893 cc Power output 188 kW/255 bhp at engine speed 6,400 rpm 01_31_09 Boxster S power/torque diagram Engine type MA121 Displacement 3,436 cc Power output 228 kW/310 bhp at engine speed 6,400 rpm 01_32_09...
  • Page 12 Boxster Boxster S Cayman Cayman S Cayman power/torque diagram Engine Engine type MA120C Displacement 2,893 cc Power output 195 kW/265 bhp at engine speed 7,200 rpm 1_33_09 Cayman S power/torque diagram Engine type MA121C Displacement 3,436 cc Power output 235 kW/320 bhp at engine speed 7,200 rpm 1_34_09...

  • Page 13: Crankcase

    Boxster Boxster S Cayman Cayman S Crankcase The new Boxster and Cayman engines, like the 911 models, feature a two-part, vertically split crankcase with integrated crankshaft thrust blocks. Engine 1_05_09 The actual crankcase is made completely of an aluminum-silicon alloy (ALUSIL). This method offers the following advantages: •...
  • Page 14 Boxster Boxster S Cayman Cayman S Engine 1_35_09 Cylinders are now connected differently in the cylinder-head cover area, as on the 911 models. The individual cylinders, which originally stood freely in the water jacket (open deck design), are now connected by a closed cylinder deck (closed deck design).

  • Page 15: Crankshaft/Crankshaft Bearings

    Boxster Boxster S Cayman Cayman S Crankshaft/crankshaft bearings The drop-forged crankshaft runs on eight bearings and has twelve counterweights. Main bearing 4 is designed as a thrust bearing. Axial play is determined by two Engine thrust plates, which are inserted at the left and right of the bearing. The main bearings are designed as plain bearings with a diameter of 63 mm.

  • Page 16: Connecting Rods

    Boxster Boxster S Cayman Cayman S Connecting rods The connecting rods (6) are forged and are split (cracked) at the big end following Engine machining. Both parts are aligned with one another via the fractured surface. Although a matching number is not needed for cracked connecting rods because of the fact that each fractured surface has a different shape, matching numbers are used here to ensure process reliability.

  • Page 17: Pistons

    Boxster Boxster S Cayman Cayman S Pistons The pistons on the new Boxster and Cayman models are forged from a light alloy. Since mixture formation is different on the basic models and the S version, the Engine piston shape is also different. Mixture formation and the direct fuel injection (DFI) combustion process require a special piston crown shape.

  • Page 18: Belt Drive

    Boxster Boxster S Cayman Cayman S Belt drive The belt drive in the new Boxster and Cayman engines has been improved Engine compared to previous models through the following measures in particular: • Double-sided poly-V-belt • Light-alloy torsional vibration damper •...
  • Page 19 Boxster Boxster S Cayman Cayman S Belt tensioner The new maintenance-free, hydraulic belt tensioner with its speed-proportional damping minimises the belt vibrations on the bearings in the system. Engine 1_13_09...

  • Page 20: Cylinder Head

    Boxster Boxster S Cayman Cayman S Cylinder head The cylinder heads in the new engines are designed as a single piece without a Engine separate housing for the hydraulic bucket tappets. It was possible to reduce the weight of the new cylinder heads compared to the previous models (two-piece cylinder heads with a separate bucket tappet guide housing) by using an improved casting process.
  • Page 21 Boxster Boxster S Cayman Cayman S Cylinder-head gasket To ensure the excellent sealing quality of the surface of the multi-layer steel seal, it is covered with high temperature-resistant plastic. The advantage of this steel seal Engine is that the heat can be conducted very well away from the cylinder head. Camshaft bearing The camshafts are guided directly in the cylinder head by means of individual bear - ing saddles in the bearing seat.

  • Page 22: Camshafts

    Boxster Boxster S Cayman Cayman S Cylinder head cover The cylinder head cover is a separate part made of light alloy. To ensure excellent Engine sealing, a moulded elastomer seal is fitted between the cylinder head and cylinder head cover. 1_16_09 Camshafts The exhaust and intake camshafts are hollow-cast from chilled cast iron and are dri-...

  • Page 23: Chain Drive

    Boxster Boxster S Cayman Cayman S Chain drive Another special feature of the new generation of engines is that these engines no longer have an intermediate shaft. This drive shaft, which was fitted between the Engine crankshaft and the camshafts on previous models, was required in order to reduce the transmission ratio and thus the dynamic forces of the timing chains.

  • Page 24: Variocam Plus

    Boxster Boxster S Cayman Cayman S Camshaft control with valve-lift adjustment VarioCam Plus) The requirements imposed on engine design with regard to customer requests for Engine higher performance combined with improved driving comfort, compliance with statutory emissions limits and reduced fuel consumption give rise to conflicting design criteria.

  • Page 25: Vacuum Pump

    Boxster Boxster S Cayman Cayman S Vacuum pump The Boxster and Cayman models use a higher-performance mechanical vacuum pump to provide the vacuum for the brake booster and various vacuum valves. Its Engine familiar rotary vane technology as well as its outer position on cylinder head 4-6 and its drive via the outlet camshaft have been adopted.

  • Page 26: Oil Supply

    Boxster Boxster S Cayman Cayman S Oil supply The oil supply system in the new generation of engines has been thoroughly revised Engine with the following objectives in mind: • To ensure the supply of oil even during very high lateral and axial acceleration •...
  • Page 27 Boxster Boxster S Cayman Cayman S Compared to the previous models, the new 2.9 and 3.4-liter engines have not only one, but two extraction points in each cylinder head. In addition, the new Boxster and Cayman engines now have a total of 5 oil pumps instead of 3. These are Engine located in the oil pan and are driven by a shared shaft.
  • Page 28 Boxster Boxster S Cayman Cayman S Function Depending on the input values for engine speed, engine load, engine oil tempera- Engine ture and the expected change in engine speed, a specific control valve (4) position is defined using a map in the DME control unit. The control valve position regulates the oil pressure for the spring piston on the gear wheel, which can move in axial direction.

  • Page 29: Cooling

    Boxster Boxster S Cayman Cayman S Cooling The cooling concept is an enhancement based on the effective cylinder head cross- flow cooling used on previous models and was developed to selectively cool the hot Engine spots in the cylinder head and crankcase. The design and position of the new coolant pump as well as the revamped internal engine cooling ducts in particular in the cylinder head are new.
  • Page 30 Boxster Boxster S Cayman Cayman S The greater engine power has resulted in a greater cooling requirement in the area of the cylinder head. The cooling ducts in the cylinder head have been revamped Engine and the hottest spot on the positioning ring of the outlet valves has been additionally cooled to ensure cooling in this area, which is subject to substantial thermal loads.

  • Page 33: Fuel And Ignition System Dme)

    Boxster 2 Fuel and ignition systems (DME) Boxster S Cayman Cayman S The main focus here is on new developments and modifications compared to previous Boxster and Cayman models. More detailed basic information can be found in the Technical Service Information for the previous Boxster and Cayman models. Fuel and ignition system General information All new Boxster and Cayman models, as with the new 911 Carrera, use a completely...
  • Page 34 Boxster Boxster S Cayman Cayman S 3.4-liter engine in the Boxster S, Cayman S with direct fuel injection DFI) Fuel and ignition system The Boxster S and Cayman S models are also using totally redesigned 3.4-liter engines with direct fuel injection (DFI) from model year 2009. The power output of the new S models has increased to 310 bhp (228 kW) for the Boxster S and to 320 bhp (235 kW) for the Cayman S, while the displacement has stayed the same.
  • Page 35 Increase in power and torque over the entire rpm range • Better responsiveness Fuel and ignition system • Much lower fuel consumption values and CO emissions combined with greater performance 2_38_09 The illustration shows the 3.4-liter engine with DFI with intake system, exhaust system and Porsche Doppelkupplung (PDK).
  • Page 36 Boxster Boxster S Cayman Cayman S These objectives have been achieved thanks to the following enhancements and technologies of the new 3.4-liter engines with DFI: Fuel and ignition system • Use of direct fuel injection (DFI) • Engine control unit EMS SDI 3.1 •...
  • Page 37 Boxster Boxster S Cayman Cayman S 3.4-liter engine with DFI in the Boxster S, Cayman S Fuel and ignition system 2_39_09 The idle speed of the new DFI engines on the S models is set to 680 +/- 40 rpm and the maximum engine speed is limited to 7,500 rpm.
  • Page 38 Boxster Boxster S Cayman Cayman S Characteristics of the 3.4-liter flat engine with direct fuel injection DFI) Fuel and ignition system • Homogenous operation • Better cylinder charging • Reduced knock sensitivity • Higher compression ratio • High-pressure stratified charge ignition •...
  • Page 39 Boxster Boxster S Cayman Cayman S Starting phase of DFI engines with high-pressure stratified charge ignition High-pressure stratified charge ignition is used in the DFI flat engines in order to Fuel and ignition system optimize cold starting with regard to fuel consumption and emissions. In this process, fuel is injected once into the specially shaped piston recess just prior to the end of the compression stroke when the engine is being started.
  • Page 40 Boxster Boxster S Cayman Cayman S Upper load range of DFI engines Engine operation at low rpm and high engine load leads to special requirements Fuel and ignition system for the mixture-forming process within the engine. Here, dual injection takes place in the upper load range up to approx.
  • Page 41 Technical • Communication with step oxygen sensors LSF 4.2 behind the catalytic converter • Communication with the optional Porsche Doppelkupplung (PDK) Service Information (SIT): 1 Engine • Communication with PSM •...
  • Page 42 Boxster Boxster S Cayman Cayman S The DME control unit controls the following actuators: • 6 ignition modules (individual ignition coils with integral driver) Fuel and ignition system • 6 fuel injectors (high-pressure fuel injectors) • Control unit for fuel pump (for demand control of the in-tank fuel pump, low-pressure side) •...
  • Page 43 Communication with the Porsche Doppelkupplung PDK) control unit The complex co-ordination between the engine and the optional Porsche Doppel - kupplung (PDK) also requires a highly dynamic, powerful engine control unit. Only these parameters allow high performance and low fuel-consumption values and...
  • Page 44 Boxster Boxster S Cayman Cayman S Hot-film mass air flow sensor MAF 7 All new Boxster and Cayman models from model year 2009 use the new hot-film Fuel and ignition system mass air flow sensor MAF 7-RP (RP = Reduced Pressure Drop). This mass air flow sensor has a 5-pin connector with a trapezoidal shape and is welded to the measur- ing tube.

  • Page 45: Low-Pressure Fuel Supply

    Boxster Boxster S Cayman Cayman S Fuel supply The engine is designed to provide optimum performance and fuel consumption if unleaded unleaded fuel 93 octane When fuel with 90 octane is used, Fuel and ignition system the engine's knock controller automatically adapts the ignition timing. The fuel tank’s filling capacity is approx.
  • Page 46 Boxster Boxster S Cayman Cayman S Fuel pressure on the low-pressure side The fuel pressure on the low-pressure side is kept at a constant value of approx. Fuel and ignition system 5.0 bar by the pressure regulator in the fuel tank (previous MPI systems: approx. 4 bar).

  • Page 47: High-Pressure Fuel System

    Boxster Boxster S Cayman Cayman S Fuel high-pressure system in DFI flat engines The fuel high-pressure system generates the injection pressure of 580 to 1740 psi (40 to 120 bar). The fuel is distributed to the high-pressure injectors by the high- Fuel and ignition system pressure pump via the high-pressure lines to the fuel rails of cylinder banks 1 and 2.
  • Page 48 Boxster Boxster S Cayman Cayman S Control and temperature compensation Depending on the amount of fuel required and the calculated fuel temperature, the Fuel and ignition system DME control unit, together with the flow control valve, regulates the amount of fuel on the high-pressure side upstream of the high-pressure injectors.
  • Page 49 Boxster Boxster S Cayman Cayman S Flow control valve for fuel high pressure The flow control valve is an electric control valve and is located on the intake side (low-pressure side) of the high-pressure pump. The DME control unit activates the Fuel and ignition system flow control valve using a current of 0 to approx.
  • Page 50 Boxster Boxster S Cayman Cayman S Fuel high-pressure control The fuel is sucked in from the low-pressure side (5.0 bar) by the pump pistons via Fuel and ignition system the flow control valve and the intake valves. The pistons pump the fuel into the high- pressure system via the exhaust valves.
  • Page 51 Boxster Boxster S Cayman Cayman S The fuel high-pressure system normally operates in flow control mode. Pressure control is activated only when the fuel flow rates are very low near idle Fuel and ignition system speed: • Engine at idle speed •...
  • Page 52 Boxster Boxster S Cayman Cayman S The rail volume is determined by the permissible pressure variation behavior and a short starting time. The volume and the chokes in the high-pressure system dampen Fuel and ignition system pressure-induced vibrations, but they delay attainment of the release pressure for injection when the engine is started.
  • Page 53 Boxster Boxster S Cayman Cayman S Fuel injectors/DFI high-pressure injectors The electromagnetically operated fuel injectors are on the intake side of the cylinder heads. They are activated by the DME control unit in accordance with the firing Fuel and ignition system order.
  • Page 54 Boxster Boxster S Cayman Cayman S In addition to the amount of fuel injected, the injection time and the drop size, the shape and alignment of the fuel jet are also important. Fuel and ignition system The illustration shows a typical DFI fuel injector S The spray-cone angle is the spray angle of the fuel jet and is approx.

  • Page 55: Ignition System

    Boxster Boxster S Cayman Cayman S Ignition system General information Fuel and ignition system The functional principle of the ignition system for the new 2.9-liter and 3.4-liter flat engines essentially corresponds to that of the Cayenne V8 DFI engines. The ignition system map in the DME control unit has been designed to meet DFI-specific requirements.
  • Page 56 Boxster Boxster S Cayman Cayman S Ignition coil with integral driver All parts in this newly developed component are installed as a complete unit in a Fuel and ignition system special rod ignition module housing. This is connected electrically and mechanically to the spark plug in the spark-plug recess via the short high-voltage plug.

  • Page 57: Air Routing On Intake Side

    Boxster Boxster S Cayman Cayman S Intake air side, air routing Air cleaner Fuel and ignition system All new Boxster and Cayman models are fitted with the same air cleaner as their previous models. On the Boxster models only, the size and position of the opening to the Helmholz resonator (H) have been modified at the air cleaner output in the intake area for the intake system.
  • Page 58 Boxster Boxster S Cayman Cayman S Tuning flap As on the previous models, the switchable tuning flap allows the air oscillations in Fuel and ignition system the intake system to be adapted to the respective engine speed. This ensures high torques even at low engine speeds, a more uniform torque curve and high maximum power.

  • Page 59: Exhaust System, Emission Control

    Boxster Boxster S Cayman Cayman S Exhaust system, emission control General information Fuel and ignition system The exhaust systems on all new Boxster and Cayman models have been redesigned to achieve maximum performance with minimum emissions. Design of the exhaust system The new Boxster and Cayman models are fitted with a completely redesigned exhaust gas system compared to the previous models.
  • Page 60 Boxster Boxster S Cayman Cayman S Exhaust manifolds and catalytic converters The redesigned manifolds with integrated main catalytic converters and nearly equal Fuel and ignition system pipe lengths largely correspond to those of the new 911 Carrera models. They permit efficient conversion of pollutants and a balanced gas cycle between the cylinders.
  • Page 61 Boxster Boxster S Cayman Cayman S Tailpipes on the S models As on the previous models, the S models with 3.4-liter displacement are equipped with a twin tailpipe in stainless steel with a brushed finish. Identical twin tailpipes Fuel and ignition system with a larger pipe cross-section and a new design are now used on the new Boxster S and Cayman S.
  • Page 62 Boxster Boxster S Cayman Cayman S Emission control All new Boxster and Cayman models comply with all emissions limits currently Fuel and ignition system applicable in the markets such as EURO 5 and LEV2/ULEV for USA. A reduced EURO 4 data record is used for countries with EURO 2 limits. The new engine generations on all new Boxster and Cayman models satisfy the prerequisite for compliance with the new Euro 5 emissions standard applicable for Europe from 1.9.2009 (in place of Euro 4) primarily through the use of the...

  • Page 63: Liter Engine With Mpi

    Boxster Boxster S Cayman Cayman S 2.9 liter engine with intake manifold injection ME 7.8.2 in the Boxster and Cayman The illustration shows the 2.9-liter engine with intake manifold injection MPI with Fuel and ignition system intake system, exhaust system and manual transmission. 2_55_09 Only the differences between the 2.9-liter engine with intake manifold injection and the 3.4-liter DFI engine are described below.

  • Page 64: Dme Control Unit Me 7.8.2

    Ignition coils with integral driver • Control of the dynamic oil pressure control • Communication with the optional Porsche Doppelkupplung (PDK) 2_62_09 The DME control unit can be programmed with the data records for the various Boxster and Cayman models on a country-...

  • Page 65: Intake System

    Boxster Boxster S Cayman Cayman S Intake system of the 2.9-liter engine with intake manifold injection The geometric dimensions of the individual pipes of the intake manifolds of the right Fuel and ignition system and left cylinder banks have been adapted to the engine characteristics of the 2.9-liter engine.

  • Page 66: Exhaust System

    Boxster Boxster S Cayman Cayman S Exhaust system for 2.9-liter engine The exhaust system on the new Boxster and Cayman models is identical with the Fuel and ignition system S models except for the tailpipe. Emission control The new 2.9-liter basic models of the Boxster and the Cayman with 2.9-liter engine and intake manifold injection continue to use secondary-air injection.

  • Page 69: Porsche Doppelkupplung Pdk)

    Moreover, the driver is also given the opportunity to shift the gears manually using sliding buttons on the new 3-spoke sports steering wheel for PDK or with the gear selector for PDK, which is also new. The Porsche Doppelkupplung (PDK) consists of a housing accommodating in principle 2 transmissions with 2 clutches, i.e.

  • Page 70: General Information

    The Porsche Doppelkupplung (PDK) is both a manual and automatic transmission. Transmission The special feature of the Porsche Doppelkupplung (PDK) is that two gears can always be engaged - one gear is engaged while driving and the next potential gear is already pre-selected.

  • Page 71: Transmission Data

    Boxster Boxster S Cayman Cayman S Transmission data The transmissions of the basic Boxster and Cayman models as well as the Boxster S and Cayman S are identical. Transmission Boxster/Cayman Boxster S/Cayman S Transmission CG2.00 CG2.20 type 1st gear 11/43 11/43 3.91 3.91...

  • Page 72: Transmission Oils

    Oil types/oil fill quantities/oil chambers/change intervals Due to high shearing strains that occur in the differential, two different oil chambers Transmission are used in the Porsche Doppelkupplung (PDK). 3_65_09 The oil chamber for hydraulic oil is shown in red, while the oil chamber for gear wheel oil is shown in blue in the illustration above.
  • Page 73 Boxster Boxster S Cayman Cayman S Oil filling The correct hydraulic oil level is important for operating the transmission without running into problems. The following preconditions must be met in order to check or Transmission correct the oil level: • Engine must be idling •...
  • Page 74 Boxster Boxster S Cayman Cayman S Transmission concept In principle, a “Doppelkupplung” (double clutch) transmission can be understood as Transmission a parallel-switched transmission made up of two fully synchronized shift-sleeve transmissions (transmission 1 and transmission 2). Each transmission has its own clutch: •...
  • Page 75 Gears can be changed both on the steering wheel and using the selector lever. There is no gear lock on vehicles with the Porsche Doppelkupplung (PDK), which means that selector-lever positions P – R – N – D are available.
  • Page 76 3_67_09 A new 3-spoke sports steering wheel for PDK is used in conjunction with the Porsche Doppelkupplung (PDK) on the new Boxster and Cayman models. This completely redesigned steering wheel has two sliding switches, which are incorpo- rated neatly and conveniently into the steering-wheel spokes. Pressing these switches forward changes up a gear, and pulling them or pressing them towards the driver from the back of the steering wheel changes down a gear.
  • Page 77 Cayman Cayman S Display in instrument cluster for Porsche Doppelkupplung PDK) Gearshifts for the new Porsche Doppelkupplung (PDK) are displayed in the instru- ment cluster. The shift indicator is based on an enhanced Tiptronic S concept. In Transmission addition to the usual selector-lever position display (driving mode) via red LEDs, the new instrument cluster also has a numeric gear display.
  • Page 78 Boxster Boxster S Cayman Cayman S Gearshift strategy The center console includes a SPORT and SPORT PLUS button. The basic gearshift Transmission characteristics change, depending on which button is pressed. 3_08_09 Driving in selector-lever position “M”, SPORT and SPORT PLUS button not active Upshifts and downshifts can be performed both on the steering wheel and using the selector lever.
  • Page 79 Boxster Boxster S Cayman Cayman S Driving in selector-lever position “M”, SPORT PLUS button active Upshifts and downshifts can be performed both on the steering wheel and using the selector lever. Gearshifts are not adaptive and are purely power-oriented, with a Transmission corresponding loss of comfort.
  • Page 80 Boxster Boxster S Cayman Cayman S Driving in selector-lever position “D”, SPORT PLUS active Shift map adaptations are not active in this program. The most sporty map is acti- Transmission vated permanently. Gearshifts are power-oriented with reduced gearshift comfort. Downshifts in decele- ration state and deceleration downshifts are accomplished with intermediate throttle application and are therefore very audible.
  • Page 81 Boxster Boxster S Cayman Cayman S Special functions • Launch Control racing start function) Transmission This function is available both in selector-lever position “D” and “M” in SPORT PLUS mode. Preconditions are as follows: Vehicle stationary, brake applied, kick- down active. The function is triggered by releasing the brake. The double clutch in the transmission now enables optimum wheel slip at maximum acceleration.
  • Page 82 At the same time, an 8-second timer is started in the control unit. If the upshift or downshift button is pressed again within these 8 seconds, the timer is restarted. The Porsche Doppelkupplung (PDK) automati- cally switches back to Automatic mode (“D” appears in the instrument cluster) if: •...
  • Page 83 Boxster Boxster S Cayman Cayman S Warm-up program The warm-up map is a shift program with raised gear-changing points, which has the effect of heating the catalytic converters to their operating temperature as quickly Transmission as possible. The engine and transmission also reach their operating temperature more quickly with this map.
  • Page 84 Cayman Cayman S Upshift suppression for 7th gear 7th gear is designed as an overdrive on the Porsche Doppelkupplung (PDK). This Transmission means that in various driving situations, e.g. high road resistance, the vehicle would decelerate when 7th gear is engaged. As a result, 7th gear is not engaged in such situations.
  • Page 85 Boxster Boxster S Cayman Cayman S Drive-Off Assistant If the vehicle is stopped on an incline, the driver will apply the brake and set a certain brake pressure. When the driver now switches from the brake pedal to the Transmission accelerator pedal in order to drive off, the set brake pressure is maintained for as long as it takes for the vehicle to drive off.
  • Page 86 Boxster Boxster S Cayman Cayman S Basic transmission Gear wheel set Transmission 1 Drive shaft 1 2 Drive shaft 2 3 Main shaft 4 Pinion shaft 5 Intermediate gear wheel, reverse 3_69_09 The gear wheel set in the transmission comprises input shaft 1 (1), input shaft 2 (2), the main shaft (3), the pinion shaft (4) and the intermediate gear wheel (5).
  • Page 87 Boxster Boxster S Cayman Cayman S Transmission 1 Loose gear wheel for 4th gear 2 Synchronizing hub with synchronization 3 Loose gear wheel for 6th gear 4 Spacer 3_71_09 5 Fixed gear wheel for 2nd gear The illustration above shows the structure of input shaft 2. Fixed gear wheel for 4th gear Spacer Fixed gear wheel for 6th gear...
  • Page 88 Boxster Boxster S Cayman Cayman S Transmission 3_73_09 The direction change for reverse gear is accomplished via an intermediate gear wheel (1), which is located between input shaft 1 and the main shaft. 1 Bevel gear 2 Constant gear wheel 3 Parking-lock gear 3_74_09...
  • Page 89 Boxster Boxster S Cayman Cayman S Synchronization Basic operating principle of servo-lock synchronization Transmission Synchronization in neutral position. The ball (2) holds the operating sleeve (5) in neutral. 1 Synchroni3er ring 2 Ball 3 Clutch hub 4 Guide sleeve 5 Operating sleeve 6 Spring 7 Pressure piece 8 Loose gear wheel...
  • Page 90 Boxster Boxster S Cayman Cayman S Transmission 3_21_09 3_22_09 The synchronizer ring (1) continues to block the operating sleeve for as long as there is a difference in speed between the clutch hub (3) and operating sleeve. The synchronizer ring can only be turned back through the operating sleeve when the speed is the same.
  • Page 91 Boxster Boxster S Cayman Cayman S Synchronization of reverse, 1st, 2nd and 3rd gear Triple cone synchronizer is used for reverse, 1st, 2nd and 3rd gear. The use of three friction cones has resulted in a considerable reduction in synchronizing forces. Transmission This reduces shifting forces when engaging gears.
  • Page 92 Boxster Boxster S Cayman Cayman S Final drive with differential Transmission 1 Cover 2 Flange 3 Ring gear 4 Differential 5 Pinion shaft 3_75_09 The illustration above shows the position of the final drive in the transmission. 1 Ring gear 2 Differential pinions 3 Shaft bevel gears 4 Planet-gear carrier...
  • Page 93 Boxster Boxster S Cayman Cayman S Shifting Transmission 1 Shift rod for gears 4 and 6 2 Shift rod for gears 5 and 7 3 Shift rod for gears 1 and 3 4 Shift rod for gears 2 and reverse A Shift rod 3_76_09 B Magnet...
  • Page 94 Boxster Boxster S Cayman Cayman S Parking lock Even if the vehicle is in gear, it cannot be prevented from rolling back in the same Transmission way as with a manual transmission because the clutches are opened in depressuri- zed state and therefore do not stop the vehicle from moving. The parking lock pre- vents the vehicle from rolling away, as with an automatic transmission.
  • Page 95 Boxster Boxster S Cayman Cayman S Power flow The torques are transferred either via clutch 1 or 2. Clutch 1 drives input shaft 1 (inner input shaft) and clutch 2 drives input shaft 2 (outer input shaft). Transmission 1st, 3rd, 5th, 7th and reverse gear are on input shaft 1, while 2nd, 4th and 6th gear are on input shaft 2.
  • Page 96 Transmission Double clutch The wet double clutch is a central module of the Porsche Doppelkupplung (PDK). With its wide range of technical features, it implements the functional requirements of the transmission control system, thereby shaping the special character of this transmission concept.
  • Page 97 Special hydraulic oil is used for actuating the double clutch hydraulically and for cooling the clutch. This oil is also used for shifting gears. The Porsche Doppelkupp- lung (PDK) has a separate oil circuit for lubricating the gear wheel set and for coo-...
  • Page 98 Boxster Boxster S Cayman Cayman S Both clutches can be actuated and operated with slip regulation independently of each other. Transmission Both clutches display slight centrifugal force overcompensation. The double clutch is not fully slip-regulated in any operating state, which means that the vehicle must be held with the brake when in gear to prevent it from rolling away.
  • Page 99 Boxster Boxster S Cayman Cayman S Hydraulic control The hydraulic switching device performs the following tasks: • Controls the system and reducing pressure Transmission • Supplies oil to the actuators, clutches, actuating cylinders, cooling system and lubrication system • Activates the clutches and actuating cylinders •...
  • Page 100 Boxster Boxster S Cayman Cayman S Transmission 1 Centering bore B 2 Locking groove 3 Pass-through screws (20) 4 Centering bore 5 Clamp 6 Oil discharge for temperature sensor 7 Pressure regulator 8 Solenoid valves 3_45_09 1 Clamp 2 Port plate 3 Intermediate plate 4 Valve housing 5 M6 bolts in hydraulic switching device...
  • Page 101 Boxster Boxster S Cayman Cayman S Transmission Solenoid valve 1 Solenoid valve 2 Gear valve 2 (EDS5) Gear valve 1 (EDS6) Pressure reducing valve Clutch valve 1 (EDS1) Clutch valve (EDS2) Clutch selector valve (EDS3) Pressure control valve (EDS4) 10 Switch-over valve 11 Cylinder selection valve 2 12 Transmission selection valve 3_83_09...
  • Page 102 Boxster Boxster S Cayman Cayman S Oil cooler The oil cooler is fitted on the outside of the transmission. It cools the clutch fluid Transmission and hydraulic oil, which is heated up significantly more than gear-wheel oil as a result of operating the clutch (frictional heat). 3_85_09 1 Oil cooler (oil/water heat exchanger) 2 Cooler supply line...
  • Page 103 Boxster Boxster S Cayman Cayman S Sensors The following sensors are used in the transmission for recording speed, temperature, pressure and distance signals. Transmission • 4 distance sensors (combined in one housing) • 2 rpm sensors (combined in one housing) •...
  • Page 104 Boxster Boxster S Cayman Cayman S Distance sensors The distance sensor unit (also called “sensor tower”) is used for recording the Transmission position of each individual shift rod (1). It is designed as an assembly, made up of 4 integrated absolute distance sensors. 3_54_09 Each shift rod (1) is assigned a sensor, which converts the linear movement of the shift rod into a distance-proportional PWM signal.
  • Page 105 Boxster Boxster S Cayman Cayman S rpm sensors The rpm sensors (1) record the transmission input speeds and rotation directions for input shafts 1 and 2. They are designed as an assembly made up of two indivi- Transmission dual rpm sensors in one housing. The sensor wheel (2) records the speed of input shaft 1, while the fixed gear wheel for 2nd gear records the speed of input shaft 2.
  • Page 106 The two pressure sensors (1) for measuring the clutch pressure values of the two Transmission Porsche Doppelkupplung (PDK) clutches are read directly at the rotary transmission feed-through point. They are fitted in the centring plate and are connected to the wire harness (3) by connectors (2).
  • Page 107 Boxster Boxster S Cayman Cayman S Temperature sensor The temperature sensor is used to record the sump temperature of the hydraulic oil. This involves measuring a temperature-dependent resistance. Transmission 3_57_09 The supply voltage is 5 V. The diagnostic system checks the sensor as follows: •...
  • Page 108 Boxster Boxster S Cayman Cayman S Electronic transmission control The transmission control unit is connected to other control units in the vehicle via Transmission the CAN bus. The control unit receives information about the driver’s wishes, comprising the following items: •...
  • Page 109 Boxster Boxster S Cayman Cayman S Manual transmission Clutch Transmission Power is transmitted between the engine and transmission via a single-plate dry clutch and dual-mass flywheel. The pressure plate consists of GGG 60 nodular cast iron and has a diameter of 240 mm. The S models, like the 911 Carrera S vehicles, are equipped with a self-adjusting X- Tend clutch.
  • Page 110 Boxster Boxster S Cayman Cayman S With the new generation of engines, the flange shape between the engine and transmission has been redefined. The transmission housing has been reworked Transmission accordingly and the ribbed structure for improved stiffness on the inner wall of the transmission housing has been reinforced to withstand a higher load.
  • Page 113 • Lightweight chassis with long wheelbase and large track widths with modified anti-roll bars and spring/damper units, specific setups for Boxster and Cayman respectively • Adaptation of the driving dynamics to the new Porsche Doppelkupplung (PDK) for outstanding performance • Highly responsive and agile hydraulic rack-and-pinion steering with variable ratio •...
  • Page 114 Boxster Boxster S Cayman Cayman S In addition to the basic chassis, the variable damping system Porsche Active Suspension Management (PASM) with chassis lowered by 10 mm is offered for the Chassis Boxster/Cayman and Boxster S/Cayman S. With the mechanical rear differential lock option, appropriately adapted anti-roll bars are installed at the rear axle.
  • Page 115 Boxster Boxster S Cayman Cayman S Spring strut The spring strut consists of a double-tube gas-filled shock absorber and a coil spring, which in turn is adapted to the different vehicle versions. Chassis The springs are color-coded to indicate the spring tolerance and the chassis version.
  • Page 116 Boxster Boxster S Cayman Cayman S Rear axle The McPherson axle used on the new Boxster and Cayman is essentially the same Chassis as the axle used on the previous model. The springs, dampers and anti-roll bars have been redesigned for the new models. For driving comfort, new rebound stop springs have been used in the shock absorbers, while new foam pads have been used on the springs.
  • Page 117 Porsche Active Suspension Management PASM) As on the previous models, the new Boxster and Cayman models also feature the electronically controlled damping system Porsche Active Suspension Management (PASM) with actively adjustable dampers. To adapt to the improved driving performance of the new models, the system has been modified both hydraulically in its damping characteristics and with regard to system control.
  • Page 118 Boxster Boxster S Cayman Cayman S Wheels and tires Standard wheels Chassis All new Boxster and Cayman models come with newly developed 17 and 18-inch standard wheels in a unique design. Development work here focused on improving performance through lightweight materials and the actual design. 17-inch Boxster III wheel The new Boxster, like its predecessor, comes with 17-inch wheels as standard.
  • Page 119 Boxster Boxster S Cayman Cayman S Tires To guarantee the improved driving performance of the new Boxster and Cayman models, the tires have also been enhanced. Improved rubber compounds and Chassis re designed tires ensure higher performance. Low rolling resistances were also taken into consideration during the development of the new tires.
  • Page 120 Boxster Boxster S Cayman Cayman S Tire Pressure Monitoring 2nd generation) Timely detection of a gradual loss of pressure not only increases driving safety, but Chassis can also prevent uneven tire wear and increased fuel consumption. The optional Tire Pressure Monitoring system (TPM) has therefore been available for all Boxster and Cayman models since the end of 2005.
  • Page 121 Boxster Boxster S Cayman Cayman S Design and function Control unit Chassis Similar to previous models, the control unit is located at the front of the luggage compartment on the right-hand side. The control unit analyses the incoming data from the antenna and forwards the relevant information to the instrument cluster. Since the data is transmitted via cable from the central antenna, the control unit is designed to pick up both frequencies (433/315 MHz).
  • Page 122 Boxster Boxster S Cayman Cayman S Wheel electronics The wheel electronics unit (wheel transmitter, 433 or 315 MHz) is screwed to the Chassis rim using the wheel valve. The wheel electronics unit comprises the following components: Pressure sensor, temperature sensor, roll switch, measuring and control electronics, receiver and transmitter as well as a battery.
  • Page 123 Boxster Boxster S Cayman Cayman S Fast detection of a wheel change without re-calibration If the TPM system is not re-calibrated following a wheel change, the system detects this within max. 3 minutes of driving the vehicle and generates the message “Wheel Chassis change? Input new TPM settings”...
  • Page 124 Boxster Boxster S Cayman Cayman S Soft warning The main purpose of the soft warning is the early detection of pressure loss over Chassis time as a result of diffusion. This warning can only be generated up to a speed of max.
  • Page 125 Cayman Cayman S Brake system To meet the high requirements with regard to the braking performance of a Porsche, all new Boxster and Cayman models also have a brake system that is optimally Chassis designed to suit the relevant vehicle features. The standard brake system of the Boxster and Cayman models with a 2.9-liter engine features black anodized brake...
  • Page 126 Porsche Stability Management PSM) Like the previous models, the new Boxster and Cayman models come as standard Chassis with Porsche Stability Management for high active driving safety in manoeuvers involving extreme longitudinal and lateral acceleration without affecting the typical Porsche agility.
  • Page 127 Boxster Boxster S Cayman Cayman S Enhanced braking readiness The enhanced braking readiness through pre-filling of the brake system serves to shorten the stopping distance in emergencies. When the accelerator pedal is Chassis released very quickly (an action that typically indicates imminent emergency braking), brake fluid is pumped from the PSM hydraulic unit to the wheel brakes before the brake pedal is actually pressed.
  • Page 128 All new Boxster and Cayman models both with manual transmission and with the Chassis new Porsche Doppelkupplung (PDK) feature a Drive-Off Assistant as standard. It prevents the vehicle from rolling forward or back on a hill for a limited time by holding the vehicle automatically and in a controlled way using the operating brake.
  • Page 131 Boxster Body Boxster S Cayman Cayman S General information The Boxster models for model year 2009 are a clear enhancement of the unique Boxster design. Body 5_01_09 Boxster Boxster S General information Bodyshell Cayman Cayman S General information Bodyshell...
  • Page 132 Boxster Boxster S Cayman Cayman S Bodyshell The bodyshell technology is essentially the same as for model year 2005 with Body regard to bending and torsional rigidity as well as side impact protection and is described in the Technical Service Information brochures for the Boxster and Boxster S model year 2005.
  • Page 133 Boxster Boxster S Cayman Cayman S General information The design of the Cayman models is characterized by a particularly muscular dynamism. At the same time the elongated coupé line produces a visual impression Body of elegance and very high quality. 5_04_09...
  • Page 134 Boxster Boxster S Cayman Cayman S Bodyshell The bodyshell technology is essentially the same as for model year 2006 with regard Body to bending and torsional rigidity as well as side impact protection and is described in the Technical Service Information brochures for the Cayman and Cayman S model year 2006.
  • Page 135 Cayman Cayman S General information The main objective of the Porsche designers for the new Boxster models was to make the classic design of the Boxster even more sporty and more dynamic, while at Exterior body equipment the same time ensuring greater visual differentiation between the Boxster and the Cayman –...
  • Page 136 Boxster Boxster S Cayman Cayman S Front view In the front view it is clear that the lines are much more angular compared to the Exterior body equipment previous model, with a greater emphasis on diagonal lines. The result is a modern, more dynamic face for the vehicle.
  • Page 137 Boxster Boxster S Cayman Cayman S Side view The new front air intakes are also visible in the side view and, together with the strongly emphasized front spoiler that continues around to the side, consolidate the very Exterior body equipment sporty appearance.
  • Page 138 Boxster Boxster S Cayman Cayman S Rear view The new Boxster models feature a completely new rear apron. The lower line of the Exterior body equipment new tail lights with their more delicate appearance overall exhibits a downward curve: this shifts the visual focus downwards while also emphasizing the muscular width of the rear.
  • Page 139 Boxster Boxster S Cayman Cayman S Convertible top The Boxster is a classic roadster. It therefore has a very closely cut, lightweight fabric top, which stows away under its cover by electric means in just 12 seconds Exterior body equipment and does not impact the available load options even when stowed.
  • Page 140 Boxster Boxster S Cayman Cayman S Occupant protection The Boxster and Boxster S come with full-size airbags for driver and passenger as Exterior body equipment standard. 6_07_09...
  • Page 141 Boxster Boxster S Cayman Cayman S General information The main objective with the new generation of Cayman models was to enhance both the powerful dynamism and the uniqueness of the design. Exterior body equipment The changes to features are similar to those made on the Boxster models (new front and rear apron, new and larger external air intakes with redesigned front light modules, new LED lighting concept, redesigned standard wheels and door mirrors, new tailpipes).
  • Page 142 Boxster Boxster S Cayman Cayman S Front view More heavily accentuated on the new Cayman models than on the Boxster are the Exterior body equipment strong diagonal lines that describe a downward-pointing “V” from the joints of the luggage compartment lid through the headlights to the middle air intake and give the face of the vehicle a more athletic look.
  • Page 143 Boxster Boxster S Cayman Cayman S Side view The Cayman is characterized in particular by a striking side view: • Strongly curved quarter panel Exterior body equipment • Emphasized sculpting • Long wheelbase with short projections • Long, flowing line from the roof to the rear typical of the coupé •...
  • Page 144 Boxster Boxster S Cayman Cayman S Door mirrors The shape of the double-arm door mirrors has been redesigned in order to increase Exterior body equipment the field of vision to the rear and comply with future legal requirements. Optimized water management also means that the mirror glass stays much cleaner. Rear view The rear section exudes a strong appeal.
  • Page 145 Boxster Boxster S Cayman Cayman S The redesigned number plate cut-out as well as the redesigned tail unit in the lower part of the rear apron emphasize the width and give the vehicle the appearance of making “fuller” contact with the road. Exterior body equipment 6_11_09 The new tail lights are identical to those on the Boxster models.
  • Page 146 Boxster Boxster S Cayman Cayman S Occupant protection The Cayman and Cayman S come with full-size airbags for driver and passenger as Exterior body equipment standard. 6_13_09...
  • Page 147 Boxster Interior body equipment Boxster S Cayman Cayman S General information The interior of the new Boxster and Cayman models has been revised with respect to ergonomics and design quality. On the new models it is now much tidier and of Interior body equipment better quality with a new center console.
  • Page 148 Doppelkupplung PDK) improves driving comfort in winter in particular. The heated steering wheel can be conveniently activated or deactivated separately by means of a switch in the 6 o'clock spoke of the Porsche Doppelkupplung PDK) steering wheel. The redesigned 3-spoke sports steering wheel for Porsche Doppelkupplung is always installed with the optional Porsche Doppelkupplung PDK).
  • Page 151 Boxster 8 Heating and air conditioning Boxster S Cayman Cayman S Externally controlled compressor General information Heating and air conditioning The 2nd generation Boxster and Cayman models, like the 911 Carrera, are fitted with an “externally controlled compressor”. With the externally controlled system, the air conditioner operating panel has a direct effect on the compressor and thus on the cooling output.
  • Page 152 Boxster Boxster S Cayman Cayman S Operating principle of the externally controlled compressor The externally controlled compressor (from Denso) is an air side-controlled swash- Heating and air conditioning plate (adjusting) compressor, similar in function and design to the compressors used on the previous models. The gaseous refrigerant has a pressure of 145 - 435 212°...
  • Page 153 Boxster Boxster S Cayman Cayman S Variable PWM signal 400 Hz) Amperage rating [amp] Compressor status Heating and air conditioning 0.0 – 0.3 Off (no load) 0.3 – 0.8 Continuous adjustment > 0.8 Limited At a coolant temperature of T > 244° F. The piston stroke can be varied continuously via the change in the amperage rating of the PWM signal, as described above by means of pressure compensation in the (118°...
  • Page 154 Boxster Boxster S Cayman Cayman S Operation air conditioner operating panel) Air conditioning control is operated via an operating panel (air-conditioning regulator) Heating and air conditioning with an integrated control unit in the centre console. The operating panel looks similar to the operating panel used in the current sports car except for small changes on the operator interface.
  • Page 155 Boxster Boxster S Cayman Cayman S Actuators and sensors Evaporator temperature sensor Heating and air conditioning The temperature of the evaporator is primarily used as the basis for controlling the electronic control valve in the externally controlled compressor. The sensor is not fitted directly in the evaporator vanes.
  • Page 156 Boxster Boxster S Cayman Cayman S Position of the evaporator temperature sensor On the sports car, the evaporator temperature sensor (arrow) is located on the Heating and air conditioning back of the heater unit housing. The connecting cable for the sensor is routed close to the condensation outlet.
  • Page 157 Boxster Boxster S Cayman Cayman S Air-conditioned seats General information Heating and air conditioning Seat ventilation or ventilation for the two front seats (standard or fully electronic seats) is also available as an option in combination with heated seats for the 2nd generation of Boxster and Cayman models.
  • Page 158 Boxster Boxster S Cayman Cayman S Operating principle of air-conditioned seats Fine perforations in the leather cover on the centre strip of the seat and backrest Heating and air conditioning allow the surface ventilation or airing of the seat upholstery. The passengers’ requirements with regard to seating comfort for the two front seats can be met indi- vidually by adjusting the ventilation and air-conditioning level and selecting the required seat heating setting.
  • Page 159 Boxster Boxster S Cayman Cayman S Controlling air-conditioned seats The fan modules in the seat surfaces and backrests are activated directly from the air conditioner operating panel. The PWM signal used for this has a frequency Heating and air conditioning of 100 Hz.
  • Page 160 Boxster Boxster S Cayman Cayman S Fan modules for the seat surface and backrest (here: seat surface) Heating and air conditioning 8_08_09 8_09_09 Air ducts for the seat surface and backrest 1 Fan module 2 Cushion foam 3 Air-permeable cushioned mat Cushion foam structure (fixed in the middle) Opening for fan module (seat surface)
  • Page 161 General information Heating and air conditioning On all 2nd generation sports cars, the sports steering wheel for Porsche Doppel - kupplung (PDK) as well as the optional multifunction steering wheels for Porsche Doppelkupplung (PDK) can come with steering wheel heating as an optional extra for greater comfort during the cold season.
  • Page 163 Instruments, instrument cluster Voice control Shift indicator CD/DVD changer Audio and communication, CDR-30 BOSE ® Surround Sound System Porsche Communication Management 169 Audio interface Touchscreen and operating logic TV tuner, satellite radio Operating principles of PCM Sport Chrono Package Plus Audio...
  • Page 164 Boxster Boxster S Cayman Cayman S Main headlights and front light module The direction indicators are integrated into the main headlight module as before. Electrics und electronics The separate Boxster and Cayman front light modules, which are mounted into the respective external air intakes, include fog lights as standard.
  • Page 165 Boxster Boxster S Cayman Cayman S Bi-Xenon headlight with dynamic cornering light and LED daytime running lights optional) Bi-Xenon headlights with dynamic headlight beam adjustment, dynamic cornering Electrics und electronics light, LED daytime running lights as well as headlight cleaning system are available as an option for the Boxster and Cayman.
  • Page 166 Boxster Boxster S Cayman Cayman S Innovative lighting technology: Bi-Xenon Bi-Xenon lamps produce light based on the gas-discharge principle. Electrics und electronics A spark discharge between two electrodes produces an “ionized gas tube” in the Xenon gas-filled lamp piston, through which electric current flows, which in turn causes the gas to light up.
  • Page 167 Boxster Boxster S Cayman Cayman S This technology improves active safety for night-time driving by providing optimal illumination in bends. The light beam is projected on to the road to a maximum range without dazzling on-coming traffic. When driving on twisting roads in the dark, Electrics und electronics on secondary roads or in protracted highway bends, the driver can see which way the road is going and detect any obstacles much earlier and can adapt his driving...
  • Page 168 Boxster Boxster S Cayman Cayman S Speed and swivel angle Electrics und electronics 0 – 3 mph (0 – 5 km/h) No swivel action. Start-up: Headlights start to swivel, depending on the steering 3 mph (5 km/h) angle. Flat characteristic for smooth transmission. or faster Headlights swivel by max.
  • Page 169 Boxster Boxster S Cayman Cayman S Electrics und electronics 9_11_09 The tail lights are designed as a single unit and combine the direction indicator, reversing light, brake light, position light, side marker light and reflector in one housing. The rear fog light is on the driver’s side. 9_12_09 Apart from their new design, the most conspicuous feature of the new tail lights is the use of LEDs for rear and brake lights and for the rear fog light.
  • Page 170 Boxster Boxster S Cayman Cayman S Electrics und electronics Brake lights on the Cayman 9_13_09 Tail lights on the Cayman 9_14_09 Brake lights on the Boxster 9_15_09 Tail lights on the Boxster 9_16_09 The use of LED technology for the tail lights has the following advantages over tail lights equipped with ordinary bulbs: •...
  • Page 171 • Display of the Porsche Doppelkupplung (PDK) shift pattern (P-R-N-D) as well as the manual operating position via LEDs. The engaged gear is displayed digitally •...
  • Page 172 The driver is only prompted to perform an upshift if the previously selected speed and acceleration can be continued in the next-highest gear. The actual display is located above the Porsche Doppelkupplung (PDK) shift pattern (P-R-N-D) in the shape of a triangle.
  • Page 173 Boxster Boxster S Cayman Cayman S Audio and communication CDR-30 audio system Electrics und electronics Boxster and Cayman models are equipped as standard with an audio system with CD radio (CDR-30), 2 tweeters in the dashboard, 2 woofers in the door panels as well as 2 power amplifiers rated at 25 W each.
  • Page 174 Boxster Boxster S Cayman Cayman S The following equipment versions are optionally available for the CDR-30: Electrics und electronics Mobile phone preparation • With Bluetooth ® interface to connect a mobile phone to the Hands-free Profile (HFP). Includes the hands-free function and muting as well as operation of the basic functions via the CDR-30 or the multi-function steering wheel.
  • Page 175 Porsche Communication Management PCM) optional) The new 2nd generation Boxster/Cayman models can optionally be equipped with Porsche Communication Management (PCM 3.0). As the central control unit for all Electrics und electronics audio and communication equipment, it is now even more efficient, more versatile and easier to use.
  • Page 176 Boxster Boxster S Cayman Cayman S Electrics und electronics 9_25_09 9_26_09 Upper part of chassis Upper part of chassis with DVD autochanger with single DVD Double tuner SDARS Sports car control panel Lower part of chassis, basic Telephone module HDD 9_26.1_09...
  • Page 177 Boxster Boxster S Cayman Cayman S Electrics und electronics GPS, Display controls gyrometer Graphics Antenna Single DVD FM/AM tuner diversity or DVD changer Main processor Digital tuner SDARS I/O processor Microphone(s) Analogue amplifier Phone Bluetooth NF in Video RFK (E1) Video TV tuner Dig.
  • Page 178 Boxster Boxster S Cayman Cayman S Electrics und electronics 9_27_09 9_28_09 The touchscreen has a long-lasting, easy-to-clean coating. This protects the surface from marks and soiling from fingerprints. By integrating the number pad into the touchscreen control panel, it was possible to significantly increase the diameter of the color screen from 5.8 to 6.5 inches compared to the last generation.
  • Page 179 Boxster Boxster S Cayman Cayman S Operating principles of PCM 3.0 Electrics und electronics 1 Main functions can be selected directly via function keys 2 A menu item is selected and activated • via the rotary/push knob or • via the touchscreen 3 Select OPTION to display manage- ment functions or specific options for the current display in a context menu...
  • Page 180 Boxster Boxster S Cayman Cayman S Navigation module optional) Navigation in the new PCM 3.0 is performed for the first time via an integrated Electrics und electronics 40-GB hard drive, on which data for most countries in a specific region is stored (e.g.
  • Page 181 Boxster Boxster S Cayman Cayman S In split-screen mode, a list of the next manoeuvers the driver must make can be displayed in the form of pictograms beside the current map view, for example. Electrics und electronics 9_32_09 The familiar enhanced functions have been adopted: route guidance along a previously recorded route (Backtrace Navigation/option) as well as navigation in non-digitally recorded areas using a compass and GPS are also supported.
  • Page 182 Boxster Boxster S Cayman Cayman S Electronic logbook optional) The electronic logbook is still offered in conjunction with the navigation module. It is Electrics und electronics used for automatically recording the mileage, distance travelled, date and time as well as the start and destination address for each trip. There are now two ways of reading out data: either using the standard Bluetooth ®...
  • Page 183 Boxster Boxster S Cayman Cayman S Telephone module optional) The internal GSM telephone module, which is available on request, offers optimised sound quality and is extremely easy to use. As a quad-band telephone module (for Electrics und electronics GSM networks 800, 900, 1800 and 1900), it now covers all GSM frequency ranges currently used worldwide.
  • Page 184 Bluetooth ® can be found at wheel or voice control - while your mobile phone stays comfortably in your jacket www.porsche.com pocket. (vehicle selection\convenience). Mobile phone preparation optional) The telephone module is the best solution for customers with a GSM Bluetooth ®...
  • Page 185 Boxster Boxster S Cayman Cayman S Cordless handset for telephone module optional) A cordless (Bluetooth ® ) handset is available together with the telephone module. This replaces the previous PCM handset. The handset is colour-coordinated to suit Electrics und electronics the instruments and has its own display as well as its own keypad for making and taking discrete telephone calls inside the vehicle.
  • Page 186 Surround Sound System optional) The BOSE ® Surround Sound System is developed specifically for Porsche and is optimally adapted to the new Boxster/Cayman models. A total of 11 (Boxster) or 12 loudspeakers (Cayman), including an active subwoofer and centre speaker as well as a 7-channel digital amplifier guarantee an impressive audio experience.
  • Page 187 Boxster Boxster S Cayman Cayman S Stereo sources, such as CDs, are played in a Surround mode, which is generated by the patented BOSE ® Centerpoint ® technology. The new Centerpoint II algorithm ® extracts an even more precise and realistic stereophonic sound from the stereo Electrics und electronics signal.
  • Page 188 Boxster Boxster S Cayman Cayman S Universal audio interface optional) The optional universal audio interface makes it possible for the first time to connect Electrics und electronics an external audio source, e.g. an iPod ® or a USB stick, and use it conveniently via the PCM system.
  • Page 189 Boxster Boxster S Cayman Cayman S TV tuner optional) The TV tuner receives unencrypted analog (PAL, Secam and NTSC) and digital (DVB- T) TV signals. For safety reasons and to comply with legal regulations, only sound Electrics und electronics output is possible while driving. Depending on the legal requirements in the relevant countries, the exact speed limit for switching off the display is between 0 and 5 km/h (3 mph).
  • Page 190 Electrics und electronics combination with the CDR-30 radio and a Sport Chrono Package Plus is offered as an option in combination with Porsche Communication Management (PCM) on the new Boxster and Cayman models. Both packages contain the familiar features: • Analog stopwatch on the dashboard •...
  • Page 191 Boxster S Cayman Cayman S The introduction of an additional SPORT PLUS button in conjunction with Porsche Doppelkupplung (PDK) is completely new in both packages. Actuating this button allows uncompromisingly sporty gearshifts for maximum performance on race Electrics und electronics tracks.
