- Page 1 USER MANUAL INSTALLATION, CONNECTION AND CONFIGURATION OF AUTOMOTIVE DSP PROCESSORS RESOLUT A-DSP RESOLUT J-DSP RESOLUT T-DSP (version 1.3)
- Page 2 Congratulate you with purchasing of processor Resolut! Our goal is to suggest you a product with uncompromising sound quality and wide opportunity of setup. We are sure that during operation of our processor you will feel fully its advantages and get real pleasure.
-
Page 3: Table Of Contents
Principles of processor’s setup Software processor’s settings Expanded opportunities of software Resolut SRC remote controllers’ settings Volume control without using Resolut SRC remote controller Processors’ plugin Technical parameters and characteristics of Resolut A-DSP: Technical parameters and characteristics of Resolut J-DSP:... -
Page 4: General Recommendations And Precautions
GENERAL RECOMMENDATIONS AND PRECAUTIONS 1. Processor is intended for installation in auto systems with power supply of 12 Volt direct current with grounded negative polarity upon the vehicle's body. Connection with another characters (for instance, with power supply of 24 volt or with positive polarity upon the vehicle's body) could disable it. -
Page 5: Processor's Connection
Playback of multi-channel signal (Dolby Digital, DTS) does not support 3. USB. Connects to PC's , laptop or MAC for management by Resolut DSP Tool software. 4. Control. Interface for connection Resolut Smart Remote Control 5. -
Page 6: Principles Of Processor's Setup
6. Outputs. Processor's signal outputs for turning on amplifiers. PRINCIPLES OF PROCESSOR’S SETTINGS It uses Resolut DSP Tool software on your laptop or PC for processor's configuration. New version of software is available on our official web-site resolut-audio.com. After setup you should use USB jack and connect processor to your laptop or PC and turn on software. -
Page 7: Software Processor's Settings
WORKING OF PROGRAM FOR PROCESSOR’S SETTINGS You can view menu of Resolut DSP Tool in this picture: 1. Preset. You can change presets when you configurate. You can save only 4 configurations. 2. Input. You can choose input source. 3. Save. - Page 8 Read All –reading of current processor's configuration. In case, when ▪ connection between PC and processor is lost (for instance, random touch the USD jack and etc.), it is possible to read current processor's configuration for repeating software's displaying. Choose Plugin – Plugin update in processor when changing configuration. For ▪...
- Page 9 Low Pass 12dB и High Pass 12dB – additional filters of higher and lower frequencies. Subwoofer – setting amplitude-frequency characteristic correction for ▪ adjusting bass level with using of Resolut SRC remote control when Parametric mode is selected. Working of such adjustment will be discussed in corresponding section of this Guide.
- Page 10 Advice: For reducing pressure on processor use only necessary number of lines. In other line use None regime in equalization's box. 8. A-Inputs. When click, program shows analog input tab. configurating of analog inputs (with an installed analogue input module). Functions the same as for digital inputs.
- Page 11 12. Group. For convenience you can group some outpus' channels for synchronous adjustment of signals' levels and delays. Pay attention, equalization and filters for each channel is configurating individually. 13. Volume slider Use sliders for quick adjustment or state exact values of signals' level.
- Page 12 18. PEQ. When click, program shows menu of equalization's configuration. You can correct frequency-response characteristic for each output channel by five-line parametric equalizer. Available in each adjustment of line: Low Shelf и High Shelf – correction of frequency-response characteristic by ▪...
-
Page 13: Expanded Opportunities Of Software
If connection to processor in management window will be shown DAC tab. It’s content depends on processor’s model, example: Configurating of harmonic’s character in according with original Resolut Harmonizer technology. Using of digital-analogue converters’ potential with our special developed original algorithm of processing sound signal give opportunity to configurate sound more accurate. - Page 14 Our aim is to provide you with maximum and uncompromising system configuration options, therefore, in Resolut processors, we implemented a choice of output filters operation mode. The software allows you to directly change the type of digital filter while the processor is working and choose the one that provides the most comfortable sound specifically in your audio system.
-
Page 15: Resolut Src Remote Controllers' Settings
Control connector). ▪ Remote display orientation – choice of orientation on the screen of optional Resolut SRC remote control. Allows you to install the panel in two variants - with right or left encoder position. ▪ Subwoofer mode –choice of bass level adjustment. Classic implies usual... - Page 16 Now you can adjust bass level through connected optional Resolut SRC (or set it in control and settings program in Remote tab). Signal will be corrected according to...
-
Page 17: Volume Control Without Using Resolut Src Remote Controller
If necessary to adjust overall volume in system using the processor (example, if source does not have volume control), we strongly recommend using optional Resolut SRC wired control panel. In addition to adjusting volume, it allows you to switch sources and tuning presets, adjust bass level in system (subwoofer level or... -
Page 18: Processors' Plugin
For instance, when adding and deleting modules. It can be done by these steps: Step 1. Open the software Resolut DSP Tool. Save processor's configuration. Use button Save, give the name to this file and save it on your device. -
Page 19: Technical Parameters And Characteristics Of Resolut A-Dsp
TECHNICAL SPECIFICATIONS AND CHARACTERISTICS OF RESOLUT A-DSP: Configurations and possible connections: ▪ Number of analogue outputs: 8 Number of digital inputs: 2 ▪ Digital processing: Central chip: Analog Devices ADAU1452 ▪ Ratio signal/noise, digital input: 144 Db ▪ Digital-analogue transformation: Digital-analogue transformation: AK449X, 32 bit ▪... -
Page 20: Technical Parameters And Characteristics Of Resolut J-Dsp
TECHNICAL SPECIFICATIONS AND CHARACTERISTICS OF RESOLUT J-DSP: Configurations and possible connections: ▪ Number of analogue outputs: 8 Number of digital inputs: 2 ▪ Digital processing: Central chip: Analog Devices ADAU1466 ▪ Ratio signal/noise, digital input: 140 дБ ▪ Digital-analogue transformation: Digital-analogue transformation: ES9028PRO, 32 bit ▪... -
Page 21: Technical Parameters And Characteristics Of Resolut T-Dsp
TECHNICAL SPECIFICATIONS AND CHARACTERISTICS OF RESOLUT T-DSP: Configurations and possible connections: ▪ Number of analogue outputs: 8 Number of digital inputs: 2 ▪ Digital processing: Central chip: Analog Devices ADAU1466 ▪ Ratio signal/noise, digital input: 140 dB ▪ Digital-analogue transformation: Digital-analogue transformation: ES9038PRO, 32 bit ▪... -
Page 22: Guarantee
GUARANTEE Resolut production is under guarantee only in country, where it was sold and made by official Resolut distributor. Official distributor has the right to refuse to guarantee of the product, if this product was bought in another country and was sold to consumer with principle One Way Delivery Without Return.
