MAYTONI TRX004-222 Installation Manual

Magnetic lighting track system
Hide thumbs

Advertisement

Quick Links

Download this manual
maytoni technical
www.maytoni.de
MAGNETIC LIGHTING
TRACK SYSTEM
S35

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRX004-222 and is the answer not in the manual?

Questions and answers

Related Manuals for MAYTONI TRX004-222

Summary of Contents for MAYTONI TRX004-222

  • Page 1 MAGNETIC LIGHTING TRACK SYSTEM...
  • Page 2 DESCRIPTION AND PURPOSE OF THE DEVICE The magnetic track TRX004-2 is the basis for the construction of track lighting systems and is designed for installation and supply of power to track lamps in a DC mains with a rated voltage of 48V.
  • Page 3 SAFE OPERATION REGULATIONS All installation and mounting services must be rendered by persons having the appropriate permits and qualifications. Please contact a qualified electrician, where necessary. All installation and dismantling work should be performed in a powered down state only.
  • Page 4 ELEMENTS OF MAGNETIC TRACK SYSTEMS OF BUILT-IN MOUNTING power input track angle-connector enternal angle power plug angle-connector connector L - 1000mm TRA004EC-22B TRA004B-22B TRA004CL-22B TRX004-221B TRA004ICL-22B TRA004CPC-22B L - 2000mm TRX004-222B outer angle- straight connector...

  • Page 5: Scope Of Supply

    SCOPE OF SUPPLY MAGNETIC BUILT-IN TRACK track track 84 × 87 × 1000 84 × 87 × 2000 TRX004-221B TRX004-222B ACCESSORIES FOR MAGNETIC BUILT-IN TRACK internal outer angle-connector angle-connector angle-connector 85 × 100 × 100 85 × 120 × 120 85 ×...
  • Page 6 SCOPE OF SUPPLY UNIVERSAL ACCESSORIES FOR MAGNETIC TRACK SYSTEM power input straight power angle power 18 × 18 × 520 connector connector 18 × 18 × 195 18 × 18 × 365 TRA004B-22B TRA004PC-22B TRA004CPC-22B driver drivert driver 159 ×...

  • Page 7: Installation Diagram

    INSTALLATION DIAGRAM INSTALLATION DIAGRAM FOR BUILT- IN MAGNETIC TRACK OPTION 1. SURFACE The magnetic built-in track can be installed on 1 or 2 drywall layers. The most MOUNTING WITH THE USE preferred option is two-layer drywall as the structure becomes more reliable OF CLAMPS and rigid.
  • Page 8 INSTALLATION MANUAL BUILT-IN MAGNETIC TRACK Cut the track according to the drawing dimensions. Cutting is permitted in any place at an angle of 90 degrees. 2. Cut the current-carrying cores by 5 mm and crimp their guides in the track.
  • Page 9 INSTALLATION USING SINGLE-LAYER GYPSUM BOARDS 12 MM BUILT-IN MAGNETIC TRACK Install the ceiling profile in line with the required dimensions. 2. Insert the supply cable into the track. 3. Install the track in the mounting groove and secure it with screws.
  • Page 10 INSTALLATION USING DOUBLE-LAYER GYPSUM BOARDS 12 MM BUILT-IN MAGNETIC TRACK Install 12 mm gypsum board in the ceiling profile by securing it with screws. 2. Insert the supply cable into the track. 3. Install the track in the mounting groove and secure it with screws.
  • Page 11 SURFACE-MOUNTED TRACK DIAGRAM FOR SURFACE/SUSPENDED MOUNTED MAGNETIC TRACK power input angle power angle-connector internal plug track connector angle-connector L - 1000mm TRA004EC-21B TRA004B-22B TRA004CL-21B TRA004CPC-22B TRX004-211B TRA004ICL-21B L - 2000mm TRX004-212B straight surface mount...
  • Page 12 SCOPE OF SUPPLY SURFACE/SUSPENDED MOUNTED MAGNETIC TRACK track track 38 × 1000 × 80 38 × 2000 × 80 TRX004-211B TRX004-212B ACCESSORIES OF THE MAGNETIC TRACK SYSTEM FOR SURFACE/SUSPENDED MOUNTING straight angle-connector internal plug connector 89 × 89 × 80 angle-connector 2 ×...
  • Page 13 SCOPE OF SUPPLY UNIVERSAL ACCESSORIES FOR MAGNETIC TRACK SYSTEM power input straight power angle power 18 × 18 × 520 connector connector 18 × 18 × 195 18 × 18 × 365 TRA004B-22B TRA004PC-22B TRA004CPC-22B driver drivert driver 159 ×...
  • Page 14 INSTALLATION MANUAL SURFACE-MOUNTED Cut the track according to the design dimensions. Cutting is permitted in any MAGNETIC TRACK place at an angle of 90 degrees. 2. Cut the current-carrying cores by 5 mm and crimp their guides in the track.
  • Page 15 INSTALLATION MANUAL SURFACE MOUNTING OF MAGNETIC TRACK OPTION 1. SURFACE MOUNTING Fix the clamps for the surface-mounted track on the wall at 60 cm intervals. WITH THE USE OF CLAMPS 2. Insert the supply cable into the track, through the prepared hole.
  • Page 16 INSTALLATION MANUAL OPTION 2. INSTALLATION 4. Fix the profile to the surface using the mounting angles. OF TRACK IN COMBINATION 5. Stretch the ceiling cloth and glue the edges of the harpoons along the entire WITH THE STRETCH CEILING profile length.
  • Page 17 INSTALLATION MANUAL INSTALLATION OF MAGNETIC Screw the suspension mounts into the base. TRACK IN A SUSPENDED WAY 2. Install the suspension mounts in the groove on the backside of the track. 3. Fasten the rope holder. Insert the ropes into the holders. Adjust the length of suspension mounts.
  • Page 18 CONNECTING THE POWER SUPPLY TO THE TRACK USING THE Prepare a niche, insert the power source into the niche and connect a 230V CONVENTIONAL POWER 50Hz power cable to it. SUPPLY SOURCE 2. Connect the driver to the 230V 50Hz mains according to the markings on it.
  • Page 19 TIPS AND PRECATIOINARY MEASURES When planning the placement of system elements, make sure to include a service hatch in the project for driver maintenance. 2. Take appropriate measures to prevent the track from deformation during transportation and installation.

  • Page 20: Power Input

    POWER INPUT The power input can be installed in any track section, according to the rule, the input 1 supplies power to no more than 20 meters of the track. 2. Be extremely careful when marking mounting locations and installing wall clamps.
  • Page 21 Fault description Cause Remedy The lighting fixture does not operate Loose connection of current-carrying Install the lighting fixture on the track parts until full contact between the adapter and current-carrying wires is reached Check the contacts of the lead-in...

  • Page 22: Warranty

    MANUFACTURER Maytoni GmbH, Feldstiege 98, Münster, Germany, 48161 IMPORTER Maytoni GmbH, Feldstiege 98, Münster, Germany, 48161 Developed in Germany.
  • Page 23 +49 (0) 2533 64 295200 maytoni technical www.maytoni.de info@maytoni.com...
