Summary of Contents for Prima PRWC403
- Page 1 Undercounter Wine Cooler Instruction Manual PRWC401 PRWC402 PRWC403 PRWC404...
- Page 2 INTRODUCTION Thank you for buying your new Wine Cooler. To ensure that you get the best results from your new purchase, we strongly suggest that you read this instruction manual thoroughly before use. This manual contains installation advice, usage instructions and other important facts about your Cooler.
- Page 3 WARNINGS - To prevent damaging the door gasket, make sure the door is fully open when pulling shelves out of the rail compartment. - The appliance must be positioned so that the plug is accessible. Release the electric cord and move your Cooler to its final location.
-
Page 4: Electrical Shock Hazard
- This appliance is intended to be used exclusively for the storage of wine. ELECTRICAL SHOCK HAZARD To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic precautions: - Read all instructions before using the wine cooler. - DANGER or WARNING: Risk of child entrapment. - Page 5 - The refrigerant of this appliance is R600a, flammable and explosive articles should not be put in or near the cabinet, to avoid the risk of fire or explosion. - This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or...
-
Page 6: Environmental Protection
ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is marked according to the European directive on Waste Electrical and Electronic Equipment (WEEE). -
Page 7: Installation
INSTALLATION Before using your wine cooler Remove the exterior and interior packing. IMPORTANT: Before connecting the wine cooler to the power source, let it stand upright for at least 12 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. - Page 8 WARNING: INCORRECT EARTHING CAN RESULT IN THE RISK OF ELECTRIC SHOCK Attention! Store wine in sealed bottles Do not overload the cabinet Do not open the door unless necessary Do not cover shelves with aluminium foil or any other shelf material which may prevent air circulation Should the wine cabinet be stored without use for long periods it is suggested, after careful cleaning, to leave the door ajar to allow air...
-
Page 9: Operating Your Wine Cabinet
OPERATING YOUR WINE CABINET Please use the cabinet within ambient temperatures between 16-32ºC, if the ambient temperature is higher or lower than this, it will cause the temperature to fluctuate in the cabinet, possibly preventing it from reaching 4-20ºC. SETTING THE TEMPERATURE To change the temperature Press the "+"... - Page 10 When you use the wine cooler for the first time or you restart the cooler after having been shut off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the LED readout.
-
Page 11: Control Panel
CONTROL PANEL Buttons Power -To switch the appliance on/off (press and hold this button for approximately 5 seconds) Light -Used to switch the internal light on/off “+” -Used to raise the temperature in 1ºC increments “-” -Used to lower the temperature in 1ºC increments TEMPERATURE ALARM If inner temperature is higher than 25°C and after lasting more than 24 hours, “E3”... -
Page 12: How To Change The Door Opening
HOW TO CHANGE THE DOOR OPENING This appliance has reversible doors but is delivered with a right hinged door. The left hand hinge kit comes with the unit (in the box), should you wish to reverse the hinge on your unit follow the directions below: 1 Screws 2 Hinge axis 3 Lower hinge 4 Door 5 Top hinge (Right) 6 Screws... - Page 13 Install and align the door. Move the screws（1）from left to the right side. Insert the plastic caps to cover the holes on the top right(8).
-
Page 14: Installing The Handle
INSTALLING THE HANDLE Remove the door gasket till you see the drilled holes by pulling from the top corner. (see below drawing). Fix the handle to the screws and push the gasket back into place. -
Page 15: Wine Bottle Stacking
WINE BOTTLE STACKING Stores max. 7 Bordeaux style bottles 750ml. - Page 16 Stores max.19 Bordeaux style bottles 750ml.
-
Page 17: Care And Maintenance
CARE AND MAINTENANCE Cleaning your wine cooler Turn off the power, unplug the appliance, and remove all items including shelves and rack. Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to 2 pints of water. -
Page 18: Moving Your Wine Cooler
Moving your wine cooler Remove all items. Securely tape down all loose items (shelves) inside your appliance. Wind the adjustable legs up to the base to avoid damage. Tape the door shut. Be sure the appliance stays secure in the upright position during transportation. -
Page 19: Problems With Your Wine Cooler
PROBLEMS WITH YOUR WINE COOLER You can solve many common wine cabinet problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling Primacare. TROUBLESHOOTING GUIDE Problem Possible Cause Not plugged in. -
Page 20: Recommended Storage Temperatures
DEFROSTING/CONDENSATION Your wine cabinet is designed with an “Auto-cycle” defrost system. When the RUN cycle is OFF, the refrigerated surface of the wine cabinet (interior rear wall) defrosts automatically. The defrosted water is channelled into a drain pan which is located at the back of the cabinet next to the compressor from where it evaporates. - Page 21 Care For more information on Prima appliances，please visit www.prima-appliances.uk/primacare For all your In-warranty service calls，phone 0844 576 6841...
