Operation Manual
Specifications
MODEL NO.
NF2502X4
Max. P.S.I.
120
70-120
Operating Pressure
Range
1/4" NPT
Air Inlet
Weight
4.66
10.25
Height
Length
11.75
Width
3
Type of Fastener
Finish Nail
16 Gauge
Fastener Lengths
See page 17
Fastener Capacity
110 pcs.
This manual contains information that is important for you to know and
understand. This information relates to protecting YOUR SAFETY and
PREVENTING EQUIPMENT PROBLEMS. PLEASE READ THIS MANUAL.
DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615
MG-NS2X4A
7/16/99
Nailer/Stapler
SNC1002X4
NB2002X4
120
120
70-120
70-120
1/4" NPT
1/4" NPT
2.3
2.6
7.5
8.1
11.3
9
2.25
2
Narrow Crown
Brad Nail
Staple 18 Gauge
18 Gauge
See page 18
See Page 19
150 pcs.
110
NB1252X4
NBSNC2X4
120
120
70-120
57-110
1/4" NPT
1/4" NPT
2.55
3.3
7.75
9.68
9.75
9.72
2.25
2.44
Brad Nail
Brad Nail 18 Gauge/
18 Gauge
Narrow Crown
Staple 18 Gauge
1/2" - 1 1/2"
See page 20
See page 21
110 pcs.
100 pcs.
Advertisement
Table of Contents
Related Manuals for DeVillbiss Air Power Company 2by4 Contractor Series
Summary of Contents for DeVillbiss Air Power Company 2by4 Contractor Series
-
Page 1: Specifications
Nailer/Stapler Operation Manual Specifications MODEL NO. NF2502X4 SNC1002X4 Max. P.S.I. 70-120 Operating Pressure Range 1/4" NPT Air Inlet Weight 4.66 10.25 Height Length 11.75 Width Type of Fastener Finish Nail Narrow Crown 16 Gauge Staple 18 Gauge Fastener Lengths See page 17 See page 18 Fastener Capacity 110 pcs. -
Page 2: Table Of Contents
TABLE OF CONTENTS Tool Specifications ... Front Cover Table of Contents ... 2 Limited Warranty ... 3 Safety Guidelines & Warning Chart ... 4 Lubrication and Maintenance ... 7 Recommended Hook-up ... 9 Contact Trip Safety Mechanism ... 9 Operating A Contact Trip Tool Checking The Operation Of Contact Trip Safety Mechanism Loading The Tool ... -
Page 3: Limited Warranty
LIMITED WARRANTY ONE YEAR FROM DATE OF PURCHASE All merchandise manufactured by DeVilbiss Air Power Company/ExCell Manufacturing is warranted to be free of defects in workmanship and material which occur during the first year from the date of purchase by the original purchaser (initial user). -
Page 4: Safety Guidelines & Warning Chart
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information URGENT SAFETY INFORMATION - A relates to protecting YOUR HAZARD THAT WILL CAUSE SERIOUS SAFETY and PREVENTING INJURY OR LOSS OF LIFE. EQUIPMENT PROBLEMS. - Page 5 Risk of head injury. HAZARD TO LOOK FOR WHAT COULD HAPPEN Metal fragments, fasteners, or other Injury to eyes, head and hearing material could be projected against head or into eyes resulting in serious injury or property damage. Contin- ued exposure to an operating tool can result in permanent hearing dam- age.
- Page 6 Risk from flying objects. HAZARD TO LOOK FOR Fasteners could ricochet or be Injury to self or others in the work area. propelled causing serious injury or property damage. When working along edges or next to voids in work surface, the con- tact trip safety mechanism could be depressed and allow the tool to discharge a fastener into the air...
-
Page 7: Lubrication And Maintenance
LUBRICATION AND MAINTENANCE Do not store the tool in cold weather. Frost or ice can form on the operating valves or mechanisms and the tool may not operate correctly. In cold weather operation (near or below freezing), DO NOT USE a permanent antifreeze such as ethylene glycol for a cold weather lubricant. - Page 8 Figure 3 Regulator Air Flow Oiler Filter NOTE Excessive oil will damage o-rings and seal of tool. If in-line oiler is used, manual lubrication through the air inlet is not required on a daily basis. Do not use any type of flammable gases or oxygen as a power source for the tool.
-
Page 9: Recommended Hook-Up
RECOMMENDED HOOK-UP The following illustration shows the proper hook-up which will help prolong the life of the Tool. MALE QUICK NAILER CONNECTOR FEMALE (Supplied with Tool) QUICK COUPLER HOSE (3/8" I.D.) CONTACT TRIP SAFETY MECHANISM 2X4 CONTRACTOR SERIES Never keep the trigger pulled on contact trip tools when carrying or holding the tool. -
Page 10: Operating A Contact Trip Tool
OPERATING A CONTACT TRIP TOOL: Requires finger to be off the trigger and the nose of the Tool to be placed on the work surface. The contact trip safety mechanism is then depressed against the work surface and the trigger pulled to drive a fastener. - Page 11 NOTE Use DeVilbiss Air Power fasteners or equivalent for proper performance of tool. See page 17-20 for fastener information. Handle the tool carefully. Respect the tool as a working implement and always as- sume the tool contains fasteners: a. Never use the tool as a toy and engage in horseplay.
-
Page 12: Operating The Tool
OPERATING THE TOOL READ THIS MANUAL AND UNDERSTAND ALL SAFETY WARNINGS AND INSTRUC- TIONS BEFORE OPERATING TOOL. Protect your eyes and ears. Wear Z87 safety glasses with side shields. Wear hearing protection. Employers and users are responsible for ensuring the user or anyone near the tool uses the prescribed safety equipment. -
Page 13: Clearing A Jam From The Tool
CLEARING A JAM FROM THE TOOL Disconnect tool from air compressor before adjusting, clearing jams, servicing, relocating and during non-operation. FASTENER JAMMED IN FASTENER DISCHARGE AREA: 1. Disconnect tool from air hose. 2. NF2502X4, NB1252X4, NB2002X4, NBSNC2X4 Release the magazine latch to open the magazine. - Page 14 FASTENER JAM INSIDE MAGAZINE 1. Disconnect tool from air hose. 2. NF2502X4, NB1252X4, NB2002X4, NBSNC2X4 Release the magazine latch to open the magazine. Magazine Latch SNC1002x4 Pull feeder shoe back into "locked" position. Feeder 3. Remove jammed fasteners. 4. Reload fasteners into magazine. Refer to Loading the Tool section in this manual.
-
Page 15: Troubleshooting Guide
TROUBLESHOOTING GUIDE Stop using the Tool immediately if any of the following occur. Serious personal injury could occur. Warranty repairs or replacements must be performed by a DeVilbiss Air Power Authorized Service Center Only. PROBLEM Air leaking at trigger valve Seals in trigger valve housing area. - Page 16 TROUBLESHOOTING GUIDE (cont'd) PROBLEM Fasteners are jammed in Worn/damaged feed pawl. tool. Worn/damaged feed pawl spring. Fasteners are not correct size. Fasteners are bent. Nail height setting incorrect. Nailer/Stapler misfires or Air pressure regulated too high. sinks two nails/staples at the same time.
-
Page 17: Nf2502X4
NF2502X4 6 & 7MM 1/4" NPT INLET COMBINATION PLUG (AC100) CRESCENT WRENCH FINISH NAIL FASTENERS Tool 2X4 Part Number NFF12525 NFF15025 NFF17525 NF2502X4 NFF20025 NFF22525 NFF25025 PAGE 17 SAFETY GLASSES LUBRICATING OIL FINISH NAILER 3 4 5mm ALLEN WRENCHES ” 2”... -
Page 18: Snc1002X4
SNC1002X4 NARROW 3 & 4 CROWN ALLEN INLET PLUG STAPLE WRENCHES FASTENER Tool 2X4 Part Number SNCF06350 SNC1002X4 SNCF07550 SNCF10050 SAFETY GLASSES 1/4" NPT NARROW LUBRICATING (AC100) CROWN STAPLER Steel Driver Series Description Qty per Box Comparable Part 5/8" Staple 5000 3/4"... -
Page 19: Nb2002X4
NB2002X4 LUBRICATING ALLEN WRENCHES 1/4" NPT INLET Plug (AC100) 5/8" Tool 2X4 Part Number NBF07550 NBF10050 NBF12550 NB2002X4 NBF15050 NBF17550 NBF20050 SAFETY GLASSES BRAD NAIL FASTENERS BRAD NAILER Steel Driver Series Description Qty per Box Comparable Part 3/4" Brad 5000 1"... -
Page 20: Nb1252X4
NB1252X4 LUBRICATING ALLEN WRENCHES 1/4" NPT INLET PLUG (AC100) Tool 2X4 Part Number NBF06350 NBF07550 NB1252X4 NBF10050 NBF12550 SAFETY GLASSES BRAD NAIL FASTENERS BRAD NAILER Steel Driver Series Description Qty per Box Comparable Part 5/8" Brad 5000 3/4" Brad 5000 1"... -
Page 21: Nbsnc2X4
NBSNC2X4 LUBRICATING 4MM 3MM SIGNATURE ALLEN SAFETY WRENCHES GLASSES 3/4” 5/8” 1” ” ” 3/8” Tool Range ” Tool 2X4 Part Number SNCF06350 SNCF07550 SNCF10050 SNCF12550 SNCF15050 NBSNC2X4 NBF06350 NBF07550 NBF10050 NBF12550 NBF15050 PAGE 21 NARROW CROWN STAPLE & BRAD NAIL FASTENERS COMBINATION BRAD NAILER/ NARROW CROWN STAPLER... -
Page 22: Repair Kits Available
REPAIR KITS AVAILABLE NF2502X4 K-0521 Top Repair Kit K-0522 Bottom Repair Kit SNC1002X4 and NB1252X4 K-0525 Top Repair Kit K-0526 Bottom Repair Kit PAGE 22 K-1664 Driver Blade Kit K-0523 Trigger Repair Kit K-9025 Driver Blade Kit for SNC1002x4 K-1832 Drive Blade Kit for NB1252x4 K-0527 Trigger Repair Kit... - Page 23 REPAIR KITS AVAILABLE NB2002X4 K-0517 Top Repair Kit K-1850 Driver Blade Kit K-0518 Bottom Repair Kit K-0519 Trigger Repair Kit NBSNC2X4 B340-06 Top Repair Kit BN2B-10 Driver Blade Kit B232-23 Bottom Repair Kit B251-02 Trigger Repair Kit PAGE 23...
- Page 24 Nailer/Stapler Operation Manual Call our Toll Free Number 1-800-888-2468, Ext 2, then 1, to obtain the location of the nearest Authorized Service Center for ordering repair parts and for warranty repairs. When ordering repair parts from your local Authorized Service Center, always give the following information: •...
