Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YFM70KDXR/YFM70KPAR YFM70KPHR/YFM70KPSR WARNING This ATV should not be ridden by anyone under 16 years of age. LIT-11626-37-07 BYY-F8199-10...
Page 2 EBU37021 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
Page 3 Congratulations on your purchase of the Yamaha YFM70KDXR / YFM70KPAR / YFM70KPHR / YFM70KPSR. This ATV represents the result of many years of Yamaha experience in the production of fine sporting, touring, and pace-setting racing machines. With the purchase of this Yamaha, you can now ap- preciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
Page 4 EBU17331 IMPORTANT MANUAL INFORMATION EBU17344 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERIOUS IN- JURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential per- sonal injury hazards.
Page 5 Please check your local riding laws and regulations before operating this ATV. EBU17403 YFM70KDXR / YFM70KPAR / YFM70KPHR / YFM70KPSR OWNER’S MANUAL ©2024 by Yamaha Motor Corporation, U.S.A. 1st edition, March 2023 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A.
Page 6: Table Of Contents
Multi-function display (YFM70KPAR / EWB00012 WARNING YFM70KPHR / YFM70KPSR) ....5-6 Handlebar switches ........5-12 Indicates a hazardous situation which, if not Drive lever “2WD/4WD” (YFM70KDXR) ..5-17 avoided, could result in death or serious injury. Throttle lever..........5-18 Speed limiter..........5-19 Front brake lever........
Page 7 Differential gear oil ........6-3 CROSSING THROUGH SHALLOW Coolant............6-3 WATER ........... 8-20 Front and rear brakes........6-3 RIDING OVER ROUGH TERRAIN..... 8-22 Throttle lever ..........6-4 SLIDING AND SKIDDING ......8-22 Tires ............6-4 WHAT TO DO IF........8-23 Chassis fasteners........
Page 8 U.S.A. 2020 AND LATER MODEL ATV pedal ............9-50 LIMITED WARRANTY (for USA)....12-4 Checking the wheel hub bearings.....9-50 YAMAHA EXTENDED SERVICE (Y.E.S.) Checking the stabilizer bushes ....9-51 (for USA) ..........12-6 Lubricating the rear knuckle pivots...9-51 Lubricating the steering shaft ....9-52 INDEX ............
Page 9: Vehicle Identification
EBU38860 VEHICLE IDENTIFICATION EBU26016 EBU26032 Vehicle identification number Identification numbers The vehicle identification number is stamped into Record the vehicle identification number, model the frame. This 17-digit number is used to identify label information and key identification number in your individual ATV. the spaces provided below.
Page 10 EBU26021 Key identification number The key identification number is stamped into the key. Record this number in the space provided and use it for reference when ordering a new key. 1. Model label Your specific model can be identified by checking the model type code found on the model label.
Page 11: Location Of The Warning And Specification Labels
EBU17661 LOCATION OF THE WARNING AND SPECIFICATION LABELS...
Page 12 Never remove any labels from your ATV. If a label becomes difficult to read or comes off, request a re- placement label from your Yamaha dealer. Overloading this ATV or carrying cargo improperly can change handling, stability and braking performance and can lead to an accident.
Page 13 6 YFM70KPSR WARNING IMPROPER TIRE PRESSURE OR OVERLOADING CAN CAUSE LOSS OF CONTROL. LOSS OF CONTROL CAN RESULT IN SEVERE INJURY OR DEATH. OPERATING TIRE PRESSURE: Set with tires cold 7 YFM70KPSR • Recommended : FRONT : 5.0 psi, (35 kPa) REAR : 4.4 psi, (30 kPa) •...
Page 14 WARNING UNDER Wait for the engine to return to normal idle speed before shifting. 2UD-F151E-00 Operating this ATV if you are under the age of 16 increases your chance of severe injury or death. NEVER operate this ATV if you are under age 16.
Page 15 Certification of Compliance This ATV complies with applicable provisions of ANSI/SVIA 1-2017 and is subject to an approved ATV action plan submitted by YAMAHA and on file with the U.S. Consumer Product Safety Commission. YAMAHA MOTOR CORPORATION U.S.A. 6555 Katella Avenue, Cypress, California 90630-5101, U.S.A.
Page 16: Safety Information
EBU17432 SAFETY INFORMATION SAFETY INFORMATION  Never allow a child under age 16 to operate an EBU27236 ATV without adult supervision, and never allow AN ATV IS NOT A TOY AND CAN BE HAZARD- continued use of an ATV by a child if he or she OUS TO OPERATE.
Page 17  Always inspect your ATV each time you use it to  Always follow proper procedures for climbing make sure it is in safe operating condition. Al- hills as described in this manual. Check the ter- ways follow the inspection and maintenance rain carefully before you start up any hill.
Page 18  Always use proper procedures if you stall or roll reduced stopping ability. Test your brakes after backwards when climbing a hill. To avoid stall- leaving water. If necessary, apply them several ing, use the proper gear range and maintain a times to let friction dry out the linings.
Page 19 In the event of an accident tention. If necessary, contact your riding party 1. If serious injuries are incurred, you may be or local authorities to let them know where safer staying next to your vehicle; it may you are and what has happened. shield you from oncoming riders.
Page 20 While you may find aftermarket products similar in of the operator and may limit control ability, design and quality to genuine Yamaha accesso- therefore, such accessories are not recom- ries, recognize that some aftermarket accessories mended.
Page 21  Do not run engine outdoors where engine EWB00073 WARNING exhaust can be drawn into a building through openings such as windows and doors. Avoid Carbon Monoxide Poisoning All engine exhaust contains carbon monoxide, FOR MORE INFORMATION ABOUT ATV SAFE- a deadly gas.
Page 22: Description
EBU17681 DESCRIPTION EBU17691 EBU17701 Left view Right view 1. Radiator cap 1. Rear shock absorber 2. Battery 2. Fuel tank cap 3. Fuses 3. Storage compartment 4. Air filter 4. Spark plug 5. Spark arrester 5. Winch (YFM70KPSR) 6. Rear brake light switch 6.
Page 23: Controls And Instruments
YFM70KPAR / YFM70KPHR / YFM70KPSR EBU17715 Controls and instruments 6 7 8 9 10 11 YFM70KDXR 2 3 4 7 8 9 10 1. Drive select lever 2. Rear brake lever 3. Handlebar switches 1. Drive select lever 4. Winch switch (YFM70KPSR) 2.
Page 24: Instrument And Control Functions
EBU1772C INSTRUMENT AND CONTROL FUNCTIONS EWB00012 “ ” (off) WARNING All electrical systems are off. The key can be re- Indicates a hazardous situation which, if not moved. avoided, could result in death or serious injury. EBU29913 Main switch 1. Main switch “...
Page 25: Indicator Lights And Warning Lights
YFM70KPAR / YFM70KPHR / YFM70KPSR EBU26699 Indicator lights and warning lights YFM70KDXR 1 2 3 4 5 6 1. Differential gear lock indicator light “ ” 2. Low-range indicator light “L” 3. High-range indicator light “H” 1. Fuel level warning light “ ”...
Page 26 “ ” (on), or EBU38270 Park indicator light “ ” (YFM70KDXR) / “ ” if the warning light remains on, have a Yamaha (YFM70KPAR / YFM70KPHR / YFM70KPSR) dealer check the vehicle. This indicator light comes on when the transmis-...
Page 27 “ ” (on), or if the warning The warning light comes on in red when the en- light remains on, have a Yamaha dealer check the gine is overheating. If the red light comes on, stop electrical circuit.
Page 28 “ ” (on), or if the warning curs, have a Yamaha dealer check the EPS light remains on, have a Yamaha dealer check the system. vehicle. The electrical circuit of the warning light can be checked by turning the key to “...
Page 29: Multi-Function Display (Yfm70Kpar / Yfm70Kphr / Yfm70Kpsr)
ferential gear is completely locked or unlocked. Turn the handlebar or start moving to help the dif- Due to the synchronizing mechanism in the differ- ferential lock to engage or disengage. ential gear case, the light may not come on until the ATV starts moving.
Page 30 The multi-function display is equipped with the Odometer and tripmeters following:  speedometer  odometer  tripmeters  clock  hour meter  voltage display  coolant temperature display  fuel gauge  brightness control mode  error code display 1.
Page 31 Push the “SELECT” button to switch between the Clock, hour meter, voltage display and coolant odometer “ODO”, the tripmeters “TRIP A” and temperature display “TRIP B”, and the service tripmeter “ ” in the following order: ODO → TRIP A → TRIP B → →...
Page 32 18 volts, “Hi” is dis- played. ECB03570 NOTICE If the voltage display indicates “Lo” or “Hi”, there may be trouble with the battery charging circuit or the battery may be faulty. If this oc- curs, have a Yamaha dealer check or repair the vehicle.
Page 33  The radiator fan turns on and off automatically Coolant temperature display according to the coolant temperature. Fuel gauge 1. Coolant temperature display When the coolant is in the normal operating tem- perature range, the temperature is displayed. 1. Fuel gauge When the coolant temperature rises, the coolant temperature display will begin to flash.
Page 34 If the electrical circuit for the fuel gauge is not 3. Push the “SELECT” button to confirm the se- working correctly, all display segments will flash lected brightness level and exit the brightness repeatedly. Have a Yamaha dealer check the vehi- control mode. cle. Error code display Brightness control mode 1.
Page 35: Handlebar Switches
If the display indicates an error code, note the YFM70KPAPR / YFM70KPHR / YFM70KPSR code number and have a Yamaha dealer check the vehicle. ECB00812 NOTICE If the multi-function display indicates an error code, the vehicle should be checked as soon as possible in order to avoid engine damage.
Page 36 YFM70KPAR / YFM70KPHR / YFM70KPSR EBU18102 Start switch “ ” Push this switch to crank the engine with the start- er. See the starting instructions on page 7-1 prior to starting the engine. EBU34123 LOCK Light switch “ /OFF” Set this switch to “ ”...
Page 37 In While the override switch is pushed, the segments this case, take the ATV to a Yamaha dealer at the of the speedometer digits will appear as shown in first opportunity.
Page 38 EWB00151 EWB00164 WARNING WARNING Always ride at a slow speed when the ATV is in Always stop the ATV before changing from four-wheel-drive differential gear lock, and al- two-wheel drive to four-wheel drive and vice low extra time and distance for maneuvers. versa.
Page 39  “LOCK” (four-wheel drive with the differential gear locked): power is supplied to the front and rear wheels and the differential gear is locked. Unlike in four-wheel drive, all wheels turn at the same speed, giving maximum traction. LOCK EWB00132 WARNING Always stop the ATV before changing from four-wheel drive to four-wheel-drive differen-...
Page 40: Drive Lever "2Wd/4Wd" (Yfm70Kdxr)
 Riding before the differential gear is properly en- EBU37201 Drive lever “2WD/4WD” (YFM70KDXR) gaged or disengaged (e.g., when the icon and indicator light are flashing) will cause the vehicle speed to be limited until the differential gear is completely engaged or disengaged. ...
Page 41: Throttle Lever
EWB00164 EBU18286 Throttle lever WARNING Always stop the ATV before changing from two-wheel drive to four-wheel drive and vice versa. The ATV handles differently in two- wheel drive than in four-wheel drive in some circumstances. Changing from two-wheel drive to four-wheel drive or vice versa while moving may cause the ATV to unexpectedly handle differently.
Page 42: Speed Limiter
the adjusting screw in direction (b). Do not EBU18325 Speed limiter turn the adjusting screw out more than 12 mm (0.47 in) or the throttle cable could be damaged. Always make sure the throttle lever free play is adjusted to 3.0–5.0 mm (0.12– 0.20 in).
Page 43: Brake Pedal And Rear Brake Lever
The front brake lever is located on the right han- dlebar. To apply the front brake, pull the brake le- ver toward the handlebar grip. EBU18444 Brake pedal and rear brake lever 1. Rear brake lever The brake pedal is located on the right side of the ATV and the rear brake lever is located on the left handlebar.
Page 44: Drive Select Lever
EBU18614 EBU37980 Drive select lever Fuel tank cap 1. Drive select lever 1. Fuel tank cap The drive select lever is used to shift the transmis- Remove the fuel tank cap by turning it counter- sion into the low-range, high-range, neutral, re- clockwise.
Page 45: Fuel
of sparks, open flames, or other sources of 3. Wipe up any spilled fuel immediately. NOTICE: Immediately wipe off spilled fuel ignition such as the pilot lights of water heat- ers and clothes dryers. with a clean, dry, soft cloth, since fuel may 2.
Page 46: Seat
ECB00071 Recommended fuel: NOTICE Regular unleaded gasoline (Gasohol [E10] Use only unleaded gasoline. The use of leaded acceptable) gasoline will cause severe damage to internal Fuel tank capacity: engine parts, such as the valves and piston 18 L (4.8 US gal, 4.0 Imp.gal) rings, as well as to the exhaust system.
Page 47: Storage Compartment
To install the seat EBU34152 Storage compartment ECB02320 NOTICE Do not store metal or sharply edged objects, like tools, in the storage compartment. If they must be stored, wrap them in appropriate cushion material to prevent damaging the stor- age compartment. The storage compartment is located in front of the seat.
Page 48: Front Carrier
A drain plug is fitted at the bottom of the storage compartment. If any water collects in the storage compartment, remove the drain plug, drain the water, and then install the drain plug. 1. Storage compartment When storing any documents in the storage com- partment, be sure to wrap them in a plastic bag so that they will not get wet.
Page 49: Rear Carrier
Uneven adjustment can cause poor handling A special wrench can be obtained at a Yamaha and loss of stability, which could lead to an ac- dealer to make this adjustment.
Page 50 Front spring preload setting: Minimum (soft): 1 (YFM70KPAR, YFM70KPHR, YFM70KPSR) Standard: 2 (YFM70KPAR, YFM70KPHR, YFM70KPSR) Maximum (hard): 5 (YFM70KPAR, YFM70KPHR, YFM70KPSR) Rear spring preload setting: 1. Special wrench Minimum (soft): 1 (YFM70KPAR, YFM70KPHR, YFM70KPSR) Standard: 2 (YFM70KPAR, YFM70KPHR, YFM70KPSR) Maximum (hard): 5 (YFM70KPAR, YFM70KPHR, YFM70KPSR) 5-27...
Page 51: Winch (Yfm70Kpsr)
EWB04350 Trailer towing equipment can be obtained at a WARNING Yamaha dealer. (See page 7-7 for precaution in- To reduce the risk of injury or death, read and formation.) follow the Winch Owner’s Manual prior to use. Never let anyone come between the winch and pulled object or the winch and anchor point.
Page 52: Auxiliary Dc Jack
EBU19187 Auxiliary DC jack 1. Trailer hitch receiver 1. Auxiliary DC jack cap 2. Auxiliary DC jack Auxiliary DC jack system capacity: 10.0 A (120 W) (YFM70KDXR, YFM70KPAR, YFM70KPHR) 8.0 A (96 W) (YFM70KPSR) 5-29...
Page 53 ECB03760 NOTICE  Turn off the accessory before plugging into/un- Do not use any single electrical accessory or plugging from the jack. combination of accessories that require more  When the auxiliary DC jack is not being used, than the stated capacity at any one time. This cover it with the cap.
Page 54: Pre-Operation Checks
Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
Page 55 ITEM ROUTINE PAGE • Check operation. If soft or spongy, have Yamaha dealer bleed hy- draulic system. • Check brake pads for wear, and replace if necessary. Front brake 6-3, 9-42, 9-43, 9-44 • Check brake fluid level in reservoir, and add specified brake fluid to specified level if necessary.
Page 56: Fuel
Add oil as necessary. (See page 9-19.)  Check that there is no free play in the front EBU19591 brake lever. If there is free play, have a Yamaha Final gear oil dealer check the brake system. Make sure that the final gear oil is at the specified ...
Page 57: Throttle Lever
If there is any leakage, the brake system should be checked by a Yamaha dealer. Brake operation Test the brakes at slow speed after starting out to make sure they are working properly.
Page 58 Tire pressure must be checked and set when the OPERATING TIRE PRESSURE (cold): tires are cold. The tire pressure should be the FRONT: (Recommended) same on both sides, and must be adjusted ac- 35.0 kPa (0.350 kgf/cm², 5.0 psi) cording to vehicle loading conditions. Set the tire REAR: (Recommended) pressure as specified below.
Page 59 250 kPa (2.5 kgf/cm², 36 psi) This ATV is equipped with tubeless tires and tire Rear air valves. After extensive tests, only the tires list- 250 kPa (2.5 kgf/cm², 36 psi) ed below are approved for this model by Yamaha.
Page 60: Chassis Fasteners
Aftermarket tires and rims The tires and rims that came with your ATV were designed to match the performance capabilities and to provide the best combination of handling, braking, and comfort. Other tires, rims, sizes, and combinations may not be appropriate. EBU19841 Chassis fasteners Make sure that all nuts, bolts and screws are...
Page 61: Operation
See the “Engine break-in” section on page 7-5 the ATV. If there is a control or function you do not prior to operating the engine for the first time. understand, ask your Yamaha dealer. EWB00632 WARNING To start the engine 1.
Page 62: Operating The Drive Select Lever And Driving In Reverse
If the indicator light does not come on, EBU36231 have a Yamaha dealer check the electrical Operating the drive select lever and circuit. driving in reverse 3. Apply the rear brake lever or brake pedal.
Page 63 - Driving on bumpy roads at high speeds. - Sideways sliding or skidding. - Unnecessary hard braking. Such usage may result in damage to the drivetrain. Shifting: Neutral to High-range and High-range to Low-range 1. Bring the ATV to a complete stop. 2.
Page 64 6. P (Park)  When in reverse, the reverse indicator light should come on. If the indicator light does not come on, have a Yamaha dealer check the elec- trical circuit.  Due to the synchronizing mechanism in the en- gine, the indicator light may not come on until the ATV starts moving.
Page 65: Engine Break-In
Since the engine is brand new, do not put an ex- Yamaha dealer check the ATV. cessive load on it for the first 240 km (150 mi) or 15 hours. During this period the various parts in...
Page 66: Parking On A Slope
Yamaha for use on your ATV. Many companies with no connection to Yamaha manufacture parts and accessories or offer other modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these aftermarket compa- nies produce. Therefore, Yamaha can neither en-...
Page 67 Yamaha or modifications not specifically bulky object attached to the handlebars which recommended by Yamaha, even if sold and in- could make steering difficult, an accessory that stalled by a Yamaha dealer. limits your ability to move around on the seat, or one that limits your view.
Page 68  Never exceed the weight limits shown. An over- the weight on the hitch. If you are carrying cargo loaded ATV can be unstable. and towing a trailer, include the tongue weight in the maximum ATV load limit.  Load cargo on the carriers as close to the center MAXIMUM LOADING LIMIT ATV loading limit (total weight of rider, car- of the ATV as possible.
Page 69 EWB00012 WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Page 70: Riding Your Atv
EBU21133 RIDING YOUR ATV...
Page 71: Getting To Know Your Atv
Before you begin to ride, be complete the certified training course offered by sure you have read this Owner’s Manual com- Yamaha. They should then regularly practice the pletely and understand the operation of the con- skills learned in the course and the operating tech-...
Page 72 more information about the training course, con- tact an authorized ATV dealer or call 1-800-887- 2887. Riding your ATV requires skills acquired through practice over a period of time. Do not attempt to operate at maximum perfor- mance until you are totally familiar with the ATV’s handling and performance characteristics.
Page 73 Apparel Always wear the following to reduce risk of injury in an accident:  Approved motorcycle helmet that fits properly  Eye protection (goggles, helmet face shield, or protective eyewear)  Over-the-ankle boots, gloves, long-sleeved shirt or jacket, and long pants An approved helmet and other personal protective equipment can reduce the severity of injuries in an accident.
Page 74 Wear eye protection when operating your ATV to Do not operate after or while consuming alco- reduce the risk of a serious accident or injury. Eye hol or drugs. protection, such as a face shield or goggles, may The operator’s performance capability is reduced reduce the risk of foreign material getting in your by the influence of alcohol or drugs.
Page 75 nance procedures and schedules described in the Owner’s Manual. WARNING! Failure to inspect the ATV before riding it or failure to maintain it properly increases the possibility of an acci- dent and equipment damage. [EWB01433] Speed limiter For riders less experienced with this model, the throttle lever housing is equipped with a speed limiter.
Page 76 Loading and accessories Take extra precautions when driving with a load or trailer. Follow these instructions and always use EWB01463 WARNING common sense and good judgment when carrying cargo or towing a trailer. Improper loading or towing can increase the risk of loss of control, an overturn, or other ac- MAXIMUM LOADING LIMIT cident.
Page 77 drive slowly (shift into first gear or low drive if avail- able on this model) whenever you are carrying heavier loads or when towing a trailer. During operation Always keep your feet on the footboards during operation; otherwise, they may contact the rear wheels.
Page 78 ATV should the engine has stopped. To reduce the risk of fire be genuine Yamaha or equivalent components during operation or after leaving the ATV, do not designed for use on this ATV and should be in- let brush, grass and other materials collect under stalled and used according to instructions.
Page 79: Be Careful Where You Ride
rials may have collected. Do not idle or park the BE CAREFUL WHERE YOU RIDE vehicle in long dry grass or other dry ground cov- This ATV is designed for off-road use only. WARNING! Paved surfaces may seriously af- To prevent burns, avoid touching the exhaust sys- fect handling and control of the ATV, and may tem.
Page 80 WARNING! Never operate this ATV on any pub- lic street, road or highway, even a dirt or gravel one. You could collide with another vehicle. [EWB01032] Do not operate on rough, slippery, or loose terrain Know the terrain where you ride. Ride cautiously in until you have learned and practiced the skills nec- unfamiliar areas.
Page 81 When riding in an area where you might not easily Do not ride in areas posted “no trespassing”. be seen, such as desert terrain, mount a caution Do not ride on private property without getting flag on the ATV. DO NOT use the flag pole bracket permission.
Page 82: Turning Your Atv
Select a large, flat area off-road to become familiar ECB00252 NOTICE with your ATV. Make sure that this area is free of obstacles and other riders. You should practice Do not shift from low-range to high-range or control of the throttle, brakes, shifting procedures, vice versa without coming to a complete stop.
Page 83 As you approach a curve, slow down and begin to may continue to go straight. If the ATV doesn’t turn the handlebars in the desired direction. As turn, come to a stop and then practice the proce- you do so, put your weight on the footboard to the dure again.
Page 84: Climbing Uphill
 Avoid crossing the side of a steep hill if pos- CLIMBING UPHILL sible. When crossing the side of a hill, shift EWB01672 WARNING your weight to the uphill side of the ATV. Climbing hills improperly can cause overturns or loss of control. Use proper riding techniques described in this Owner’s Manual.
Page 85 It is important when climbing a hill to make sure that your weight is transferred forward on the ATV. This can be accomplished by leaning forward and, on steeper inclines, standing on the footboards and leaning forward over the handlebars. When- ever possible, ride straight up hills.
Page 86: Riding Downhill
If you start to roll backwards, DO NOT apply either brake abruptly. If you are in “2WD”, apply only the front brake. When fully stopped, apply the rear brake as well, and then shift to the park position. If you are in “4WD”, because all wheels are inter- connected by the drive train, applying either brake will brake all wheels, therefore, avoid sudden ap- plication of either the front or rear brake as the...
Page 87  Shift your weight backward and to the up rear brake will brake all wheels. When descending side of the hill. hills, using either brake lever or the brake pedal  Never go down a hill at high speed. will brake the wheels on the downhill side. Avoid ...
Page 88: Crossing A Slope
CROSSING A SLOPE As you travel across a slope, lean your body in the uphill direction. It may be necessary to correct the EWB01633 WARNING steering when riding on loose surfaces by pointing the front wheels slightly uphill. When riding on Improperly crossing hills or turning on hills could cause loss of control or cause the ATV to slopes, be sure not to make sharp turns either up...
Page 89: Crossing Through Shallow Water
CROSSING THROUGH SHALLOW WATER EWB01642 WARNING Operating this vehicle through deep or fast- flowing water can lead to loss of control or an overturn. To reduce your risk of drowning or other injuries, use care when crossing through water. Never operate this ATV water deeper than the depth specified in your Owner’s Man- ual, as tires may float, increasing the risk of an overturn.
Page 90 Test your brakes after leaving the water. If neces- Wash the ATV in fresh water if it has been operat- sary, apply them several times to let friction dry ed in salt water or muddy conditions. out the linings. Do not continue to ride your ATV without verifying that you have regained proper braking ability.
Page 91: Riding Over Rough Terrain
accident. Be sure to keep your feet firmly mounted on the footboards at all times. Avoid jumping the ATV as loss of control and damage to the ATV may result. SLIDING AND SKIDDING EWB01663 WARNING Skidding or sliding improperly may cause you to lose control of this ATV.
Page 92: What To Do If
To reduce the tendency for the front wheels to slide in loose or slippery conditions, positioning your weight over the front wheels will sometimes help. With practice, over a period of time, skill at con- trolled sliding can be developed. The terrain should be chosen carefully before attempting If the rear wheels of your ATV start to slide side- such maneuvers, since both stability and control...
Page 93  If your ATV is traversing a sloping surface: WHAT TO DO...  If your ATV doesn’t turn when you want it to: Be sure to ride with your weight positioned to- Bring the ATV to a stop and practice the turning wards the uphill side of the ATV to maintain maneuvers again.
Page 94: Periodic Maintenance And Adjustment
The intervals given in the periodic maintenance vice or while using the vehicle. If you are not fa- charts should be considered as a general guide miliar with vehicle service, have a Yamaha under normal riding conditions. However, DE- dealer perform the service.
Page 95: Owner's Manuals
Make sure to cle to a Yamaha dealer to check the torque set- protect the owner’s manuals by putting them in a tings and adjust them as necessary.
Page 96: Periodic Maintenance Chart: Emission Control System
 For odometer or hour meter-equipped vehicles, follow the month maintenance interval if the ATV isn’t ridden for the stated distance or engine operating hours.  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
Page 97 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours √ √ √ Spark arrester • Clean. • Check the air cut-off valve, reed valve, and hose Air induction sys- for damage.
Page 98: Periodic Maintenance Chart: General Maintenance And Lubrication
 For odometer or hour meter-equipped vehicles, follow the month maintenance interval if the ATV isn’t ridden for the stated distance or engine operating hours.  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
Page 99 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours • Check for cracks or other damage, and replace if √ √ √ √ necessary. Brake hoses •...
Page 100: Engine Oil
INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours √ √ √ Steering shaft • Lubricate with lithium-soap-based grease. • Check operation and repair or replace if dam- √...
Page 101 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours Moving parts and √ √ √ √ • Lubricate. cables • Check operation. • Check throttle lever free play, and adjust if neces- √...
Page 102: Removing And Installing Panels
EWB00012 WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. EBU23091 Removing and installing panels The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed.
Page 103 Panel B To remove the panel 1. Remove panel A. 2. Remove the front carrier by removing the bolts. 1. Panel A To install the panel Place the panel in the original position. 1. Front carrier 2. Carrier bolt (upper) 9-10...
Page 104 1. Carrier bolt (under the fenders) 1. Panel B 2. Carrier bolt (lower) 2. Quick fastener 3. Remove the quick fasteners, and then pull the To install the panel panel upward to remove it. 1. Place the panel in the original position, and then install the quick fasteners.
Page 105 Panel C To remove the panel 1. Remove the seat. (See page 5-23.) 2. Remove panel A. 3. Remove the hoses from panel C. 2. Install the front carrier by installing the bolts and tightening them to the specified torques. Tightening torques: Carrier bolt (upper): 34 N·m (3.4 kgf·m, 25 lb·ft)
Page 106 1. Bolt 1. Screw 2. Quick fastener To install the panel 5. Remove the screws under the storage com- 1. Place the panel in the original position. partment lid, and then pull the panel upward to remove it. To ease removal of panel C, shift the drive select lever into the reverse position.
Page 107 2. Install the screws, quick fasteners, bolts, and hoses. Make sure that the hoses are properly connected and routed, and are not pinched. 3. Install panel A. 4. Install the seat. Panels D and E To remove a panel 1. Panel D 1.
Page 108 To install a panel Panels F and G 1. Place the panel in the original position, and To remove a panel then install the bolt. 1. Remove the panel bolts, footboard bolt, and footboard nut. 1. Panel F 2. Footboard nut 3.
Page 109 1. Panel G 2. Footboard nut 3. Footboard bolt 4. Panel bolt 5. Projection 2. Pull the panel downward while pushing the projection. To install a panel 1. Place the panel in the original position. 2. Install the bolts and nut, and then tighten them to the specified torques.
Page 110: Checking The Spark Plug
Tightening torques: Panel bolt: 4.0 N·m (0.40 kgf·m, 3.0 lb·ft) Footboard nut: 4.0 N·m (0.40 kgf·m, 3.0 lb·ft) EBU38133 Checking the spark plug The spark plug is an important engine component, which is easy to check. Since heat and deposits will cause any spark plug to slowly erode, the 1.
Page 111 If the spark plug shows a distinctly different color, the engine could be operating improperly. Do not attempt to diagnose such problems yourself. In- stead, have a Yamaha dealer check the vehicle. 1. Spark plug gap 2. Check the spark plug for electrode erosion...
Page 112: Engine Oil And Oil Filter Cartridge
Tightening torque: Spark plug: If the engine was started before checking the oil 13 N·m (1.3 kgf·m, 9.6 lb·ft) level, warm up the engine, and then wait at least 10 minutes until the oil settles for an accurate reading. If a torque wrench is not available when installing 3.
Page 113 1. Engine oil dipstick 1. Maximum level mark 2. Minimum level mark 5. Insert the dipstick completely into the oil filler 6. If the engine oil is at or below the minimum hole, and then remove it again to check the oil level mark, add sufficient oil of the recom- level.
Page 114 1. Oil filter cartridge 2. Oil filter wrench An oil filter wrench is available at a nearby Yamaha 1. Engine oil drain bolt dealer. 2. Gasket 8.
Page 115 1. O-ring 1. Torque wrench Tightening torque: Oil filter cartridge: Make sure that the O-ring is properly seated. 17 N·m (1.7 kgf·m, 13 lb·ft) 9. Install the new oil filter cartridge with an oil fil- 10. Install panel F. ter wrench, and then tighten it to the specified 11.
Page 116: Why Yamalube
Be sure to wipe off spilled oil on any parts after the Why Yamalube engine and exhaust system have cooled down. YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion and belief that engine oil is ECB00301 an important liquid engine component.
Page 117: Final Gear Oil
1. Final gear oil age before each ride. If any leakage is found, have 2. Gasket a Yamaha dealer check and repair the ATV. In ad- 3. Final gear oil level check bolt dition, the final gear oil level must be checked and 4.
Page 118 To change the final gear oil 1. Park the ATV on a level surface. 2. Place an oil pan under the final gear case to collect the used oil. 3. Remove the final gear oil filler bolt, the final gear oil level check bolt, the final gear oil drain bolt and their gasket to drain the oil from the final gear case.
Page 119: Differential Gear Oil
The differential gear case must be checked for oil leakage before each ride. If any leakage is found, 1. Final gear oil have a Yamaha dealer check and repair the ATV. 2. Gasket In addition, the differential gear oil level must be 3.
Page 120 To check the differential gear oil level 5. Install the oil filler bolt and its gasket, and then 1. Park the ATV on a level surface. tighten the bolt to the specified torque. 2. Remove the differential gear oil filler bolt and Tightening torque: its gasket, and then check the oil level in the Differential gear oil filler bolt:...
Page 121: Coolant
4. Install the drain bolt and its new gasket, and Recommended differential gear oil: then tighten the bolt to the specified torque. See page 11-1. Tightening torque: 6. Check the oil filler bolt gasket for damage, Differential gear oil drain bolt: and replace it if necessary.
Page 122 1.99 L (2.10 US qt, 1.75 Imp.qt) The coolant should be between the minimum and If genuine Yamaha coolant is not available, use an maximum level marks. ethylene glycol antifreeze containing corrosion in- hibitors for aluminum engines and mix with dis- tilled water at a 1:1 ratio.
Page 123 0.24 L (0.25 US qt, 0.21 Imp.qt) a Yamaha dealer check the antifreeze con- tent of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.
Page 124 EBU34213 To change the coolant EWB01891 WARNING Wait for the engine and radiator to cool before removing the radiator cap. You could be burned by hot fluid and steam blown out under pressure. Always place a thick rag over the cap when opening.
Page 125 1. Radiator cap 1. Coolant drain bolt 2. Gasket 5. Place a container under the engine, and then remove the coolant drain bolt and its gasket. (Use a trough or a similar object as shown to prevent coolant from spilling on the engine guard.) 1.
Page 126 6. Place a container under the coolant reservoir Tightening torque: to collect the used coolant. Coolant drain bolt: 7. Remove the coolant reservoir cap. 10 N·m (1.0 kgf·m, 7.4 lb·ft) 8. Disconnect the coolant reservoir hose on the coolant reservoir side, and then drain the 11.
Page 127 15. When coolant begins to flow out of the bolt 18. Loosen the cylinder head air bleed bolt, with- hole, tighten the water pump air bleed bolt to out removing it, to allow all of the air to es- the specified torque. cape from the air bleed bolt hole.
Page 128 24. Start the engine, and then check for coolant leakage. If any leakage is found, have a Yamaha dealer 1. Footboard nut check the cooling system. 2. Footboard bolt A 3.
Page 129: Cleaning The Air Filter Element
EBU34234 Cleaning the air filter element The air filter element should be cleaned at the in- tervals specified in the periodic maintenance chart. Clean or replace the air filter element more frequently if you ride in unusually wet or dusty ar- eas.
Page 130 2. Remove the seat. (See page 5-23.) 3. Remove the air filter case cover by unhooking the air filter case cover holders. 1. Air filter element 5. Pull off the air filter element lock plate, and then remove the sponge material from the air 1.
Page 131 2. Sponge material damaged. 3. Air filter element lock plate 9. Apply Yamaha foam air filter oil or other qual- 6. Wash the sponge material gently but thor- ity foam air filter oil to the sponge material. oughly in solvent. WARNING! Always use parts cleaning solvent.
Page 132: Cleaning The Spark Arrester
case. Never operate the engine with the air filter element removed. Doing so would al- low unfiltered air to enter the engine, caus- ing rapid engine wear and possible engine damage. Additionally, the fuel injection system would be affected resulting in poor engine performance and possible over- heating.
Page 133: V-Belt Case Drain Plug
V-belt case, remove the V-belt case drain plug to drain the water from the case. If water drains from the V-belt case after removing the plug, have a Yamaha dealer check the ATV as the water may affect other engine parts. 9-40...
Page 134: Adjusting The Throttle Lever Free Play
The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the inter- vals specified in the periodic maintenance chart. 1. Rubber cover 2.
Page 135: Checking The Front Brake Pads And Rear Brake Friction Plates
The rear brake friction plates must be checked peared, have a Yamaha dealer replace the brake and, if necessary, replaced by a Yamaha dealer at pads as a set. the intervals specified in the periodic maintenance chart.
Page 136: Checking The Brake Fluid Level
Therefore, be sure to check the brake pads for wear and the brake system for leakage. If the brake fluid level suddenly goes down, have a Yamaha dealer check the brake sys- tem before further riding. EWB02721 WARNING Improper maintenance can result in loss of braking ability.
Page 137: Changing The Brake Fluid
There should be no free play at the brake lever  Oil seals: Replace every two years. end. If there is free play, have a Yamaha dealer in-  Brake hoses: Replace every four years. spect the brake system.
Page 138 Adjusting the brake lever free play Measure the brake lever free play as shown. 1. Locknut 2. Brake lever free play adjusting bolt 1. Brake lever free play 2. To increase the brake lever free play, turn the brake lever free play adjusting bolt in direction Brake lever free play: (a).
Page 139 1. Brake cable adjuster locknut 1. Brake pedal free play 2. Brake lever free play adjusting nut 3. Rubber cover Brake pedal free play: 12.0–17.0 mm (0.47–0.67 in) 5. Loosen the brake cable adjuster locknut. 6. To increase the brake lever free play, turn the If the free play is incorrect, adjust it as follows.
Page 140: Axle Boots
Check the axle boots for tears or damage. If any damage is found, have them replaced by a Yamaha dealer. 1. Brake pedal free play adjusting nut 2. Locknut 3. To increase the brake pedal free play, turn the brake pedal free play adjusting nut in direc- tion (a).
Page 141: Brake Light Switches
If a cable is damaged or does not move lows, but the front brake light switch should be ad- smoothly, have a Yamaha dealer check or replace justed by a Yamaha dealer. Turn the rear brake light switch adjusting nut while holding the brake light switch in place.
Page 142: Checking And Lubricating The Front And Rear Brake Levers
EWB02582 Recommended lubricants: WARNING Front brake lever:  Inspect cables frequently and replace if Silicone grease damaged. Corrosion can result when the ca- Rear brake lever: ble sheaths become damaged, and cables Lithium-soap-based grease can also become frayed or kinked, which could restrict the operation of controls and Front brake lever lead to an accident or injury.
Page 143: Checking And Lubricating The Brake Pedal
Yamaha dealer check the wheel hub bearings. To access the brake pedal pivot, remove panel G. (See page 9-9.)
Page 144: Checking The Stabilizer Bushes
The rear knuckle pivots must be lubricated at the or damage at the intervals specified in the periodic intervals specified in the periodic maintenance maintenance chart. chart. Have a Yamaha dealer replace the stabilizer bush- es if necessary. Recommended lubricant: Lithium-soap-based grease 9-51...
Page 145: Lubricating The Steering Shaft
For parts equipped with a grease nipple, use a grease gun. EBU25096 Lubricating the steering shaft The steering shaft must be lubricated by a Yamaha dealer at the intervals specified in the pe- riodic maintenance chart. Recommended lubricant: Lithium-soap-based grease 9-52...
Page 146: Battery
 It is recommended to have the battery serviced KEEP OUT OF REACH OF CHILDREN. by a Yamaha dealer. To remove the battery 1. Remove panel A. (See page 9-9.) 2. Remove the front carrier by removing the bolts.
Page 147 3. Remove the battery holding plate by remov- ing the nuts. 4. Disconnect the negative battery lead first, then the positive battery lead by removing their bolt. NOTICE: When removing the bat- tery, the main switch must be off, and the negative lead must be disconnected be- fore the positive lead.
Page 148 ECB00622 ECB00942 NOTICE NOTICE  Always keep the battery charged. Storing the Never attempt to open the battery or remove the battery cell seals, as this would permanent- battery in a discharged state for an extended ly damage the battery. period of time will cause permanent battery damage.
Page 149: Replacing A Fuse
5. Install the panel.  Make sure the positive and negative battery leads are installed as shown.  Fully charge the battery before installing it. EBU30525 Replacing a fuse 1. Positive battery lead (red) 2. Negative battery lead (black) 3. Install the battery holding plate by installing the nuts.
Page 150 YFM70KDXR YFM70KPAR / YFM70KPHR / YFM70KPSR 1. Headlight fuse 1. Headlight fuse 2. Signaling system fuse 2. Radiator fan motor fuse 3. Radiator fan motor fuse 3. Signaling system fuse 4. Ignition fuse 4. Ignition fuse 5. Auxiliary DC jack fuse 5.
Page 151 1. Turn off all electrical systems. (See page 5-1.) Specified fuses: 2. Remove panel A. (See page 9-9.) Main fuse: 3. Remove the blown fuse, and then install a 40.0 A new fuse of the specified amperage. Headlight fuse: WARNING! Always use a fuse of the spec- 10.0 A (YFM70KDXR) ified rating, and never use a substitute ob- 15.0 A (YFM70KPAR, YFM70KPHR,...
Page 152: Replacing A Headlight Bulb
5. If the fuse immediately blows again, have a Yamaha dealer check the vehicle. 6. Install the panel. EBU34223 Replacing a headlight bulb If a headlight bulb burns out, replace it with the specified bulb as follows. Left and right headlight bulbs 1.
Page 153 4. Remove the burnt-out bulb. 7. Install the bulb cover and the cover at the rear 5. Place a new bulb into position. NOTICE: Do of the headlight. NOTICE: Make sure the not touch the glass part of the bulb. Oil bulb cover is securely fitted over the sock- from your fingers or other contamination et and seated properly.
Page 154 4. Remove the burnt-out bulb. 5. Place a new bulb into position. NOTICE: Do not touch the glass part of the bulb. Oil from your fingers or other contamination will adversely affect the transparency of the glass, luminosity of the bulb, and bulb life.
Page 155: Adjusting A Headlight Beam
9. Adjust the handlebar-mounted light beam if necessary. EBU25553 Adjusting a headlight beam ECB00691 NOTICE It is advisable to have a Yamaha dealer make this adjustment. To raise a headlight beam, turn the headlight beam adjusting screw in direction (a). 9-62...
Page 156: Replacing The Brake/Tail Light Bulb
YFM70KPAR / YFM70KPHR / YFM70KPSR 1. Brake/tail light bulb holder 1. Handlebar-mounted light beam adjusting screw 2. Remove the burnt-out bulb by pushing it in EBU25615 and turning it counterclockwise. Replacing the brake/tail light bulb If the brake/tail light bulb burns out, replace it as follows.
Page 157: Removing A Wheel
3. Insert a new bulb into the bulb holder, push it EBU36243 Installing a wheel in, and then turn it clockwise until it stops. 1. Install the wheel with the arrow mark pointing 4. Install the bulb holder (together with the bulb) in the forward rotating direction of the wheel, by turning it clockwise.
Page 158: Troubleshooting
The following troubleshooting charts represent quick and easy procedures for checking these vi- tal systems yourself. However, should your ATV require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary 1. Tapered nut tools, experience, and know-how to service the 2.
Page 159: Troubleshooting Charts
Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the ATV. Check the compression. 4. Compression The engine does not start. There is compression.
Page 160 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK.  Tap water can be used in an emergency. Change to the recommended coolant as soon as possible.
Page 161: Cleaning And Storage
EBU25861 CLEANING AND STORAGE and deterioration of wheel bearings, EBU25883 Cleaning brakes, transmission seals and electrical Frequent, thorough cleaning of your ATV will not devices. Many expensive repair bills have only enhance its appearance but will improve its resulted from improper high-pressure de- general performance and extend the useful life of tergent applications such as those avail- many components.
Page 162: Storage
8. If the headlight lens has fogged up, start the 3. Fill up the fuel tank and add fuel stabilizer (Fu- engine and turn on the headlight to help re- el Med Rx if available), and then run the en- move the moisture.
Page 163 6. Put the frame on stands or blocks to raise all wheels off the ground. (Alternatively, turn the wheels each month to prevent the tires from degrading in one spot.) 7. Cover the muffler outlet with a plastic bag to prevent moisture from entering it.
Page 164: Specifications
EBU25964 SPECIFICATIONS Dimensions: Number of cylinders: Single cylinder Overall length: Displacement: 2070 mm (81.5 in) 686 cm³ Overall width: Bore × stroke: 1180 mm (46.5 in) 102.0 × 84.0 mm (4.02 × 3.31 in) Overall height: Starting system: 1240 mm (48.8 in) Electric starter Wheelbase: Engine oil:...
Page 165 Front tire: 2.10 L (2.22 US qt, 1.85 Imp.qt) Size: Final gear oil: AT25 x 8-12 Type: Manufacturer/model: Yamaha Friction Modified Plus Shaft Drive Oil (Part No.: MAXXIS/MU19 ACC-SHAFT-PL-32) Rear tire: Quantity: Size: 0.52 L (0.55 US qt, 0.46 Imp.qt)
Page 166 Front brake: Type: Hydraulic disc brake Rear brake: Type: Mechanical wet multiple disc brake Front suspension: Type: Double wishbone Rear suspension: Type: Double wishbone Electrical system: System voltage: 12 V Battery: Model: YTX20L-BS Voltage, capacity: 12 V, 18.0 Ah Lights: Headlight: T19L, 30.0 W/30.0 W Handlebar-mounted light:...
Page 167: Consumer Information
EBU25984 CONSUMER INFORMATION EBU29663 Vehicle Emission Control Information label The Vehicle Emission Control Information label is affixed at the location in the illustration. This label shows specifications related to exhaust emissions as required by federal law, state law and Environ- ment Canada.
Page 168: Noise Regulation (For Usa)
EBU26062 Noise regulation (for USA) TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
Page 169: Maintenance Record
EBU36901 Maintenance record Copies of work orders and/or receipts for parts you purchase and install will be required to document maintenance done in accordance with the warranty. The chart below is printed only as a reminder to you that the maintenance work is required. It is not acceptable proof of maintenance work. MAINTENANCE INTERVAL DATE OF SERVICING DEALER...
Page 170: Yamaha Motor Corporation, U.s.a. 2020 And Later Model Atv Limited Warranty (For Usa)
EBU30973 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL ATV LIMITED WARRANTY (for USA) Yamaha Motor Corporation, U.S.A. hereby warrants THE CUSTOMER’S RESPONSIBILITY under this YAMAHA MOTOR CORPORATION, U.S.A. MAKES that new Yamaha ATVs purchased from warranty shall be to:...
Page 171 Attention: Warranty Department 3. Each Yamaha ATV dealer is held responsible for his setup, service and war- ranty repair work. This will ensure that Yamaha Motor Corporation, U.S.A. has an up-to-date registration record in accordance with federal law.
Page 172: Yamaha Extended Service (Y.e.s.) (For Usa)
Y.E.S. coverage is transferable to a new owner if you shows in the comprehensive coverage benefits. There sell or trade in your ATV. That can make your Yamaha are no mileage limitations. Coverage isn’t limited to “moving par ts” or the “drive train” like many other plans.
Page 173 Yamaha. See your dealer today! YAMAHA EXTENDED SERVICE A special note: If visiting your dealer isn’t convenient, contact Yamaha with your VIN number (vehicle identification number). We’ll be happy to help you get the Y.E.S. coverage you need. Yamaha Service Marketing P.O. Box 6555...
Page 174: Index
INDEX Accessories and loading ..........7-6 Differential gear lock, indicators (YFM70KPAR / Accessories, DC jack ...........5-29 YFM70KPHR / YFM70KPSR) ........5-6 Air filter element, cleaning ..........9-36 Differential gear oil ..........6-3, 9-26 Axle boots ..............9-47 Drive lever 2WD/4WD (YFM70KDXR) ......5-17 Drive select lever ............
Page 175 Headlight bulb, replacing ..........9-59 Owner’s Manuals ............9-2 High beam indicator light ..........5-3 High-range indicator light (YFM70KPAR / Panels, removing and installing ........9-9 YFM70KPHR / YFM70KPSR) ........5-3 Park indicator light ............5-3 Parking ................7-5 Identification numbers ........... 1-1 Parking on a slope ............
Page 176 Trailer hitch (YFM70KPAR / YFM70KPHR / YFM70KPSR) .............5-28 Troubleshooting ............9-65 Troubleshooting charts ..........9-66 Valve clearance ............9-41 V-belt case drain plug ..........9-40 Vehicle Emission Control Information label ....12-1 Vehicle identification number .........1-1 Warranty, extended (for USA) ........12-6 Warranty, limited (for USA) ...........12-4 Wheel hub bearings, checking ........9-50 Wheel, installing ............9-64 Wheel, removing ............9-64...
Page 177 EBU30393 For your best ownership experience, think Genuine Yamaha! Genuine Yamaha Parts – Genuine Yamaha replacement parts are the exact same parts as the ones originally equipped on your vehicle, providing you with the performance and durability you have come to expect.
Page 178 WARNING Improper ATV use can result in SEVERE INJURY or DEATH. ALWAYS USE NEVER USE NEVER CARRY NEVER USE AN APPROVED ON PUBLIC PASSENGERS WITH DRUGS HELMET AND ROADS OR ALCOHOL PROTECTIVE GEAR NEVER operate: ALWAYS without proper training or instruction. use proper riding techniques to avoid at speeds too fast for your skills or the vehicle overturns on hills and rough...

Yamaha YFM70KPSR 2024 Owner's Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Yamaha YFM70KPSR 2024

Summary of Contents for Yamaha YFM70KPSR 2024

Table of Contents
