- Page 1 AIR CONDITIONER Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at all times. TYPE: PORTABLE AIR CONDITIONER LP0524WFR LP0624WFR EN ENGLISH ES ESPAÑOL www.lg.com Rev.00 Copyright © 2023 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS 3 SAFETY INSTRUCTIONS 19 MAINTENANCE IMPORTANT SAFETY INSTRUCTIONS Emptying the Water Collection Tank Cleaning the Case Cleaning the Air Filter 8 PRODUCT OVERVIEW 20 TROUBLESHOOTING Key Parts and Components Before Calling for Service 9 INSTALLATION 22 WARRANTY Electrical Information 10 Before Installing the Air Conditioner... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. This is the safety alert symbol. - Page 4 Do not tamper with controls. If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug it immediately, and contact an LG Electronics Customer Information Center. straight out from the outlet. Do not grasp the power cord or touch the appliance controls with wet hands.
- Page 5 If water enters the product, turn off the power at the main circuit, then unplug the product and call for service. If the product has been submerged, contact the LG Electronics Customer Information Center for instructions before resuming use. Unplug the product if it will not be used for long periods.
- Page 6 Never spray the product with water or use strong cleaning agents or solvents when cleaning the air conditioner. Use a soft cloth to avoid scratching the exterior. To clean the interior, contact the LG Electronics Customer Information Center or a dealer. Using harsh detergents may cause corrosion or damage to the unit.
- Page 7 SAFETY INSTRUCTIONS Caution, risk of fire ● The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specified for operation. ● The appliance shall be stored so as to prevent mechanical damage from occurring. ●...
-
Page 8: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Key Parts and Components temperature, and WIRELESS REMOTE CONTROL Fan Speed The remote control allows you to adjust the temperature and operate most functions of the air conditioner from across the room. using the bottom drain port. NOTE Features may change depending on model. -
Page 9: Installation
INSTALLATION INSTALLATION WARNING Electrical Information This appliance should be installed in Power cord may include a current interrupter accordance with the National Electrical device. TEST and RESET buttons are provided Code. on the plug case. The device should be tested on Use of extension cords could cause serious TEST button injury or death. -
Page 10: Before Installing The Air Conditioner
INSTALLATION Before Installing Wireless Remote Control the Air Conditioner Inserting Batteries If the display screen of the remote control begins to fade, replace the batteries. Insert AAA (1.5 V) batteries before using the remote control. Remove the cover on the back of the remote control. -
Page 11: Preparing For Installation
INSTALLATION Preparing for Installation Basic Installation Materials Supplied Diffuser Flexible Vent Mounting Hose Bracket 1 Panel H (18") 1 Panel I (9 11/16") 1 Panel J (18") 1 Panel K (18") Window vent pane Extension panel Extension panel Extension panel 2 Long adhesive 1 Non-adhesive 2 Short adhesive... -
Page 12: Selection Of Installation Location
INSTALLATION Selection of Installation Location 20″ NOTE The length of the flexible vent hose is specially designed according to the specification of this product. Do not replace or extend it with a hose that is not specifically designed for use with this product as this could cause malfunction. -
Page 13: Window Vent Panel And Extensions
INSTALLATION Window Vent Panel and Extensions The window installation kit allows you to install the air conditioner in most vertical-sliding windows 18″ to 50″ wide, or horizontal-sliding windows from 18″ to 50″ high. Panel Length Panel I ( 9 ″ Fig. -
Page 14: Installing Vent Panels
INSTALLATION Installing Vent Panels Long adhesive foam seal ↓ ↑ Long adhesive foam seal Attach the long adhesive foam weather Insert the panel assembly in the bottom sash seals to the top and bottom sides of the channel. Use care when installing the window vent panel assembly. - Page 15 INSTALLATION Slot Screw Insert Align the tabs on the diffuser with slots in the Insert the screw in the hole in the diffuser to outer slide section. Insert the diffuser into the prevent the diffuser from sliding out of the opening in the vent panel.
-
Page 16: Operation
OPERATION OPERATION Control Panel and Remote Control Fan Speed NOTE • Available functions may vary by model. • The number and location of LEDs on the control panel may vary by model. - Page 17 OPERATION Fan Speed Power ( Turns the air conditioner on and off. Press repeatedly to toggle the fan speed A chime sounds to confirm you have turned between High and Low settings. An LED it on or off. illuminates to indicate the selected fan speed.
- Page 18 OPERATION Auto Swing Removing Condensation Buildup This functions may not be supported, depending on the model. Condensation can build up inside the unit when the Cool and Dry modes are used. The fan can be set to run for a short period Light after the product is turned off to help keep Sets the display screen brightness:...
-
Page 19: Maintenance
MAINTENANCE MAINTENANCE Cleaning the Air Filter The air filters should be cleaned every two weeks. Depending on indoor air quality, more WARNING frequent cleaning may be needed. A dirty air filter will decrease airflow and reduce Before cleaning or performing maintenance, efficiency. -
Page 20: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service. Problem Possible Cause Solutions... - Page 21 TROUBLESHOOTING Problem Possible Cause Solutions obstruct the air conditioner from Air conditioner The cooling coils are iced over. properly cooling the room. Set the freezing up. mode control at High Fan or High Cool. This is normal for a short period in Water collects in Moisture removed from air and areas with little humidity;...
-
Page 22: Warranty
If during in-home service repair cannot be completed, it may be necessary to remove, repair and return the product. If in-home service is unavailable, LG may elect, at our option, to provide for transportation of our choice to and from an LG authorized service center. - Page 23 HOW TO OBTAIN WARRANTY SERVICE & ADDITIONAL INFORMATION: Call 1-800-243-0000 or visit our website at www.lg.com. Mail to: LG Customer Information Center (ATTN: CIC) 201 James Record Road, Huntsville, AL 35824...
-
Page 24: Arbitration Notice
The AAA Rules are available online at www.adr.org/consumer. Send a copy of your written demand for arbitration, as well as a copy of this provision, to the AAA in the manner described in the AAA Rules. You must also send a copy of your written demand to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue Englewood Cliffs, NJ 07632. - Page 25 LG Customer Information Center Centro de Información al Cliente de LG 1-800-243-0000 Register your product Online! Centro de Información al Cliente de LG LG Electronics Inc. www.lg.com 111 Sylvan Ave., Englewood Cliffs, NJ 07632...
