Summary of Contents for Sierra AX2

  • Page 2 Thank you once again for choosing Sierra LSV. We’re excited to be a part of your adventures and cant wait to see the memories you create with your new vehicle.

  • Page 3: Table Of Contents

    Notes and Contact Info........47 Sierra LSV Owner’s Manual...

  • Page 4: Introduction And Safety

    Complete Spec Table can be found on pages 40-41 NOTE: This manual represents the most current information at the time of publication. Sierra LSV is continually working to further improve its vehicles and other products. These improvements may affect servicing procedures.
  • Page 5 • Always maintain adequate distance between vehicles around you. • Always reduce speed in wet/Icy roads or areas. • Always use caution entering sharp or blind turns. • Always use extreme caution where pedestrians are present . Sierra LSV Owner’s Manual...
  • Page 6 Do NOT navigate slopes steeper than 18% grade. Further information can be found in your Owner’s Manual included with this vehicle. Sierra LSV Owner’s Manual...
  • Page 7 Owner’s Manual included with this vehicle. IMPORTANT: When turning the LCD display on by the key-switch this notice will appear. Please read through and acknowledge the details called out in this message before operating the vehicle. Sierra LSV Owner’s Manual...
  • Page 8 Do NOT navigate slopes steeper than 18% grade. Further information can be found in your Owner’s Manual included with this vehicle. Sierra LSV Owner’s Manual...
  • Page 9 • A CAUTION with the safety alert symbol indicates a hazard or unsafe practice that could result in minor personal injury. CAUTION • A CAUTION without the safety alert symbol indicates a potentially hazardous situation that could result in property damage. Sierra LSV Owner’s Manual...

  • Page 10: General Warnings

    • The vehicle will not provide protection from lightning, flying objects, or other storm-related hazards. If caught in a storm while driving a SIERRA LSV, exit the vehicle and seek shelter in accordance with applicable safety guidelines for your location.
  • Page 11 2. Connect the battery cables, positive (+) cable first. 110 in·lb 3. Tighten battery terminals to (12.4 N·m). 4. Turn battery power ON by pressing button shown below. LED light will appear as shown Image C Battery Powered ON/OFF Button Positive (+) Negative (-) Sierra LSV Owner’s Manual...
  • Page 12 Anyone using, repairing, or servicing the vehicle must understand and heed the safety symbols on the vehicle battery or batteries. MODEL IDENTIFICATION The serial number of each vehicle is printed on a decal mounted either on the driver side front frame or in the battery compartment. Sierra LSV Owner’s Manual...

  • Page 13: Before You Drive

    Additional Phone Charging Other Phone Call Mic and LCD Diagnostic. PHONE 2 amp wireless charger Note Some phone cases may obstruct charging CHARGE PAD More Speedometer, Battery gauge See next page for full features LCD DISPLAY Sierra LSV Owner’s Manual...
  • Page 14 Yellow 22% - 13% Red 12% - 0% Time 12 or 24 hr Normal Headlights Headlight Icon Headlight Icon High Beams (not shown) Turn Signal Icons Not Shown Motor amps Home Icon To app screen main page Sierra LSV Owner’s Manual...
  • Page 15 Before you drive aPPS SCREEN Home Screen SETTINGS PhoNE SCREEN mUSIC SCREEN Return to Speedometer BT id Sierra LSV Owner’s Manual...

  • Page 16: Controls And Indicators

    Press to engage Lights On/Off Twist forward to turn lights on. Push Lever Down Left Turn Signal Right Turn Signal Push Lever Up Press Button to engage Hazard switch Hi/Lo Beam Pull towards driver to engage Hi/Lo Beams. Sierra LSV Owner’s Manual...
  • Page 17 4. Brake lever release pre-attached in case of cart fault/ dead battery. Located at the motor brake, the lever can be pulled forward to release brake. You will still need to place cart in TOW mode as well. Only use lever in situations where there is no battery power. Sierra LSV Owner’s Manual...
  • Page 18 The brake pedal is the large pedal on the left. To slow or stop the vehicle, press the brake pedal with your foot. Electric vehicles use a special electrical system, which employs motor braking in Sierra LSV’s. In those modes, the vehicle operates...
  • Page 19 Controls and Indicators ACCELERATOR PEDAL AX1, AX2, and AX3 Accelerator Pedal Accelerator Pedal Must not be depressed when starting vehicle. BRAKE PEDAL AX1, AX2, and AX3 Brake Pedal Brake Pedal WARNING • The park brake will release automatically when the accelerator is pressed. The park brake is mounted to the motor and automatically engages when cart is at rest and/or key is switched to the off position.
  • Page 20 The USB port is not designed for the transfer of data. HIGH/LOW SPEED SWITCH LOCATION High/Low switch is located under the front seat AX1/AX2 on the controller cover. On the AX3/AX4 it is under the rear row seat on controller cover.

  • Page 21: Pre-Operation And Daily Safety Checklist

    PRE-OPERATION AND DAILY SAFETY CHECKLIST Each Sierra LSV vehicle has been thoroughly inspected and adjusted at the manufacturing facility; however, upon receiving your new vehicle(s), you should become familiar with its controls, indicators, and operation. Carefully inspect each vehicle to ensure that it is in proper working condition before accepting delivery.
  • Page 22 • Steering: The vehicle should be easy to steer and should not have any play in the steering wheel. • General: Listen for any unusual noises such as squeaks or rattles. Check the vehicle’s ride and performance. Have a Sierra LSV distributor/dealer or a trained technician investigate anything unusual.

  • Page 23: Driving Instructions

    • Do not drive the vehicle under tree limbs, bridges, tunnels, or other objects that are less than 80 inches (203 cm) from the ground. • Do NOT use a cellphone while operating the vehicle. Sierra LSV Owner’s Manual...

  • Page 24: Towing

    • Do not tow more than one Sierra LSV with another Sierra LSV. If more than one vehicle must be towed, an adequately powered vehicle (tractor or full sized truck) properly fitted, with a tow hitch height of 11 inches (28 cm) should be used.

  • Page 25: Transporting On A Trailer

    Only certified technicians should do this task. • Do not tow a Sierra LSV vehicle behind a passenger vehicle or truck on a public road unless it is on an approved trailer. • The vehicle to be towed should be properly secured to the trailer, with the Drive/Reverse or switch in the NEUTRAL position, the key switch the off position.

  • Page 26: Storage

    • Batteries in a low state of charge will freeze at low temperatures. • To avoid exposing electrical components to moisture and subsequent damages, do not use any type of pressure washing or steam cleaning equipment to wash the vehicle. Sierra LSV Owner’s Manual...
  • Page 27 13. Ensure Power Switch on battery is turned OFF 14. If disconnecting the battery for storage, disconnect negative (-) battery cable and secure it in a way that ensures the cable will contact with battery terminal. Sierra LSV Owner’s Manual...
  • Page 28 • When returning from storage , press the power button on the battery and check the state of charge and temperature in the battery app. • If the battery temperature is below 32 C, DO NOT attempt to charge the battery. Charging below freezing temperatures can cause damage to the battery and create risk of fire. Sierra LSV Owner’s Manual...
  • Page 29 Contact your local Sierra LSV distributor/dealer to perform all repairs and semiannual and annual periodic service. • If any problems are found during scheduled inspection or service, do not operate the vehicle until repairs are made.

  • Page 30: Periodic Service Schedule

    The PSI is on the side wall. Thoroughly wash vehicle including General vehicles the underside. Initial (one-time) inspection by owner or Battery Perform General Safety Inspection trained technician after six weeks of use. Table continued on next page. Sierra LSV Owner’s Manual...
  • Page 31 WARNING If any problems are found during scheduled inspection or service, do not operate the vehicle until repairs are made. Failure to make necessary repairs could result in fire, property damage, severe personal injury, or death. Sierra LSV Owner’s Manual...

  • Page 32: Battery Charger

    WARNING • Only trained technicians should repair or service the charger. Contact your nearest authorized Sierra LSV distributor/ dealer. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 33 Using a different battery type (different brand, different capacity, etc.) can cause under or overcharging and subsequent battery damage unless the charger is first reprogrammed with a new charging algorithm. Sierra LSV only recommends OEM replacement battery. Contact your authorized Sierra LSV dealer/distributor with any questions about battery and charger compatibility or algorithm updates.
  • Page 34 Replacement charger safety decals are available. Contact your local authorized Sierra LSV distributor/dealer. DIAGNOSTIC PORT The charger has a USB port for use by Sierra LSV authorized technicians for data transfer, reconfguration, and updates. Keep the USB port cover in place when the port is not in use.
  • Page 35 WD- 40® brand spray lubricant. The plug should then be inserted and removed several times to ensure ease of insertion, ease of removal, and good electrical contact. Sierra LSV Owner’s Manual...
  • Page 36 The charger also will function outside of that range down to 85 VAC and up to 270 VAC although charging times will be longer. Outside of the 85 to 270 VAC range, the charger will not operate. LONG-TERM STORAGE Sierra LSV chargers are designed to be left connected with AC power to the charger during off-season or long term storage. Sierra LSV Owner’s Manual...
  • Page 37 Vehicles should be restricted to 40 to 50 amp hours of discharge or 36 holes of golf (or 40 minutes of private use) between charges until the batteries have been properly seasoned (50 to 70 charge cycles). For maximum battery life, Sierra LSV recommends that electric vehicles always be recharged after 40 to 50 amp hours of discharge or each night in order to avoid deeply discharging the batteries.
  • Page 38 NOTE: The charge cord shows a red LED that signals it has power, this is NOT the battery charge status. It will always show red. The charger itself will flash a code on charge status. See next page for more info. Sierra LSV Owner’s Manual...

  • Page 39: Charge Status Indicators

    Low temperature delay start, when the internal temperature Red- Green- yellow- yellow- yellow- yellow- yellow of the charger is lower than-2 CT C higher than-30°C, wait yellow- yellow- yellow 1~2 minutes and start the J Sierra LSV Owner’s Manual...

  • Page 40: Cleaning Vehicle And Info

    NoTE: Dispose of waste water properly. ACCESSORIES a complete line of parts and accessories is available from Sierra lSV. To find your local authorized Sierra lSV dealer, visit www.sierralsv.com. Care should be taken that these accessories are properly installed by trained technicians, and that they are used in the manner for which they were designed.
  • Page 41 SUBSEQUENT OWNER REGISTRATION In the event a vehicle is bought as a used vehicle, we strongly urge the new owner to register the vehicle with Sierra LSV. This will enable us to contact you if the need arises. Please send your name, address, and serial number(s) of the vehicle(s) to info@sierralsv.com.

  • Page 42: Vehicle Specifications

    Electrical System: Battery output-48V DC, through controller inverter to 48V AC Battery: 105ah Lithium ion battery Batteries: Dual 105ah Lithium ion battery Charger: Enpower Ch 4200 Series Smart Charger 15a, 48V STEERING/SUSPENSION/BRAKES STEERING: Self-adjusting rack and pinion Sierra LSV Owner’s Manual...
  • Page 43 15 to 25 mph (32 to 40 km/h) forward speed Standard seating capacity Trans-axle Gear Ratio 12.31:1 12.31:1 18 to 20 psig 18 to 20 psig front and Rear Tire Pressure (124 to 138 kPa ) (124 to 138 kPa ) Sierra LSV Owner’s Manual...

  • Page 44: Error Codes

    Current exceeding limit 2. Motor failure. Powered up when the gear is in D or R Restart the key switch when the gear is in N Powered up when the gear is in D or R Sierra LSV Owner’s Manual...

  • Page 45: Warranties

    SIERRA LSV LIMITED WARRANTY Sierra LSV hereby warrants to the Original Purchaser, as those terms are defined herein, and subject to the provisions, limitations and exclusions in this limited warranty, that its new vehicle or new component purchased from Sierra LSV or an Authorized Dealer or Distributor shall be free from defects in material and workmanship under normal use and service for the periods stated below, subject to the provisions, limitations and exclusions in this limited warranty.
  • Page 46 The provisions of this limited warranty shall not apply to failure due to the following conditions: 1. Battery 1.1. Improper charging of a vehicle due to the use of a battery charger model not approved by Sierra LSV for use with the vehicle.
  • Page 47 WARRANTY. In the event that another pre-printed warranty document, certificate or both offered by or through Sierra LSV at the time of sale of this vehicle (each an “Additional Warranty Document”) is deemed to conflict with the limitations or exclusions contained herein, the limitations and exclusions contained herein shall continue to apply to both this limited warranty statement and, to the maximum extent permitted by law, to each Additional Warranty Document.
  • Page 48 NO CONSEQUENTIAL DAMAGES IN NO EVENT SHALL SIERRA LSV BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS RELATED TO PROPERTY OTHER THAN THE VEHICLE, LOSS OF USE, LOSS OF TIME, INCONVENIENCE, OR ANY OTHER ECONOMIC LOSS.

  • Page 49: Notes And Contact Info

    NOTES Sierra LSV Contact info Website: www.sierralsv.com Email: info@sierralsv.com Phone: 1-877-877-5993 Address: 317 Industrial Blvd Thomasville, GA 31792 Sierra LSV Owner’s Manual...
