- Page 1 Smart GSM/GPS car alarms CA-1802 and CA-1803 Athos Control Guarding User manual Communication Accessories 4453 - Jablotron - Manuál Athos - EN.indd 1 18.5.2010 9:25:34...
-
Page 2: Table Of Contents
Remote access and service ......................... 10 Telephoning using a handsfree set (HF-03) ..................11 Other functions ............................ 11 CA-1802 and CA-1803 Athos Thank you for purchasing our product. May you always find your car where you have parked it. JABLOTRON ALARMS a.s. 4453 - Jablotron - Manuál Athos - EN.indd 2 18.5.2010 9:25:34... -
Page 3: Car Alarm Control
More information is available from the installer or from the manufacturer. b) By the original car remote control Setting: W hen the car is locked with its remote control, the car alarm is set concurrently. 4453 - Jablotron - Manuál Athos - EN.indd 3 18.5.2010 9:25:34... - Page 4 T he car alarm may confirm the change of status with an SMS message If you forget the wording of SMS message commands, you can ask the alarm unit for “help” by sending the HELP command. 4453 - Jablotron - Manuál Athos - EN.indd 4 18.5.2010 9:25:35...
- Page 5 Set the alarm (and lock the vehicle if operated according to paragraph 1.a) AM EXT Partially set the alarm (and lock the vehicle if the RC-80 remote control is used) Unset the alarm (and unlock the vehicle if operated according to paragraph 1.a) Block (immobilize) the car UNIMO Unblock (mobilize) the car STATUS Send an SMS about the current status of the car alarm Send the last known GPS position LOCATOR Send an SMS with the approximate position of the car 2) 3) HELP Send an SMS with help SIREN Triggers on a siren for 30 seconds CREDIT Check the amount of credit (when using a pre-paid SIM card) AUX parametr Control of appliances, see page 12 UC xx...x New PASSWORD (change after installation). The xx..x password can consist of 4 to 8 characters (A to Z and 0 to 9), the default one is USER • Only basic ASCII can be used in the SMS command texts. • Ask the installer to edit the SMS commands for you. Only with the CA-1803 The service must be supported by your GSM provider The function must be set by an installer 4453 - Jablotron - Manuál Athos - EN.indd 5 18.5.2010 9:25:35...
-
Page 6: Other Services
The detectors (sensors) are powered by batteries with a lifetime exceeding 1 year. When the batteries are low, the system sends an SMS message. Should you need more information, contact the installer or the manufacturer. 4453 - Jablotron - Manuál Athos - EN.indd 6 18.5.2010 9:25:35... -
Page 7: Alarm - Car Intrusion
• by sending an SMS command to unset the alarm from a mobile phone Unsetting the alarm will terminate the sending of SMS messages and calling. You will subsequently receive an SMS confirming proper alarm termination. When the car alarm is controlled with the RC-80 wireless keyfob, alarm termination will only switch off the siren, but the car will remain secured and locked. It can only be unlocked with repeated pressing of the unset button. Reduction of the number of alarms: If an alarm is triggered repeatedly by the same sensor (e.g. a faulty bonnet sensor) at a time when the alarm is set, then this sensor is bypassed after 3 triggered alarms. It will be re-enrolled when the alarm is set again. Remote switching of the siren: T he siren can also be triggered remotely from authorized phones using the “SIREN” SMS command. This command will switch the siren on for 30 seconds. The siren can be triggered off with the “SIREN OFF” command. A siren alarm can be disabled by an installer If calling in the case of an alarm having been activated and you answer the call, you will hear the sound of a siren. If the car is equipped with 5) a handsfree set, being able to listen in to the sounds in the car interior will be subsequently triggered. 4453 - Jablotron - Manuál Athos - EN.indd 7 18.5.2010 9:25:35... -
Page 8: Signalling
GSM signal and it will not be able to send any messages or make Before switching Flashing indicates wireless detector activation a call in the case of an alarm. the ignition on After switching Flashing indicates the number of enrolled cont- the ignition on rollers 4453 - Jablotron - Manuál Athos - EN.indd 8 18.5.2010 9:25:35... -
Page 9: Car Location And Immobilization
Time:3.12.09 11:35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . current local time 2) LOCATOR If the SIM card used in the car alarm supports the possibility of finding an approximate position of the car in a GSM network, the “LOCATOR” command will find out where the car is located The service must be supported by the GSM operator The direct link to the Google maps is an additional feature for more comfort for users. JABLOTRON ALARMS is not responsible for its proper function in case some changes on the Google maps web page. 4453 - Jablotron - Manuál Athos - EN.indd 9 18.5.2010 9:25:35... -
Page 10: Remote Access And Service
Ask the installer whether the IMO circuit has been installed in the car and what it blocks. Remote access and service www.gsmlink.cz Both the user and the installer can use the www.gsmlink.cz website to register the car alarm and commu- nicate with it remotely. The access is secure and protected with a password. The website allows inspec- tion and control of the car alarm and the changing of phone numbers and texts. The CA-1803 version also allows the display of the current car position on a map. It is also possible to obtain an extract from the event memory listing including time information, source, event type and car movement history If you need to change any car alarm settings, you do not usually have to go to your service company. You just have to make a phone call and the installer can perform remote setting. More detailed information about the GSMLink application is available at www.jablotron.cz. Only with CA-1803 4453 - Jablotron - Manuál Athos - EN.indd 10 18.5.2010 9:25:35... -
Page 11: Telephoning Using A Handsfree Set (Hf-03)
You can thus listen to what is happening in the car or even speak to the person inside. Other functions • Checking the voltage and the battery in the car A set car alarm checks for a sudden drop in voltage in the car supply. It also checks the car battery volt- age. If it drops below 10.5 V, the system sends a warning SMS. If the car alarm is equipped with a BB-02 backup battery, it is able to communicate even when the car battery is disconnected. (If the car alarm is only powered by the BB-02, the siren is disabled.) The function must be enabled by an installer 4453 - Jablotron - Manuál Athos - EN.indd 11 18.5.2010 9:25:36... - Page 12 AUXA (B) ON ON - the relay remains triggered for the maximum of 60 min (1 can be used instead of ON) AUXA (B) OFF OFF - triggers the relay off (0 can be used instead of OFF) AUXA (B) xxM xxM - number of minutes for which the output shall be triggered AUXA (B) xxS xxS - number of seconds for which the output shall be triggered The “AUX” command can be customised (e.g. to HEATING) • Monitoring car operation – Vehicle log book (CA-1803 only) The Vehicle log book service can be used for the detailed monitoring of company vehicles. This service allows the automatic download of information about individual trips made by a given vehicle. This is sub- sequently displayed on a website with secured access both as a text overview of trips and on a map. 4453 - Jablotron - Manuál Athos - EN.indd 12 18.5.2010 9:25:36...
- Page 13 A simplified form of car operation monitoring is also offered by the GSMLink website. The points which the car went through are shown as text including the precise time, and information about its speed. Each record contains a “link” button which shows the exact position on a map. The service provided via the GSMLink website is free of charge. More information is available at www.jablotron.com. • Roaming If you travel abroad and your SIM card has roaming activated, the car alarm will work there too. The device will automatically enter the roaming partner’s network. However, LOCATOR and CREDIT functions may not be available in foreign countries. • Bluetooth - GPS for navigation The CA-1803 BT car alarm can be used as an external Bluetooth GPS positioning source. It can be easily used for communication with a navigational program, e.g. in a PDA or a mobile phone. Further information is available in the installation manual or from the installer. 4453 - Jablotron - Manuál Athos - EN.indd 13 18.5.2010 9:25:36...
- Page 14 Conditions of the guarantee The manufacturer’s guarantee applies to the product itself, not to its installation which is the installer’s responsibility. The guarantee does not apply to batteries and possible sub-modules from other suppliers (e.g. a SIM card). The manufacturer provides a guarantee and a free repair service only if the installation and use of the product is in conformity with the instructions. The manufacturer shall not be held responsible for damage caused by the incorrect or unsuitable use of the product or possibly by its faults caused by intentional damage or damage caused by force majeure (fire, lightning strikes, etc.). The manufacturer recommends regular annual inspections to check the product is 100% functional. You can stipulate them to your installer. 4453 - Jablotron - Manuál Athos - EN.indd 14 18.5.2010 9:25:36...
- Page 15 Installed by: If there are any problems … Contact the company which installed your alarm. They will usually be able to offer you the best help. Or you can contact the manufacturer: JABLOTRON ALARMS a.s. Phone: ......Pod Skalkou 33, 466 01 Jablonec nad Nisou Tel. advisory services: +420 483 559 987, 483 559 999 www.jablotron.com 4453 - Jablotron - Manuál Athos - EN.indd 15 18.5.2010 9:25:36...
- Page 16 Manufacturer: JABLOTRON ALARMS a.s. Pod Skalkou 33, 466 01 Jablonec nad Nisou Czech Republic Tel.: +420 483 559 911 www.jablotron.com 4453 - Jablotron - Manuál Athos - EN.indd 16 18.5.2010 9:25:26...
